Summary of Contents for VDO MS 4150 RS MP3

  • Page 1 MS 4150 RS www.vdodayton.com...
  • Page 2 Attention! Only use this system when it is safe to do so. It is more important to keep your eyes on the road and your hands on the wheel. Due to constantly changing traffic conditions, we unfortunately cannot guarantee 100 % precision under all circumstances. Attention ! N’utilisez le système que si vous ne mettez pas en danger votre vie ou celle des autres usagers de la route.

  • Page 3: Connections

    SDVC [A1] [A3] [A2] [A5] [A4] [A6] [A8] [A7] +12V Power Amplifier Tel. in TMC receiver Remote CD Changer +30˚ -10˚...

  • Page 4: Connectors

    MS 4150 RS MP3 Connector Overview ISO chamber A: Connection Input digital speedometer signal / SDVC / GALA Switch input reversing signal (reversing light plus) Switch input telephone mute function + 12 V permanent positive; terminal 30 Switch output for electronic antenna /relay motor antenna Switch input pilot light +12 V ignition positive / ACC;...
  • Page 5 Illustrations ....Page 3 Contents..... Page 7 Mounting instructions .

  • Page 7: Table Of Contents

    Contents GENERAL INFORMATION ........9 Notes on operating instructions......9 Class 1 laser product .
  • Page 8 CONTENTS C-IQ – INTELLIGENT CONTENT ON DEMAND ......39 C-IQ - Your key to map, traffic and travel information ....39 NAVIGATION .

  • Page 9: General Information

    Notes on operating instructions The following reading aids are used to simplify these operating instructions: requests you to perform an action. shows the unit’s reaction. ✎ provides additional information – identifies a list. Safety instructions and warnings contain important information for the safe use of the unit.

  • Page 10: Safety Instructions

    GENERAL INFORMATION Safety instructions The use of the navigation radio by no means relieves the driver of his/her responsibilities. The highway code must always be observed. Always observe the current traffic situation. The applicable traffic regulations and the prevailing traffic situation always take precedence over the instructions issued by the navigation system if they contradict one another.

  • Page 11: How Does The Navigation System Work

    How does the navigation system work? Important notes on the function of your navigation radio In principle, the system is functional with poor GPS reception, although the accuracy of the positioning may be impaired by poor or interrupted GPS reception or errors can occur in the determination of the position, which result in incorrect position reporting.

  • Page 12: The Digital Road Map

    GENERAL INFORMATION The digital road map To be able to plan a route to a destination address, the navigation system not only requires the current position of the vehicle but also a digital road map containing the destination address itself and the roads leading to the destination address. This digital road map is on the map CD which you insert into the navigation computer.

  • Page 13: Route & Sound - Navigating And Listening To An Audio Cd

    Route & Sound - Navigating and listening to an audio CD With the new generation of our navigation radio units, you may insert a map CD, plan your route, then insert an audio CD and the system will still guide you to your intended destination. The navigation computer saves the road system in a defined area around the planned route (corridor) in its main memory.

  • Page 14: Rds (Radio Data System)

    GENERAL INFORMATION RDS (Radio Data System) Many FM stations transmit RDS information. The navigation radio evaluates the RDS telegram and offers the following advantages: – PS (Program Service Name): Display of station name, PTY (Program TYpe): Station selection by program type, ➽ page 31 –...

  • Page 15: Installation Instructions

    IMPORTANT INFORMATION Please read this information carefully and follow the all the instructions outlined below. This will ensure the reliable operation and long service life of your navigation radio. Keep the packaging and operating instructions in a safe place in order to pass them on to a subsequent owner in the event of selling the unit at a later date.
  • Page 16 INSTALLATION INSTRUCTIONS Connection overview, ISO chamber A, Fig. 2: Connection Input digital speedometer signal / SDVC Switch input reversing signal (reversing light plus) Switch input telephone mute function + 12 V permanent positive; terminal 30 Switch output for electronic antenna /relay motor antenna Switch input pilot light +12 V ignition positive;...
  • Page 17 Reversing signal (A2): Connect pin A2 to a suitable reversing signal point (positive lead of reversing lamp). Note: Operation of the navigation system is not possible without a reversing signal. The absence of a reversing signal may lead to inaccurate navigation. Telephone mute function (A3), optional: Connect pin A3 to the mute function output of the car phone or the hands-free unit.
  • Page 18 INSTALLATION INSTRUCTIONS Optional connections ISO chamber C, Fig. 4 - 6 Line-out (yellow connector C1): (adapter cable, accessories) An amplifier with additional loudspeakers can be connected to the unit via this connector. Telephone input (green connector C2): (adapter cable, accessories) Connect the loudspeaker output of your mobile phone or hands-free unit to lead C2.
  • Page 19 Install installation bracket, Fig. 8 - 10 The navigation radio can be installed into a vehicle’s DIN radio slot using the installation bracket provided. Note before installing, Fig. 13: ✎ The radio must be installed horizontally. Deviations of - 10 to + 30 degrees can be set in the “Mounting angle”...
  • Page 20 INSTALLATION INSTRUCTIONS Setting the mounting angle In order to ensure perfect functioning of the system, the navigation radio must be set to the actual mounting angle in the instrument panel. 1. In navigation mode: Select the “ 2. Depending upon the installation, set the angle to between -10 and +30 degrees. The system does not differentiate between negative and positive angles.

  • Page 21: Operation

    Control elements MUTE RADIO MS 4150 CD.C SOUND POWER VOLUME 1 o ... . Release button for operating panel 2 SOUND ..Opens the “ 3 POWER/VOLUME .

  • Page 22: Inserting A Cd

    OPERATION Inserting a CD 1. Open the front panel. 2. Insert the CD into the drive (printed side up). For audio CDs, playback starts automatically. 3. Close the front panel. Removing a CD 1. Open the front panel. 2. Press the eject button. 3.

  • Page 23: Menu Operation

    Menu operation Cursor The currently selected line or field on the screen is designated as the cursor. The cursor is identified by an inverse field (bright letters on black background). Move the cursor by turning the right rotary control. Confirm by pressing the right rotary control. To confirm, the cursor will be displayed briefly as a frame around the selected field.
  • Page 24 OPERATION Options for entering characters The line at the bottom of the display displays command symbols which allow you to perform the following functions: c : Destination country selection (in this case, “D” for Germany). : Save an address in the personal address book. : Jump to menu “Special dest.”.

  • Page 25: Information" Menu

    The “INFORMATION” menu The “ ” menu allows you to configure the type and amount of information the unit will receive via the radio data system (RDS). Press the INFO button. The “ ” menu is displayed. The following options are available: TMC Scan (Traffic Message Channel) If you activate this function, the automatic search will only look for stations transmitting TMC information and will ensure that you receive as much TMC data as...
  • Page 26 “INFORMATION” MENU Behaviour of TMC and TA If you switch on TMC Scan, you ensure that the radio will only search for stations transmitting TMC data during the automatic search. If the reception quality of the TMC station deteriorates drastically, the unit will indicate this by outputting a warning message.

  • Page 27: Sound Settings

    The “SOUND” menu In the “ ” menu, you can set your navigation radio’s sound and several other sound reproduction parameters to your own preferences. The sound settings for bass and treble/tone are valid for the currently active sound source (radio, CD or CDC).
  • Page 28 SOUND SETTINGS SDVC (speed-dependent volume increase) To compensate for environmental noise, the volume for audible information increases as a function of the speed. Choose a setting for the speed-dependent increase of the volume. Select to deactivate the function or select increase.

  • Page 29: Radio

    Listening to radio Time of day Waveband Frequency Station name (only for RDS stations) If the unit is not yet in radio mode: Press the RADIO button. Select waveband In radio mode: Press the RADIO button again. Select the desired waveband and press the right rotary control. ✎...

  • Page 30: Presets

    RADIO Setting frequency manually Activate “Manual tuning” in the radio menu. ➽ next page. Slowly turn the right rotary control to the right or left in order to change the reception frequency step-by-step. Turn the control quickly by a few notches in order to start a fast search. Press the control to stop the search.
  • Page 31 Manual Tuning Select this option to set a frequency manually, for example, if the desired station cannot be set using the automatic search function. See previous page for this function. PTY Search (only in FM) This function allows you to search for stations of the desired program type. Select the desired program type from the list.

  • Page 32: Cd Player

    CD PLAYER CD player CD Audio: CD title (only with CD text) MP3: directory name CD-Audio: Track and artist (only with CD text) MP3: File name or ID3 tag (if available) Track number You can play 12 cm audio CDs and discs with MP3 files on your CD player. We strongly recommend only playing 12 cm CDs.

  • Page 33: Cd / Mp3 Playback

    ID3 tag display For MP3 CDs, the currently selected directory and below it the ID3 tag (title and artist) of the current piece of music will be displayed. ✎ When a new track is played, the file name is shown briefly first, followed by the ID3 tag. ✎...

  • Page 34: The "Cd" Menu

    CD PLAYER The “CD” menu In CD player mode: Press the MENU button. The “ ” menu is displayed. The following functions are available: Manual Search Activate this function in order to perform a manual search using the right rotary control. Turn the right rotary control one notch to the right or left in order to start the first level of the fast search forwards or backwards.

  • Page 35: Cd Changer

    CD changer (accessories) CD title (only with CD Text or if CD title has been entered) Track and artist (only with CD text) Selected CD in magazine Track number A digital CD changer can be connected to the navigation radio. We strongly recommend only playing 12 cm CDs.

  • Page 36: The "Cd Changer" Menu

    CD CHANGER The “CD CHANGER” menu In CD changer mode: Press the MENU button. The “ ” menu is displayed. The following functions are available: Manual Search Activate this function in order to perform a manual search using the right rotary control. Turn the right rotary control one notch to the right or left in order to start the first level of the fast search forwards/backwards.

  • Page 37: Initialisation

    The “INITIALISATION” menu Select “ menus: “ ”, “ ”. The “ ” menu is displayed. The “ ” menu allows you to adjust the navigation radio to your needs. The following functions are available: Telephone Adapt your unit’s telephone input to your car phone: –...
  • Page 38 INITIALISATION On Off logic Activate this function to limit the operation of the device to one hour after the ignition key is removed. Display Setting the display contrast and the display brightness. Set the contrast and brightness for the display between 0 and 31 as required. Loudspeaker Test Activate this function to control the loudspeaker connections and positions.

  • Page 39: C-Iq - Intelligent Content On Demand

    C-IQ - Your key to map, traffic and travel information With your navigation radio you get several CDs containing all the available map data of Europe, plus digital travel guide products and TMC data (for dynamic navigation). The information or products on the CDs are encrypted and, if required and after expiry of an activation period, can be activated fee.

  • Page 40: Registering The Navigation System

    C-IQ – INTELLIGENT CONTENT ON DEMAND Registering the navigation system In order to activate other C-IQ products, you must register your navigation system with C-IQ Service. This also ensures that you will receive updated CDs on a regular basis, and will therefore always be using the latest maps (does not apply to unlimited activation).
  • Page 41 My C-IQ You have the choice of obtaining information about your activation status at any time. Select “ ” in the “ Select “ have activated. Select “ ” if you wish to view details of products you have received which will soon be active.
  • Page 42 C-IQ – INTELLIGENT CONTENT ON DEMAND Preview Together with your map and travel information software you will also receive the opportunity to inspect different products free of charge before ordering them. You can have the system display the status of this preview: Select “...

  • Page 43: Info Points Function

    Info Points function Visual and audible indication of important points along your route. Different providers of travel and traffic information have optimised these specifically for navigation systems. This includes information about fixed speed camera installations or other safety relevant information (e.g. schools, kindergartens, etc.) and places of interest to tourists.

  • Page 44: Navigation

    NAVIGATION Main control A map CD must be inserted into the CD player for some of the functions in navigation mode. If the unit is not yet in navigation mode: Press the NAV button. The navigation main control is displayed. The following items are available in the main control: Destination input Opens the “...

  • Page 45: Destination Input

    Destination input Destinations may be entered in several ways: – Entering city, road and house number or junction by means of the “typewriter.” See the following page. Loading an address stored in the personal address book. ➽ page 65. – –...
  • Page 46 NAVIGATION step: City or postal code Select “ ” in the destination input menu. The display automatically shows “ typewriter window, the name of the last destination city is already displayed. If you want to enter a destination address in the city shown, simply select “...
  • Page 47 step: Road Once the city has been entered the input wizard automatically jumps to the “ ” input menu. Enter the name of the road using the “typewriter” or select a name from the list using step: House number or junction If house numbers are available for a selected road, they can be entered with a separate input menu.

  • Page 48: Special Destinations (Pois)

    NAVIGATION Special destinations (POIs) You may also input the destination address by selecting special facilities (POI = Points of Interest) stored in the database. These include e.g.: – airports, – hotels, – petrol station, – car repair garages – car parks, etc. Depending upon the information already entered in the destination input screen, a list of general interest facilities appears which are present on the current map CD.
  • Page 49 Special facilities in the vicinity of the current position You may also set a destination address by selecting a special facility in the vicinity of the current vehicle location. Select “ A list of categories of special facilities is shown. Select the required category.

  • Page 50: Via Point Input

    NAVIGATION Via point input If you wish to visit other locations en route to the entered destination address, these can be stored as via points. The navigation system then plans the route to include the via points in the given sequence before the destination address is reached.
  • Page 51 NAVIGATION Delete via points not reached Via point which you have not reached or which are no longer desirable to you must be deleted from the via point list so that the navigation system may plan the route to the next via point or to the final destination.

  • Page 52: Guidance

    NAVIGATION Guidance Guidance screen The guidance screen appears as soon as you activate the guidance. The guidance screen displays the following information: 1 Road direction arrow: The arrow indicates the course of the road. 2 Simplified presentation of the next turn-off prompt (early warning). 3 Status field.
  • Page 53 9 Stationary traffic display: As soon as any traffic obstructions reported by TMC pertain to the planned route, a brief message appears, indicating the distance to the nearest obstruction and its type. This function can be activated/deactivated from the menu “ ”.
  • Page 54 NAVIGATION Audible messages During guidance, the navigation radio will provide acoustic routing information in addition to the symbols on the guidance screen. Commonly, the directive to turn into another road consists of two voice messages: an early warning e.g. “Right turn ahead” the instruction to turn e.g.
  • Page 55 Road direction arrow On longer route segments without junctions or crossroads, an arrow is displayed indicating the course of the road over the next 100 m or so. In addition, a reduced diagram of the next turn-off prompt appears on the left, above the route direction arrow. Thus, the driver is always warned in advance of the next change of direction.

  • Page 56: Route Selection

    NAVIGATION Route selection During guidance, you may also modify the route criterion and activate or deactivate dynamic route planning. The system will then plan a new route taking into account the new setting of the current position of your car. In the guidance screen, select the symbol for route selection (on the basis of the setting in the destination input U, V, W or X).

  • Page 57: Information During Guidance

    Information during guidance During guidance, you can call up several information screens: Move the cursor to the The list of information menus appears. The following information menus are available: Route list This option is available as soon as a route has been planned.
  • Page 58 NAVIGATION Displaying/deleting via points If via points have been entered for the current destination, the “ The number of via points still to be reached also appears. Select the required via point from the list in order to view details or delete it. Destination Display of current destination address with Name (if entered), country code, city, road, and junction.

  • Page 59: Traffic Information

    Traffic information Use the “Traffic info” option in the main control to obtain information about traffic conditions in three different categories: – At the car position – At the destination – On the route ✎ To access traffic information, the radio must be tuned to an RDS TMC station. ✎...
  • Page 60 NAVIGATION By turning the right rotary control, you can access two further screens containing details about the selected traffic obstruction. The second details screen indicates the section in which the traffic obstruction is located and the third, the information about the obstruction provided by the TMC provider.

  • Page 61: Dynamic Guidance With Tmc

    Dynamic guidance with TMC With RDS TMC (Traffic Message Channel), the current traffic situation is taken into account when planning the route to your destination. You will be informed, for example, of accidents, congestion or construction sites as soon as such a traffic situation occurs. If you approach the traffic obstruction, the automatic detour option is activated and the navigation system will plan, if required, an alternative route.
  • Page 62 NAVIGATION Bypassing a traffic obstruction locally When you approach the last exit before reaching a traffic obstruction, the navigation system will alert you and offer you the option of planning a detour route. As soon as a traffic obstruction is detected on your route and the detour option is displayed on the guidance screen: Confirm the detour option in the top line of the guidance screen.

  • Page 63: Dynamic Route Planning

    Dynamic route planning Unlike dynamic guidance, which provides information about traffic conditions on your route and on request about local traffic conditions, dynamic route planning takes into account the whole of the current traffic situation in a configurable area (horizon) in the vicinity of the current position of the car.

  • Page 64: Alternative Route

    NAVIGATION Alternative route During guidance, you can cause the navigation system to plan an alternative route. Use this function if, for example, you want to avoid stationary traffic not reported via TMC or if you wish to plan an alternative route. The alternative route will be calculated for a selectable distance from the current position of the car.

  • Page 65: Address Manager

    Address manager The navigation radio offers the opportunity of storing at least 30 destination addresses in a personal address book. In the address book, you can store your destinations separately under the categories “Private” and “Business”. The “Home” and “Work” shortcuts, which can be programmed with your home address and business address respectively, are also available here.
  • Page 66 NAVIGATION Store current loc. Would you like to store a favourite restaurant in the destination memory? You can store the current position of your car as follows: Select “ Select which address books the address should be stored in (private, business, home or work).

  • Page 67: Emergency Menu

    Emergency menu In the main control, select “ The “ ” menu is displayed. The following options are available in the “ ” menu: GPS position Display of the current geographic vehicle location as calculated by the Global Positioning System. Longitude, altitude and elevation above sea level (provided adequate GPS reception is available) will be displayed.

  • Page 68: System Settings

    NAVIGATION System settings To customise the navigation functions to your own needs, you can change several settings. In the main control, select “ The “ The following information screens are available: Speed In the “ ” menu, you can configure the following settings: Speed correction The navigation radio uses an average cruising speed to calculate the remaining travel time and the estimated time of arrival.

  • Page 69: Settings For Dynamic Route Planning

    Limit (xx/h) This enables you to specify a value manually so that a speed warning will be given if you exceed this speed (useful if using winter tyres, for example). Select “ ” and set the desired limit for the fixed speed warning. Select “...

  • Page 70: Default Settings

    NAVIGATION Delay Use this value to indicate the anticipated delay time due to a traffic obstruction at or above which the navigation system should suggest that a new route be planned. Select a value between 5 and 60 minutes. ✎ The anticipated delay is calculated on the basis of the data received from the TMC station and may deviate from the actual situation.

  • Page 71: System Information

    Service For diagnosing hardware and software problems (code-protected). The option “ ” is exclusively reserved for service work on the navigation radio performed by an authorised service company. System information The “ ” menu displays information about the software and hardware version (for service purposes).

  • Page 72: Troubleshooting

    TROUBLESHOOTING In rare instances, your navigation radio may not function the way you expect it to. Before calling the service department, please read the operating instructions thoroughly and go through the following check list; it may be possible to quickly remedy an apparent malfunction.
  • Page 73 Symptoms Navigation Display shows “Please insert map CD”. The number of satellites in the “GPS/Compass” information menu is 0. The directions cannot be heard or are very quiet. Guidance is not accurate. Displayed position does not correspond to actual vehicle position. Directions do not correspond to the actual traffic conditions.

  • Page 74: Tips & Tricks

    TIPS & TRICKS Tips for convenient operation Cross-border guidance Owing to the high data volume, the European navigation data is stored on several CD ROMs (map CDs). In order to nevertheless achieve cross-border guidance, the most important European cities and roads (Major Roads Europe) are additionally stored on the map CDs at present.

  • Page 75: Menu Overview

    MENU OVERVIEW BAND RADIO - Menu RADIO SOUND CD·C·MP3 Menu INFO...
  • Page 76 MENU OVERVIEW...
