IMB202 LGA775 ATX Board User's Manual
1.1

Specifications

®
CPU: Intel Core
processors
System Chipset: Intel
CPU Socket: LGA775
Front-Side Bus: 800/1066/1333 MT/s (200/266/333 MHz)
BIOS
Phoenix-Award PnP Flash BIOS
System Memory
Four DDR2 DIMM sockets
Maximum up to 8GB DDR2 memory
Support Dual Channel DDR2 667/800 MHz memory
Onboard Multi-I/O
Controller: Winbond W83627DHG and W83627HG
Serial Ports: 3 ports for RS-232 (COM2/3/4) and 1 port for
RS-232/422/485 (COM1)
Parallel Port: One bi-directional with ECP/EPP/SPP support
Floppy Controller: Support for two drives (1.44MB for each)
USB Interface
Twelve USB 2.0 high speed compliant
Display
Integrated on Intel Q35 GMCH (For CRT Only)
Ethernet
®
Inte l i82566DM and Realtek RTL8111B PCI Express x1
gigabit Ethernet controllers support 10/100/1000Mb/s
Serial ATA
Support Serial ATA/ ATA II
Six Serial ATA Channels for total of Six Serial ATA hard drive
(with ICH9-DO only)
Maximum transfer rate could up to 3Gb/s
Support SATA RAID 0, 1, 0+1, 5 function (with ICH9-DO only)
2
TM TM
2 Quad, Core 2 Duo and Celeron
®
Q35 & ICH9/DO
®
Introduction
