to restore the system when a "wake up" event occurs.
Run VGABIOS if S3 Resume
When this item is set Auto, the system will run VGA BIOS if it is
resumed from the S3 state.
Power Management
This option allows you to select the type (or degree) of power saving for
Doze, Standby, and Suspend modes. The table below describes each
power management mode:
It is maximum power savings, only available for SL
Max Saving
CPUs. The inactivity period is 1 minute in each mode.
It sets each mode. Select time-out periods in the PM
User Define
Timers section.
It is minimum power savings. The inactivity period is 1
Min Saving
hour in each mode (except the hard drive).
Disabled Default value
Video Off Method
This setting determines the manner in which the monitor is blanked.
Turns OFF vertical and horizontal
V/H
synchronization ports and writes blanks to the
SYNC+Blank
video buffer
Select this option if your monitor supports the
DPMS
Display Power Management Signaling (DPMS)
standard of the Video Electronics Standards
Association (VESA). Use the software supplied
for your video subsystem to select video power
management values.
System only writes blanks to the video buffer.
Blank Screen
Video Off In Suspend
This item defines if the video is powered down when the system is
put into suspend mode.
Suspend Type
If this item is set to the default Stop Grant, the CPU will go into Idle
Mode during power saving mode.
Suspend Mode
After the selected period of system inactivity (1 minute to 1 hour),
all devices except the CPU shut off. The default value is "Disabled".
