Tighten the cables securely . Loose ca-
bles can cause a fire.
The engine must never be driven with
the battery disconnected . There is a
risk of serious damage to the alternator
and the electrical system .

5 .3 .2 Battery charging

The battery must be fully charged befo-
re being used for the first time.
Please refer to 9 .9 for the battery char-
ging procedure .
5 .4

SEAT (7)

Release the seat stopper (6:S) and tilt the seat
bracket (7:L) up.
Install the support in the front (top) holes as
follows:
1 . Put the shoulder washers (7:F) on the screws
(7:G), complete with washers (7:R).
2 . Insert the screws, complete with shoulder
washers, in the slots in the seat bracket. Put
the set in the washers (7:E) and in the holes
in the seat plate. Screw the seat into place.
Tightening torque: 9±1.7 Nm.
Tightening the screws to a torque over
9±1 .7 Nm, will damaged the seat .
3 . Check that the seat moves easily in the slots
in the bracket.
Install the support in the front (top) holes as
follows:
1 . Put the knobs (7:H) on the screws (7:G).
2 . Put a washer (7:E) on each screw.
3 . Insert the screws in the slots on the bracket
and tighten manually.
4 . Fold the seat back down and set it in the de-
sired position.
5 . Tighten the knobs (7:H) by hand.
The knobs (7:H) and the seat will be da-
maged if tools are used .
The seat can be folded. If the machine is parked
outside where it is exposed to rain, fold the seat
forward to protect the seat cushion from getting
wet.
The seat is locked in place. To lift or lower the seat,
first release the stopper (7:S).
The seat can be folded. If the machine is parked
outside where it is exposed to rain, fold the seat
12
ENGLISH
(Translation of the Original Instructions)
forward to protect the seat cushion from getting
wet.
5 .5

STEERING WHEEL (8)

In order to minimise axial play in the steering co-
lumn, place the 0.5-mm and/or 1-mm shim/s (3:K;
3:L)on the steering column between the sleeves,
pos. (8:A) as follows:
1 . Install the sleeve (8:B) on the steering co-
lumn and secure in place by inserting one
of the pins (8:C) by approximately 1/3 of its
length.
2 . Pull the sleeve and steering column upwards.
3 . Check that the 0.5-mm shim, the 1.0-mm
shim (or both) can be inserted into the gap
which is created in point (8:A).. The shim/s
must not be forced in, as there must be a
little axial play.
4 . Remove the pin (8:C) using a pin punch (8:D)
and remove the sleeve.
5 . Install the shim/s as indicated in point 3
above.
6 . Install the sleeve on the steering column and
secure by inserting both pins completely.
Block the steering column.
5 .6

TOWING DEVICE (9)

Screw the towing device (10:A) into the two holes
on the bottom side of the rear axle.
Use the screws and nuts (10:B).
Tightening torque: 22 Nm.
5 .7 FIXED MOUNTS FOR CUTTING-MEANS
ASSEMBLY HOOK-UP (10)
Only installation on the right semi-axle is de-
scribed. Perform the same procedure for the left
semi-axle..
1 . Remove the circlip (10:M) and the external
washer (10:N).
2 . Install the cutting-means assembly mount
(10:O).
The washer (10:N) with internal wing
must always be in contact with the cir-
clip . If this is not the case it may come
loose . .
3 . Install the external washer (10:N) and the
circlip (10:M).
4 . Lubricate the lubrication sump of the cutting-
means assembly mount using a grease
syringe until grease penetrates the length of
the semi-axle.
Use the screws (3:P) and the nuts (3:Q) to install
