Table 3: Button combinations
Menu or function
Advance setting menu
Access programming menu
Pipe state (Heat/Cool) selection OFF mode and system type = 2-
Ex-Factory Reset
Toggle keypad lock or unlock
Toggle EMER HEAT
Enable or disable unoccupied
mode manually

Advanced settings

You can edit user preference settings (UP), system configuration settings (SS), and installer
configuration settings (IS) through the advanced settings menu. To access the advanced settings
menu, press Mode to set the thermostat to OFF mode, then press and hold Mode and Fan for
5 seconds. The following tables list the adjustible settings.

User preference settings

Table 4: UP settings
Menu item Description
01 Temperature scale
02 User temperature calibration
03 Remote sensor temperature
calibration
04 Pipe sensor temperature
calibration
05 Backlight on duration
06 Backlight brightness level
8
Applicable in mode
OFF mode
OFF mode, when programming
is enabled in advanced settings
pipe FC
OFF mode
HEAT and COOL mode
HEAT mode
HEAT and COOL mode
FCP Non-Programmable and Programmable Fan Coil or PTAC Thermostat Largo User Guide
Button combination
Mode + Fan for 5 seconds
Mode + Up for 5 seconds
Fan + Up for 5 seconds
Mode + Fan + Up for 5 seconds
Mode + Up + Down for 10
seconds
Mode + Down for 5 seconds
Mode for 5 seconds
Setting options
F: Fahrenheit
C: Celsius
Temperature with calibration
value. Offset: +/- 5.4°F
(+/-3.0°C)
Temperature with calibration
value. Offset: +/- 5.4°F
(+/-3.0°C)
Temperature with calibration
value. Offset: +/- 5.4°F
(+/-3.0°C)
10 seconds
30 seconds
Always ON
20, 40, 60, 80, 100
Default
F
0.0°F (0.0°C)
0.0°F (0.0°C)
0.0°F (0.0°C)
10 seconds
80
