IMB202 LGA775 ATX Board User's Manual
CHAPTER 1
INTRODUCTION
®
TM
The IMB202 ATX industrial motherboard supports Intel Core 2
®
TM
Quad, Core 2 Duo, and Celeron processors at 800/1066/1333
®
MT/s. The board integrates chipsets Intel Q35 and ICH9/DO that
delivers outstanding system performance through high-bandwidth
interfaces, multiple I/O functions for interactive applications and
various embedded computing solutions. There are four DDR2 DIMM
sockets for dual channel DDR2 667/800 MHz memory, maximum
memory capacity up to 8GB. The board also features Ethernet
10/100/1000Mb, dual PCI Express x1 Gigabit Ethernet, six Serial ATA
channels (with ICH9-DO only) for total six Serial ATA hard drives at
maximum transfer rate up to 3Gb/s, ten USB 2.0 high speed
compliant, built-in high definition audio codec that can achieve the
best stability and reliability for industrial applications.
Introduction
1
