• Adhere strictly to local regulations governing the
disposal of cuttings.
• When the machine is withdrawn from service,
do not dump it in the environment, but take it to
a waste disposal facility in accordance with the
local regulations in force.

4 INSURING YOUR LAWNMOWER

Check the insurance on your lawnmower.
Contact your insurance company.
You ought to have fully comprehensive insurance
for traffic, fire, damage and theft.

5 ASSEMBLY

The battery must be fully charged befo-
re being used for the first time.
Do not use the machine until all the in-
dications provided in the "ASSEMBLY"
section have been carried out .
Unpacking and completing the assem-
bly should be done on a flat and stable
surface, with enough space for machi-
ne handling and its packaging, always
making use of suitable equipment .
5 .1

ASSEMBLY COMPONENTS (3)

The machine is delivered with the seat, armrests,
steering wheel, tow bar, quick-fit supports
dismantled. The battery is in its housing but not
connected.
The packaging holds the components needed for
assembly (3) as listed in the table below:
Pos. No. Description
Contents of the bag
A 1 Tow bar
B 2 Flanged screw
C 2 Screw for battery
D 2 Nut for battery
E 6 Washer
F 2 Shoulder washer
G 4 Screw
H 2 Screw knob
I 2 Ignition key
J 1 Pin
K 1 Shim
L 1 Shim
P 2 Screw
ENGLISH
Q
R
Installed on the front semi-axles
M
N
Attached to the tool lift
O
5 .2
[Gear]
1 . Set the lever (12:A; 12:B) to the forward
[Hydrostatic]
1 . Set the lever (13:A) to the forward position.
2 . Lift the seat stopper (7:S) and fold the seat
3 . Open the bonnet: take hold of the edge (5:A)
4 . Perform the above operations in reverse or-
5 .3
For the type of battery installed on the machine,
please refer to "0 TECHNICAL DATA TABLE"
Dimensions

5 .3 .1 Battery connection (6)

Connect the battery to the machine's electrical sy-
/
stem using the relative screws and nuts (6:F; 6:E):
8 x 20
/
1 . Connect the red cable to the battery's posi-
/
8,4 x 24 x 2,0
2 . Connect the black cable to the battery's ne-
/
8 x 20
/
/
6 x 36
16 x 38 x0,5
16 x 38 x 1,0
M10 x 35
2 Nut
2 Split lock washer
2 Safety rings
2 Washer with internal wing
2 Deck mount

BONNET(5:A)

Open the bonnet to access the fuel cock,
battery and engine.
The bonnet can be opened as follows:
position.
forward.
and lift.
der to close the bonnet.
It is strictly prohibited to start the engi-
ne when the bonnet is open .

BATTERY

CAUTION! Battery acid is corrosive and
contact with it is harmful .
Handle the battery with care taking care
not to let acid leak out .
Do not check or top up the battery fluid.
tive terminal (+).
gative terminal (-).
If the leads are disconnected/con-
nected in the wrong order, there is a
risk of a short-circuit and damage to the
battery .
Inverting the cable connections will da-
mage the alternator and the battery .
EN
M10
14 x 8,2 x 2
/
/
/
