RUGGEDCOM RST2228
Installation Guide
SFP Transceiver
RUGGEDCOM SFP2133-1ZR80
a
MM = Multi-Mode, SM = Single-Mode
b
Only compatible with SFP/SFP+ Transceiver Sockets.
c
Not compatible with SFP/SFP+ Transceiver Sockets.
Section 4.2

Available Modules

The following modules are available for use with the RUGGEDCOM RST2228. For more information about
individual modules, refer to the RUGGEDCOM Modules Catalog for the device available online.
Copper Ethernet Modules
RUGGEDCOM RMM2973-4RJ45
RUGGEDCOM RMM2973-4FC
Fiber Optic Ethernet Modules
RUGGEDCOM RMM2972-4SFP
RUGGEDCOM RMM2942-4LC2
Available Modules
Order Code
b
6GK6000-8FT52-0AA0
Speed
Mode
(Mbit/s)
10000 SM
Specifications
Ports: 4
Port Type: RJ45
Speed: 10/100/1000 Mbps
Interface: TX
Distance: 100 m (328 ft)
Specifications
Ports: 4
Port Type: FastConnect RJ45
Speed: 10/100/1000 Mbps
Interface: TX
Distance: 100 m (328 ft)
Specifications
SFP Sockets: 4
Speed: 100/1000 Mbps
Specifications
Ports: 4
Port Type: LC
Mode: MM (Multi-Mode)
Speed: 100 Mbps
Interface: FX
Wavelength: 1310 nm
Distance: 2 km (1.2 mi)
Communication Ports
a
Nominal Distance (km)
80
Article Numbers
6GK6297-3RD00-4AB0
(Standard)
6GK6297-3RD00-4AB1
(Conformal Coated)
Article Numbers
6GK6297-3FD00-4AB0
(Standard)
6GK6297-3FD00-4AB1
(Conformal Coated)
Article Numbers
6GK6297-2SA00-4AA0
(Standard)
6GK6297-2SA00-4AA1
(Conformal Coated)
Article Numbers
6GK6294-2LD00-4AC0
(Standard)
6GK6294-2LD00-4AC1
(Conformal Coated)
Chapter 4
27
