1-7-2

Measurement Scale

Wipe down the measurement tape with a dry piece of lint-free cloth every 6 months. Make sure to wipe down the
total stroke length of the axis.
Make sure the cloth is new and clean does not have any metal chips or any other particles
attached that could irreparably damage the measurement tape.
In order to access the measurement tape, you must remove the cover of the axis. Please follow the instructions in
Section 1-6-5 Installing the Linear Axis in the System for this purpose.
Measurement tape
