Expansion Modules; Digital Station - Avaya IP Office Essential Edition PARTNER Version Reference Manual

Name
IPO 500 TRNK PRI 1 UNI
IPO 500 TRNK PRI 2 UNI

4.5 Expansion Modules

The Essential Edition - PARTNER® Version control unit can support one extension unit as follows:
· Digital Station (DS) module.
or
Phone module.
·

4.5.1 Digital Station

IPO 500 Digital Station modules can be used to add additional DS ports to an Essential Edition - PARTNER® Version
system. Note that this requires the IP Office control unit to be configured with an IP Office 500 Upgrade Standard to
Professional license.
The module is referred to as the IPO 500 Digital Station 16.
PARTNER® Version, Installation and Reference Manual
IP Office Essential Edition
· Licenses
The IP Office system supports 8 unlicensed B-channels on each IP500 PRI-
U port fitted. Additional B-channels, up to the capacity of ports installed
and PRI mode selected require IP500 Universal PRI (Additional
Channels) licenses added to the configuration. These additional channels
consume the licenses based on which additional channels are configured as
in-service from port 9 of slot 1 upwards. D-channels are not affected by
licensing.
· Maximum per IP500 Control Unit: 4.
· Software Level: 4.1+.
Daughter Card Ports (9-12)
The LEDs for ports 9 to 12 of the IP500 base card are used as follows:
· Off: No trunk present.
· Green on: Trunk present.
· Green flashing: Trunk in use.
· LED 9 is used for daughter card status.
· Red On = Error
· Red Slow Flash = Initializing.
Description
IP Office 500 Trunk Card Primary Rate 1 Universal
IP Office 500 Trunk Card Primary Rate 2 Universal
System Component Details: Trunk Cards
· Red/Green Fast Flash (port 9) or Green
Fast Flash (port 10): Alarm indication
signal (AIS) from the trunk remote end.
· Red with Green Blink (port 9) or Green
Blink (port 10): Port in loopback mode
(set through IP Office System Monitor).
· Red Flash every 5 seconds = Card
okay.
· Red Fast Flash = System shutdown.
Part Number
700417439
700417462
Page 57
- Issue 1a (30 January 2010)
