SATA Mode
There are these options for you to set up SATA mode: IDE,
RAID or AHCI.
LEGACY Mode Support
Legacy mode support allows devices to function in an
operating environment that is not USB-aware.
Press <Esc> to return to the Integrated Peripherals page.
Super IO Device
Scroll to this item and press <Enter> to view the sub menu Super
IO Device.
Onboard FDC Controller
Select Enabled, if your system has a floppy disk controller
(FDC) installed on the system board and you want to use it.
If you install and-in FDC or the system has no floppy drive,
select Disabled in this field. Options: "Enabled" and
"Disabled"
.
Onboard Serial Port 1/2
Select an address and corresponding interrupt for the serial
port. Options: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3,
Disabled, Auto.
Onboard Parallel Port
This item allows you to determine access onboard parallel
port controller with which I/O address. The options available
Phoenix-Award BIOS Utility
IMB202 LGA775 ATX Board User's Manual
43
