Step 3: Connect External Devices and Cables

Connect the C Series Controller to a Network for Out-of-Band Management

Connect the C Series Controller to a Management Console

6
Connect the C Series Controller to a Network for Out-of-Band Management on page 6
Connect the C Series Controller to a Management Console on page 6
Turn off the power to the management device.
1.
Plug one end of the Ethernet cable
2.
one of the Ethernet ports on the front panel.
the other end of the cable into the network device.
Figure 4: Ethernet Cable Connector
Figure 5: Network Ports Location
USB
maintenance
Front
panel port
C5000
CONSOLE ETH0 ETH1 ETH2 ETH3
Console Network
port ports
Turn off the power to the console.
1.
Plug the RJ-45 end of the serial cable
2.
the port labeled
CONSOLE
of the port on the front panel.
Plug the female DB-9 end into the device's serial port.
3.
Figure 6: Console Cable Connector
(Figure 4 on page 6
Figure 5 on page 6
Hard disks
IOC expansion slots
(Figure 6 on page 6
on the front panel. Figure 7 on page 7
