serious conflict that the operating system can not boot. Options are:
"Enabled, Disabled".
Resources Controlled By
The Phoenix-Award Plug and Play BIOS can automatically
configure all boot and Plug and Play-compatible devices. If you
select Auto, all interrupt request (IRQ), DMA assignment, and Used
DMA fields disappear, as the BIOS automatically assigns them.
The default value is "Manual".
IRQ Resources
When resources are controlled manually, assign each system
interrupt to one of the following types in accordance with the type
of devices using the interrupt:
Legacy ISA Devices compliant with the original PC AT bus
1.
specification, requiring a specific interrupt (such as IRQ4 for serial
port 1).
PCI/ISA PnP Devices compliant with the Plug and Play standard,
2.
whether designed for PCI or ISA bus architecture.
The default value is "PCI/ISA PnP".
DMA Resources
When resources are controlled manually, assign each system DMA
channel as one of the following types, depending on the type of
device using the interrupt:
Legacy ISA Devices compliant with the original PC AT bus
specification, requiring a specific DMA channel.
PCI/ISA PnP Devices compliant with the Plug and Play standard,
whether designed for PCI or ISA bus architecture.
The default value is "PCI/ISA PnP".
PCI/VGA Palette Snoop
Some non-standard VGA display cards may not show colors
properly. This item allows you to set whether MPEG ISA/VESA
VGA Cards can work with PCI/VGA or not. When enabled, a
PCI/VGA can work with a MPEG ISA/VESA VGA card; when
disabled, a PCI/VGA cannot work with a MPEG ISA/VESA Card.
** PCI Express relative items **
Maximum Payload Size
When using DDR SDRAM and Buffer size selection, another
consideration in designing a payload memory is the size of the
