Quick Start Guide
QFX10002
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 4
Step 3: Keep Going | 6
Step 1: Begin
IN THIS SECTION
Mount the QFX10002 | 2
Connect Power to the QFX10002 | 3
To install and configure any model of the Juniper Networks QFX10002 switch, you need:
Either an electric lift or two people to lift the switch into place. An additional person is needed for securing the switch
to the rack
Electrostatic discharge (ESD) grounding strap (not provided)
One pair of front mounting rails (provided)
One pair of rear mounting blades (provided)
24 flat-head M4x6-mm Phillips mounting screws to secure the mounting rails to the chassis (provided)
16 screws to secure the chassis and mounting blades to the rack (not provided)
Screwdriver appropriate for your rack mounting screws (not provided)
Two power cords with plugs for QFX10002-36Q, four power cords with plugs for QFX10002-60C and QFX10002-72Q
that are appropriate for your geographical location (provided)

Advertisement

loading

Related Manuals for Juniper QFX10002

Summary of Contents for Juniper QFX10002

  • Page 1 16 screws to secure the chassis and mounting blades to the rack (not provided) Screwdriver appropriate for your rack mounting screws (not provided) Two power cords with plugs for QFX10002-36Q, four power cords with plugs for QFX10002-60C and QFX10002-72Q that are appropriate for your geographical location (provided)
  • Page 2 If you are mounting multiple units in the rack, mount the heaviest unit at the bottom and mount the others from bottom to top in order of decreasing weight. The QFX10002-72Q weighs 68.6 lbs (31.1 kg), the QFX10002-60C weighs 80.5 lbs (36.5 kgs), and the QFX10002-36Q weighs 54 lbs (24.5 kg). Installing the switch in a rack requires either a mechanical lift or two people to lift the device and another person to secure it to the rack.
  • Page 3 12. (Optional) Attach a grounding cable to earth ground and then attach it to the chassis grounding point. Connect Power to the QFX10002 Connecting QFX10002 to AC power 1. If the AC power source outlet has a power switch, set it to the OFF (0) position.

  • Page 4: Step 2: Up And Running

    Step 2: Up and Running IN THIS SECTION Set Parameter Values | 4 Perform the Initial Configuration | 4 Set Parameter Values You must perform the initial configuration of the switch through the console port. Before you begin, set the following parameter values in the console server or PC: Baud Rate—9600 Flow Control—None...
  • Page 5 NOTE: The RJ-45 management port, em0, and SFP management port, em1, are found on the management panel of the QFX10002. They are both labeled MGMT. 9. (Optional) Configure the static routes to remote prefixes with access to the management port.

  • Page 6: Safety Warnings Summary

    Contacting Juniper Networks | 7 See the complete QFX10002 documentation at https://www.juniper.net/documentation/product/en_US/qfx10002. Safety Warnings Summary This is a summary of safety warnings. For a complete list of warnings, including translations, see the QFX10002 switch documentation at https://www.juniper.net/documentation/product/en_US/qfx10002. WARNING: Failure to observe these safety warnings can result in personal injury or death.

  • Page 7: Power Cable Warning (Japanese)

    For technical support, see: http://www.juniper.net/support/requesting-support.html Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners.
