RUGGEDCOM RST2228
Installation Guide
7.
Connect power to the device.
Installing a Module
To install a media module, do the following:
1.
Make sure power to the device has been disconnected and wait approximately two minutes for any remaining
energy to dissipate.
2.
[Optional] If the device is installed in a rack, remove it from the rack.
3.
Remove the current module from the slot.
4.
Insert the new module into the slot.
Figure 26: Installing a Module
5.
Tighten the screw(s) to secure the module.
6.
[Optional] If necessary, install the device in the rack.
7.
Connect power to the device.
Installing/Removing Modules
Chapter 4
Communication Ports
29
