RUGGEDCOM RST2228
Installation Guide
Figure 22: Removing the CLP
1. CLP 2. Protective cover
2.
Insert the protective cover or a new CLP to prevent the ingress of dust and dirt.
Installing the CLP
To install the CLP, do the following:
1.
Remove the protective cover from the CLP port.
Figure 23: Installing the CLP
1. Protective cover 2. CLP
2.
Insert the CLP into the CLP port.
Inserting/Removing the CLP
1
2
1
2
Chapter 3
Device Management
23
