Nabco GT 710 Installation Manual

Hide thumbs Also See for GT 710:
Table of Contents

Advertisement

Quick Links

Associated Manuals Part Numbers: Opus Control Wiring and Programming Manual (P/N C-00139)
• Turn OFF all power to the Automatic Door if a Safety System is not working.
WARNING
• Instruct the Owner to keep all power turned OFF until corrective action can be achieved
by a NABCO trained technician. Failure to follow these practices may result in serious
consequences.
• NEVER leave a Door operating without all Safety detection systems operational.

Table of Contents

CHAPTER 1: WARNING LABELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CHAPTER 2: GENERAL SAFETY RECOMMENDATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CHAPTER 3: SCOPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SECTION 3.1: TO THE INSTALLER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SECTION 3.2: OBJECTIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
CHAPTER 4: INSTALL THE HEADER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SECTION 4.1: DRILL HOLES IN HEADER (GT8710) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
SECTION 4.2: PREPARE THE DOOR FRAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
SECTION 4.3: INSTALL THE SHIM (METAL DOOR FRAMES) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
SECTION 4.4: SECURE THE HEADER TO THE DOOR FRAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
SECTION 4.5: ENSURE PROPER SPINDLE LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
CHAPTER 5: INSTALL THE BOTTOM HALF OF OUTSWING ARM . . . . . . . . . . . . . . . . . . . . . . . . . 9
SECTION 5.1: MARK LOCATION OF ARM SHOE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SECTION 5.2: CUT THE THREADED ROD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SECTION 5.3: SECURE THE ARM SHOE TO THE DOOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CHAPTER 6: INSTALL THE BOTTOM HALF OF INSWING ARM . . . . . . . . . . . . . . . . . . . . . . . . . . 12
SECTION 6.1: PREPARE THE SWING DOOR FOR A TRACK WITH REVEAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
SECTION 6.2: PREPARE THE SWING DOOR FOR A TRACK WITH ZERO REVEAL . . . . . . . . . . . . . . . . . . . . . . 13
SECTION 6.3: SECURE THE TRACK TO THE DOOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
CHAPTER 7: INSTALL THE TOP HALF OF SWING ARM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
SECTION 7.1: SET PRE-LOAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
SECTION 7.2: SECURE THE TOP HALF OF OUTSWING ARM TO HEADER . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SECTION 7.3: SECURE THE INSWING ARM TO HEADER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
GT 710/8710 OPUS Low Energy Installation Manual
Nabco Entrances Inc. S82 W18717 Gemini Drive Muskego, Wisconsin 53150
Phone: (877) 622-2694 Fax: (888) 679-3319 www.nabcoentrances.com
NABCO hours of Operation: Monday to Friday 8:00 a.m.- 4:30 p.m. (Central Time)
Low Energy Sliding Door Owner's Manual (P/N C-00125) for Decal Installation
NABCO Price Book (P/N 16-9244-30) for Sensors, Switches, and Accessories
P/N C-00178 Rev 12-20-17
1 of 26

Advertisement

Table of Contents
loading

Related Manuals for Nabco GT 710

Summary of Contents for Nabco GT 710

  • Page 1: Table Of Contents

    WARNING • Instruct the Owner to keep all power turned OFF until corrective action can be achieved by a NABCO trained technician. Failure to follow these practices may result in serious consequences. • NEVER leave a Door operating without all Safety detection systems operational.
  • Page 2 GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 CHAPTER 8: INSTALL THE ARM STOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 CHAPTER 9: 120 VAC GENERAL WIRING .

  • Page 3: Chapter 1: Warning Labels

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide Rev 12-20-17 P/N C-00178 CHAPTER 1: WARNING LABELS Warning labels are universal and used to alert an individual of potential harm to one’s self or to others. The following warning labels are listed in a hierarchy order that defines the most potential danger first, and the least potential danger last.

  • Page 4: Chapter 3: Scope

    In the United States, ANSI Standard 156.19; ANSI Standard 117.1 and the Low Energy Operator section of ADA Standard covers the GT 710/8710 Swing Door Low Energy System.

  • Page 5: Section 4.1: Drill Holes In Header (Gt8710)

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide Rev 12-20-17 P/N C-00178 Note: It may be necessary to remove the Motor/Operator from the Header to reduce weight, while positioning the Header onto the Door Frame. 1. Remove the Header Cover. Remove boxes and/or parts bags from inside Header. Set aside.

  • Page 6: Section 4.3: Install The Shim (Metal Door Frames)

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 1-1/8” 1/8” (GT 8710) (GT 710) Mark Measurement Top of Door across Top door frame Figure 4 Measure from the Top of Swing door to the Top Door Frame DN 1109 4. Lift the Header up against the Top door frame until the bottom edge of Header is butted up against the Horizontal Line, at...

  • Page 7: Section 4.4: Secure The Header To The Door Frame

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide Rev 12-20-17 P/N C-00178 6. Secure the Shim to stud(s). It is recommended to use Lag Bolts. Shim Header Wall Wall Shim Header Top of Door Frame Top of Door Frame...
  • Page 8 GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 4 .5 .2 Outswing Center Pivot 1-3/4” 10-3/4” Header Outswing Overlap Center Pivot DN 1933 4 .5 .3 Inswing Butt Hinge 1-3/4” 6-1/2” Header Bu Hinge...

  • Page 9: Chapter 5: Install The Bottom Half Of Outswing Arm

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide Rev 12-20-17 P/N C-00178 CHAPTER 5: INSTALL THE BOTTOM HALF OF OUTSWING ARM SECTION 5 .1: Mark Location of Arm Shoe Center Pivot BACK DOOR CHECK XXX HAND CLOSED SWITCH UNITS SWITCH Bu /Off...
  • Page 10 GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 DIM A = REVEAL Door Figure 12 Reveal and Swing Arm DN 1114 Table 2 Butt Hinge Reveal Dim A Dim B Dim A Dim B...

  • Page 11: Section 5.3: Secure The Arm Shoe To The Door

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide Rev 12-20-17 P/N C-00178 4. The distance between the Center Eye of the Link and the end of Rod equals: Minus (1) inch from the appropriate Rod length that was found within Table 2 or Table 3.

  • Page 12: Chapter 6: Install The Bottom Half Of Inswing Arm

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 CHAPTER 6: INSTALL THE BOTTOM HALF OF INSWING ARM SECTION 6 .1: Prepare the Swing Door for a Track With Reveal Table 4 Small Track Mounting Locations (12-1/4 inches) 1. Find the appropriate measurements for Reveal, and Track location within Table 4 or Table 5.

  • Page 13: Section 6.2: Prepare The Swing Door For A Track With Zero Reveal

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide Rev 12-20-17 P/N C-00178 Dim C = Center Pivot 1-11/16” 3/8” Sex Bolt holes Face of Swing Door Dim A = Reveal Back of Header Figure 16 Measure to Mark the First Sex Bolt Hole used to secure the Track...

  • Page 14: Chapter 7: Install The Top Half Of Swing Arm

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 0 - 1/4” Reveal using a Straight Arm To prevent the Swing Arm from Spacer hi ng the Lip of Header, a Spacer is 12.25”...

  • Page 15: Section 7.2: Secure The Top Half Of Outswing Arm To Header

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide Rev 12-20-17 P/N C-00178 PRELOAD: 1 NOTCH = 18 DEGREES 10-25x.25” 10-25x.25” Set Screw Set Screw RIGHT HAND LEFT HAND Figure 21 Preload: Inswing Arm DN 0022 DN 0023...

  • Page 16: Chapter 8: Install The Arm Stop

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 Inswing Arm 21” Track Wheeled Roller Inswing Arm “0” Reveal 12-1/4” Track Wheeled Roller Figure 24 Insert the Swing Arm into the Track DN 1375 CHAPTER 8: INSTALL THE ARM STOP...

  • Page 17: Chapter 9: 120 Vac General Wiring

    Permanent wiring shall be employed as required by local codes. CAUTION Electrical circuit to Nabco operator must not be not shared with other equipment such CAUTION as lighting, cash registers, or any device that might cause electrical interference on the circuit.

  • Page 18: Chapter 10: Adjustments

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 CHAPTER 10: ADJUSTMENTS SECTION 10 .1: Adjust Opening/Closing Force on LCN Tension Spring Improperly installed/adjusted Tension Springs may cause property damage or personal injury. WARNING Please follow instructions carefully.

  • Page 19: Section 11: Troubleshooting

    Notice: If after troubleshooting a problem, and a satisfactory solution cannot be achieved, please call Nabco Entrances at 1-877-622-2694 between 8 am – 4:30pm Central time for additional assistance. DO NOT leave any problem unresolved. If the door cannot be repaired immediately, turn off the door and leave it inoperable until repairs can be made.

  • Page 20: Service Parts: Gt 710 Low Energy Header

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 SERVICE PARTS: GT 710 LOW ENERGY HEADER DN 1123 20 of 26...
  • Page 21 GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide Rev 12-20-17 P/N C-00178 GT 710 Low Energy Header Item Part Finish/Sizes/Notes Description T-00337 PHSMS:#8x0.625L.:PHIL C-00067 NAMEPLATE,NABCO LOGO A-00883 “OPERATOR, GT710 - OPUS,RH” A-00884 “OPERATOR, GT710 - OPUS,LH”...

  • Page 22: Service Parts: Gt 8710 Low Energy Header

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 SERVICE PARTS: GT 8710 LOW ENERGY HEADER DN 1128 22 of 26...
  • Page 23 GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide Rev 12-20-17 P/N C-00178 GT 8710 Low Energy Header Item Part Finish/Sizes/Notes Description A-00883 “OPERATOR, GT710 - OPUS,RH” A-00884 “OPERATOR, GT710 - OPUS,LH” T-00016 Zinc FHMS,1/4-20x0.438L.,PHIL,UNDERCUT,ZINC T-00108 Dark Bronze FHMS,1/4-20x0.438L.,PHIL,UNDERCUT,BLK ZN...

  • Page 24: Service Parts: Swing Arm Assemblies

    GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 SERVICE PARTS: SWING ARM ASSEMBLIES Outswing Arm Assembly Inswing Arm Reveal Equal to 0 degrees Inswing Track Assembly (12.25 inch) (CU) Inswing Arm Assembly...
  • Page 25 GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide Rev 12-20-17 P/N C-00178 Swing Arm Assemblies Item Part Finish/Sizes/Notes Description T-00261 SHSS,5/16-24x0.500L.,CUP PT. T-00223 FHCS,3/8-24x1.250L.,ZINC M-01045 WASHER,STEEL,.375IDx.75ODx.375THK. A-00752 “ROLLER,REPLACEMENT” A-60545 Clear “ARM,INSWING,CU,NON PANIC,NH,204” A-70545 Dark Bronze...
  • Page 26 GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide www.NabcoEntrances.com P/N C-00178 Rev 12-20-17 Swing Arm Assemblies Item Part Finish/Sizes/Notes Description A-60435 Clear “C.U. GUIDE TRACK,21.0L,204” A-70435 Dark Bronze C.U. GUIDE TRACK,21.0L,313 26 of 26...
