- Page 1 Taiwan Systems & Technology Lab Installation of nVIDIA M1060 at the Side Bay of Expension Tray iDataPlex Service Guide 2010/7/29...
- Page 2 Taiwan Systems and Technology Lab Slide M1060 halfway into side bay Check Points M1060 extender in the groove of blue retainer bracket. Power cable for M1060 is not tangled (not yet connected to M1060). 2010/7/29...
-
Page 3: Connect Power Cable
Taiwan Systems and Technology Lab Connect power cable 2010/7/29... - Page 4 Taiwan Systems and Technology Lab Push the heatsink down and move the card forward until the gold fingers stop at the slot on the riser card Check Points While forwarding the card, ensure the edge of I/O bracket meets chassis bottom.
- Page 5 Taiwan Systems and Technology Lab Push M1060 gently into slot Check Points Do not lift M1060 during this step. Check if screw holes on M1060 and chassis aligned. EMI shield (blue line) is not higher than I/O bracket (red line). More illustrations on the next page for the definitions of the lines.
- Page 6 Taiwan Systems and Technology Lab Red line: Bottom surface of I/O bracket. Blue line: as shown. Same level as the edge of I/O aperture. 2010/7/29...
- Page 7 Taiwan Systems and Technology Lab … another picture of correct installation 2010/7/29...
- Page 8 Taiwan Systems and Technology Lab Screw side cover on 2010/7/29...
