IBM Power System IC922 Manual page 23

Figure 8. Connecting the power cords to the system
7. Attach all other cables to the rear of the server.
Figure 9. Rear view of the system with ports displayed
Table 1. Port descriptions
Identifier Description
1 Video Graphics Array (VGA)
Note: Cables up to 3 meters are supported.
2 Serial
Note: Cables up to 3 meters are supported.
3 Dedicated BMC Ethernet. Use this port for the BMC/IPMI interface (eth1).
4 Shared BMC Ethernet. (eth0)
5 USB 3.0
Note: Cables up to 3 meters are supported. The USB 3.0 port on the front of the system
has the same restriction.
Installing and configuring the 9183-22X 9
