Wolf E Series Information Booklet

Wolf E Series Information Booklet

Electronic control
Hide thumbs Also See for E Series:
Table of Contents

Advertisement

Quick Links

Download this manual
ELECTRONIC CONTROL
INFORMATION BOOKLET
Wall Oven
Wall Oven-2 & Wall Oven-3
E-Series Wall Oven
Warming Drawer (WWD30)
Electric & Induction Cooktop
Dual Fuel & Dual Fuel-3
NOTE:
If more detailed information on the
electronic controls is needed, reference the
appropriate Wolf Technical Service Manual.
Wolf Appliance Co., Inc.
•
803317
•
Rev G
•
2007

Advertisement

Table of Contents
loading

Related Manuals for Wolf E Series

Summary of Contents for Wolf E Series

  • Page 1 Warming Drawer (WWD30) Electric & Induction Cooktop Dual Fuel & Dual Fuel-3 NOTE: If more detailed information on the electronic controls is needed, reference the appropriate Wolf Technical Service Manual. Wolf Appliance Co., Inc. • 803317 • Rev G •...
  • Page 2 Notes PAGE 2...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PAGE WALL OVEN (L-SERIES) Unique Electronic Control Input Operation........7 Field Option Mode................7 User Preference Offset Mode..........7 Temperature Display Preference..........7 Sabbath Feature................7 Time Cook Feature................8 Delayed Start Feature..............8 Temperature Probe Feature.............8 Self-Clean Mode................9 Basic Electronic Control Input Operations........9 Bake Mode..................9 Convection Bake Mode..............10 Convection Mode................10...
  • Page 4 TABLE OF CONTENTS PAGE WALL OVEN (L-SERIES) (Continued) Testing the Oven Relay Board............14 Element Testing................14 Fans and Motors................15 RTD Testing..................16 Probe Testing..................16 Error Code Chart..............17 to 18 WALL OVEN-2 Testing the Wall Oven-2 Relay Board..........19 Element Testing................19 Ohm Testing elements at Relay Board.......... 20 Fans and Motors................
  • Page 5 TABLE OF CONTENTS PAGE WALL OVEN (E-SERIES) Acronym Chart.................25 Unique Electronic Control Input Operations........26 User Option Mode................27 Language Selection............... 27 Temperature Display Preference........... 27 User Preference Offset..............27 Clock Display Preference.............. 28 Backlight Brightness Setting............28 LCD Contrast Selection..............28 Beeper Tone Selection..............28 Sabbath Feature................
  • Page 6 TABLE OF CONTENTS PAGE ELECTRIC COOKTOP Diagnostic Mode................42 Initiating Different Modes..............42 Mode 1 Checking LEDs..............43 Mode 2 Checking Cooling Fan............43 Mode 3 Checking the Electronic Hardware Version......44 Mode 4 Checking Ambient Temp. of Thermistor of Power Board..............44 Mode 5 Checking Heat Sink Thermistor on Power Board....45 Mode 6 Checking LiD Switch on the Cover ( not available on 15”)..
  • Page 7 TABLE OF CONTENTS PAGE DUAL FUEL RANGE (Continued) Cooking Modes.................60 Bake Mode.................60 Bake Stone Mode...............60 Broil Mode..................60 Convection Mode................61 Convection Bake Mode...............61 Convection Broil Mode..............61 Convection Roast Mode.............62 Roast Mode................62 Oven Features................63 Dehydration Mode..............63 Delayed Start Feature (Start Cooking Now)........63 Delayed Start Feature (Start Cooking Later).......64 Probe Feature................64 Sabbath Feature................65...

  • Page 8: Wall Oven (L-Series)

    WALL OVENS UNIQUE ELECTRONIC CONTROL INPUT OPERATIONS • FIELD OPTION MODE - In this mode you can access User Preference Offset and Temperature Display Preference features. User Preference Offset ~ Unit must be off. ~ Press and Hold the TEMPERATURE Key for 5 sec. ~ Press the number keys to enter a new numeric value up to 35.

  • Page 9: Time Cook Feature

    • TIME COOK FEATURE ~ Unit must be off. ~ Press OVEN ON key. ~ Press desired cooking mode (Example: Bake Mode). ~ Change preset temperature if desired by using the number keys. ~ Press the COOK TIME key. Enter the hours/minutes desired for cooking.

  • Page 10: Self-Clean Mode

    • SELF-CLEAN MODE ~ Unit must be off. ~ Press OVEN ON key. ~ Press the SELF-CLEAN key. ~ Press the ENTER key. • To change Self-Clean time for 2 to 4 hours ~ Unit must be off ~ Press the OVEN ON key. ~ Press the SELF-CLEAN key.

  • Page 11: Convection Bake Mode

    • CONVECTION BAKE MODE ~ Unit must be off. ~ Press the OVEN ON key. ~ Press the CONVECTION BAKE key. ~ Change preset temperature if desired. ~ Press the ENTER key. • CONVECTION MODE ~ Unit must be off. ~ Press the OVEN ON key.

  • Page 12: Roast Mode

    • ROAST MODE ~ Unit must be off. ~ Press the OVEN ON key. ~ Press the ROAST key. ~ Change preset temperature if desired. ~ Press the ENTER key. • CONVECTION ROAST MODE ~ Unit must be off. ~ Press the OVEN ON key. ~ Press the CONVECTION ROAST key.

  • Page 13: Diagnostic Mode

    DIAGNOSTIC MODE In Diagnostic Mode the last seven errors that have occurred to the oven controlling all the relays on the relay board and controller feed- back of temperature and switches will be displayed. A Double Oven can store fourteen error codes. Seven for the upper oven and seven for the lower oven.

  • Page 14: Single Oven

    • SINGLE OVEN ~ Unit must be off. ~ Press and Hold the TEMPERATURE key and the 0 “ZERO” key for 3 seconds. ~ Release both keys. NOTE: To toggle from one error code to another, the ENTER key must be pressed. The ENTER key will need to be pressed seven times to make sure there are no other codes.

  • Page 15: Testing The Oven Relay Board

    TESTING THE OVEN RELAY BOARD ELEMENT TESTING First access Diagnostic Mode. once in Diagnostic Mode, the Technician can press a key to activate an element. The element relay and the dou- ble line breaker(DLB) will close to complete a 240/208 VAC circuit through a specific element.

  • Page 16: Fans And Motors

    FANS AND MOTORS First access Diagnostic Mode. Once in Diagnostic Mode, the techni- cian can press a key to activate a fan or a motor. The fan and motor relays will close to complete a 120 VAC circuit through a specific fan or motor.

  • Page 17: Rtd Testing

    RTD TESTING First access Diagnostic Mode. Once in Diagnostic Mode, the RTD temperature as read by the Oven Controller is shown in the corre- sponding display. NOTE: Diagnostic Mode will end 2 minutes after the last key stroke or when the CLEAR key is pressed. PROBE TESTING First access Diagnostic Mode.
  • Page 18 ERROR CODE CHART ERROR CODE POSSIBLE CAUSE TEST / ACTION Door Lock or Unlock Ohm door lock switches. Switches not sensed with- Replace MDL (Motor Door in 60 seconds while driv- Lock) Assembly ing the door lock motor OVER TEMP Over temperature occurs Ohm RTD sensor, replace if when the oven reaches a...

  • Page 19: Error Code Chart

    ERROR CODE CHART ERROR CODE POSSIBLE CAUSE TEST / ACTION SENSOR CAL Analog to Digital error Replace Oven Controller during calibration phase CONTROL COM Communication lost with Check flat flex cable the oven controller between control panel assembly and oven con- troller for bad connection.

  • Page 20: Testing The Wall Oven-2 Relay Board

    TESTING THE WALL OVEN-2 RELAY BOARD ELEMENT TESTING First access Diagnostic Mode. Once in Diagnostic Mode, the Technician can press a key to activate an element. The element relay and the double line breaker(dlb) will close to complete a 240/208 VAC circuit through a specific element.

  • Page 21: Ohm Testing Elements At Relay Board

    Ohm Testing Elements at Relay Board This procedure will allow the service technician to ohm any of the ele- ments directly at the relay board. At the relay board, pull the wire off of the terminal DLB/E11. This is done to keep from ohming the relay board. It does not take the High Limit out of the equation, but if the technician DOES NOT get an ohm reading from the DLB lead to all of the element leads, then, there is a problem with the High Limit.

  • Page 22: Fans And Motors

    Fans and Motors First access Diagnostic Mode. Once in Diagnostic Mode, the technician can press a key to activate a fan or a motor. The fan and motor relays will close to complete a 120 VAC circuit through a specific fan or motor. If the Oven Controller detects the functionality through switches, an indicator will be illumi- nated on the corresponding display.

  • Page 23: Fan Apperancy Logging (Enable Or Disable)

    Fan Apperancy Logging (Enable or Disable) 1. Put the unit into field test mode. (Press and hold the "TEMPERATURE" and "0" key simultaneously for 3 seconds) 2. If fan apparency logging is enabled, an "L" will be displayed in the stop time number segment area.

  • Page 24: Error Code Chart

    ERROR CODE CHART ERROR CODE POSSIBLE CAUSE TEST / ACTION Door Lock or Unlock Switches not sensed Ohm door lock switches. Replace MDL (Motor within 60 seconds while driving the door Door Lock) Assembly lock motor Over temperature occurs when the oven Ohm RTD sensor, replace if bad.
  • Page 25 Notes PAGE 25...
  • Page 26 E-SERIES WALL OVEN The following information is intended as a quick reference only. Refer to E- Series Technical Service Manual 807792 for complete technical information. E-SERIES Acronym Chart ACRONYM ALTERNATE DESCRIPTION ALT. DESC. Cyclical Redundancy Check Double Line Break L2 Relay on Relay Board End of Cycle FMEA Failure Mode/Effects Analysis...
  • Page 27 UNIQUE ELECTRONIC CONTROL INPUT OPERATIONS: User Option Mode User option mode is activated by pressing and holding CLOCK key for 3 sec- onds. (Use following keys to navigate through menu) ENTER Key: Moves to next selection in order described below, saving any changes. If at last selection, returns to first selection.
  • Page 28 UNIQUE ELECTRONIC CONTROL INPUT OPERATIONS: (Cont.) Clock Display Preference LILA will display “SELECT 12/24 HOUR CLOCK. (PRESS 1 – 12 HR, PRESS 2 – 24 HR). The clock type selected will be displayed in MTD as “12Hr” or “24Hr” as appropriate. Backlight Brightness Setting LILA will display "SELECT BACKLIGHT BRIGHTNESS.
  • Page 29 DIAGNOSTICS/SHOWROOM MENU MODE: Pressing the Timer key for 3 seconds while both cavities are in Idle mode, or from Showroom mode. Press 1 = Diagnostics Mode Press 1 = Self Test* Press 2 = Manual Test Press 3 = Error History Press 4 = Version Info Press 5 = Statistics Press 2 = Showroom Mode...
  • Page 30 E-SERIES Manual Test Mode Enter into the Manual Test by entering Diagnostics/Showroom Mode (Press and hold TIMER 3 Seconds) and choosing the Manual Test from the Service Mode Entry menu (Key Press 2). NOTE: If a communication failure with the Relay Module exists, Manual Test entry will be inhibited and an appropriate message displayed in the LILA.
  • Page 31 E-SERIES Technical Data Chart Part Description Part # Voltage Amperage Watts Ohms Motorized Latch 808582 12000 Temp Sensor - Upr 808584 1091 75°F Temp Sensor - Lwr 807940 1091 75°F Oven Light 808636 1500 Element, Conv 9.02 to 10.43 2165 to 2503 23 to 26.6 Element, Conv 7.82 to 9.04...
  • Page 32 E-SERIES Element Ohm Testing Element Wire # Plug Terminal Wire # Plug Terminal Test Upper Right Convection or 11-E10 P13 9-RCvtE9 Single Oven Upper Left Convection or 11-E10 P13 7-LCvtE8 Single Oven Upper Broil or 5-E5 4-BroilE4 Single Oven Upper Outer Bake or 5-E5 2-ObakeE3...
  • Page 33 E-SERIES Error Code Chart Priority Displayed Phrase Service Instruction RTD Open (Upper/Lower) RTD failure (device or RTD Shorted wiring) (Upper/Lower) Meat Probe failure Temp Probe Short (device or wiring) No Inner Bake element detect No Outer Bake element detect No Broil element detect Check specified element &...
  • Page 34 E-SERIES Error Code Chart (cont.) Priority Displayed Phrase Service Instruction Outer Bake relay shorted Broil relay shorted Left Convect relay shorted Right Convect relay shorted MDL relay shorted Left Convect Fan triac shorted Right Convect Fan triac shorted Cooling Fan triac shorted Oven Light relay shorted DLB1 shorted DLB2 shorted...
  • Page 35 E-SERIES Error Code Chart (cont.) Priority Displayed Phrase Service Instruction Keypad circuit error Keypad comm error detected by the UIM Keypad comm error detected by Check keypad & connections the Keypad Keypad FMEA error Keypad EE CRC error Keypad mains sync error UIM EE checksum error UIM configuration data CRC error UIM fuse error...
  • Page 36 E-SERIES Diagnostic/Showroom Entry Menu Flow Chart 1. AUTO SELF TEST DIAGNOSTIC/SHOWROOM 1. SELF TEST ACTIVE Mode Entry: Press and Hold TIMER key for 3 Seconds. TIME OUT: No key press for 5 min. test shuts down. 1 key = Diag/Showroom Press #1 = Self Test VALID KEY PRESSES: Press #2 = Manual Test...
  • Page 37 E-SERIES Diagnostic/Showroom Manual Menu Flow Chart Definitions/Clarifications: MANUAL TEST Toggle: Means to switch Initial Manual Test Entry between the test or load on or off. Valid Keys 1. BEEPER TEST TIMED COOK "ENTER" 2. BROIL ELEMENT TEST BROIL "ENTER" CONVECTION 3.
  • Page 38 E-SERIES Diagnostic/Showroom Statistics Menu Flow Chart Unit Operation Time # of Power-On-Resets STATISTICS Displayed: (LIL) "Mode 1. Press 1 for details. Operation Time Last 5 functions Displayed: (LIL) Operation Time Last Set Temp Displayed: (LIL) "Mode 2. Press 2 for details. "Press SET TIMER to see last 5 functions."...
  • Page 39 WARMING DRAWER (WWD30) FIELD SERVICE MODE UNIQUE KEYSTROKES: KEYPRESS TEMP DISPLAY TIMER DISPLAY Enter Diagnostics rE (Sr if in showroom mode) 0018 (Meaning revision 1.8) TIMER TIMER TIMER TIMER TIMER TIMER TIMER (Control On Time) 1:60 = 16000 hr. (See note below) TIMER ELE (Element On Time) 95:00 = 950000 hr.
  • Page 40 WARMING DRAWER (WWD30) FIELD SERVICE MODE FUNCTIONAL TEST KEYSTROKES: KEYPRESS TEMP DISPLAY TIMER DISPLAY “ON” INDICATOR Func ON (Relay closed, TEMP Element on) Func OFF (Relay Opens, TEMP Element Off) Func ON (Relay closed, Fan TEMP turns on) Func OFF (Relay Opens, Fan TEMP turns Off) TEMP...
  • Page 41 Notes PAGE 41...
  • Page 42 ELECTRIC COOKTOPS DIAGNOSTIC MODE Diagnostic mode allows the Service Technician to inspect the func- tions of the cooktop controls. In diagnostic mode the last eight error codes that have been recorded by the cooktop control can be accessed. A total of 15 different modes can be accessed, once diag- nostic mode has been initiated.
  • Page 43 Mode 1 - Checking the LEDs In this mode, ALL LEDs will blink at a rate of .75 seconds ON and .25 seconds OFF. This includes the “LOCK” LED as well as the Zone indicators for the surface units. Mode 2 - Checking the Cooling Fan To enter Mode 2 while engaged in diagnostic mode, touch the “ON/OFF”...
  • Page 44 Mode 3 - Checking the Electronic Hardware Version To enter Mode 3 while engaged in diagnostic mode, touch the “+” keypad on the left front control. When this is done the result will be: • The bar lights on the left front control will illuminate 3 LEDs and flash at the rate mentioned in Mode 1.
  • Page 45 Mode 5 - Checking Heat Sink Thermistor on Power Board To enter Mode 5 while engaged in diagnostic mode, touch the “+” keypad on the left front control. When this is done the result will be: • The bar lights on the left front control will illuminate 5 LEDs and flash at the rate mentioned in Mode1.
  • Page 46 Mode 7 - Last Error Code Recorded to Eeprom To enter Mode 7 while engaged in diagnostic mode, touch the “+” keypad on the left front control. When this is done the result will be: • The bar lights on the left front control will illuminate 6 LEDs and flash at the rate mentioned in Mode1.
  • Page 47 Mode 15 - Checking Software Version - (Not available for 15”) To enter Mode 15 while engaged in diagnostic mode, touch the “+” keypad of the left front control. When this is done the result will be: • The bar lights on the left front control will illuminate 15 LEDs and flash at the rate described in Mode1.
  • Page 48 INTERPRETING HEX DECIMAL CODE The bar lights located on the control panel are divided into four differ- ent groups. These four groups have numeric values. (See Figure 1). When the bar lights are illuminated, the numeric value for each group needs to be added together.
  • Page 49 In Figure 2, you see an example of bar lights that could be illuminat- ed. When reading the bar lights according to Most Significant to Least Significant numeric value, they add up to: 2 + 1 = 3; 4 + 1 = 5 and 8 + 4 = 12 or C. So you have 3 - 5 - C.
  • Page 50 Temperature °C / Hex Decimal Chart 10.1 21.0 29.0 35.5 10.6 21.3 29.3 35.7 11.1 21.7 29.5 35.9 11.5 22.0 29.8 36.1 12.0 22.3 30.0 36.4 12.5 22.6 30.3 36.6 12.9 23.0 30.5 36.8 13.3 23.3 30.8 37.0 13.8 23.6 31.0 37.2 14.2...
  • Page 51 Temperature °C / Hex Decimal Chart 41.1 46.0 50.5 54.7 41.2 46.2 50.7 54.8 41.4 46.4 50.8 55.0 41.6 46.5 51.0 55.1 41.8 46.7 51.1 55.3 42.0 46.9 51.3 55.4 42.2 47.0 51.5 55.6 42.4 47.2 51.6 55.7 42.6 47.4 51.8 55.9 42.8...
  • Page 52 Temperature °C / Hex Decimal Chart 58.6 62.4 66.0 69.5 58.8 62.5 66.1 69.7 58.9 62.7 66.3 69.8 59.1 62.8 66.4 69.9 59.2 62.9 66.5 70.0 59.3 63.1 66.7 70.2 59.5 63.2 66.8 70.3 59.6 63.3 66.9 70.4 59.8 63.5 67.1 70.5 59.9...
  • Page 53 Temperature °C / Hex Decimal Chart 73.0 76.4 79.7 83.1 73.1 76.5 79.8 83.2 73.2 76.6 80.0 83.3 73.3 76.7 80.1 83.5 73.5 76.9 80.2 83.6 73.6 77.0 80.3 83.7 73.7 77.1 80.5 83.8 73.8 77.2 80.6 83.9 74.0 77.4 80.7 84.1 74.1...
  • Page 54 POSSIBLE ERROR CODES Error 1: Ambient Temperature High The ambient temperature read by the control exceeds the ERROR TEMPERA- TURE limit (85°C + x) specified in EEPROM, or the temperature sensor input has failed. Error 2: Heatsink Temperature High The heatsink temperature read by the control exceeds the ERROR TEMPERA- TURE limit (110°C + x) specified in EEPROM, or the temperature sensor input has failed.
  • Page 55 INDUCTION COOKTOP DIAGNOSTIC MODE Diagnostic mode allows the Service Technician to determine the cause of the failure. In diagnostic mode only the last error code is displayed. To initiate diagnostic mode, the unit must to be in the “LOCK” mode. Then, press and hold the universal “OFF”...
  • Page 56 INDUCTION COOKTOP ERROR LED ON CODE POSSIBLE CAUSE CORRECTIVE ACTION Shorted Temperature Sensor Check connection. on front Cooking Zone Replace front element Open Temperature Sensor on Check connection. front Cooking Zone Replace front element Shorted Temperature Sensor Check connection. on rear Cooking Zone Replace rear element.
  • Page 57 Notes PAGE 57...
  • Page 58 DUAL FUEL RANGES ELECTRONIC CONTROL INPUT OPERATIONS Time of Day Clock • Press the CLOCK key on display panel, “CLOCK” will flash on and off. • Press the up or down arrow touch pad to increase or decrease the time. Stop when correct time of day shows in display window. •...
  • Page 59 FIELD OPTION MODE UPO (User Preference Offset) • Press and hold the CLOCK touch pad for 5 seconds. • Turn the knob to the left or right to increase or decrease the UPO in 1° increments as much as ±35°. Changing Clock to 24 Hours •...
  • Page 60 COOKING MODES Bake Mode NOTE: Bake Stone Element must be removed during all cooking modes excepts Bake Stone Mode. • Turn oven function selector bezel counter clockwise to BAKE.. • To change temperature, immediately turn oven selector knob right to increase temperature or left to decrease oven temperature setting.
  • Page 61 Convection Mode • Turn oven function selector bezel clockwise to the dark area on dial marked CONV. • To change temperature, immediately turn oven selector knob right to increase temperature or left to decrease oven temperature setting. Oven will turn on after 2 seconds or press ENTER touch pad.
  • Page 62 Convection Roast Mode • Turn oven function selector bezel clockwise to dark area on dial marked ROAST. • To change temperature, immediately turn oven selector knob right to increase temperature or left to decrease temperature setting. Oven will turn on after 2 seconds or press ENTER touch pad. •...
  • Page 63 OVEN FEATURES Dehydration Feature • Turn oven function selector bezel clockwise to CONV. • Turn oven selector knob to left until “deH” shows in display window, this is at 170° (75°C)F. • Release the oven selector knob. • Turn oven selector knob left to the desired dehydration temperature.
  • Page 64 Delayed Start Feature - (To Start Cooking Later) • Turn oven function selector bezel to the desired mode. • Press COOK TIME touch pad. • Press up or down arrow touch pad on the display panel to increase or decrease the desired cook time. •...
  • Page 65 Sabbath Feature • Turn oven function selector bezel to either the BAKE or ROAST mode. • To change preset temperature if needed, press OVEN LIGHT touch pad to turn oven lights on or off. • Press and hold ENTER touch pad on display panel for 5 seconds. Oven chimes twice and the word “SAb”...
  • Page 66 DIAGNOSTIC MODE Initiating Diagnostic Mode • Oven function selector bezel must be in the OFF position. • Press and hold CLOCK touch pad and TIMER touch pad for 3 seconds. • Turn the oven selector knob to the right seven separate times, this will toggle from error code 1 thru 7.
  • Page 67 ERROR CODE CHART ERROR CODE POSSIBLE CAUSE TEST / ACTION Door Lock or Unlock Perform motorized door lock Switches not sensed with- test procedure in diagnostic in 60 seconds while driv- mode. Ohm door lock ing the door lock motor switches.
  • Page 68 TESTING THE OVEN RELAY BOARD Element Testing First access diagnostic mode. Once in diagnostic mode, the technician can turn the oven function selector bezel to activate an element. The element relay and the double line breaker(dlb) will close to complete a 240/208 VAC circuit through a specific element.
  • Page 69 RTD Testing First access Diagnostic Mode. Once in diagnostic mode, the RTD tem- perature is shown in display window of oven selector knob. If the RTD is open, “Err 03” will be shown in the display of the electronic control housing.
  • Page 70 Fan and Motor Testing Chart Turn Bezel or Press Relay(s) Activated Action Response Touch Pad on ECH Broil Right Convection Right Right Convection Convection Fan Fan ON Turns ON Roast Left Convection Left Convection Left Convection Fan & 18” Cavity Fan Turns ON Fan ON Bake...
  • Page 71 Technical Data Chart Part Description Voltage Amperage Watts Ohms Motorized Latch 2900 1091 @ 75°F Temperature Sensor Oven Light 1 to 2 Element, Convection 2400 Element, Convection 1803 Fan, Convection CCW Fan, Convection CW Element, Bake-18” 6.04 1450 39.7 39.7 Element, Bake-18”...
  • Page 72 Notes PAGE 72...
