AS1051 Series User's Guide
Corded
handset
Accessory
handset and
charger
Rechargeable
If any items are missing or damaged, never use damaged products!
Important Safety Instructions!
When using your telephone equipment, basic safety precautions should always
be followed to reduce the risk of fire, electric shock and injury to persons,
including the following:
- This unit is NOT waterproof. DO NOT expose this unit to rain or moisture.
- Do not use this product near water, for example, near a bath tub, wash bowl,
kitchen sink or laundry tub, in a wet basement or near a swimming pool.
- Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
- Do not use the telephone to report a gas leak in the vicinity of the leak.
- Use only the power cord and batteries indicated in this manual. Do not
dispose of batteries in a fire. They may explode. Check with local codes for
possible special disposal instructions.
- Do not place the handset in any charging cradle without the battery installed
and the battery cover securely in place.
What's in the box?
AS1051 base
with answering
system
Coiled
cord
You will also fi nd:
Charger AC
adapter
Battery
cover
battery pack
SAVE THESE INSTRUCTIONS!
Telephone
Base AC
cord
adapter
Desk stand/wall
mount bracket
If you purchased
You should
model number:
AS1051
1 of each
AS1051-2
2 of each
AS1051-3
3 of each
AS1051-4
4 of each
AS1051-5
5 of each
AS1051-6
6 of each
have:
Advertisement
Table of Contents
Related Manuals for Uniden AS1051 Series
Summary of Contents for Uniden AS1051 Series
- Page 1 AS1051 Series User's Guide What's in the box? Corded Telephone AS1051 base Base AC handset cord adapter with answering system Coiled Desk stand/wall cord mount bracket You will also fi nd: Accessory If you purchased You should Charger AC handset and...
-
Page 2: Table Of Contents
What's in the manual? Installing Your Phone ...... 1 Using Multi-Station Features ..16 Set Up the Base ......1 Expanding Your Phone ....16 Test the Connection ....... 3 Using Conference Calling .... 16 Set Up the Accessory Handset(s) .. 3 Using Privacy Mode ..... -
Page 3: Installing Your Phone
Installing Your Phone Set Up the Base Attach the stand Before you attach the stand, you have to decide if you want the phone to rest on a desk or hang on a wall. For desktop use DESK 1. Turn the stand so the word is right-side up (it will DESK be on the right). - Page 4 For wall mount use only 1. On the front of the base, pull the clip (that holds the corded handset in place) out of its slot. 2. Rotate the clip 180 degrees. 3. Flip it from front to back and slide it back into the slot. Connect the power and telephone cords 1.
-
Page 5: Test The Connection
Test the Connection Pick up the corded handset from the base. You should hear a dial tone and the display on the base should say Talk. When you get a dial tone, make a quick test call. If... Try... the display says Check Tel Line checking the connection between or you don't hear a dial tone the base and the phone jack. -
Page 6: Changing From Tone To Pulse Dialing
Connect the charger 1. Connect a charger AC adapter to each charger's power jack and set the plug into the notch as shown. (These adapters might already be connected.) 2. Plug the other end of the adapter into a standard AC power outlet. 3. -
Page 7: Getting To Know Your Phone
Getting to Know Your Phone Parts of the Base If the key name is spelled out on the key itself, it's not labeled in the drawing below. Corded handset ON/OFF PHONEBOOK/LEFT Display PLAY/STOP CALLER ID/RIGHT DELETE DOWN Antenna SPEAKER Microphone Coiled Twelve-key dial pad handset... - Page 8 Key name What it does (and icon) - In standby: open the menu. MENU/SELECT - In the menu or any list: select the highlighted item. - In standby: start playing messages. PLAY/STOP - While a message is playing: stop playing messages. - In the menu or any list: exit the menu completely.
-
Page 9: Parts Of The Handset
Parts of the Handset If the key name Display is spelled out on CLEAR/ INTERCOM the key itself, it's not labeled in the PHONEBOOK/ CALLER ID/ LEFT RIGHT drawing to the right. DOWN SPEAKER Twelve-key dial pad MESSAGES/ MUTE Microphone Charging contacts Handset keys and how they work Key name... -
Page 10: Reading The Displays
Key name What it does (and icon) - During a call: hang up. - In the menu or any list: exit and go to standby. - Switch a normal call to the speakerphone (and back). SPEAKER ( - In standby: open the redial list. REDIAL/PAUSE - While entering a phone number: insert a 2-second pause. -
Page 11: Using The Menus
Using the Menus The menus are designed to be as easy as possible. Some users don't even need the manual once they know how to perform these actions: Open the menu Press MENU/SELECT The arrow cursor on the left side of the line shows which Move the cursor menu item is currently highlighted. -
Page 12: The Base Setup Menu
Turn on Auto Talk so you can answer the phone just by Autotalk picking up the handset from the cradle (without having to press any buttons). Turn on Any Key Answer so you can answer the phone Any Key Answer by pressing a key on the twelve-key dial pad. -
Page 13: Register Handset (Base Only)
Register Handset (Base Only) This menu lets you register additional handsets to this base or re- register a handset that you had to reset for some reason (see "Resetting and Registering Handsets" on page 27). Entering Text on Your Phone When you want to enter text into your phone (for example, a name in the phonebook), use the twelve-key dial pad to enter the letters printed on the number keys. -
Page 14: Using Your Phone
Using Your Phone To... From the base From a cordless handset Dial the number, then pick up Dial the number, then press make a call the corded handset. TALK/FLASH answer a call Pick up the corded handset. Press TALK/FLASH Return the handset to the Press or return the hang up... -
Page 15: Using The Redial List
Change the When On the base On a handset ringer the phone is in select Off, Low, select Off, Low, volume standby Medium, or High. Medium, or High. earpiece you are on a normal choose one of 6 choose one of 6 volume call volume levels. -
Page 16: Using Seven-Digit Dialing
3. On the handset, press to dial the number. On the base, TALK/FLASH pick up the corded handset. (You can also press or pick up the corded handset before TALK/FLASH opening the CID list. Find the number you want to dial, then press MENU/SELECT Caller ID menu options With the phone in standby, open the CID list and find the number you... -
Page 17: Using The Phonebook
Using the Phonebook Each station can store up to 70 entries in its phonebook. Open/close the phonebook Press PHONEBOOK. Press to scroll through the phonebook DOWN Scroll through the entries from A to Z or to scroll from Z to A. Jump to entries that start Press the number key corresponding to the with a certain letter... -
Page 18: Using Multi-Station Features
Your base supports a total of six AS116 accessory handsets, including any that were supplied with your phone. Your base might be compatible with other Uniden accessory handsets; please visit our website for a list of compatible handsets. Accessory handsets must be registered to the base before you can use them. -
Page 19: Using Call Transfer
Using Call Transfer To... From the base From a cordless handset 1. Press 1. Press FIND HANDSET/INTERCOM CLEAR/INTERCOM put the call on hold. put the call on hold. transfer a 2. Select the station you want to transfer the call to, or select All to page all the stations at the same time. -
Page 20: Using Special Features
Using Special Features Using Your Phone During a Power Failure Because it includes a corded handset, your phone can perform several of its functions during a power failure. The following features will operate during a power failure (all other features are disabled): Making and receiving calls with the base corded handset. -
Page 21: Using The Answering System
Using the Answering System Setting Up Your Answering System Recording your outgoing message Your personal outgoing message or greeting can be between 2 seconds and 30 seconds long. If you don't want to record an outgoing message, the system will use its pre-recorded greeting: Hello, no one is available to take your call. - Page 22 Delete your greeting From the base From a cordless handset 1. Switch to your personal greeting 1. Switch to your personal greeting following the steps above. following the steps above. 2. While the system is playing back 2. While the system is playing back your greeting, press your greeting, press DELETE...
-
Page 23: Getting Your Messages
Getting Your Messages Accessing your answering system from a handset You can access your system from a handset whenever the phone is in standby. Press MESSAGES/MUTE to start remote operation mode. next previous Use PHONEBOOK/LEFT and CID/RIGHT to scroll Press MENU/SELECT Press END to exit through the options. -
Page 24: Screening Your Calls
From a handset To... From the base (remote operation) Press Press or select 1:Repeat PHONEBOOK/LEFT replay previous repeatedly until you hear the repeatedly until you hear the messages message you want to replay. message you want to replay. skip a message Press Press or select 3:Skip. -
Page 25: Away From Home
Using the System While You're Away from Home You can also operate your answering system from any touch-tone phone. Before you can use this feature, you have to program a security code. Programming a security code 1. With the phone in standby, open the menu from any station. 2. -
Page 26: Solving Problems
Solving Problems If you have any trouble with your phone, try these simple steps first. If… Try… - Checking the telephone cord connection. No stations can make - Disconnecting the base AC adapter. Wait a few or receive calls. minutes, then reconnect it. One cordless handset - Moving the handset closer to the base. -
Page 27: Weak Or Hard To Hear Audio
If… Try… - Making sure no other handset is using the system. A handset can't access the answering system. - Making sure the phone is in standby. My outgoing message - Seeing if there was a power failure. You may have to is gone. - Page 28 Here are some hints for when the static is... on 1 handset or in 1 location: on all handsets or in all locations: - Check nearby for one of the - Check near the base for the source common interference sources. of interference.
- Page 29 Resetting and Registering Handsets If you are having trouble with a cordless handset or if you want to replace one, you need to clear the registration information from the base and the handset: Do you have the base the handset is registered to? 1.
-
Page 30: Handling Liquid Damage
Handling Liquid Damage Moisture and liquid can damage your cordless phone. If the handset or base is exposed to moisture or liquid, but only the exterior plastic housing is affected, wipe off the liquid and use as normal. If moisture or liquid has entered the plastic housing (i.e. liquid can be heard in the phone or liquid has entered the handset battery compartment or vent openings on the base), follow these steps: Handset... -
Page 31: Battery Information
Rechargeable Batteries Must Be Recycled or Disposed of Properly. Uniden works to reduce lead content in PVC coated cords in our products and accessories. Call waiting, CID, CIDCW, and Voice Mail are telephone line services. Your phone supports these services, but you have to arrange for them through your telephone provider. - Page 32 UNIDEN AS1051使用說明書 Using the Speakerphone (使用揚聲器) 機座及子機也有附設揚聲器，要使用機座之揚聲 器，按Speaker鍵代替拿起有線話筒。要使用子 Using the Menus (使用說明) 機之揚聲器，按Speaker鍵代替Talk/Flash鍵 1) 按 Menu/Select 鍵進入說明 1) 要打電話，撥號後從機座或子機按Speaker鍵 2) 用在左邊之箭咀選擇要選之選項 2) 要接電話，直接從機座或子機按Speaker鍵 3) 移動箭咀以選擇選項，再按Menu/Select鍵 3) 轉變通話到揚聲器，按機座或子機之Speaker 4) 按Phonebook/Left鍵以返回上一板面 鍵 5) 於手機按End鍵或在主機按Play/Stop鍵以關 4) 轉換到耳筒，直接拿起有線話筒或按子機上 閉說明主頁 之Speaker鍵 Day & Time Setting (時間及日期設定) 5) 中斷揚聲器之通話，可按機座之Speaker鍵或...
- Page 33 Using Multi-Station Features 1) 按 CID 鍵 (使用多於一部子機) 2) 選擇你需要回撥的號碼，按 TALK 鍵撥出 此機座能與外置之子機發揮出有用之多子機功能 3) 在座機可拿起有線聽筒，電話會自動撥出 1) 此機座支援最多6部AS116之子機，包括與購 買電話時附設之子機 Use of Call Waiting (使用來電候接) 2) 此母機或可與其他Uniden子機相容，詳情可 1) 當有來電候接時，電話會響起一個音效和顯 留覽網址 示來電者身份項表之資訊。按Flash鍵轉換現 3) 使用子機前需為子機登記方可使用，未登記 時及等候之通話而每次轉換到另一方時都會 之手機會顯示手機未登記之信息 有短暫之停頓 4) 任何與母機一同包裝好的子機已經登記了 Using the Phonebook (使用電話簿) 5) 如該子機於早前已登記了另一部母機，你需...
- Page 34 Using Call Transfer (使用來電轉駁) Using Voice Message Notifi cation 1) 要轉駁一來電，在機座按Find Handset/ (使用口信提示功能) Intercom鍵使通話暫停，再選擇要轉駁之子 1) 此功能支援（FSK)口信提示，如你有安裝口 機，此時該子機會響閙，接聽電話後之前的 信服務，當有口信時電話會作出提示，一個 通話會切斷；在無線手機按 Clear/Intercom （V)符號會出現在顯示器。 在手機頂的口信 鍵使通話暫停，之後的步驟如上 燈會閃動 2) 要取消轉駁在機座按 Speaker 回到之前通 2) 要再設定口信提示器，可在機座打開目錄選 話；在無線手機按Talk/Flash鍵即返回之前 擇環球設定，選擇VMWI 重設再選擇YES以重 通話 設 3) 要接聽轉駁之來電，在機座拿起話筒再按 Using the Answering System Clear/Intercom鍵，再按Speaker鍵；在無線...
- Page 35 Greeting (歡迎辭) 打入系統 1) 在機座或無線手機先選取個人錄製之歡迎辭 1) 打你的電話號碼等待系統接聽 2) 當歡迎辭正播放中，在機座按Delete鍵或在 2) 當播放歡迎辭時按0字馬上進入你的安全密碼 無線手機按4字答錄設定目錄選項 （你有3次輸入你的安全密碼機會) 1) 記錄歡迎辭，可從機座記錄（詳情可從上參 3) 系統會宣佈當時之時間，記憶儲存之訊息數 考) 量和協助提示。之後它會開始發出Beep聲令 2) 歡迎辭選項，可從機座更改或刪除個人之歡 你意會它正在等待你的指令 迎辭（詳情可從上參考) 4) 當你聽到間歇之Beep聲，你可輸入下列列表 3) 保安密碼，輸入一個兩位數字在進入答錄系 之指令 統前需輸入 0－1重覆口信 4) 響閙時間，可設定播放歡迎辭前之響閙次 0－2播放口信 數，分別為2，4，6 0－3略過口信 5) 錄製時間，設定來電者可留言之時間，分別 0－4刪除口信 為1分鐘或4分鐘。你也可選擇只播放歡迎辭 0－5停止重播 而不讓來電者留言...
