Technical Information
Electrohydraulic Actuators PVE-EX

Specifications

7-pin Layout

4-Pin layout

Radiometric Control Signal

Radiometric Fixed Control Signal (0-10 V)

12 | © Danfoss | October 2017
7-pin connector
1 2 3 4 5 6 7
4-Pin connector, Group II
1 2 3
Versions
PVEO-EX-24V, PVEO120-EX-24V
PVEH/-EX/-U-EX, PVES/-EX/-U-EX, PVES120/-EX/-U-EX, PVEH120-EX
Radiometric control signal for PVEH/PVES
PIN Function of the pin
1 U Demand signal
S
2 V Supply voltage to solenoid valves (can be switched off separately)
bat2
3 GND Ground
4 Error Error pin (See
5 GND DI-A Signal low when spool is stroked to A side (Only for DI versions)
6 GND DI-B Signal low when spool is stroked to B side (Only for DI versions)
*
7 V Supply voltage to DI versions
bat
*
Pin 2 and 7 shall be connected together for PVE modules without the DI function.
Signal voltage (U ) Control
S
Neutral
U = 0.5 • U
S DC
Radiometric control signal for PVEH/PVES
PIN Function of the pin
1 U Demand signal
S
2 V Supply Voltage
bat
3 GND Ground
4 Error Error pin (See
4
PVE-EX fault monitoring on page 23)
Q: P → A
U = (0.5 → 0.25) • U
S DC
PVE-EX fault monitoring on page 23)
Pin 1 Pin 2 Pin 3 Pin 4
U -A U -B GND —
DC DC
U V GND Error
s bat
Versions
PVES-EX
PVEH-EX
PVES120-EX
PVEH120-EX
PVEH-DI-EX
PVEH120-DI-EX
Q: P → B
U = (0.5 → 0.75) • U
S DC
Versions
PVEH-U
PVES-U-EX
PVES120-U-EX
