Model number
Exterior Appearence
Color Appearance
Design Style
Grates
Configuration
Energy type
Cooktop Burners
Fuel Type
Control Location
Control Type
Oven Capacity
Ignition System
Cooktop Surface
Convection Technology
Bake Burner
Oven Cleaning Type
Oven Modes
Broil Element
Oven Rack
Shelves Positions
Oven door features
Beneath Oven Cavity
Removable door and glasses
Installation Type
High Performance Double Burner
Simmer Burner
Exterior Dimensions
Overall Height (in.)
Overall Width (in.)
Overall Depth (in.)
Electrical Requirements
Volts; Hertz; Amps
Accessories (Included)
Wok Stand
5 inch. Backgurad
Rotisserie Pan
LP Conversion Kit
2 Years full waranty
OR24SDMBGX2-N
24'' Gas Range - MSRP: $3,109.00
Selected Model
OR24SDMBGX2-N
Stainless Steel
European
Robust Cast-iron
Features
4 Burners
Gas
Sealed
Natural Gas (NG) or Propane (LP)
Upfront
Rotative Knobs
Capacity
2.5 pi.cu
Cooktop Features
Electronic with automatic reignition
Stainless Steel
Oven Features
Traditional Convection
13000 BTU
Manual
4
8500 BTU
2
3
Cool Touch Triple Glazed Door
Storage
Yes
Installation
Built-in (Flush with the Cabinets) or Free
Standing
Burner ratings
12000 BTU
6000 BTU
3500-1000 BTU
35 5/8'' - 36 3/8''
23 7/8''
24''
120V; 60Hz; 0.1 Amp
Included
Included
Included
Included
Warranty
Entire Appliance, In-Home Parts & Labour
Advertisement
Related Manuals for Fisher & Paykel OR24SDMBGX2-N
Summary of Contents for Fisher & Paykel OR24SDMBGX2-N
- Page 1 OR24SDMBGX2-N 24'' Gas Range - MSRP: $3,109.00 Selected Model Model number OR24SDMBGX2-N Exterior Appearence Color Appearance Stainless Steel Design Style European Grates Robust Cast-iron Features Configuration 4 Burners Energy type Cooktop Burners Sealed Fuel Type Natural Gas (NG) or Propane (LP)
