Page 1 Products Solutions Services BA01690D/06/EN/01.18 71384786 Valid as of version 01.02.zz (Device firmware) Operating Instructions Proline Prowirl F 200 PROFIBUS PA Vortex flowmeter...
Page 2 • The manufacturer reserves the right to modify technical data without prior notice. Your Endress+Hauser Sales Center will supply you with current information and updates to these instructions. Endress+Hauser...
Page 3: Table Of Contents
Proline Prowirl F 200 PROFIBUS PA Table of contents Table of contents About this document ....6 Installation ..... . . 20 Document function .
Page 4 10.8.1 Steam application ....120 13.3 Endress+Hauser services ....181 10.8.2 Liquid application ....121...
Page 5 14.2 Spare parts ......182 14.3 Endress+Hauser services ....183 14.4 Return .
Page 6: About This Document
About this document Proline Prowirl F 200 PROFIBUS PA About this document Document function These Operating Instructions contain all the information that is required in various phases of the life cycle of the device: from product identification, incoming acceptance and storage, to mounting, connection, operation and commissioning through to troubleshooting, maintenance and disposal.
Page 7: Tool Symbols
Proline Prowirl F 200 PROFIBUS PA About this document 1.2.4 Tool symbols Symbol Meaning Flat blade screwdriver Allen key Open-ended wrench 1.2.5 Symbols for certain types of information Symbol Meaning Permitted Procedures, processes or actions that are permitted. Preferred Procedures, processes or actions that are preferred.
Page 8: Documentation
• The W@M Device Viewer : Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. For a detailed list of the individual documents along with the documentation code →...
Page 9: Basic Safety Instructions
Proline Prowirl F 200 PROFIBUS PA Basic safety instructions Basic safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.
Page 10: Workplace Safety
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
Page 11: It Security
Proline Prowirl F 200 PROFIBUS PA Basic safety instructions IT security We only provide a warranty if the device is installed and used as described in the Operating Instructions. The device is equipped with security mechanisms to protect it against any inadvertent changes to the device settings.
Page 12: Product Description
Product description Proline Prowirl F 200 PROFIBUS PA Product description The device consists of a transmitter and a sensor. Two device versions are available: • Compact version – transmitter and sensor form a mechanical unit. • Remote version - transmitter and sensor are mounted in separate locations.
Page 13: Incoming Acceptance And Product
A0028673 and documents present? • If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • Depending on the device version, the CD-ROM might not be part of the delivery! The Technical Documentation is available via the Internet or via the Endress+Hauser Operations App, see the "Product identification"...
Page 14: Transmitter Nameplate
"Supplementary device-dependent documentation" →  8 • The W@M Device Viewer: Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. 4.2.1...
Page 15: Sensor Nameplate
Proline Prowirl F 200 PROFIBUS PA Incoming acceptance and product identification 4.2.2 Sensor nameplate Order code for "Housing" option B "GT18 two-chamber, 316L, compact" and option K "GT18 two-chamber, 316L, remote" Ser. no.: Size: Qmax(G): Ptest: Materials: Gasket: A0034423  3...
Page 16 Incoming acceptance and product identification Proline Prowirl F 200 PROFIBUS PA Order code for "Housing" option C "GT20 two-chamber, aluminum, coated, compact" Ser. no.: Size: Qmax(G): Ptest: Materials: Gasket: A0034161  4 Example of a sensor nameplate Nominal diameter of sensor...
Page 17: Symbols On Measuring Device
Proline Prowirl F 200 PROFIBUS PA Incoming acceptance and product identification Order code for "Housing" option J "GT20 two-chamber, aluminum, coated, remote" Order code: Ser. no.: Ext. ord. cd.: Size: Qmax(G): Ptest: Materials: Gasket: A0034162  5 Example of a sensor nameplate...
Page 18: Storage And Transport
Storage and transport Proline Prowirl F 200 PROFIBUS PA Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Do not remove protective covers or protective caps installed on process connections.
Page 19: Measuring Devices With Lifting Lugs
Proline Prowirl F 200 PROFIBUS PA Storage and transport 5.2.2 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device.
Page 20: Installation
Installation Proline Prowirl F 200 PROFIBUS PA Installation Installation conditions 6.1.1 Mounting position Mounting location A0015543 Orientation The direction of the arrow on the sensor nameplate helps you to install the sensor according to the flow direction (direction of medium flow through the piping).
Page 21 Proline Prowirl F 200 PROFIBUS PA Installation Inlet and outlet runs To attain the specified level of accuracy of the measuring device, the inlet and outlet runs mentioned below must be maintained at the very minimum. × 5 × DN 20 ×...
Page 22 Installation Proline Prowirl F 200 PROFIBUS PA Flow conditioner If the inlet runs cannot be observed, the use of a flow conditioner is recommended. The flow conditioner is fitted between two pipe flanges and centered by the mounting bolts. Generally this reduces the inlet run needed to 10 × DN with full accuracy.
Page 23: Requirements From Environment And Process
‣ If operating outdoors: Avoid direct sunlight, particularly in warm climatic regions. You can order a weather protection cover from Endress+Hauser. →  185. Thermal insulation For optimum temperature measurement and mass calculation, heat transfer at the sensor must be avoided for some fluids. This can be ensured by installing thermal insulation. A wide range of materials can be used for the required insulation.
Page 24: Special Mounting Instructions
Installation Proline Prowirl F 200 PROFIBUS PA A0019212 Maximum insulation height ‣ When insulating, ensure that a sufficiently large area of the housing support remains exposed. The uncovered part serves as a radiator and protects the electronics from overheating and excessive cooling.
Page 25: Mounting The Measuring Device
Proline Prowirl F 200 PROFIBUS PA Installation A0019209  7 Layout for delta heat measurement of saturated steam and water Measuring device Temperature sensor Heat exchanger Heat flow Protective cover Observe the following minimum head clearance: 222 mm (8.74 in) For information on the weather protection cover, see →...
Page 26: Mounting The Transmitter Of The Remote Version
Installation Proline Prowirl F 200 PROFIBUS PA 1. Ensure that the direction of the arrow on the sensor matches the flow direction of the medium. 2. To ensure compliance with device specifications, install the measuring device between the pipe flanges in a way that it is centered in the measurement section.
Page 27: Turning The Transmitter Housing
Proline Prowirl F 200 PROFIBUS PA Installation Post mounting 20 70 … ( 0.79 to 2.75) SW 13 A0033486  9 mm (in) 6.2.5 Turning the transmitter housing To provide easier access to the connection compartment or display module, the transmitter housing can be turned.
Page 28: Post-Installation Check
Installation Proline Prowirl F 200 PROFIBUS PA 3 mm A0032238 1. Loosen the securing clamp of the electronics compartment cover using an Allen key. 2. Unscrew cover of the electronics compartment from the transmitter housing. 3. Optional: pull out the display module with a gentle rotational movement.
Page 29: Electrical Connection
Proline Prowirl F 200 PROFIBUS PA Electrical connection Electrical connection Connection conditions 7.1.1 Required tools • For cable entries: Use corresponding tools • For securing clamp: Allen key 3 mm • Wire stripper • When using stranded cables: Crimper for wire end ferrule •...
Page 30 Electrical connection Proline Prowirl F 200 PROFIBUS PA Oil-resistance According to DIN EN 60811-2-1 Shielding Galvanized copper-braid, opt. density approx.85 % Cable length 5 m (16 ft), 10 m (32 ft), 20 m (65 ft), 30 m (98 ft) Operating temperature When mounted in a fixed position: –50 to +105 °C (–58 to +221 °F);...
Page 31: Terminal Assignment
Proline Prowirl F 200 PROFIBUS PA Electrical connection 7.1.4 Terminal assignment Transmitter Connection version for PROFIBUS PA, pulse/frequency/switch output A0013570 A0018161 Maximum number of terminals Maximum number of terminals for order code for "Accessory mounted", option NA "Overvoltage protection" Output 1: PROFIBUS PA...
Page 32 Electrical connection Proline Prowirl F 200 PROFIBUS PA Experience shows that the best results with regard to EMC are achieved in most cases in installations with one-sided shielding on the feed side (without capacitance termination at the field device). Appropriate measures with regard to input wiring must be taken to allow unrestricted operation when EMC interference is present.
Page 33: Requirements For The Supply Unit
Proline Prowirl F 200 PROFIBUS PA Electrical connection 7.1.7 Requirements for the supply unit Supply voltage Transmitter An external power supply is required for each output. The following supply voltage values apply for the outputs available: Supply voltage for a compact version without a local display Order code for "Output"...
Page 34: Connecting The Measuring Device
Electrical connection Proline Prowirl F 200 PROFIBUS PA Connecting the measuring device NOTICE Limitation of electrical safety due to incorrect connection! ‣ Have electrical connection work carried out by appropriately trained specialists only. ‣ Observe applicable federal/national installation codes and regulations.
Page 35: Connecting The Remote Version
Proline Prowirl F 200 PROFIBUS PA Electrical connection Connection via device plug A0032229 ‣ Plug in the device plug and tighten firmly. Removing a cable 3 (0.12) A0032240 ‣ To remove a cable from the terminal, use a flat-blade screwdriver to push the slot between the two terminal holes while simultaneously pulling the cable end out of the terminal.
Page 36 Electrical connection Proline Prowirl F 200 PROFIBUS PA 3. Connect the transmitter. How the connecting cable is connected in the transmitter housing depends on the measuring device approval and the version of the connecting cable used. In the following versions, only terminals can be used for connection in the transmitter housing: •...
Page 37 Proline Prowirl F 200 PROFIBUS PA Electrical connection 4. Wire the connecting cable:  Terminal 1 = brown cable Terminal 2 = white cable Terminal 3 = yellow cable Terminal 4 = green cable 5. Connect the cable shield via the cable strain relief.
Page 38 Electrical connection Proline Prowirl F 200 PROFIBUS PA Connecting transmitter via terminals 3 mm A0034173 1. Loosen the securing clamp of the electronics compartment cover. 2. Unscrew the electronics compartment cover. 3. Pull out the display module with a gentle rotational movement. To make it easier to access the lock switch, attach the display module to the edge of the electronics compartment.
Page 39 Proline Prowirl F 200 PROFIBUS PA Electrical connection NOTICE The connection board of the wall housing is connected to the electronics board of the transmitter via a signal cable! ‣ Pay attention to the signal cable when lifting the transmitter housing! Lift the transmitter housing.
Page 40: Ensuring Potential Equalization
Electrical connection Proline Prowirl F 200 PROFIBUS PA Connecting cable (option "mass pressure-/temperature-compensated") 8. Disconnect both signal cables from the connection board of the wall housing. by pressing in the locking clip on the connector. Remove the transmitter housing. 9. Guide the connecting cable through the cable entry and into the connection housing (if using a connecting cable without an M12 device plug, use the shorter stripped end of the connecting cable).
Page 41: Post-Connection Check
Proline Prowirl F 200 PROFIBUS PA Electrical connection Post-connection check Are cables or the device undamaged (visual inspection)?  Do the cables used meet the requirements→  29?  Do the mounted cables have adequate strain relief?  Are all cable glands installed, securely tightened and leak-tight? Cable run with "water trap"...
Page 42: Operation Options
Operation options Proline Prowirl F 200 PROFIBUS PA Operation options Overview of operation options A0032227 Local operation via display module Computer with operating tool (e.g. FieldCare, SIMATIC PDM) Control system (e.g. PLC) Endress+Hauser...
Page 43: Structure And Function Of The Operating Menu
Proline Prowirl F 200 PROFIBUS PA Operation options Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: "Description of Device Parameters" document supplied with the device Operating menu for operators and maintenances...
Page 44: Operating Philosophy
Operation options Proline Prowirl F 200 PROFIBUS PA 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (operator, maintenance etc.). Each user role contains typical tasks within the device lifecycle. Menu/parameter User role and tasks...
Page 45: Display
Proline Prowirl F 200 PROFIBUS PA Operation options Access to the operating menu via the local display 8.3.1 Operational display X X X X X X X 1120.50 A0029346 Operational display Device tag→  70 Status area Display area for measured values (4-line) Operating elements→...
Page 46: Navigation View
Operation options Proline Prowirl F 200 PROFIBUS PA Measurement channel numbers Symbol Meaning Measurement channel 1 to 4 The measurement channel number is displayed only if more than one channel is present for the same measured variable type (e.g. Totalizer 1 to 3).
Page 47 Proline Prowirl F 200 PROFIBUS PA Operation options Status area The following appears in the status area of the navigation view in the top right corner: • In the submenu – The direct access code for the parameter you are navigating to (e.g. 0022-1) –...
Page 48: Editing View
Operation options Proline Prowirl F 200 PROFIBUS PA 8.3.3 Editing view Numeric editor Text editor User ABC_ DEFG HIJK LMNO PQRS TUVW A0013999 A0013941 Editing view Display area of the entered values Input mask Operating elements →  49 Input mask...
Page 49: Operating Elements
Proline Prowirl F 200 PROFIBUS PA Operation options Selection of letters from a to z. abc _ … Selection of special characters. "'^ _ … ~& Confirms selection. Switches to the selection of the correction tools. Exits the input without applying the changes.
Page 50: Opening The Context Menu
Operation options Proline Prowirl F 200 PROFIBUS PA Operating key(s) Meaning Enter key For operational display • Pressing the key briefly opens the operating menu. • Pressing the key for 2 s opens the context menu. In a menu, submenu •...
Page 51 Proline Prowirl F 200 PROFIBUS PA Operation options 2. Press  +  simultaneously.  The context menu is closed and the operational display appears. Calling up the menu via the context menu 1. Open the context menu. 2. Press  to navigate to the desired menu.
Page 52: Navigating And Selecting From List
Operation options Proline Prowirl F 200 PROFIBUS PA 8.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus.
Page 53: Calling Up Help Text
Proline Prowirl F 200 PROFIBUS PA Operation options The direct access code consists of a 5-digit number (at maximum) and the channel number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation view, this appears on the right-hand side in the header of the selected parameter.
Page 54: Changing The Parameters
Operation options Proline Prowirl F 200 PROFIBUS PA 8.3.9 Changing the parameters For a description of the editing view - consisting of the text editor and numeric editor - with symbols →  48, for a description of the operating elements →  49 Example: Changing the tag name in the "Tag description"...
Page 55: User Roles And Related Access Authorization
Proline Prowirl F 200 PROFIBUS PA Operation options Ent. access code Invalid or out of range input value Min:0 Max:9999 A0014049-EN 8.3.10 User roles and related access authorization The two user roles "Operator" and "Maintenance" have different write access to the parameters if the customer defines a user-specific access code.
Page 56: Enabling And Disabling The Keypad
Operation options Proline Prowirl F 200 PROFIBUS PA 8.3.12 Enabling and disabling the keypad lock The keypad lock makes it possible to block access to the entire operating menu via local operation. As a result, it is no longer possible to navigate through the operating menu or change the values of individual parameters.
Page 57: Fieldcare
PROFIBUS PA network T-box Measuring device Via service interface (CDI) A0034056 Service interface (CDI = Endress+Hauser Common Data Interface) of the measuring device Commubox FXA291 Computer with FieldCare operating tool with COM DTM CDI Communication FXA291 8.4.2 FieldCare Function scope FDT-based plant asset management tool from Endress+Hauser.
Page 58 Operation options Proline Prowirl F 200 PROFIBUS PA Access is via: • PROFIBUS PA protocol →  56 • CDI service interface →  57 Typical functions: • Configuring parameters of transmitters • Loading and saving device data (upload/download) • Documentation of the measuring point •...
Page 59: Devicecare
DeviceCare Function scope Tool to connect and configure Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. For details, see Innovation Brochure IN01047S Source for device description files See information →...
Page 60: System Integration
System integration Proline Prowirl F 200 PROFIBUS PA System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.01.02 • On the title page of the Operating Instructions • On the transmitter nameplate • Firmware version parameter Diagnostics →...
Page 61: Manufacturer-Specific Gsd
Proline Prowirl F 200 PROFIBUS PA System integration 9.2.1 Manufacturer-specific GSD This GSD guarantees the unrestricted functionality of the measuring device. Device-specific process parameters and functions are therefore available. Manufacturer-specific GSD ID number File name PROFIBUS PA 0x1564 EH3x1564.gsd The fact that the manufacturer-specific GSD should be used is specified in the Ident number selector parameter by selecting the Manufacturer option.
Page 62: Cyclic Data Transmission
System integration Proline Prowirl F 200 PROFIBUS PA Manual setting The manual setting is made in the Ident number selector parameter via the option Prowirl 72 (0x153B) or Prowirl 73 (0x153C). Afterwards, the Prowirl 200 PROFIBUS PA makes the same input and output data and measured status information available for cyclic data exchange.
Page 63: Description Of The Modules
Proline Prowirl F 200 PROFIBUS PA System integration Configuration MODETOT ← Analog Output block 1 →  66 Input values AO ← Discrete Input block 1 to 2 →  67 Output values DI → Discrete Output block 1 to →...
Page 64 System integration Proline Prowirl F 200 PROFIBUS PA Channel Input variable Corrected volume flow Density Pressure Flow velocity Energy flow Calculated saturated steam pressure Total mass flow Steam quality Heat flow difference Reynolds number Specific volume Degree of overheating Factory setting...
Page 65 Proline Prowirl F 200 PROFIBUS PA System integration Channel Input variable Condensate mass flow Heat flow difference Factory setting Function block Factory setting: TOTAL Totalizer 1, 2 and 3 Volume flow Data structure Input data of TOTAL Byte 1 Byte 2...
Page 66 System integration Proline Prowirl F 200 PROFIBUS PA SETTOT_MODETOT_TOTAL module The module combination consists of the SETTOT, MODETOT and TOTAL functions: • SETTOT: Control the totalizers via the PROFIBUS master. • MODETOT: Configure the totalizers via the PROFIBUS master. • TOTAL: Transmit totalizer value, along with the status, to the PROFIBUS master.
Page 67 Proline Prowirl F 200 PROFIBUS PA System integration Assigned compensation values A compensation value is permanently assigned to the individual Analog Output blocks. CHANNEL Function block Compensation value 1507 AO 1 External compensation The compensation values must be transmitted to the device in the SI basic unit The selection is made via: Expert →...
Page 68 System integration Proline Prowirl F 200 PROFIBUS PA DO module (Discrete Output) Transmit discrete output values from the PROFIBUS master (Class 1) to the measuring device. Discrete output values are used by the PROFIBUS master (Class 1) to enable and disable device functions.
Page 69: Commissioning
Proline Prowirl F 200 PROFIBUS PA Commissioning Commissioning 10.1 Function check Before commissioning the measuring device: ‣ Make sure that the post-installation and post-connection checks have been performed. • "Post-installation check" checklist→  28 • "Post-connection check" checklist →  41 10.2...
Page 70: Configuring The Measuring Device
Commissioning Proline Prowirl F 200 PROFIBUS PA 10.4 Configuring the measuring device • The Setup menu with its guided wizards contains all the parameters needed for standard operation. • Navigation to the Setup menu X X X X X X X 20.50...
Page 71 Proline Prowirl F 200 PROFIBUS PA Commissioning XXXXXXXXX A0029422  20 Header of the operational display with tag name Tag name Enter the tag name in the "FieldCare" operating tool →  58 Navigation "Setup" menu → Device tag Parameter overview with brief description...
Page 72: Selecting And Setting The Medium
Commissioning Proline Prowirl F 200 PROFIBUS PA 10.4.2 Selecting and setting the medium The Medium selection wizard systematically guides the user through all the parameters that must be configured in order to select and set the medium. Navigation "Setup" menu → Medium selection ‣...
Page 73: Setting The System Units
Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Fixed process pressure The following conditions are Enter fixed value for process 0 to 250 bar abs. 0 bar abs. met: pressure. • Order code for "Sensor Dependency version",...
Page 74 Commissioning Proline Prowirl F 200 PROFIBUS PA Navigation "Setup" menu → System units ‣ System units →  75 Volume flow unit →  75 Volume unit Mass flow unit →  75 Mass unit →  75 Corrected volume flow unit →...
Page 75 Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection Factory setting Volume flow unit – Select volume flow unit. Unit choose list Country-specific: • m³/h Result • ft³/min The selected unit applies for: •...
Page 76 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter Prerequisite Description Selection Factory setting Energy flow unit With order code for "Sensor Select energy flow unit. Unit choose list Country-specific: version": • kW Result Option "Mass (integrated • Btu/h The selected unit applies for: temperature measurement)"...
Page 77 Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter Prerequisite Description Selection Factory setting Dynamic viscosity unit – Select dynamic viscosity unit. Unit choose list Pa s Result The selected unit applies for: • Dynamic viscosity parameter (gases) • Dynamic viscosity...
Page 78: Configuring The Analog Inputs
Commissioning Proline Prowirl F 200 PROFIBUS PA 10.4.4 Configuring the analog inputs The Analog inputs submenu guides the user systematically to the individual Analog input 1 to n submenu. From here you get to the parameters of the individual analog input.
Page 79: Configuring The Local Display
Proline Prowirl F 200 PROFIBUS PA Commissioning 10.4.5 Configuring the local display The Display wizard guides you systematically through all the parameters that can configured for configuring the local display. Navigation "Setup" menu → Display ‣ Display Format display →  80 Value 1 display →...
Page 80: Interface
Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 81: Configuring The Low Flow Cut Off
Proline Prowirl F 200 PROFIBUS PA Commissioning Navigation "Setup" menu → Communication ‣ Communication →  81 Device address Parameter overview with brief description Parameter Description User entry Factory setting Device address Enter device address. 0 to 126 10.4.7 Configuring the low flow cut off The Low flow cut off wizard systematically guides the user through all the parameters that must be set to configure low flow cut off.
Page 82 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Assign process variable – Select process variable for low • Off flow cut off. • Volume flow • Corrected volume flow •...
Page 83: Advanced Settings
Proline Prowirl F 200 PROFIBUS PA Commissioning 10.5 Advanced settings The Advanced setup submenu together with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu X X X X X X X 20.50 0104-1 Main menu...
Page 84: Setting The Medium Properties
Commissioning Proline Prowirl F 200 PROFIBUS PA ‣ Totalizer 1 to n →  109 ‣ Display →  111 ‣ Heartbeat setup ‣ Configuration backup display →  113 ‣ →  115 Administration 10.5.1 Setting the medium properties In the Medium properties submenu the reference values for the measuring application can be set.
Page 85 Proline Prowirl F 200 PROFIBUS PA Commissioning Dynamic viscosity →  87 ‣ Gas composition →  87 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Enthalpy type The following conditions are Define which kind of enthalpy •...
Page 86 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter Prerequisite Description Selection / User Factory setting entry Reference pressure The following conditions are Enter reference pressure for 0 to 250 bar 1.01325 bar met: the calulation of the reference • Order code for "Sensor density.
Page 87 Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Calorific value The following conditions are Enter gross calorific value to Positive floating- 50 000 kJ/kg met: calculate the energy flow. point number • Selected medium: –...
Page 88 Commissioning Proline Prowirl F 200 PROFIBUS PA Navigation "Setup" menu → Advanced setup → Medium properties → Gas composition ‣ Gas composition →  90 Gas type →  90 Gas mixture Mol% Ar →  91 Mol% C2H3Cl →  91 Mol% C2H4 →...
Page 89 Proline Prowirl F 200 PROFIBUS PA Commissioning Mol% n-C5H12 →  96 Mol% n-C6H14 →  96 Mol% n-C7H16 →  96 Mol% n-C8H18 →  96 Mol% n-C9H20 →  96 Mol% Ne →  97 Mol% NH3 →  97 →...
Page 90 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Gas type The following conditions are Select measured gas type. • Hydrogen H2 Methane CH4 met: • Helium He • In the Select medium •...
Page 91 Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Mol% Ar The following conditions are Enter amount of substance for 0 to 100 % met: the gas mixture. In the Select medium parameter, the Gas option is selected.
Page 92 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter Prerequisite Description Selection / User Factory setting entry Mol% C3H8 The following conditions are Enter amount of substance for 0 to 100 % met: the gas mixture. In the Select medium parameter, the Gas option is selected.
Page 93 Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Mol% CO2 The following conditions are Enter amount of substance for 0 to 100 % met: the gas mixture. In the Select medium parameter, the Gas option is selected.
Page 94 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter Prerequisite Description Selection / User Factory setting entry Mol% HCl The following conditions are Enter amount of substance for 0 to 100 % met: the gas mixture. • In the Select medium parameter, the Gas option is selected.
Page 95 Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Mol% N2 The following conditions are Enter amount of substance for 0 to 100 % met: the gas mixture. In the Select medium parameter, the Gas option is selected.
Page 96 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter Prerequisite Description Selection / User Factory setting entry Mol% n-C5H12 The following conditions are Enter amount of substance for 0 to 100 % met: the gas mixture. • In the Select medium parameter, the Gas option is selected.
Page 97 Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Mol% Ne The following conditions are Enter amount of substance for 0 to 100 % met: the gas mixture. • In the Select medium parameter, the Gas option is selected.
Page 98: Performing External Compensation
Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter Prerequisite Description Selection / User Factory setting entry Mol% other gas The following conditions are Enter amount of substance for 0 to 100 % met: the gas mixture. • In the Select medium parameter, the Gas option is selected.
Page 99 Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry External value With order code for "Sensor Assign variable from external • Off version": device to process variable. • Pressure Option "Mass (integrated •...
Page 100: Carrying Out A Sensor Adjustment
Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter Prerequisite Description Selection / User Factory setting entry Fixed process pressure The following conditions are Enter fixed value for process 0 to 250 bar abs. 0 bar abs. met: pressure. • Order code for "Sensor Dependency version",...
Page 101 Inlet run correction The Inlet Run Correction feature of Endress+Hauser' s measuring device presents an economic method for shortening the inlet run and does not generate any additional pressure loss. The typical systematic errors caused by the pipe component in question are corrected.
Page 102 Commissioning Proline Prowirl F 200 PROFIBUS PA Effect on accuracy of reduced, straight inlet run E [%] E [%] -0.5 -0.5 -1.0 -1.0 10 15 20 25 30 35 40 45 50 10 15 20 25 30 35 40 45 50...
Page 103: Configuring The Pulse/Frequency
Proline Prowirl F 200 PROFIBUS PA Commissioning Example Influence of the diameter mismatch without using the correction function: • Mating pipe DN 100 (4"), schedule 80 • Device flange DN 100 (4"), schedule 40 • This installation position results in a diameter mismatch of 5 mm (0.2 in). If the correction function is not used, an additional measuring uncertainty of approx.
Page 104 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Assign pulse output The Pulse option is selected in Select process variable for • Off Volume flow the Operating mode pulse output.
Page 105 Proline Prowirl F 200 PROFIBUS PA Commissioning Minimum frequency value →  105 Maximum frequency value →  106 Measuring value at minimum →  106 frequency Measuring value at maximum →  106 frequency →  107 Failure mode Failure frequency →...
Page 106 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter Prerequisite Description Selection / User Factory setting entry Maximum frequency value In the Operating mode Enter maximum frequency. 0 to 1 000 Hz 1 000 Hz parameter, the Frequency option is selected, and one of...
Page 107 Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Failure mode In the Operating mode Define output behavior in • Actual value 0 Hz parameter (→  103), the alarm condition. • Defined value Frequency option is selected, •...
Page 108 Commissioning Proline Prowirl F 200 PROFIBUS PA Assign status →  109 Switch-on value →  109 Switch-off value →  109 Switch-on delay →  109 →  109 Switch-off delay Failure mode →  109 Invert output signal →...
Page 109: Configuring The Totalizer
Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Assign status • The Switch option is Select device status for switch • Low flow cut off Low flow cut off selected in the Operating output.
Page 110 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter overview with brief description Parameter Prerequisite Description Selection Factory setting Assign process variable – Select process variable for • Volume flow • Totalizer 1: totalizer. • Mass flow Volume flow • Corrected volume •...
Page 111: Carrying Out Additional Display Configurations
Proline Prowirl F 200 PROFIBUS PA Commissioning 10.5.6 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣...
Page 112 Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 113: Configuration Management
Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Decimal places 3 A measured value is specified Select the number of decimal • x x.xx in the Value 3 display places for the display value.
Page 114 Commissioning Proline Prowirl F 200 PROFIBUS PA You can do so using the Configuration management parameter and the related options found in the Configuration backup display submenu. Navigation "Setup" menu → Advanced setup → Configuration backup display ‣ Configuration backup display Operating time →...
Page 115: Using Parameters For Device Administration
Proline Prowirl F 200 PROFIBUS PA Commissioning Options Description Duplicate The transmitter configuration from another device is duplicated to the device using the display module. Clear backup data The backup copy of the device configuration is deleted from the display module of the device.
Page 116 Commissioning Proline Prowirl F 200 PROFIBUS PA Navigation "Diagnostics" menu → Simulation ‣ Simulation →  117 Assign simulation process variable →  117 Value process variable Frequency simulation →  117 Frequency value →  117 Pulse simulation →  117 Pulse value →...
Page 117 Proline Prowirl F 200 PROFIBUS PA Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Assign simulation process variable – Select a process variable for • Off the simulation process that is • Volume flow activated.
Page 118: Protecting Settings From Unauthorized
Commissioning Proline Prowirl F 200 PROFIBUS PA Parameter Prerequisite Description Selection / User Factory setting entry Switch status In the Switch output Select the status of the status • Open Open simulation parameter output for the simulation. • Closed (→  117) Switch output...
Page 119: Write Protection Via Write Protection
Proline Prowirl F 200 PROFIBUS PA Commissioning Parameters which can always be modified via the local display Certain parameters that do not affect the measurement are excepted from parameter write protection via the local display. Despite the user-specific access code, they can always be modified, even if the other parameters are locked.
Page 120: Application-Specific Commissioning
Commissioning Proline Prowirl F 200 PROFIBUS PA 3. Pull out the display module with a gentle rotational movement. To make it easier to access the write protection switch, attach the display module to the edge of the electronics compartment.  Display module is attached to the edge of the electronics compartment.
Page 121: Liquid Application
Proline Prowirl F 200 PROFIBUS PA Commissioning 2. In the Select medium parameter, select the Steam option. 3. When pressure measured value is read in In the Steam calculation mode parameter, select the Automatic (p-/T- compensated) option. 4. If pressure measured value is not read in: In the Steam calculation mode parameter, select the Saturated steam (T- compensated) option.
Page 122: Gas Applications
Commissioning Proline Prowirl F 200 PROFIBUS PA 10. In the Dynamic viscosity parameter, enter the viscosity of the fluid. 10.8.3 Gas applications For accurate mass or corrected volume measurement, it is recommended to use the pressure-/temperature-compensated sensor version. If this sensor version is not available, read in the pressure via the PA.
Page 123 Proline Prowirl F 200 PROFIBUS PA Commissioning 2. In the Select medium parameter, select the Gas option. 3. In the Select gas type parameter, select the Gas mixture option. Configuring gas composition Navigation: Setup → Advanced setup → Medium properties → Gas composition 4.
Page 124 8. In the Reference temperature parameter (→  86) enter the temperate for calculating the reference density. Endress+Hauser recommends the use of active pressure compensation. This fully rules out the risk of measured errors due to pressure variations and incorrect entries .
Page 125: Calculation Of The Measured
Proline Prowirl F 200 PROFIBUS PA Commissioning flow. The error resulting from this assumption (typically 1 to 5 %) is often considerably smaller than the error caused by inaccurate composition data. This method should not be used for condensing gases (e. g. saturated steam).
Page 126 Commissioning Proline Prowirl F 200 PROFIBUS PA Medium Fluid Standards Explanation AGA NX-19 For fixed process pressure, pressure measured directly at the meter body or if the pressure is read in via PROFIBUS PA ISO 12213-3 • Contains SGERG-88, AGA8 Gross Method 1 •...
Page 127 Proline Prowirl F 200 PROFIBUS PA Commissioning Medium Fluid Standards Explanation Heat/energy option Water IAPWS- – IF97/ASME Liquefied ISO 6976 Contains GPA 2172 Liquids Other Linear – liquid equation The measuring device is capable of calculating the volume flow, and other measured variables derived from the volume flow, across all steam types with full compensation using the pressure and temperature.
Page 128 Commissioning Proline Prowirl F 200 PROFIBUS PA p = Process pressure ρ = Density Pre-programmed gases The following gases are pre-programmed in the flow computer: Hydrogen Helium 4 Neon Argon Krypton Xenon Nitrogen Oxygen Chlorine Ammonia Carbon monoxide Carbon dioxide...
Page 129 Proline Prowirl F 200 PROFIBUS PA Commissioning Steam quality, total mass flow and condensate mass flow The following additional measured variables are available with the Wet Steam Measurement application package: • Steam quality is output as a direct measured value (on local display/PROFIBUS PA) •...
Page 130: Operation
Operation Proline Prowirl F 200 PROFIBUS PA Operation 11.1 Reading the device locking status Device active write protection: Locking status parameter Operation → Locking status Function scope of the "Locking status" parameter Options Description None The access status displayed in the Access status display parameter applies →...
Page 131 Proline Prowirl F 200 PROFIBUS PA Operation Navigation "Diagnostics" menu → Measured values → Process variables ‣ Process variables Volume flow →  132 Corrected volume flow →  132 Mass flow →  132 Flow velocity →  132 Temperature →...
Page 132 Operation Proline Prowirl F 200 PROFIBUS PA Parameter overview with brief description Parameter Prerequisite Description User interface Volume flow – Displays the volume flow currently Signed floating-point measured. number Dependency The unit is taken from the Volume flow unit parameter (→  75).
Page 133: Totalizer
Proline Prowirl F 200 PROFIBUS PA Operation Parameter Prerequisite Description User interface Heat flow difference The following conditions are met: Displays the heat flow difference Signed floating-point • Order code for "Sensor version" currently calculated. number option "Mass (integrated Dependency temperature measurement)"...
Page 134: Output Values
Operation Proline Prowirl F 200 PROFIBUS PA Totalizer status 1 to n →  134 Totalizer status (Hex) 1 to n →  134 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign process variable –...
Page 135: Adapting The Measuring Device To The Process
Proline Prowirl F 200 PROFIBUS PA Operation Parameter overview with brief description Parameter Prerequisite Description User interface Terminal voltage 1 – Displays the current terminal voltage 0.0 to 50.0 V that is applied at the output. Pulse output The Pulse option is selected in the...
Page 136: Showing Data Logging
Operation Proline Prowirl F 200 PROFIBUS PA Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Control Totalizer 1 to n In the Assign process variable Control totalizer value. • Totalize Totalize parameter, one of the • Reset + hold following options is selected: •...
Page 137 Proline Prowirl F 200 PROFIBUS PA Operation Navigation "Diagnostics" menu → Data logging ‣ Data logging Assign channel 1 →  138 Assign channel 2 →  138 Assign channel 3 →  138 Assign channel 4 →  138 Logging interval →...
Page 138 Operation Proline Prowirl F 200 PROFIBUS PA Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Assign channel 1 The Extended HistoROM • Off application package is • Volume flow available. • Corrected volume flow  The software options •...
Page 139 Proline Prowirl F 200 PROFIBUS PA Operation Parameter Prerequisite Description Selection / User Factory setting entry Logging interval The Extended HistoROM Define the logging interval for 1.0 to 3 600.0 s 10.0 s application package is data logging. This value available. defines the time interval between the individual data points in the memory.
Page 140: Diagnostics And Troubleshooting
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting 12.1 General troubleshooting For local display Error Possible causes Solution Local display dark and no output Supply voltage does not match the Apply the correct supply voltage signals value indicated on the nameplate.
Page 141 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting For access Error Possible causes Solution No write access to parameters Hardware write protection enabled Set the write protection switch on main electronics module to the OFF position →  119.
Page 142: Diagnostic Information On Local Display
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA 12.2 Diagnostic information on local display 12.2.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display.
Page 143 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. • For local display with touch control: the background lighting changes to red.
Page 144: Calling Up Remedial Measures
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA 12.2.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage...
Page 145 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Xxxxxx/…/…/ Device name: Xxxxxxx Mass flow: kg/h 12.34 Device tag: Xxxxxxx Volume flow: 12.34 m /h ³ Status signal: Function check (C) Xxxxxx Diagnostics 1: C485 Simu... Remedy information: Deactivate... Failure (F)
Page 146: Calling Up Remedy Information
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Diagnostic code Diagnostic Diagnostic Status signal Short text behavior number ↓ ↓ ↓ Electronics Example modules A0013962 A0013956 NAMUR 3-digit number NE 107 12.3.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly: •...
Page 147 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Available diagnostic behaviors The following diagnostic behaviors can be assigned: Diagnostic behavior Description Alarm The device stops measurement. The totalizers assume the defined alarm condition. A diagnostic message is generated. For local display with touch control: the background lighting changes to red.
Page 148 Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA The diagnostic information is grouped as follows: • Diagnostic information pertaining to the sensor: diagnostic number 000 to 199 →  148 • Diagnostic information pertaining to the electronics: diagnostic number 200 to 399 →...
Page 149: Overview Of Diagnostic Information
Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information pertaining to the process: diagnostic number 800 to 999 Measured value status (fixed assignment) Diagnostic behavior Device diagnosis Quality Coding Category (configurable) (fixed assignment) Quality Substatus (hex) (NE107) Process...
Page 150 Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 022 Temperature sensor defective 1. Check plug connections • Calculated saturated 2. Change pre-amplifier steam pressure Measured variable status [from the factory] 3.
Page 151 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 082 Data storage 1. Change main electronic module • Calculated saturated 2. Change sensor steam pressure Measured variable status • Density • Energy flow Quality •...
Page 152: Diagnostic Of Electronic
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 122 Temperature sensor defective 1. Check plug connections • Calculated saturated 2. Change pre-amplifier steam pressure Measured variable status [from the factory] 3.
Page 153 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 261 Electronic modules 1. Restart device • Calculated saturated 2. Check electronic modules steam pressure Measured variable status 3. Change I/O Modul or main electronics •...
Page 154 Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 271 Main electronic failure 1. Restart device • Calculated saturated 2. Change main electronic module steam pressure Measured variable status • Density •...
Page 155 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 275 I/O module failure Change I/O module • Calculated saturated steam pressure Measured variable status • Density • Energy flow Quality • Flow velocity...
Page 156 Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 282 Data storage 1. Restart device • Calculated saturated 2. Contact service steam pressure Measured variable status • Density • Energy flow Quality •...
Page 157 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 311 Electronic failure 1. Transfer data or reset device • Calculated saturated 2. Contact service steam pressure Measured variable status • Density •...
Page 158 Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 350 Pre-amplifier defective Change pre-amplifier • Calculated saturated steam pressure Measured variable status [from the factory] • Density • Energy flow Quality •...
Page 159: Diagnostic Of Configuration
Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 371 Temperature sensor defective 1. Check plug connections • Calculated saturated 2. Change pre-amplifier steam pressure Measured variable status [from the factory] 3.
Page 160 Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 412 Processing Download Download active, please wait • Calculated saturated steam pressure Measured variable status • Density • Energy flow Quality Uncertain •...
Page 161 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 442 Frequency output 1. Check process – 2. Check frequency output settings Measured variable status [from the factory] Quality Good Quality substatus...
Page 162 Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 453 Flow override Deactivate flow override • Calculated saturated steam pressure Measured variable status • Density • Energy flow Quality Good • Flow velocity...
Page 163 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 485 Simulation measured variable Deactivate simulation • Calculated saturated steam pressure Measured variable status • Density • Energy flow Quality Good • Flow velocity...
Page 164 Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 494 Switch output simulation Deactivate simulation switch output • Calculated saturated steam pressure Measured variable status • Energy flow • Flow velocity...
Page 165 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 539 Flow computer configuration incorrect 1. Check input value (pressure, • Calculated saturated temperature) steam pressure Measured variable status 2. Check allowed values of the medium •...
Page 166: Diagnostic Of Process
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA 12.5.4 Diagnostic of process Diagnostic information Remedy instructions Influenced measured variables Short text 801 Supply voltage too low Increase supply voltage • Calculated saturated steam pressure Measured variable status • Density •...
Page 167: Information
Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 829 Ambient temperature too high Reduce ambient temperature of pre- • Calculated saturated amplifier steam pressure Measured variable status [from the factory] •...
Page 168 Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 833 Electronic temperature too low Increase ambient temperature • Calculated saturated steam pressure Measured variable status [from the factory] • Density • Energy flow...
Page 169: Information
Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 835 Process temperature too low Increase process temperature • Calculated saturated steam pressure Measured variable status [from the factory] • Density • Energy flow...
Page 170: Information
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 842 Process limit Low flow cut off active! • Calculated saturated 1. Check low flow cut off configuration steam pressure Measured variable status •...
Page 171: Information
Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 870 Measuring inaccuracy increased 1. Check process • Calculated saturated 2. Increase flow volume steam pressure Measured variable status [from the factory] •...
Page 172: Information
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 873 Water detected Check process (water in piping) • Calculated saturated steam pressure Measured variable status [from the factory] • Density • Energy flow...
Page 173: Information
Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 945 Sensor range exceeded Check immediately process conditions • Calculated saturated (pressure-temperature rating) steam pressure Measured variable status [from the factory] • Density •...
Page 174: Operating Conditions For Displaying The Following Diagnostics
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Diagnostic information Remedy instructions Influenced measured variables Short text 972 Degrees of superheat limit excceeded 1. Controll process conditions • Calculated saturated 2. Install pressure transmitter or enter steam pressure Measured variable status [from the factory] correct fixed pressure value •...
Page 175: Diagnostic List
Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Navigation "Diagnostics" menu  Diagnostics →  175 Actual diagnostics →  175 Previous diagnostics Operating time from restart →  175 Operating time →  175 Parameter overview with brief description...
Page 176: Event Logbook
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN  23 Taking the example of the local display To call up the measures to rectify a diagnostic event: •...
Page 177: Overview Of Information Events
Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Navigation path Diagnostics → Event logbook → Filter options Filter categories • All • Failure (F) • Function check (C) • Out of specification (S) • Maintenance required (M) • Information (I) 12.8.3...
Page 178: Resetting The Measuring Device
Diagnostics and troubleshooting Proline Prowirl F 200 PROFIBUS PA Info number Info name I1514 Upload started I1515 Upload finished I1552 Failed: Main electronic verification I1553 Failed: Pre-amplifier verification 12.9 Resetting the measuring device Using theDevice reset parameter (→  115) it is possible to reset the entire device configuration or some of the configuration to a defined state.
Page 179 Proline Prowirl F 200 PROFIBUS PA Diagnostics and troubleshooting Extended order code 3 →  179 ENP version →  179 Parameter overview with brief description Parameter Description User interface Factory setting Device tag Shows name of measuring point. Max. 32 characters, such as...
Page 180: 12.11 Firmware History
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: –...
Page 181: Maintenance
3. Dry, clean or replace the seals if necessary. 13.2 Measuring and test equipment Endress+Hauser offers a wide variety of measuring and test equipment, such as W@M or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services.
Page 182: Repairs
• The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory.
Page 183: Endress+Hauser Services
14.3 Endress+Hauser services Endress+Hauser offers a wide range of services. Your Endress+Hauser Sales Center can provide detailed information on the services. 14.4 Return The measuring device must be returned if it is need of repair or a factory calibration, or if the wrong measuring device has been delivered or ordered.
Page 184: Disposing Of The Measuring Device
Repairs Proline Prowirl F 200 PROFIBUS PA 2. Carry out the mounting and connection steps from the "Mounting the measuring device" and "Connecting the measuring device" sections in reverse order. Observe the safety instructions. 14.5.2 Disposing of the measuring device WARNING Danger to personnel and environment from fluids that are hazardous to health.
Page 185: Accessories
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 186: For The Sensor
Accessories Description Applicator Software for selecting and sizing Endress+Hauser measuring devices: • Choice of measuring devices for industrial requirements • Calculation of all the necessary data for identifying the optimum flowmeter: e.g. nominal diameter, pressure loss, flow velocity and accuracy.
Page 187: System Components
 Operating Instructions BA00027S and BA00059S DeviceCare Tool to connect and configure Endress+Hauser field devices.  Innovation brochure IN01047S 15.3 System components...
Page 188: Technical Data
Technical data Proline Prowirl F 200 PROFIBUS PA Technical data 16.1 Application Depending on the version ordered, the measuring device can also measure potentially explosive, flammable, poisonous and oxidizing media. To ensure that the device remains in proper operating condition for its service life, use the measuring device only for media against which the process-wetted materials are sufficiently resistant.
Page 189 Proline Prowirl F 200 PROFIBUS PA Technical data Order code for "Sensor version; DSC sensor; measuring tube" Option Description Measured variable The totalized values for: Volume; Alloy C22; Alloy C22 • Volume flow Volume high-temperature; 316L; 316L • Mass flow •...
Page 190 Technical data Proline Prowirl F 200 PROFIBUS PA Flow measuring ranges in US units Liquids Gas/steam [in] [ft³/min] [ft³/min] ½ 0.045 to 2.9 0.23 to 15 0.14 to 8.8 0.7 to 74 1½ 0.34 to 22 1.7 to 180 0.56 to 36 2.9 to 480...
Page 191 Proline Prowirl F 200 PROFIBUS PA Technical data 4 · Q [m³/s] · [kg/m³] ρ · D [m] · µ [Pa · s] π 4 · Q [ft³/s] · [lbm/ft³] ρ · D [ft] · µ [lbf · s/ft ] ²...
Page 192 Technical data Proline Prowirl F 200 PROFIBUS PA mf [m/s] x² [m/s] = max AmpMin 50 [m] · a [m/s ] ² mf [ /s] x² [ /s] = max AmpMin 164 [ ] · a [ft/s ] ² A0034303...
Page 193 Proline Prowirl F 200 PROFIBUS PA Technical data Flow rate is dependent on the Reynolds number Re = 5000 Minimum measurable flow rate based on signal amplitude AmpMin The Applicator is available for calculation purposes. Upper range value The measuring signal amplitude must be below a certain limit value to ensure that the signals can be evaluated without error.
Page 194 • Operating pressure to increase accuracy (Endress+Hauser recommends the use of a pressure measuring device for absolute pressure, e.g. Cerabar M or Cerabar S) • Medium temperature to increase accuracy (e.g. iTEMP) •...
Page 195: Output
Proline Prowirl F 200 PROFIBUS PA Technical data Digital communication The measured values are written from the automation system to the measuring device via PROFIBUS PA. 16.4 Output Output signal Pulse/frequency/switch output Function Can be set to pulse, frequency or switch output...
Page 196 Technical data Proline Prowirl F 200 PROFIBUS PA Number of switching Unlimited cycles Assignable functions • Off • On • Diagnostic behavior • Limit value – Volume flow – Corrected volume flow – Mass flow – Flow velocity – Temperature –...
Page 197: Power Supply
Proline Prowirl F 200 PROFIBUS PA Technical data Local display Plain text display With information on cause and remedial measures Backlight Additionally for device version with SD03 local display: red lighting indicates a device error. Status signal as per NAMUR recommendation NE 107 Interface/protocol •...
Page 198 Technical data Proline Prowirl F 200 PROFIBUS PA Supply voltage Transmitter An external power supply is required for each output. The following supply voltage values apply for the outputs available: Supply voltage for a compact version without a local display Order code for "Output;...
Page 199: Performance Characteristics
Proline Prowirl F 200 PROFIBUS PA Technical data Cable entries • Cable gland: M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in) • Thread for cable entry: – NPT ½" – G ½" Cable specification →...
Page 200 Technical data Proline Prowirl F 200 PROFIBUS PA A0034077 Reynolds number 5 000 10 000 Reynolds number for minimum permitted volume flow in measuring tube • Standard • Option N "0.65% volume PremiumCal 5-point, extended turndown" [m/s] · · D [m] π...
Page 201 Proline Prowirl F 200 PROFIBUS PA Technical data Temperature • Saturated steam and liquids at room temperature, if T > 100 °C (212 °F): < 1 °C (1.8 °F) • Gas: < 1 % o.r. [K] • Volume flow: 70 m/s (230 ft/s): 2 % o.r.
Page 202 Proline Prowirl F 200 PROFIBUS PA Mass flow (user-specific liquids) To specify the system accuracy, Endress+Hauser requires information about the type of liquid and its operating temperature or information in table form about the dependency between the liquid density and the temperature.
Page 203: Installation
Proline Prowirl F 200 PROFIBUS PA Technical data The repeatability can be improved if the measured volume is increased. Repeatability is not a device characteristic but a statistical variable that is dependent on the boundary conditions indicated. Response time If all the configurable functions for filter times (flow damping, display damping, current...
Page 204: Process
Technical data Proline Prowirl F 200 PROFIBUS PA Vibration resistance Vibration, sinusoidal according to IEC 60068-2-6 • Order code for "Housing", option C "GT20 two-chamber, aluminum, coated, compact", J "GT20 two-chamber, aluminum, coated, remote", K "GT18 two-chamber, 316L, remote" – 2 to 8.4 Hz, 7.5 mm peak –...
Page 205 Proline Prowirl F 200 PROFIBUS PA Technical data Seals Order code for "DSC sensor seal" Option Description Medium temperature range Graphite (standard) –200 to +400 °C (–328 to +752 °F) Viton –15 to +175 °C (+5 to +347 °F) Gylon –200 to +260 °C (–328 to +500 °F)
Page 206: 16.10 Mechanical Construction
Technical data Proline Prowirl F 200 PROFIBUS PA Sensor Maximum sensor measuring range Lower (LRL) Upper (URL) [bar (psi)] [bar (psi)] [bar (psi)] [bar (psi)] 2 bar (30 psi) 0 (0) +2 (+30) 6.7 (100.5) 10 (150) 4 bar (60 psi)
Page 207 Proline Prowirl F 200 PROFIBUS PA Technical data Weight in US units All values (weight) refer to devices with ASME B16.5, Class 300/Sch. 40 flanges. Weight information in [lbs]. Weight [lbs] [in] Order code for "Housing", option C Order code for "Housing", option B "GT20 two-chamber, aluminum, coated, compact"...
Page 208 Technical data Proline Prowirl F 200 PROFIBUS PA Weight [kg] [mm] sensor connection housing sensor connection housing Order code for "Housing", option J Order code for "Housing", option K "GT20 two-chamber, aluminum, coated, remote" "GT18 two-chamber, 316L, remote" 36.1 37.3 71.1...
Page 209 Proline Prowirl F 200 PROFIBUS PA Technical data Pressure rating Weight [mm] [kg] PN 10 to 25 25.7 PN 40 27.5 PN10 to 25 36.4 PN 40 44.7 EN (DIN) Pressure rating Weight [mm] [kg] Class 150 0.03 Class 300 0.04...
Page 210 Technical data Proline Prowirl F 200 PROFIBUS PA Pressure rating Weight [mm] [kg] 15.8 19.1 26.5 Weight in US units Pressure rating Weight [in] [lbs] ½ Class 150 0.07 Class 300 0.09 Class 150 Class 300 1½ Class 150 Class 300...
Page 211 Proline Prowirl F 200 PROFIBUS PA Technical data Cable entries/cable glands A0028352  28 Possible cable entries/cable glands Female thread M20 × 1.5 Cable gland M20 × 1.5 Adapter for cable entry with internal thread G ½" or NPT ½"...
Page 212 Technical data Proline Prowirl F 200 PROFIBUS PA Sensor connection housing The material of the sensor connection housing is dependent on the material selected for the transmitter housing. • Order code for "Housing" option J "GT20 two-chamber, aluminum, coated, remote": Coated aluminum AlSi10Mg •...
Page 213 Proline Prowirl F 200 PROFIBUS PA Technical data Process connections DN 15 to 300 (½ to 12"), pressure ratings PN 10/16/25/40/63/100, Class 150/300/600, as well as JIS 10K/20K: Welding neck flanges DN 15 to 300 (½ to 12") Compliant with:...
Page 214: 16.11 Operability
Technical data Proline Prowirl F 200 PROFIBUS PA The following materials are available depending on the pressure rating: • Stainless steel, multiple certifications, 1.4404/F316/F316L) • Alloy C22/2.4602 List of all available process connections 16.11 Operability Languages Can be operated in the following languages: •...
Page 215: 16.12 Certificates And Approvals
EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. C-Tick symbol The measuring system meets the EMC requirements of the "Australian Communications and Media Authority (ACMA)".
Page 216: 16.13 Application Packages
Such packages might be needed to address safety aspects or specific application requirements. The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your Endress+Hauser...
Page 217: 16.14 Accessories
Proline Prowirl F 200 PROFIBUS PA Technical data local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com. Detailed information on the application packages: Special Documentation for the device 16.14 Accessories Overview of accessories available for order →  185 16.15 Supplementary documentation...
Page 218 Technical data Proline Prowirl F 200 PROFIBUS PA Contents Documentation code NEPSI Ex i XA01644D NEPSI Ex ic, Ex nA XA01645D INMETRO Ex d XA01642D INMETRO Ex i XA01640D INMETRO Ex nA XA01641D EAC Ex d XA01684D EAC Ex nA...
Page 219: Index
Proline Prowirl F 200 PROFIBUS PA Index Index Access authorization to parameters Declaration of Conformity ..... 10 Read access ......55 Define access code .
Page 220 Index Proline Prowirl F 200 PROFIBUS PA Degree of protection ..... . . 40 Measuring device ......29 I/O electronics module .
Page 221 Proline Prowirl F 200 PROFIBUS PA Index Medium temperature range ....204 Menu Packaging disposal ......19 Diagnostics .
Page 222 Index Proline Prowirl F 200 PROFIBUS PA Remote version Storage conditions ......18 Connecting the connecting cable ....35 Storage temperature .
Page 223 Proline Prowirl F 200 PROFIBUS PA Index Tool tip Via write protection switch ....119 see Help text Write protection switch ..... . 119 Tools Electrical connection .
Page 224 www.addresses.endress.com...

Endress+Hauser Proline Prowirl F 200 PROFIBUS PA Operating Instructions Manual

1 About this Document

2 Basic Safety Instructions

3 Product Description

4 Incoming Acceptance and Product

Identification

5 Storage and Transport

6 Installation

7 Electrical Connection

8 Operation Options

9 System Integration

10 Commissioning

11 Operation

12 Diagnostics and Troubleshooting

13 Maintenance

14 Repairs

15 Accessories

16 Technical Data

Index

Quick Links

Related Manuals for Endress+Hauser Proline Prowirl F 200 PROFIBUS PA

Summary of Contents for Endress+Hauser Proline Prowirl F 200 PROFIBUS PA

Table of Contents
