Page 1 HIROSHIMA, JAPAN Important Notes About This Manual Keep this manual in the glove compartment as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Page 2 Illustrations complement the words of the manual to best explain how to enjoy your NOTE Mazda. By reading your manual, you can A NOTE provides information and find out about the features, important sometimes suggests how to make better safety information, and driving under use of your vehicle.
Page 3: Table Of Contents
Table of Contents Pictorial Index Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Before Driving Use of various features, including keys, doors, mirrors and windows.
Page 5: Pictorial Index
Pictorial Index Interior, exterior views and part identification of your Mazda. Interior Overview (Left-Hand Drive Exterior Overview......1-12 Model)..........1-2 Front........... 1-12 Interior Equipment (View A)..1-2 Rear..........1-13 Interior Equipment (View B)..1-3 Interior Equipment (View C)..1-4 Interior Equipment (View D)..1-5 Interior Equipment (View E)..1-6 Interior Overview (Right-Hand Drive Model)..........1-7...
Page 6 ② Turn and lane-change signal..................page 4-94 ③ Audio control switches..................page 5-15 ④ INFO switch..................page 4-22, 4-41, 4-60 ⑤ Mazda Radar Cruise Control (MRCC) switches........page 4-165, 4-178 ⑥ Cruise control switches..................page 4-261 ⑦ Wiper and washer lever..................page 4-95 ⑧ i-stop OFF switch....................page 4-16 ⑨...
Page 7 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View B) ① Instrument panel illumination knob............page 4-26, 4-45, 4-63 ② Active driving display................... page 4-73 ③ Instrument cluster....................page 4-20 ④ Heated steering wheel switch................page 2-23 ⑤ Seat warmer switches.................... page 2-21 ⑥...
Page 8 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View C) ① Head restraint......................page 2-19 ② Seat belt.........................page 2-24 ③ Bottle holder....................... page 5-153 ④ Overhead lights....................page 5-145 ⑤ Overhead console....................page 5-154 ⑥ Sunroof switch...................... page 3-43 ⑦ Vanity mirror.......................page 5-145 ⑧...
Page 9 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View D) ① Seat belt......................... page 2-24 ② Lever......................page 2-15, 2-18 ③ Head restraint......................page 2-19 ④ USB power outlet....................page 5-151 ⑤ Child safety lock....................page 3-17 ⑥ Armrest box......................page 5-154 ⑦...
Page 10 Pictorial Index Interior Overview (Left-Hand Drive Model) Interior Equipment (View E) ① Remote handles..................... page 2-15 ② Anchor brackets....................page 2-46 ③ Luggage compartment cover.................page 3-25 ④ Accessory socket....................page 5-149 ⑤ Cargo sub-compartment..................page 5-155 ⑥ Cargo securing loops..................page 5-155 The equipment and installation position varies by vehicle...
Page 11 ① Wiper and washer lever..................page 4-95 ② Audio control switches..................page 5-15 ③ INFO switch..................page 4-22, 4-41, 4-60 ④ Mazda Radar Cruise Control (MRCC) switches........page 4-165, 4-178 ⑤ Cruise control switches..................page 4-261 ⑥ Lighting control.....................page 4-87 ⑦ Turn and lane-change signal..................page 4-94 ⑧...
Page 12 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View B) ① Glove compartment.....................page 5-154 ② Heated steering wheel switch................page 2-23 ③ Seat warmer switches.................... page 2-21 ④ CD player......................page 5-79 ⑤ DVD player......................page 5-82 ⑥ Hazard warning flasher switch................page 4-102 ⑦...
Page 13 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View C) ① Vent......................... page 5-5 ② Rearview mirror....................page 3-38 ③ Sunvisor......................page 5-145 ④ Overhead lights....................page 5-145 ⑤ Overhead console....................page 5-154 ⑥ Sunroof switch...................... page 3-43 ⑦ Vanity mirror.......................page 5-145 ⑧...
Page 14 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View D) ① Centre console....................page 5-154 ② External input terminal..................page 5-17 ③ Accessory socket....................page 5-149 ④ Rear map lights....................page 5-145 ⑤ Door-lock knob..................... page 3-17 ⑥ Power window switch................... page 3-40 ⑦...
Page 15 Pictorial Index Interior Overview (Right-Hand Drive Model) Interior Equipment (View E) ① Remote handles..................... page 2-15 ② Anchor brackets....................page 2-46 ③ Luggage compartment cover.................page 3-25 ④ Accessory socket....................page 5-149 ⑤ Cargo sub-compartment..................page 5-155 ⑥ Cargo securing loops...................page 5-155 1-11 The equipment and installation position varies by vehicle...
Page 16 Pictorial Index Exterior Overview Front ① Windscreen wiper blades..................page 6-37 ② Sunroof........................page 3-43 ③ Window......................... page 3-40 ④ Fuel-filler flap....................... page 3-34 ⑤ Request switch ......................page 3-11 ⑥ Door........................page 3-10 1-12 The equipment and installation position varies by vehicle...
Page 17 Pictorial Index Exterior Overview Rear ① Rear window wiper blade..................page 6-40 ② Liftgate........................page 3-18 ③ Outside mirror....................... page 3-36 ④ Request switch ......................page 3-11 ⑤ Electric liftgate opener..................page 3-19 1-13 The equipment and installation position varies by vehicle...
Page 18 MEMO 1-14...
Page 19 Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats............ 2-2 SRS Air Bags........2-49 Seat Precautions......2-2 Supplementary Restraint System Front Seat........2-5 (SRS) Precautions.......2-49 Rear Seat........2-15 Supplementary Restraint System Head Restraints......2-19 Components........2-56 How the SRS Air Bags Work..
Page 20: Essential Safety Equipment
The front seats contain air bag components essential to the supplementary restraint system. Such modifications could damage the supplementary restraint system and result in serious injury. Consult an Authorised Mazda Repairer if there is any need to remove or reinstall the front seats.
Page 21 Essential Safety Equipment Seats Do not drive with either front seats reclined: Sitting in a reclined position while the vehicle is moving is dangerous because you do not get the full protection from seat belts. During sudden braking or a collision, you can slide under the lap belt and suffer serious internal injuries.
Page 22 Essential Safety Equipment Seats When inserting your hand under the seat to clean the cabin or pick up something you dropped under the seat, be careful not to hurt yourself. If you contact the moving parts of the seat rail or seat frame, it could result in injury. NOTE When returning a rear seat to its original position, place the seat belt in its normal ...
Page 23: Front Seat
Seats Front Seat ▼ Adjusting the Driver's Seat Using the driving position set up procedure recommended by Mazda allows you to maintain a relaxed posture, drive the vehicle for longer periods without feeling tyred, and make quick operations naturally. Also, you can be assured of a clear view in the forward direction to help you drive more safely and comfortably.
Page 24 Press the rear part of the switch to decrease firmness. Before making adjustments to the driving position recommended by Mazda Before making adjustments, move the steering wheel and seat to their default positions. How to move the steering wheel to its default position...
Page 25 2. Lower the seat to its lowest height. 3. Sit squarely in the seat and rest your back against the seatback. Seat adjustment procedure for the driving position recommended by Mazda Adjusting the seatback angle (reclining) Adjust the seatback to the angle providing a comfortable seated posture.
Page 26 Essential Safety Equipment Seats 1. With your posture slightly slouched, move the seatback forward to the angle where your waist feels slightly cramped. Manual Seat Power Seat 2. Move the seatback backward to a comfortable seated posture without any feeling of cramping in your waist.
Page 27 Essential Safety Equipment Seats 2. With your heel set on the floor, set your right foot on the brake pedal and move the seat forward as far as possible until you feel a slight cramping in your ankle. Manual Seat Power Seat 3.
Page 28 Essential Safety Equipment Seats With the manual seat, if you raise the seat height, the seat moves forward. Adjust the seat forward or back again. Manual Seat Power Seat Adjusting the steering wheel position Adjust the steering wheel to the position where it can be operated easily and the gauges can be viewed easily.
Page 29 Essential Safety Equipment Seats Refer to Height Adjustment on page 2-19. NOTE ▼ Driving Position Memory Lumbar support adjustment cannot be The desired driving position can be called  programmed. up after programming the position. A driving position can be programmed The following driving positions can be ...
Page 30 Essential Safety Equipment Seats To move the driving position to a and a beep sounds when the operation programmed position is finished. 3. Make sure the parking brake is on. (Using a button on the side of the seat) 4. (Automatic transaxle) 1.
Page 31 Essential Safety Equipment Seats ▼ Adjusting the Front Passenger's Seat Power operation Seat Slide (Manual Seat) To move a seat forward or backward, raise the lever and slide the seat to the desired position and release the lever. Make sure the lever returns to its original position and the seat is locked in place by attempting to push it forward and backward.
Page 32 Essential Safety Equipment Seats Make sure the lever returns to its original position and the seatback is locked in place by attempting to push it forward and backward. (Power Seat) To change the seatback angle, press the front or rear side of the reclining switch. Release the switch at the desired position.
Page 33: Rear Seat
Essential Safety Equipment Seats Rear Seat Using remote handle 1. (With rear seat warmer) Turn the rear seat warmer switch off. ▼ Split Folding Refer to Seat Warmer on page 2-21. 2. After checking that the rear seats are By lowering the rear seatbacks the luggage clear, open the liftgate and lower the compartment space can be expanded.
Page 34 Essential Safety Equipment Seats (Folding the left seatback) Make sure there is nobody in the rear seat area before operating (pulling) the remote Be careful when operating the remote handle: handle with the centre seatback folded Not checking the rear seat area for persons down.
Page 35 Essential Safety Equipment Seats 3. After checking that the centre seat is CAUTION clear, open the liftgate and pull the inside remote handle on the left side of Before folding the seatbacks down with the liftgate compartment. the remote handle, make sure there is no cup in a rear cup holder.
Page 36 Essential Safety Equipment Seats 2. Press the seatback rearward and lock it WARNING in place. After returning the seatback to its upright position, make sure it is Always make sure the seat belts are fully securely locked. pulled out from under the seatbacks: ▼...
Page 37: Head Restraints
Essential Safety Equipment Seats The left and right seatbacks of the rear seat Head Restraints can be adjusted separately. Recline the seatback with the lever pulled Your vehicle is equipped with head restraints on all outboard seats and the rear centre seat.
Page 38 Essential Safety Equipment Seats Front outboard seat WARNING Always drive with the head restraints installed when seats are being used and make sure they are properly installed: Driving with the head restraints not installed is dangerous. With no support behind your head, your neck could be seriously injured in a collision.
Page 39: Seat Warmer/Seat Ventilation/Heated Steering Wheel
Essential Safety Equipment Seat Warmer/Seat Ventilation/Heated Steering Wheel Rear Seat Warmer The front/rear seats are electrically heated. The ignition must be switched ON. Press the seat warmer switch while the ignition is switched ON to operate the seat High warmer. The indicator lights turn on to indicate that the seat warmer is operating.
Page 40: Seat Ventilation
Essential Safety Equipment Seat Warmer/Seat Ventilation/Heated Steering Wheel Do not place heavy objects with sharp Seat Ventilation projections on the seat, or insert needles or The seat ventilation uses fans installed in pins into it: the seats to draw air around the seat This could cause the seat to become excessively heated and result in injury from surface and ventilate them.
Page 41: Heated Steering Wheel
Essential Safety Equipment Seat Warmer/Seat Ventilation/Heated Steering Wheel (Vehicles with front seat warmer) Heated Steering Wheel  The seat ventilation cannot be used at the same time as the front seat warmer. The grips on the left and right of the steering wheel can be warmed up.
Page 42: Seat Belt Systems
A damaged seat belt cannot provide adequate protection in a collision. Have an expert repairer, we recommend an Authorised Mazda Repairer inspect all seat belt systems in use during an accident before they are used again.
Page 43 Essential Safety Equipment Seat Belt Systems Positioning the Shoulder Portion of the Seat Belt: Improper positioning of the shoulder portion of the seat belt is dangerous. Always make sure the shoulder portion of the seat belt is positioned across your shoulder and near your neck, but never under your arm, on your neck, or on your upper arm.
Page 44 Essential Safety Equipment Seat Belt Systems CAUTION Belt retraction may become difficult if the belts and rings are soiled, so try to keep them clean. For more details about cleaning the seat belts, refer to "Seat Belt Maintenance" (page 6-70). Ring ▼...
Page 45: Seat Belt
If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting properly, have it inspected at an expert repairer, we recommend an Take up Authorised Mazda Repairer. Keep low slack on hip bone ▼ Front Shoulder Belt Adjuster...
Page 46: Seat Belt Warning Systems
Essential Safety Equipment Seat Belt Systems Seat Belt Warning Systems Seat Belt Pretensioner and Load Limiting Systems If it detects that the occupant seat belt is unfastened, the warning light or beep For optimum protection, the front seat alerts the occupant. belts and rear outboard seat belts Refer to Taking Action on page 7-54.
Page 47 2-66). expended: Always have an expert repairer, we Load limiter: recommend an Authorised Mazda Repairer The load limiting system releases belt immediately inspect the seat belt webbing in a controlled manner to reduce pretensioners and air bags after any belt force on the occupant's chest.
Page 48 Essential Safety Equipment Seat Belt Systems NOTE The pretensioner system may not  operate depending on the type of the collision. For details, refer to the SRS Air Bag Deployment Criteria (page 2-62). Some smoke (non-toxic gas) will be  released when the air bags and pretensioners deploy.
Page 49: Child Restraint
OFF indicator light illuminates. Even if the front passenger air bag is shut off, Mazda strongly recommends that children be properly restrained and child-restraint systems of all kinds are properly secured on the rear seats which are the best place for children.
Page 50 Essential Safety Equipment Child Restraint WARNING Use the correct size child-restraint system: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size. If not, the child could be seriously injured or even killed in an accident.
Page 51 Essential Safety Equipment Child Restraint Even in a moderate collision, the child-restraint system can be hit by a deploying air bag and moved violently backward resulting in serious injury or death to the child. (Taiwan, except front passenger seat, if equipped with the following label) NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
Page 52 Essential Safety Equipment Child Restraint Luggage or other items are placed on the seat with the child in the child-restraint system. A rear passenger or luggage pushing or pulling down on the front passenger seatback. Luggage or other items are placed on the seatback or hung on the head restraint. The seat is washed.
Page 53 To avoid burning yourself or a child, check them before you or your child touches them. NOTE Your Mazda is equipped with ISOFIX anchors for attachment of ISOFIX child-restraint systems on the rear seats. When using these anchors to secure a child-restraint system, refer to “Using ISOFIX Anchor” (page 2-47).
Page 54: Child-Restraint System Installation
Essential Safety Equipment Child Restraint Child-Restraint System Installation ▼ Categories of Child-Restraint Systems NOTE When purchasing, ask the manufacturer of the child-restraint system which type of child-restraint system is appropriate for your child and vehicle. (Europe and countries conforming to the UN-R 44 and UN-R 129 regulation) Child-restraint systems are classified into the following 5 groups according to the UN-R 44 regulation.
Page 55 Essential Safety Equipment Child Restraint Due to variations in the design of Child seat  child-restraint systems, vehicle seats Equal to Group 1 of the UN-R 44 and and seat belts, all child-restraint systems UN-R 129 regulation. may not fit all seating positions. Before (Europe) purchasing a child-restraint system, it Recommended child-restraint system:...
Page 56 Essential Safety Equipment Child Restraint ▼ Baby Seat Installation Position The child-restraint system can be hit by the deploying air bag and knocked out of A baby seat is used in the rear-facing position. A child in the child-restraint position only. system could be seriously injured or killed.
Page 57 Essential Safety Equipment Child Restraint Never use a rear-facing child-restraint Do not install a front-facing child-restraint system on the front passenger seat system on the front passenger seat unless it protected by an air bag: is unavoidable: NEVER use a rearward facing child restraint In a collision, the force of a deploying air on a seat protected by an ACTIVE AIRBAG in bag could cause serious injury or death to...
Page 58 Essential Safety Equipment Child Restraint Refer to the table, “Child-Restraint System Suitability for Various Seat Positions” for junior seat installation position (page 2-41). WARNING Always install a junior seat in the correct seat position: Installing a junior seat without first consulting the table “Child-Restraint System Suitability for Various Seat Positions”...
Page 59: Child-Restraint System Suitability For Various Seat Positions Table
Essential Safety Equipment Child Restraint Child-Restraint System Suitability for Various Seat Positions Table (Europe and countries conforming to the UN-R 16 regulation) Provided information in the table shows your child-restraint system suitability for various seating position. For installation suitability of other manufacturer child-restraint system, carefully consult the manufacturer's instructions which accompany the child-restraint system.
Page 60 Essential Safety Equipment Child Restraint Except Taiwan Passenger Seating position Rear (Left) Rear (Centre) Rear (Right) Airbag de-acti- Airbag activated vated Seating position suitable for uni- Yes (U) Yes (U) versal belted (Yes/No) i-Size seating po- Yes (i-U) Yes (i-U) sition (Yes/No) Largest suitable rearward facing...
Page 61 No = Child-restraint system cannot be secured on the seat, or there is no fixture. X = Child-restraint system cannot be installed. A Mazda genuine child-restraint system can be installed. Regarding child-restraint systems which can be installed, refer to the accessories catalog.
Page 62 IL = suitable for particular ISOFIX child-restraint systems (CRS). These ISOFIX CRS are those of the “specific vehicle”, “restricted” or “semi-universal” categories. A Mazda genuine child-restraint system can be installed. Regarding child-restraint systems which can be installed, refer to the accessories catalog.
Page 63 Key of letters to be inserted in the above table: U = Suitable for “universal” category restraints approved for use in this mass group. L = A Mazda genuine child-restraint system can be installed. Regarding child-restraint systems which can be installed, refer to the accessories catalog.
Page 64: Installing Child-Restraint Systems
Essential Safety Equipment Child Restraint Installing Child-Restraint Always remove the head restraint and install child-restraint system: Systems Installing a child-restraint system without removing the head restraint is dangerous. ▼ Anchor Bracket The child-restraint system cannot be installed correctly which may result in Anchor brackets for securing death or injury to the child in a collision.
Page 65 Essential Safety Equipment Child Restraint ▼ Using ISOFIX Anchor Make sure there are no seat belts or foreign objects near or around the ISOFIX anchor-secured child-restraint system: WARNING Not following the child-restraint system manufacturer's instructions when Follow the manufacturer's instructions for installing the child-restraint system is the use of the child-restraint system: dangerous.
Page 66 Essential Safety Equipment Child Restraint 4. Expand the seams on the rear of the WARNING seat bottom slightly to verify the locations of the ISOFIX anchor. Always attach the tether strap to the correct tether anchor position: Type A Type B Attaching the tether strap to the incorrect tether anchor position is dangerous.
Page 67: Srs Air Bags
Essential Safety Equipment SRS Air Bags Supplementary Restraint System (SRS) Precautions The front and side supplementary restraint systems (SRS) include different types of air bags. Please verify the different types of air bags which are equipped on your vehicle by locating the “SRS AIRBAG”...
Page 68 Essential Safety Equipment SRS Air Bags If your vehicle is also equipped with a front passenger occupant classification system, refer to the Front Passenger Occupant Classification System (page 2-66) for details. If your vehicle is equipped with a front passenger occupant classification system, the front passenger air bag deactivation indicator light illuminates for a specified time after the ignition is switched ON.
Page 69 Essential Safety Equipment SRS Air Bags Extreme Hazard! Never use a rear-facing child-restraint system on the front passenger seat with an air bag that could deploy: NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
Page 70 Essential Safety Equipment SRS Air Bags Do not attach objects on or around the area where a side air bag deploys: Attaching objects to the front seat in such a way as to cover the outboard side of the seat in any way is dangerous.
Page 71 Do not use tyres or wheels other than those specified for your Mazda: Use of any tyre or wheel other than those specified for your Mazda (page 9-10) is dangerous. Use of such wheels will prevent the vehicle's accident detections system from accurately detecting a collision or roll-over accident resulting in incorrect or unexpected air bag deployment and the possibility of serious injuries.
Page 72 Neither is likely to cause injury, however, the texture of the air bags may cause light skin injuries on body parts not covered with clothing through friction. Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and ...
Page 73 Essential Safety Equipment SRS Air Bags This highly-visible label warns against the use of a rear-facing child-restraint system on  the front passenger seat. (Except Taiwan) (Taiwan) (Taiwan, except front passenger seat, if equipped with the following label) The highly-visible labels warn against the use of a rear-facing child-restraint system on the seat protected by an air bag.
Page 74: Supplementary Restraint System Components
Essential Safety Equipment SRS Air Bags Supplementary Restraint System Components (With Front Passenger Occupant Classification System) 2-56...
Page 75 Essential Safety Equipment SRS Air Bags (Without Front Passenger Occupant Classification System) Driver/Front passenger inflators and air bags Roll-over sensor , crash sensors, and diagnostic module (SAS unit) Seat belt pretensioners (page 2-28) Front air bag sensors Side crash sensors Air bag/seat belt pretensioner system warning light (page 7-45) Side and curtain inflators and air bags Front passenger air bag deactivation indicator light...
Page 76: How The Srs Air Bags Work
SRS Air Bags How the SRS Air Bags Work Your Mazda is equipped with the following types of SRS air bags. SRS air bags are designed to work together with the seat belts to help to reduce injuries during an accident.
Page 77 Essential Safety Equipment SRS Air Bags During an impact of moderate severity, the driver's air bag deploys with lesser energy, whereas during more severe impacts and when the driver's seat is behind the reference position, it deploys with more energy. ▼...
Page 78 Essential Safety Equipment SRS Air Bags (With Front Passenger Occupant Classification System) In addition, the front passenger side air bag is designed to only deploy when the front passenger occupant classification sensor detects a passenger sitting on the front passenger's seat.
Page 79 ▼ Warning Light/Beep A system malfunction or operation conditions are indicated by a warning. Refer to Contact Authorised Mazda Repairer and Have Vehicle Inspected on page 7-45. Refer to Warning Sound is Activated on page 7-63. 2-61...
Page 80: Srs Air Bag Deployment Criteria
Essential Safety Equipment SRS Air Bags SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision. (The illustrations are the representative cases of collisions.) Types of collision A severe side colli- A roll-over/near A severe frontal/near frontal colli- A rear collision...
Page 81 Essential Safety Equipment SRS Air Bags NOTE In a frontal offset collision, the equipped air bags and pretensioners may all deploy depending on the direction, angle, and rate of impact. 2-63...
Page 82: Limitations To Srs Air Bag
Essential Safety Equipment SRS Air Bags Limitations to SRS Air Bag In severe collisions such as those described previously in "SRS Air Bag Deployment Criteria", the applicable SRS air bag equipment will deploy. However, in some accidents, the equipment may not deploy depending on the type of collision and its severity. Limitations to front/near front collision detection: The following illustrations are examples of front/near front collisions that may not be detected as severe enough to deploy the SRS air bag equipment.
Page 83 Essential Safety Equipment SRS Air Bags Limitations to side collision detection: The following illustrations are examples of side collisions that may not be detected as severe enough to deploy the SRS air bag equipment. Side impacts involving trees or poles Side impacts with two-wheeled vehicles Roll-over (Without roll-over sensor) (With roll-over sensor)
Page 84: Front Passenger Occupant Classification System
Essential Safety Equipment SRS Air Bags Front Passenger Occupant Classification System First, please read "Supplementary Restraint System (SRS) Precautions" (page 2-49) carefully. ▼ Front Passenger Occupant Classification Sensor Your vehicle is equipped with a front passenger occupant classification sensor as a part of the supplementary restraint system.
Page 85 Authorised Mazda Repairer as soon as possible. The system may not work properly in an accident.
Page 86 Essential Safety Equipment SRS Air Bags Under the following conditions, the front passenger occupant classification sensor cannot detect a passenger sitting on the front passenger's seat correctly and the deployment/ non-deployment of the air bags cannot be controlled as indicated in the front passenger air bag deactivation indicator light on/off condition chart.
Page 87 Then, if the front passenger air bag deactivation OFF indicator light still does not turn on, install the child-restraint system on the rear seat and consult an Authorised Mazda Repairer as soon as possible.
Page 88 OFF indicator light remains turned on, move the passenger to the rear seat. If sitting in the rear seat is not possible, slide the front passenger seat as far back as possible. Consult an Authorised Mazda Repairer as soon as possible.
Page 89: Constant Monitoring
Essential Safety Equipment SRS Air Bags Constant Monitoring The following components of the air bag systems are monitored by a diagnostic system: Front air bag sensors  Crash sensors, and diagnostic module (SAS unit)  Side crash sensors  Air bag modules ...
Page 90 MEMO 2-72...
Page 91 Before Driving Use of various features, including keys, doors, mirrors and windows. Keys............ 3-2 Security System....... 3-46 Keys..........3-2 Modification and Add-On Keyless Entry System....3-3 Equipment........3-46 Immobilizer System....3-46 Theft-Deterrent System .....3-48 Advanced Keyless Entry System..........3-8 Advanced Keyless Entry System ..Driving Tips........3-52 ............
Page 92: Before Driving
If your key (auxiliary key) is lost, consult The key is carried with communication your Authorised Mazda Repairer and have your code number ready. devices such as cellular phones. The key contacts or is covered by a NOTE metal object.
Page 93: Keyless Entry System
Authorised Mazda Repairer, according to the indication. KEY Warning Light (Red)  Refer to Contact Authorised Mazda Repairer and Have Vehicle Inspected on page 7-45.
Page 94 If your key is lost or stolen, consult an Additional keys can be obtained at an  Authorised Mazda Repairer as soon as Authorised Mazda Repairer. Up to 6 possible for a replacement and to make the keys can be used with the keyless lost or stolen key inoperative.
Page 95 Before Driving Keys The volume of the beep sound can also (With the advanced keyless function be changed. (Except European models)) Refer to Personalisation Features on A beep sound will be heard once. page 9-13. Use the following procedure to change the setting.
Page 96 Before Driving Keys Unlock button The hazard warning lights flash twice and the liftgate opens/closes after the beep To unlock the doors and the liftgate, press sounds. the unlock button and the hazard warning Type A Type B lights will flash twice. (With the advanced keyless function (Except European models)) A beep sound will be heard twice.
Page 97 Before Driving Keys The luggage compartment is out of the To restore the functions, press the unlock  assured operational range, however, if button on the functions-suspended key in the key (transmitter) is operable the the vehicle. engine will start. With the advanced keyless function Interior aerial Operational range...
Page 98: Advanced Keyless Entry
Authorised Before using the key near people who use Mazda Repairer for details. If the medical devices, ask the medical device advanced keyless entry system has been manufacturer or your physician if radio deactivated, you can start the engine by waves from the key will affect the device.
Page 99: Operational Range
Before Driving Advanced Keyless Entry System NOTE Operational Range The system may not operate if you are  The system operates only when the driver too close to the windows or door is in the vehicle or within operational handles, or liftgate. range while the key is being carried.
Page 100: Doors And Locks
Before Driving Doors and Locks Door Locks Always confirm the safety around the vehicle before opening a door and the liftgate: WARNING Suddenly opening a door and the liftgate is dangerous. A passing vehicle or a pedestrian could be hit and cause an Always take all children and pets with you accident.
Page 101 Before Driving Doors and Locks The vehicle lock-out prevention feature ▼ Locking, Unlocking with Request  prevents you from locking yourself out Switch (With the advanced keyless of the vehicle. function) (European models) All doors and the liftgate can be locked/ All doors and the liftgate will unlocked by pressing the request switch on automatically unlock if they are locked...
Page 102 Before Driving Doors and Locks To unlock 2. Open the driver's door. 3. Within 30 seconds of opening the To unlock the doors and the liftgate, press driver's door, press and hold the the request switch on a front door and the LOCK button on the key for 5 hazard warning lights will flash twice.
Page 103 Before Driving Doors and Locks (Walk-away auto lock function) ▼ Locking, Unlocking with A beep sound is heard when all doors Transmitter and the liftgate are closed while the All doors and the liftgate can be locked/ advanced key is being carried. All doors unlocked by operating the keyless entry and the liftgate are locked automatically system transmitter, refer to Keyless Entry...
Page 104 If this an Authorised Mazda Repairer. For details consult an expert repairer, we recommend an occurs, start the procedure from the Authorised Mazda Repairer. Refer to beginning.
Page 105 Before Driving Doors and Locks 3. Press and hold the lock side of the (Automatic transaxle vehicles) door-lock switch within 20 seconds of Current Function Number switching the ignition ON, and make Press unlock side of sure a beep sound is heard about eight lock switch once seconds afterwards.
Page 106 If you have any problems with the double You can also activate the system by locking system, consult an expert repairer,  pressing the lock button on the we recommend an Authorised Mazda transmitter twice within 3 seconds. Repairer. (With the advanced keyless ...
Page 107 Before Driving Doors and Locks How to Deactivate the System This does not operate the other door locks. Unlock the driver's door or switch the Door-lock knob ignition ON. NOTE If the power supply is interrupted (fuse blows or the battery is disconnected), the system can only be deactivated by unlocking a door with the auxiliary key.
Page 108: Liftgate
Before Driving Doors and Locks The door can only be opened by pulling Liftgate the outside handle. WARNING Unlock Never allow a person to ride in the luggage compartment: Allowing a person to ride in the luggage Lock compartment is dangerous. The person in the luggage compartment could be seriously injured or killed during sudden braking or a collision.
Page 109 Do not modify or replace the liftgate is pressed. damper stay. Consult an expert repairer, The liftgate can be closed when the we recommend an Authorised Mazda  doors are locked with the key left in the Repairer if a liftgate damper stay is vehicle.
Page 110 Before Driving Doors and Locks When the liftgate latch is released by NOTE  Confirm that the liftgate is securely closed. pressing the electric liftgate opener, the liftgate raises slightly. If the liftgate is The liftgate, move it without pressing the electric liftgate opener to verify that the not operated for a certain period of liftgate has not been left ajar.
Page 111 Before Driving Doors and Locks NOTE Never allow children to operate the power liftgate system: Do not apply unnecessary force to the  Allowing children to operate the power power liftgate when it is opening/closing liftgate switch and the keyless entry system electrically.
Page 112 Before Driving Doors and Locks NOTE (Automatic transaxle)  The ignition is switched OFF, or the When the ignition is switched ON, the  selector lever is in P with the ignition transmitter does not operate. switched ON. When opening the liftgate by pressing ...
Page 113 Before Driving Doors and Locks Operation from the driver's seat (To Operation from outside (To close) open/close) Press the power liftgate close switch while Press the power liftgate switch for about the liftgate is fully opened. The hazard one second or longer while the liftgate is warning lights flash twice and the liftgate in the fully closed/open position.
Page 114 Before Driving Doors and Locks NOTE WARNING Set the desired fully-open position of the liftgate at the position where it is open Always check the area around the power more than halfway. The position where it liftgate before opening/closing it: is less than halfway open cannot be set.
Page 115 Before Driving Doors and Locks NOTE ▼ Luggage Compartment Cover The jam-safe equipment does not activate Luggage Compartment Cover during easy closure operation when the power liftgate is between the near-shut Use the luggage compartment cover to position and fully closed position. conceal cargo or luggage.
Page 116 Before Driving Doors and Locks When opening/closing the liftgate, the 4. Remove the luggage compartment  weight of the liftgate is different cover from the vehicle at an angle. depending on whether the luggage compartment cover is used or not, however, this does not indicate a malfunction.
Page 117 Before Driving Doors and Locks 3. Remove the sideboards on both sides of the luggage compartment using the straps. Strap Side board 4. Store the luggage compartment cover with the tab facing downward. 5. Close the luggage board. 6. Return the sideboards and close the luggage board.
Page 118: Fuel And Emission
Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED FUEL, which will reduce exhaust emissions and keep spark plug fouling to a minimum. Your Mazda will perform best with fuel listed in the table. Research Octane Num- Fuel...
Page 119 Authorised Mazda Dealer. If a deposit cleaner other than the Mazda genuine product is used, it could result in damage to the fuel system or the engine internally; therefore use only the Mazda genuine product.
Page 120 Never add fuel system additives. Otherwise, the emission control system could be damaged. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details. NOTE When refuelling, always add at least 10 L (2.6 US gal, 2.2 Imp gal) of fuel.
Page 121 Either condition will damage the converter and cause poor performance. USE ONLY UNLEADED FUEL. Do not drive your Mazda with any sign of engine malfunction. Do not coast with the ignition switched off. Do not descend steep grades in gear with the ignition switched off.
Page 122 Authorised Mazda Repairer. CAUTION ® Use a Mazda genuine product or a product conforming to ISO22241-1 for AdBlue . If ® incompatible AdBlue is used, the SCR system may not operate normally. In addition, the use ®...
Page 123 When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside the vehicle, keep all windows fully open and contact an expert repairer, we recommend an Authorised Mazda Repairer immediately. Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous.
Page 124: Fuel-Filler Flap And Cap
Before Driving Fuel and Emission Fuel-Filler Flap and Cap CAUTION Always use only a designated Mazda WARNING fuel-filler cap or an approved equivalent, available at an expert repairer, we When removing the fuel-filler cap, loosen recommend an Authorised Mazda the cap slightly and wait for any hissing to Repairer.
Page 125 Before Driving Fuel and Emission 3. Attach the removed cap to the inner side of the fuel-filler flap. Fuel-filler flap Fuel-filler cap 4. Insert the refuelling nozzle all the way and begin refuelling. Pull out the refuelling nozzle after the refuelling stops automatically.
Page 126: Mirrors
Before Driving Mirrors The perceived distance of objects in the Mirrors  outer and inner regions of the wide Before driving, adjust the inside and angle mirror is different. Objects outside mirrors. appearing in the outer region are actually further away than they are in ▼...
Page 127 Before Driving Mirrors Manual folding outside mirror The ignition must be switched to ACC or ON position. Fold the outside mirror rearward until it is Type A flush with the vehicle. To fold, rotate the outside mirror switch. To return the mirror to the driving position, rotate the switch to the centre position.
Page 128 Before Driving Mirrors Rearview mirror adjustment Automatic folding function Before driving, adjust the rearview mirror The automatic folding function operates to centre on the scene through the rear when the ignition is switched to ACC or window. OFF. When the outside mirror automatic folding switch is pressed to the AUTO position (neutral position), the outside mirrors automatically fold in and out when the...
Page 129 Before Driving Mirrors To reactivate the auto-dimming function, The auto-dimming function is cancelled  press the ON/OFF button ( ). The when the ignition is switched ON and indicator light will illuminate. the shift/selector lever is in the R position. Indicator light ON/OFF button NOTE...
Page 130: Windows
Before Driving Windows Power Windows The windows can be opened/closed by operating the power window switches. WARNING Make sure the opening is clear before closing a window: Closing a power window is dangerous. A person's hands, head, or even neck could be caught by the window and result in serious injury or even death.
Page 131 Before Driving Windows The front passenger's side and rear windows can be opened/closed when the power window lock switch on the driver's door is in the unlock position. Keep this switch in the locked position while children are in the vehicle. Master control switches Front passenger's window switch...
Page 132 Before Driving Windows ▼ Auto-opening/Closing After the system has been re-initialized, each passenger window can be fully To fully open the window automatically, opened or closed automatically using the press the switch completely down, then master control switches. release. The window will fully open ▼...
Page 133: Sunroof
Before leaving the vehicle or washing  hands, head or neck becomes caught by your Mazda, make sure the sunroof is the sunroof. completely closed so that water does not get inside the cabin area.
Page 134 Before Driving Windows Tilt Operation When the sunroof is already tilted open and you want to slide it open, first close The rear of the sunroof can be tilted open the sunroof and then do a slide operation. to provide more ventilation. Open To fully tilt automatically, momentarily press the tilt/slide switch.
Page 135 Before Driving Windows In the event the jam-safe function  activates and the sunroof cannot be closed automatically, press the tilt/slide switch and the sunroof will close. The jam-safe sunroof function does not  operate until the system has been reset. ▼...
Page 136: Security System
Immobilizer System Equipment The immobilizer system allows the engine to start only with a key the system Mazda cannot guarantee the immobilizer recognises. and the theft-deterrent systems' operation if the system has been modified or if any If someone attempts to start the engine add-on equipment has been installed.
Page 137 Authorised Mazda Repairer as soon as is switched ON with the correct possible. programmed key. The security indicator If you lose a key, an Authorised Mazda  light illuminates for about 3 seconds and Repairer will reset the electronic codes then turns off.
Page 138: Theft-Deterrent System
Theft-Deterrent System intrusion sensor or the intrusion sensor If the theft-deterrent system detects an bezel. Do not install seats that are not Mazda inappropriate entry into the vehicle or the intrusion sensor detects movement in the genuine products. To prevent obstruction of intrusion...
Page 139 Before Driving Security System Opening the bonnet by operating the ▼ How to Arm the System  bonnet release handle. 1. Close the windows and the sunroof Switching the ignition ON without using  securely. the push button start. (With the intrusion sensor) NOTE ...
Page 140 Before Driving Security System NOTE hook, or placing other items which can move easily inside the vehicle. The theft-deterrent system can also  Parking in an area where there is strong  be armed by activating the auto vibration or loud noise. relock function with all the doors, When using a high pressure or ...
Page 141 Before Driving Security System ▼ To Turn Off an Armed System An armed system can be turned off using any one of the following methods: Pressing the unlock button on the  transmitter. Starting the engine with the push button ...
Page 142: Driving Tips
Environment No special running-in is necessary, but a few precautions in the first 1,000 km (600 How you operate your Mazda determines miles) may add to the performance, how far it will travel on a tank of fuel. Use economy, and life of the vehicle.
Page 143: Hazardous Driving
Before Driving Driving Tips Avoid sudden braking and sudden Hazardous Driving  manoeuvring. Do not pump the brakes. Continue to  WARNING press down on the brake pedal. Refer to Antilock Brake System (ABS) on page 4-115. Be extremely careful if it is necessary to If you get stuck, select a lower gear and downshift on slippery surfaces: ...
Page 144: Floor Mat
We recommend the use of Genuine If using an all-weather mat for winter use Mazda floor mats. always remove the original floor mat. WARNING Make sure the floor mats are secured with...
Page 145: Rocking The Vehicle
Do not spin the wheels at high speed, and Ask an expert repairer, we recommend an do not allow anyone to stand behind a Authorised Mazda Repairer to check the wheel when pushing the vehicle: following: When the vehicle is stuck, spinning the wheels at high speed is dangerous.
Page 146 Before Driving Driving Tips Drive slowly. Braking performance can ▼ Tyre Chains  be adversely affected if snow or ice Check local regulations before using tyre adheres to the brake components. If this chains. situation occurs, drive the vehicle slowly, releasing the accelerator pedal CAUTION and lightly applying the brakes several times until the brake performance...
Page 147 Before Driving Driving Tips Tyre chain selection (Europe) Installing the chains Mazda recommends hexagon type steel 1. Secure the chains on the front tyres as ring chains. Select the proper type tightly as possible. Always follow the according to your tyre size.
Page 148: Driving In Flooded Area
Do not drive the vehicle on flooded roads as it could cause short circuiting of electrical/electronic parts, or engine damage or stalling from water absorption. If the vehicle has been immersed in water, consult an expert repairer, we recommend an Authorised Mazda Repairer. 3-58...
Page 149: Turbocharger Information (Skyactiv-G 2.5T, Skyactiv-D 2.2)
Before Driving Driving Tips Turbocharger Information (SKYACTIV-G 2.5T, SKYACTIV-D 2.2) CAUTION After driving at freeway speeds or up a long hill, trailer towing for a long time, idle the engine at least 30 seconds before stopping it. Otherwise, the turbocharger could be damaged.
Page 150: Towing
Never overload vehicle or trailer. Consult an Authorised Mazda Dealer if you need further details. CAUTION Do not tow a trailer during the first 1,000 km (600 miles) of your new Mazda. If you do, you may damage the engine, transaxle, differential, wheel bearings, and other power train components.
Page 151 Before Driving Towing TRAILER NOSE WEIGHT: The weight exerted on the trailer tongue. It is varied by changing the weight distribution when loading the trailer. CAUTION Be aware of the towing load weight differences when towing at high altitudes. For altitudes exceeding 1,000 meter (3,280 ft 10 in), always reduce the towing load by 10% for every 1,000 meter (3,280 ft 10 in) increase in altitude from the load indicated under the gross combination weight heading in the maximum trailer towing-load table.
Page 152 Before Driving Towing GROSS COMBI- MODEL TOTAL TRAILER WEIGHT NATION WEIGHT Emission Drive Trailer without Trailer with Trailer with Engine Transaxle level system brake brake brake SKYACTIV-D 2.2 Manual trans- 750 kg (1,653.4 2,000 kg 4,220 kg (9,303.4 STANDARD EURO6 axle (4,409.2 lb) POWER...
Page 153 Before Driving Towing GROSS COMBINA- MODEL TOTAL TRAILER WEIGHT TION WEIGHT Emis- Drive Trailer without Trailer with Engine Transaxle sion Trailer with brake system brake brake level SKYAC- TIV-D 2.2 Manual 750 kg (1,653.4 2,100 kg (4,629.6 EURO6 4WD 4,320 kg (9,523.8 lb) STANDARD transaxle POWER...
Page 154 Before Driving Towing Israel/Gradient up to 12% GROSS COMBINA- MODEL TOTAL TRAILER WEIGHT TION WEIGHT Emis- Drive Trailer without Trailer with Engine Transaxle sion Trailer with brake system brake brake level SKYAC- Automatic 750 kg (1,653.4 1,500 kg (3,306.9 EURO6 2WD 3,560 kg (7,848.3 lb) TIV-G 2.0 transaxle...
Page 155 ▼ Trailer Hitch When towing a trailer, use an appropriate trailer hitch. We recommend using a genuine Mazda trailer hitch. Use the original holes drilled by the vehicle manufacture for securing the trailer hitch. Contact your Authorised Mazda Dealer for more information.
Page 156 ▼ Trailer Lights CAUTION Do not connect a trailer lighting system directly to the lighting system of your Mazda. This may damage your vehicle's electrical system and lighting systems. To connect the lighting system, consult an Authorised Mazda Dealer.
Page 157 Stop and re-inspect all lights and connections after driving a short distance. Driving Your Mazda will handle differently with a trailer in tow, so practice turning, backing, and  stopping in a traffic-free area. Take time to get accustomed to the extra weight and length.
Page 158 Before Driving Towing 5. If the vehicle has an automatic transaxle, put the selector lever in P position. If it has a manual transaxle, place the gear shift in 1 or R position. Starting on an Incline 1. Start the engine (page 4-5). 2.
Page 159 When Driving Information concerning safe driving and stopping. Start/Stop Engine......4-4 Switches and Controls.....4-87 Ignition Switch......4-4 Lighting Control......4-87 Starting the Engine....... 4-5 Front Fog Lights ....... 4-92 Turning the Engine Off....4-11 Rear Fog Light ......4-93 i-stop ......... 4-12 Turn and Lane-Change Signals........
Page 160 Fuel Economy Monitor....4-121 Mazda Radar Cruise Control with Stop & Go function (MRCC with Fuel Economy Monitor ...4-121 Stop & Go function) (Automatic Transaxle) ........4-174 Drive Selection.......4-127 Lane-keep Assist System (LAS) & Drive Selection ....... 4-127 Lane Departure Warning System (LDWS) ........
Page 161 Selective Catalytic Reduction (SCR) Rear View Monitor....... 4-275 System..........4-272 Rear View Monitor ....4-275 Selective Catalytic Reduction (SCR) System ........4-272 Parking Sensor System....4-287 Parking Sensor System ... 4-287 *Some models.
Page 162: When Driving
When Driving Start/Stop Engine Ignition Switch The power supply to electrical devices ▼ Push Button Start Positions turns off and the push button start indicator light (amber) also turns off. The system operates only when the key is In this position the steering wheel is within operational range.
Page 163: Starting The Engine
Consult an expert repairer, we recommend an Authorised Mazda Repairer for details. If the push button start system functions have been deactivated, you can start the engine by following the procedure indicated when the key battery goes dead.
Page 164 When Driving Start/Stop Engine This is for improved exhaust gas 6. Verify that the KEY indicator light purification and does not indicate any (green) (if equipped) in the instrument parts defect. cluster and the push button start indicator light (green) illuminate. 1.
Page 165 (page 7-42), repairer, we recommend an messages are displayed in the Authorised Mazda Repairer as soon instrument cluster). Have your vehicle as possible. If this occurs, the engine inspected at an expert repairer, we can be force-started.
Page 166 (manual If the engine still does not start, transaxle) or the brake pedal have your vehicle inspected by an (automatic transaxle) until the Authorised Mazda Repairer (page glow indicator light in the 7-34). instrument cluster turns off and (SKYACTIV-D 2.2) ...
Page 167 When Driving Start/Stop Engine (Manual transaxle vehicle with Spare keys or keys for other vehicles  i-stop function) equipped with an immobilizer system If the engine has stopped due to touch or come near the key. stalling, it can be restarted by depressing the clutch pedal within 3 seconds of the engine stopping.
Page 168 (amber) expert repairer, we recommend an flashes. In this case, the engine may Authorised Mazda Repairer as soon as start, however, have the vehicle possible. If this occurs, the engine can be checked at an expert repairer, we force-started.
Page 169: Turning The Engine Off
When Driving Start/Stop Engine NOTE Turning the Engine Off (SKYACTIV-G 2.0, SKYACTIV-G 2.5)  The cooling fan in the engine WARNING compartment could turn on for a few minutes after the ignition is switched Do not stop the engine while the vehicle is from ON to OFF, whether or not the A/C moving: is on or off, to cool the engine...
Page 170: I-Stop
3. The engine restarts automatically when the clutch pedal is depressed. Automatic transaxle (AUTOHOLD operation turned off and When not using Mazda Radar Cruise The i-stop indicator light (green) turns  Control with Stop & Go function off when the engine is restarted.
Page 171 R position. (For the (When the vehicle is stopped by the purposes of safety, always keep the Mazda Radar Cruise Control with Stop brake pedal depressed when shifting & Go function (MRCC with Stop & Go...
Page 172 Start/Stop Engine (Automatic air-conditioning) When the vehicle is stopped by the   Mazda Radar Cruise Control with The temperature setting dial of the air  Stop & Go function (MRCC with conditioner is in a position other than Stop & Go function) stop hold control...
Page 173 When Driving Start/Stop Engine NOTE The temperature setting dial of the air  Under the following conditions, a period conditioner is in the maximum heating of time is required to stop engine idling or maximum cooling (A/C ON) position. The battery power is depleted for some ...
Page 174 Battery terminals are disconnected Engine idling may not stop right after the battery terminals are disconnected. In addition, if the battery is replaced, the i-stop functions must be verified. Consult an expert repairer, we recommend an Authorised Mazda Repairer. 4-16...
Page 175 When Driving Start/Stop Engine ▼ Vehicle Roll Prevention Function (Automatic transaxle) Vehicles with the i-stop function are equipped with a vehicle roll prevention function. This function prevents the vehicle from rolling, such as when releasing the brake pedal while on a slope under the following conditions: While engine idling is stopped (prevents the vehicle from rolling back) ...
Page 176: Display
When Driving Start/Stop Engine Note that the vehicle may move suddenly after the vehicle roll prevention function is released while the vehicle is under the following conditions: The selector lever is in the N position. If the selector lever is shifted to the N position and the brake pedal is released while the i-stop function is operating, the brake force is gradually released.
Page 177 NOTE A problem in the system may be indicated under the following conditions. Have your vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. The light does not turn on when the  ignition is switched ON.
Page 178 When Driving Instrument Cluster and Display Instrument Cluster and Display Instrument Cluster Type A Type B Type C Active Driving Display ① Instrument Cluster (Type A)................. page 4-21 ② Instrument Cluster (Type B)..................page 4-40 ③ Instrument Cluster (Type C)..................page 4-59 ④...
Page 179: Instrument Cluster (Type A)
When Driving Instrument Cluster and Display Instrument Cluster (Type A) ① Speedometer......................page 4-21 ② Tachometer......................page 4-21 ③ Multi-information Display (Type A)..............page 4-22 ④ Engine Coolant Temperature Gauge..............page 4-25 ⑤ Fuel Gauge......................page 4-26 ⑥ Instrument Panel Illumination................page 4-26 ⑦...
Page 180 Reduction (SCR) System) Blind Spot Monitoring (BSM) Display  Distance Recognition Support System (DRSS) Display  Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)  System Display Mazda Radar Cruise Control (MRCC) Display ...
Page 181 When Driving Instrument Cluster and Display The screen content changes each time the INFO switch is pressed. Press the INFO switch Warning message Basic display display Press the INFO switch Press the INFO switch Distance-to-empty Trip Meter A display display Press the INFO switch Press the INFO switch Trip Meter B display...
Page 182 When Driving Instrument Cluster and Display The screen content changes each time the selector knob is pressed and held. Gauge indication Press and hold selector knob Press and hold Numerical indication selector knob Press and hold selector knob Display off 4-24...
Page 183 When Driving Instrument Cluster and Display ▼ Odometer, Trip Meter and Trip For instance, trip meter A can record the Meter Selector distance from the point of origin, and trip meter B can record the distance from The odometer is constantly displayed on where the fuel tank is filled.
Page 184 When Driving Instrument Cluster and Display If the low fuel warning light illuminates or CAUTION the fuel level is very low, refuel as soon as possible. If the engine coolant temperature gauge Refer to Taking Action on page 7-54. needle is in the red range, there is the possibility of overheating.
Page 185 When Driving Instrument Cluster and Display When the lights are turned on, the When the illumination dimmer is   lights-on indicator light in the cancelled, the instrument cluster cannot instrument cluster turns on. be dimmed even if the lights are turned Refer to Headlights on page 4-87.
Page 186 When Driving Instrument Cluster and Display The vehicle is parked. ▼ Distance-to-empty  The vehicle is driven at low speeds.  This displays the approximate distance Changing the Temperature Unit of the you can travel on the remaining fuel based Outside Temperature Display (Vehicles on the fuel economy.
Page 187 When Driving Instrument Cluster and Display ▼ Average Fuel Economy ▼ Maintenance Monitor The average fuel economy is calculated The following maintenance period every minute from the total travelled notifications can be displayed by turning distance on the trip meter and the total fuel the Maintenance Monitor on.
Page 188 When Driving Instrument Cluster and Display remaining-distance-to-empty indication is ▼ Blind Spot Monitoring (BSM) continuously displayed. Display Displays the system status. ® If the remaining amount of AdBlue Refer to Blind Spot Monitoring (BSM) on low or there is a problem with the SCR page 4-141.
Page 189 Displays the distance between your vehicle and the vehicle ahead. Displays the currently set system status. Refer to Mazda Radar Cruise Control with Refer to Distance Recognition Support Stop & Go function (MRCC with Stop & System (DRSS) on page 4-152.
Page 190 When Driving Instrument Cluster and Display ▼ Cruise Control Set Vehicle Speed Display The vehicle speed preset using the cruise control is displayed. Refer to Cruise Control on page 4-261. ▼ Warning (Display Indication) A message is displayed to notify the user of the system operation status and malfunctions or abnormalities.
Page 191 When Driving Instrument Cluster and Display ▼ Warning/Indicator Lights Instrument Cluster varies depending on model and specifications. Instrument Cluster Centre of Instrument panel Warning lights will appear in any of the highlighted areas ▼ Warning Indication/Warning Lights These lights turn on or flash to notify the user of the system operation status or a system malfunction.
Page 192 Driver Attention Alert (DAA) Warning Indication 7-45 (Amber) 7-45 Mazda Radar Cruise Control (MRCC) Warning Indication Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop 7-45 (Amber) & Go function) Warning Indication Lane-keep Assist System (LAS) & Lane Departure Warning System...
Page 193 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. ▼ Indication/Indicator Lights These lights turn on or flash to notify the user of the system operation status or a system malfunction.
Page 194 Direction Indicator/Hazard Warning Indicator Lights Hazard Warning Flasher 4-102 *1*2 7-45 Electric Parking Brake (EPB) Indication/Indicator Light 4-110 AUTOHOLD Active Indicator Light Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop 4-184 & Go function) indicator Light 4-36 *Some models.
Page 195 Driver Attention Alert (DAA) Indication 4-157 (White) 4-165 Mazda Radar Cruise Control (MRCC) Main Indication Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop 4-178 (White) & Go function) Main Indication 4-165 Mazda Radar Cruise Control (MRCC) Set Indication Mazda Radar Cruise Control with Stop &...
Page 196 If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. 2 The light turns on continuously when the parking brake is applied.
Page 197 Whenever the engine oil is replaced, a  reset of the vehicle engine control unit is necessary. Your Authorised Mazda Repairer will be able to reset the engine control unit or see page 6-27 for the Vehicle engine control unit reset procedure.
Page 198: Instrument Cluster (Type B)
When Driving Instrument Cluster and Display Instrument Cluster (Type B) ① Speedometer......................page 4-40 ② Tachometer......................page 4-40 ③ Multi-information Display (Type B)..............page 4-41 ④ Instrument Panel Illumination................page 4-45 ▼ Speedometer NOTE When the tachometer needle enters the The speedometer indicates the speed of the STRIPED ZONE, this indicates to the vehicle.
Page 199 Reduction (SCR) System) Blind Spot Monitoring (BSM) Display  Distance Recognition Support System (DRSS) Display  Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)  System Display Mazda Radar Cruise Control (MRCC) Display ...
Page 200 When Driving Instrument Cluster and Display The screen content changes each time the INFO switch is pressed. Press the INFO switch Current Fuel Economy, Warning message, Trip Meter A, Average Outside Temperature, Fuel Economy, Outside Odometer, Fuel Gauge Temperature, Odometer, Fuel Gauge Press the INFO switch Press the INFO switch Engine Coolant...
Page 201 When Driving Instrument Cluster and Display ▼ Odometer, Trip Meter and Trip For instance, trip meter A can record the Meter Selector distance from the point of origin, and trip meter B can record the distance from The odometer is constantly displayed on where the fuel tank is filled.
Page 202 When Driving Instrument Cluster and Display ▼ Fuel Gauge CAUTION The fuel gauge shows approximately how If the high engine coolant temperature much fuel is remaining in the tank when warning light (red) flashes, there is a the ignition is switched ON. We possibility of overheating.
Page 203 When Driving Instrument Cluster and Display (SKYACTIV-D 2.2) The brightness increases by rotating the  If inconsistency in engine performance or knob to the right. stalling occurs due to low fuel level conditions, refuel the vehicle as soon as possible and add at least 10 L (2.7 US gal, 2.2 Imp gal) of fuel.
Page 204 When Driving Instrument Cluster and Display ▼ Outside Temperature Display If the outside temperature is lower than about 4 °C (39 °F), the outside When the ignition is switched ON, the temperature display and the mark outside temperature is displayed. flashes for about ten seconds and a beep sound is heard once.
Page 205 When Driving Instrument Cluster and Display If there is no past fuel economy NOTE  Indicates the 0 position when the vehicle information such as after first purchasing your vehicle or the speed is about 5 km/h (3 mph) or slower. information is deleted when the battery ▼...
Page 206 When Driving Instrument Cluster and Display ® NOTE If the remaining amount of AdBlue Always set the vehicle speed according to low or there is a problem with the the laws and regulations of the country/ Selective Catalytic Reduction (SCR) city in which the vehicle is driven.
Page 207 Displays the currently set system status. Refer to Distance Recognition Support Refer to Mazda Radar Cruise Control with System (DRSS) on page 4-152. Stop & Go function (MRCC with Stop & Go function) on page 4-174.
Page 208 When Driving Instrument Cluster and Display ▼ Warning (Display Indication) A message is displayed to notify the user of the system operation status and malfunctions or abnormalities. If the warning light turns on/flashes simultaneously or a symbol is indicated in the display, check the information regarding the warning light or symbol.
Page 209 When Driving Instrument Cluster and Display ▼ Warning/Indicator Lights Instrument Cluster varies depending on model and specifications. Instrument Cluster Centre of Instrument panel Warning lights will appear in any of the highlighted areas ▼ Warning Indication/Warning Lights These lights turn on or flash to notify the user of the system operation status or a system malfunction.
Page 210 Driver Attention Alert (DAA) Warning Indication (Amber) Mazda Radar Cruise Control (MRCC) Warning Indication 7-45 Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop 7-45 (Amber) & Go function) Warning Indication Lane-keep Assist System (LAS) & Lane Departure Warning System...
Page 211 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. ▼ Indication/Indicator Lights These lights turn on or flash to notify the user of the system operation status or a system malfunction.
Page 212 Direction Indicator/Hazard Warning Indicator Lights Hazard Warning Flasher 4-102 *1*2 7-45 Electric Parking Brake (EPB) Indication/Indicator Light 4-110 AUTOHOLD Active Indicator Light Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop 4-184 & Go function) indicator Light 4-54 *Some models.
Page 213 4-157 Driver Attention Alert (DAA) Indication (White) 4-165 Mazda Radar Cruise Control (MRCC) Main Indication Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop 4-178 (White) & Go function) Main Indication 4-165 Mazda Radar Cruise Control (MRCC) Set Indication Mazda Radar Cruise Control with Stop &...
Page 214 When Driving Instrument Cluster and Display Signal Indicator Page Advanced Smart City Brake Sup- port (Advanced SCBS) 4-210 Smart City Brake Support Smart City Brake Support (SCBS) Indication [Forward] (SCBS F) 4-214 Smart City Brake Support [Reverse] (SCBS R) 4-219 Advanced Smart City Brake Sup- port (Advanced...
Page 215 If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. 2 The light turns on continuously when the parking brake is applied.
Page 216 If the vehicle is left with the ignition necessary. switched ON without starting the engine Your Authorised Mazda Repairer will be and a long period of time has elapsed able to reset the engine control unit or since preheating finished, the preheating...
Page 217: Instrument Cluster (Type C)
When Driving Instrument Cluster and Display Instrument Cluster (Type C) ① Speedometer......................page 4-59 ② Tachometer......................page 4-59 ③ Multi-information Display (Type C)..............page 4-60 ④ Instrument Panel Illumination................page 4-63 ▼ Speedometer NOTE When the tachometer needle enters the The speedometer indicates the speed of the STRIPED ZONE, this indicates to the vehicle.
Page 218 When Driving Instrument Cluster and Display ▼ Multi-information Display (Type C) Multi-information Display (Type C) INFO switch The multi-information display indicates the following information. Odometer  Trip meter  Engine coolant temperature gauge  Fuel gauge  Outside temperature  Trip Computer ...
Page 219 When Driving Instrument Cluster and Display ▼ Odometer, Trip Meter and Trip meter B can record the distance from Meter Selector where the fuel tank is filled. The display mode can be changed from When trip meter A is selected, pressing the odometer to trip meter A to trip meter B selector again within 1 second will change and then back to odometer by pressing the...
Page 220 When Driving Instrument Cluster and Display ▼ Engine Coolant Temperature Gauge the ignition is switched ON. We recommend keeping the tank over 1/4 full. Displays the engine coolant temperature. The white gauge indicates that the engine Full coolant temperature is low, and the red gauge indicates that the engine coolant temperature is high and overheating.
Page 221 When Driving Instrument Cluster and Display (SKYACTIV-D 2.2) heard when the knob has been rotated to If inconsistency in engine performance or the maximum dim position. stalling occurs due to low fuel level The brightness increases by rotating the  conditions, refuel the vehicle as soon as knob to the right.
Page 222 If you have any problems with your trip ignition ON. The outside temperature computer, consult an expert repairer, we display flashes. recommend an Authorised Mazda 2. Press the INFO switch to change the Repairer. outside temperature unit. 3. Press and hold the INFO switch for 3 seconds or longer while the outside temperature display is flashing.
Page 223 When Driving Instrument Cluster and Display Distance-to-empty mode Average fuel economy mode This mode displays the approximate This mode displays the average fuel distance you can travel on the remaining economy by calculating the total travelled fuel based on the fuel economy. distance and the total fuel consumption since the vehicle was purchased or the past The distance-to-empty will be calculated...
Page 224 When Driving Instrument Cluster and Display Current fuel economy mode The vehicle speed alarm can be set using the centre display. This mode displays the current fuel economy by calculating the amount of fuel NOTE Always set the vehicle speed according to consumption and the distance travelled.
Page 225 When Driving Instrument Cluster and Display ▼ Warning/Indicator Lights Instrument Cluster varies depending on model and specifications. Instrument Cluster Centre of Instrument panel Warning lights will appear in any of the highlighted areas ▼ Warning Indication/Warning Lights These lights turn on or flash to notify the user of the system operation status or a system malfunction.
Page 226 When Driving Instrument Cluster and Display Signal Warning Page Electric Parking Brake (EPB) Warning Light 7-45 Flashing 4-108 Brake Pedal Operation Demand Warning Light Buzzer & Flash- (Red) 7-45 Check Engine Light 7-45 i-stop Warning Light 7-45 (Amber) 7-45 Automatic Transaxle Warning Light 7-45 4WD Warning Light 7-45...
Page 227 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. ▼ Indication/Indicator Lights These lights turn on or flash to notify the user of the system operation status or a system malfunction.
Page 228 When Driving Instrument Cluster and Display Signal Indicator Page 4-92 Front Fog Light Indicator Light 4-93 Rear Fog Light Indicator Light Turn and Lane-Change Signals 4-94 Direction Indicator/Hazard Warning Indicator Lights Hazard Warning Flasher 4-102 *1*2 7-45 Electric Parking Brake (EPB) Indicator Light AUTOHOLD Active Indicator Light 4-110 Traction Control...
Page 229 If the light does not turn on or remains turned on, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. 2 The light turns on continuously when the parking brake is applied.
Page 230  reset of the vehicle engine control unit is finished. necessary. Your Authorised Mazda Repairer will be A problem in the system might be able to reset the engine control unit or indicated under the following conditions. see page 6-27 for the Vehicle engine Have your vehicle inspected by an expert control unit reset procedure.
Page 231: Active Driving Display
When Driving Instrument Cluster and Display Active Driving Display Windscreen Type Dust-proof sheet Display Optical receiver Auto Flip-up Type Mirror Combiner Optical receiver WARNING Always adjust the display brightness and position with the vehicle stopped: Adjusting the display brightness and position while driving the vehicle is dangerous as doing so could distract your attention from the road ahead and lead to an accident.
Page 232 Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)  Operation Conditions and Warnings Refer to Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) on page 4-174. Mazda Radar Cruise Control (MRCC) Operation Conditions and Warnings ...
Page 233 When Driving Instrument Cluster and Display Refer to Smart City Brake Support (SCBS) on page 4-212. Smart City Brake Support [Reverse] (SCBS R) Operation Conditions  Refer to Smart City Brake Support [Reverse] (SCBS R) on page 4-216. Smart Brake Support (SBS) Operation Conditions and Warnings ...
Page 234: Manual Transaxle Operation
When Driving Manual Transaxle Operation Manual Transaxle Shift WARNING Pattern Do not use sudden engine braking on slippery road surfaces or at high speeds: Shifting down while driving on wet, snowy, or frozen roads, or while driving at high speeds causes sudden engine braking, which is dangerous.
Page 235 When Driving Manual Transaxle Operation (With i-stop function) Indication Condition  If the engine has stopped due to stalling, The selected gear position is dis- Numeral it can be restarted by depressing the played. clutch pedal within 3 seconds of the Shift up or down to the indicated and numeral gear position is recommended.
Page 236: Automatic Transaxle
When Driving Automatic Transaxle Automatic Transaxle Controls Lock-release button Various Lockouts: Indicates that you must depress the brake pedal and hold in the lock-release button to shift (The ignition must be switched ON). Indicates the selector lever can be shifted freely into any position. Indicates that you must hold in the lock-release button to shift.
Page 237: Shift-Lock System
Rocking the Vehicle (page 3-55). 3. Press and hold the lock-release button. 4. Move the selector lever. Take the vehicle to an expert repairer, we recommend an Authorised Mazda Repairer to have the system checked. 4-79...
Page 238 When Driving Automatic Transaxle NOTE NOTE (With parking sensor system) Apply the parking brake or depress the When the selector lever is shifted to the R brake pedal before moving the selector position with the ignition switched ON, the lever from N position to prevent the parking sensor system is activated and a vehicle from moving unexpectedly.
Page 239: Manual Shift Mode
When Driving Automatic Transaxle ▼ Active Adaptive Shift (AAS) Manual Shift Mode Active Adaptive Shift (AAS) The manual shift mode gives you the feel automatically controls the transaxle shift of driving a manual transaxle vehicle by points to best suit the road conditions and allowing you to operate the selector lever driver input.
Page 240 When Driving Automatic Transaxle Gear position indication instrument cluster as well as notifies the driver to change to the most suitable gear The numeral for the selected gear position corresponding to the actual illuminates. driving condition. Instrument Cluster (Type A) Instrument Cluster (Type A) Manual shift mode Selected gear position...
Page 241 When Driving Automatic Transaxle ▼ Manually Shifting Up ▼ Manually Shifting Down You can shift gears up by operating the You can shift gears down by operating the selector lever. selector lever. M1 → M2 → M3 → M4 → M5 → M6 M6 →...
Page 242 When Driving Automatic Transaxle ▼ Second Gear Fixed Mode When the selector lever is moved back while the vehicle speed is about 10 km/h (6.2 mph) or less, the transaxle is set in the second gear fixed mode. The gear is fixed in second while in this mode for easier acceleration from a stop and driving on slippery roads such as snow-covered...
Page 243 When Driving Automatic Transaxle ▼ Shift Gear (Shifting) Speed Limit For each gear position while in the manual mode, the speed limit is set as follows: When the selector lever is operated within the range of the speed limit, the gear is shifted. Shift up The gear does not shift up while the vehicle speed is lower than the speed limit.
Page 244: Driving Tips
When Driving Automatic Transaxle Climbing steep grades from a stop Driving Tips To climb a steep grade from a stopped position: WARNING 1. Depress the brake pedal. 2. Shift to D or M1, depending on the Do not let the vehicle move in a direction load weight and grade steepness.
Page 245: Switches And Controls
When Driving Switches and Controls Lighting Control ▼ Headlights Turn the headlight switch to turn the headlights and other exterior lights on or off. When the lights are turned on, the lights-on indicator light in the instrument cluster turns on. NOTE To prevent discharging the battery, do not leave the lights on while the engine is off unless ...
Page 246 When Driving Switches and Controls When the running lights are turned on, the tail lights, and number plate lights turn on. The position lights does not turn on. The lights are turned on continuously if the ignition is switched from ON to any other position with the lights turned on.
Page 247 When Driving Switches and Controls CAUTION Do not shade the light sensor by adhering a sticker or a label on the windscreen. Otherwise the light sensor will not operate correctly. The light sensor also works as a rain sensor for the auto-wiper control. Keep hands and scrapers clear of the windscreen when the wiper lever is in the position and the ignition is switched ON as fingers could be pinched or the wipers and wiper blades...
Page 248 When Driving Switches and Controls ▼ Headlight High-Low Beam simultaneously. The lever will return to the normal position when released. The headlights switch between high and low beams by moving the lever forward or backward. High beam ▼ Coming Home Light The coming home light turns on the headlights (low beams) when the lever is Low beam...
Page 249 When the ignition switch and the headlight the system has a malfunction. switch are in the following conditions, the Refer to Contact Mazda Repairer and headlights will illuminate when the Have Vehicle Inspected on page 7-45. transmitter unlock button is pressed and ▼...
Page 250: Front Fog Lights
When Driving Switches and Controls NOTE Front Fog Lights (With auto-light control)  The front fog lights can be used when the If the fog light switch is in the ignition is switched ON. position or the headlight switch is in the Use this switch to turn on the front fog position, the fog lights will turn on lights.
Page 251: Rear Fog Light
When Driving Switches and Controls Rotate the fog light switch to the Rear Fog Light  position again (the fog light switch The rear fog light can be used when the returns to the position automatically). ignition is switched ON. Turn the headlight switch to the ...
Page 252: Turn And Lane-Change Signals
When Driving Switches and Controls The rear fog light indicator light in the Turn and Lane-Change instrument cluster illuminates while the Signals rear fog light is on. The ignition must be switched ON to use the turn and lane-change signals. ▼...
Page 253: Windscreen Wipers And Washer
When Driving Switches and Controls ▼ Lane-Change Signals Windscreen Wipers and Washer Move the lever halfway toward the direction of the lane change―until the The ignition must be switched ON to use indicator flashes― and hold it there. It the wipers. will return to the off position when released.
Page 254 If the wipers do not operate even though the wiper switch is turned to a position other than OFF, consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. ▼ Windscreen Wipers INT ring...
Page 255 When Driving Switches and Controls Auto-wiper control When the wiper lever is in the position and the ignition is switched ON, When the wiper lever is in the the wipers may move automatically in position, the rain sensor senses the amount the following cases: of rainfall on the windscreen and turns the wipers on or off automatically...
Page 256 (page 6-32). If the fluid level auto-wiper control will stop operation. is normal, consult an expert repairer, we In this case, set the wiper lever to the recommend an Authorised Mazda low speed position or high speed Repairer. position for manual operation, or...
Page 257: Rear Window Wiper And Washer
If the washer does not work, inspect the fluid level (page 6-32). If the fluid level is normal and the washer still does not work, consult an expert repairer, we recommend an Authorised Mazda Repairer. 4-99 *Some models.
Page 258: Rear Window Defogger
When Driving Switches and Controls Rear Window Defogger CAUTION The rear window defogger clears fog from Do not use sharp instruments or window the rear window. cleaners with abrasives to clean the inside of the rear window surface. They The ignition must be switched ON to use may damage the defogger grid inside the the defogger.
Page 259 When Driving Switches and Controls Manual Air-Conditioning Right-Hand Drive Model Indicator light The windscreen wiper de-icer operates in Fully Automatic Air-Conditioning conjunction with the rear window defogger. Indicator light To turn on the windscreen wiper de-icer, switch the ignition ON and press the rear window defogger switch (page 4-100).
Page 260: Horn
When Driving Switches and Controls Horn Hazard Warning Flasher To sound the horn, press the mark on The hazard warning lights should always the steering wheel. be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution when near it.
Page 261 When Driving Switches and Controls If the brake pedal is depressed while  driving on slippery roads, the emergency stop signal system could operate causing all the turn and lane change signals to flash. Refer to Emergency Stop Signal System on page 4-113.
Page 262: Brake
When Driving Brake Brake System Driving with wet brakes is dangerous. Increased stopping distance or the vehicle ▼ Foot Brake pulling to one side when braking could result in a serious accident. Light braking This vehicle has power-assisted brakes will indicate whether the brakes have been that adjust automatically through normal affected.
Page 263 When Driving Brake ▼ Electric Parking Brake (EPB) An operation sound occurs when  applying or releasing the parking brake, The EPB equipment applies the parking however, this does not indicate a brake using an electric motor. When the malfunction. parking brake is applied, the EPB switch If the EPB is not used for long periods, ...
Page 264 When Driving Brake The parking brake is applied and the EPB notifies the driver that the brake is not indicator light and the EPB switch depressed. indicator light turn on. (Type A/B instrument cluster) Refer to If a Warning Light Turns On or A message is displayed on the Flashes on page 7-42.
Page 265 When you hear this noise, consult an This is a normal effect of the brake expert repairer, we recommend an assist and does not indicate a Authorised Mazda Repairer as soon as malfunction. possible. The brake assist equipment does not ...
Page 266: Autohold
When Driving Brake AUTOHOLD The AUTOHOLD function automatically holds the vehicle stopped, even if you take your foot off the brake pedal. This function can be best used while stopped in traffic or at a traffic light. The brakes are released when you resume driving the vehicle such as by releasing the clutch pedal with the shift lever shifted to a position other than the neutral position (manual transaxle vehicle) or depressing the accelerator pedal (automatic transaxle vehicle).
Page 267 Under the following conditions, a problem with the AUTOHOLD is occurring. Have your  vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. The brake pedal operation demand warning light (red) in the instrument cluster flashes ...
Page 268 When Driving Brake ▼ AUTOHOLD System is Turned On 2. The AUTOHOLD active indicator light in the instrument cluster turns on Press the AUTOHOLD switch and when and the brakes are held. the AUTOHOLD standby indicator light turns on, the AUTOHOLD function turns AUTOHOLD standby indicator light 3.
Page 269 When Driving Brake To release AUTOHOLD and start When about 10 minutes or longer have  driving the vehicle passed since the AUTOHOLD operation started, the parking brake is If you do any of the following actions to automatically applied. Because the resume driving the vehicle, the brakes AUTOHOLD is restored when releasing release automatically and the...
Page 270 When Driving Brake (Type A/B instrument cluster) Turn off the AUTOHOLD before   If the AUTOHOLD switch is pressed switching OFF the ignition so that the without depressing the brake pedal parking brake is not applied while AUTOHOLD is operating automatically.
Page 271: Emergency Stop Signal System
When Driving Brake Emergency Stop Signal Hill Launch Assist (HLA) System HLA is a function which assists the driver in accelerating from a stop while on a If you apply the brakes suddenly while slope. When the driver releases the brake driving at a speed of about 55 km/h (34 pedal and depresses the accelerator pedal mph) or faster, the emergency stop signal...
Page 272 HLA does not operate while the  TCS/DSC indicator light is illuminated. Refer to Contact Authorised Mazda Repairer and Have Vehicle Inspected on page 7-45. HLA does not turn off even if the TCS ...
Page 273: Abs/Tcs/Dsc
The warning light turns on when the system has a malfunction. Refer to Contact Authorised Mazda Repairer and Have Vehicle Inspected on page 7-45. WARNING Do not rely on ABS as a substitute for safe...
Page 274: Traction Control System (Tcs)
▼ TCS/DSC Indicator Light The warning light turns on when the system has a malfunction. Refer to Contact Authorised Mazda Repairer and Have Vehicle Inspected on page 7-45. This indicator light stays on for a few seconds when the ignition is switched ON.
Page 275 If the TCS OFF switch is pressed and  Authorised Mazda Repairer. The DSC held for 10 seconds or more, the TCS may have a malfunction. OFF switch malfunction detection ▼ TCS OFF Switch function operates and the TCS system activates automatically.
Page 276: Dynamic Stability Control (Dsc)
When Driving ABS/TCS/DSC Use tyres of the correct size specified Dynamic Stability Control for your Mazda on all 4 wheels. (DSC) Use tyres of the same manufacturer, brand and tread pattern on all 4 The Dynamic Stability Control (DSC) wheels.
Page 277: I-Eloop
Variable voltage alternator DC-DC converter Capacitor If the capacitor is to be disposed of, always consult an expert repairer, we recommend an Authorised Mazda Repairer. For details, go to the following URL. http://www.mazda.com/csr/environment/recycling ▼ i-ELOOP Control Status Display ▼ i-ELOOP Charging Display...
Page 278 When Driving i-ELOOP If you turn the steering wheel while the message is displayed, it will feel heavier than normal, but this does not indicate an abnormality. Stop the vehicle in a safe location with the engine running and do not attempt to turn the steering wheel.
Page 279 When Driving Fuel Economy Monitor Fuel Economy Monitor For vehicles with type B audio, the Control Status, Fuel Consumption, and Effectiveness are switched and displayed by operating each icon in the display. In addition, after completing a trip, the total energy efficiency to date is displayed in the ending display when the ending display is turned on.
Page 280 When Driving Fuel Economy Monitor ▼ Fuel Consumption Display Information regarding the fuel economy is displayed. Indication on display Control status Displays the fuel economy for the past 60 minutes. Displays the fuel economy every minute for the past  1 to 10 minutes.
Page 281 When Driving Fuel Economy Monitor ▼ Control Status Display (With i-stop Function) The i-stop operation status and the i-ELOOP power generating status are displayed. Indication on display Control status With i-ELOOP system Displays the level of electricity generated by regen- erative braking.
Page 282 When Driving Fuel Economy Monitor Indication on display Control status With i-ELOOP system Displays the readiness status as to whether opera- tion of the i-stop function is available. Displays the operation readiness status of the i-stop function on the vehicle side (engine, battery, and A/C) Without i-ELOOP system using icon colouring.
Page 283 When Driving Fuel Economy Monitor Indication on display Control status Without i-ELOOP system The i-stop function operation status is indicated by the colour of the engine area. The colour is blue during i-stop function operation, and grey when it is not oper- ating.
Page 284 When Driving Fuel Economy Monitor ▼ Fuel Economy Data Reset and Trip Meter (TRIP A) Synchronization (Linking) (With Instrument Cluster (Type C)) Because the average fuel economy indication on the instrument cluster display is linked with the “Average (Since Reset)” indication on the centre display, when one is reset the other is also reset.
Page 285 Drive mode cannot be switched in the following conditions:  ABS/TCS/DSC is operating  The Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go  function) System/Mazda Radar Cruise Control (MRCC) system/cruise control is operating.
Page 286 When Driving Drive Selection NOTE If the drive selection cannot be switched to sport mode, the select mode indication flashes to notify the driver. 4-128...
Page 287 A system malfunction or operation other types of vehicles. conditions are indicated by a warning. Drive carefully when the vehicle is loaded Refer to Contact Authorised Mazda by lowering vehicle speed and applying the Repairer and Have Vehicle Inspected on brakes earlier: page 7-45.
Page 288 When Driving i-ACTIV AWD Make sure to equip the vehicle with  genuine wheels of the specified size, on all wheels. With 4WD, the system is calibrated for all 4 wheels being of the same dimensions. Tyre chains Install tyre chains to the front tyres. ...
Page 289 If the steering feels stiffer than usual during normal driving or the steering vibrates, consult an expert repairer, we recommend an Authorised Mazda Repairer. The warning indication/warning light  notifies the driver of system abnormalities and operation conditions.
Page 290 Driver fatigue detection Driver Attention Alert (DAA)................. page 4-156 Rear obstruction detection when leaving a parking space Rear Cross Traffic Alert (RCTA)................page 4-158 Full-surround recognition 360°View Monitor....................page 4-222 Driver support systems Inter-vehicle distance Mazda Radar Cruise Control (MRCC)..............page 4-162 4-132...
Page 291 Traffic Sign Recognition System (TSR)  Advanced Smart City Brake Support (Advanced SCBS)  Smart City Brake Support [Forward] (SCBS F)  Smart Brake Support (SBS)  Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)  4-133...
Page 292 The radar sensor (front) functions by detecting the radio waves reflected off a vehicle ahead sent from the radar sensor. The following systems also use the radar sensor (front). Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) ...
Page 293 When Driving i-ACTIVSENSE Adaptive Front Lighting System (AFS) The adaptive front lighting system (AFS) automatically adjusts the headlight beams to the left or right in conjunction with the operation of the steering wheel after the headlights have been turned on. NOTE Headlights do not blind drivers ...
Page 294 Camera (FSC) The warning light turns on when the system has a malfunction. Refer to Contact Authorised Mazda Repairer and Have Vehicle Inspected on page 7-45. CAUTION Do not adjust the vehicle height, modify the headlight units, or remove the camera, otherwise the system will not operate normally.
Page 295 When Driving i-ACTIVSENSE NOTE The timing in which the system switches the headlights changes under the following conditions. If the system does not switch the headlights appropriately, manually switch between high and low beams according to the visibility as well as road and traffic conditions.
Page 296 When Driving i-ACTIVSENSE Switching to high beams Adaptive LED Headlights Turn the headlight switch to the (ALH) position. The HBC indicator light (green) turns off The ALH are a system which uses the and the is illuminated. Forward Sensing Camera (FSC) to determine the situation of a vehicle ahead or a vehicle approaching in the opposite direction while driving at night to...
Page 297 When Driving i-ACTIVSENSE Wide-Range Low Beam NOTE Under the following conditions, the ALH This feature extends the illumination range may not operate normally. Manually of the light cast by the low beams while switch between the high and low beams driving at a speed less than about 40 km/h according to the visibility, and the road (25 mph).
Page 298 When Driving i-ACTIVSENSE ▼ To Operate the System The system switches the headlights to the high beams after the ignition is switched ON and the headlight switch is in the position. The ALH indicator light (green) in the instrument cluster turns on simultaneously.
Page 299 When Driving i-ACTIVSENSE Blind Spot Monitoring (BSM) The BSM is designed to assist the driver in checking the area to the rear of the vehicle on both sides during lane changes by notifying the driver of the presence of vehicles approaching from the rear in an adjacent lane.
Page 300 In the following cases, the BSM OFF indicator light turns on and operation of the system  is stopped. If the BSM OFF indicator light remains illuminated, have the vehicle inspected at an Authorised Mazda Repairer as soon as possible. Some problem with the system including the BSM warning indicator lights is detected. ...
Page 301 When Driving i-ACTIVSENSE When there is a difference in the height between your driving lane and the adjacent  lane. Directly after the BSM system becomes operable by changing the setting.  If the road width is extremely narrow, vehicles 2 lanes over may be detected. The detection ...
Page 302 When Driving i-ACTIVSENSE ▼ Blind Spot Monitoring (BSM) Warning Indicator Lights/Blind Spot Monitoring (BSM) Warning Beep The BSM or Rear Cross Traffic Alert (RCTA) system notifies the driver of the presence of vehicles in adjacent lanes or at the rear of the vehicle using the BSM warning indicator light, the warning sound and the display indicator (vehicles with instrument cluster (Type A/B) and active driving display) (BSM) while the systems are operational.
Page 303 When Driving i-ACTIVSENSE If the BSM warning indicator lights are difficult to see due to glare from surrounding brightness when travelling on snow-covered roads or under foggy conditions, press the dimmer cancellation button to cancel the dimmer and increase the brightness of BSM warning indicator lights when they turn on.
Page 304 Authorised Mazda Repairer. The TSR operates only if the navigation system SD card (Mazda genuine) is inserted in  the SD card slot. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details.
Page 305 When Driving i-ACTIVSENSE WARNING Always check the traffic signs visually while driving. The TSR helps prevent the driver from overlooking traffic signs and provides support for safer driving. Depending on the weather conditions or problems with traffic signs, a traffic sign may not be recognised or a traffic sign different from the actual traffic sign may be displayed.
Page 306 When Driving i-ACTIVSENSE A traffic sign is too bright or too dark (including electronic traffic signs).  A traffic sign is too big or too small.  There is an object similar to the traffic sign being read (such as another traffic sign or ...
Page 307 When Driving i-ACTIVSENSE The speed limit sign stored in the The vehicle speed exceeds the   navigation system is read (if the displayed speed limit sign by 30 km/h Forward Sensing Camera (FSC) does (19 mph) or more after a certain not recognise a speed limit sign).
Page 308 When Driving i-ACTIVSENSE ▼ Excessive Speed Warning If the vehicle speed exceeds the speed limit sign displayed in the active driving display, the area around the speed limit sign flashes 3 times in amber and the warning sound is activated 3 times at the same time.
Page 309 When Driving i-ACTIVSENSE 10: If the vehicle speed exceeds the speed limit sign displayed in the display by 10  km/h (5 mph), the excessive speed warning is activated. NOTE In the following cases, the excessive speed warning stops operating. ...
Page 310 The DRSS operation status is indicated in the active driving display or multi-information display. Regarding malfunctions, check the vehicle conditions or have it inspected by an expert repairer, we recommend an Authorised Mazda Repairer according to the content of the displayed message.
Page 311 When Driving i-ACTIVSENSE NOTE When the ignition is switched off, the operation status before the system was turned off is  maintained. For example, if the ignition is switched off with the DRSS operable, the system will be operable when the ignition is switched ON the next time. The DRSS can be turned on/off and the system's sensitivity can be changed.
Page 312 When Driving i-ACTIVSENSE Distance-between-vehicles guidelines Indication on display Distance be- Distance be- tween vehi- tween vehi- Multi-information display cles guide- cles guide- lines lines (During (During Active driving dis- Instrument cluster (Type Instrument cluster (Type travel at travel at play about 40 about 80 km/h (25...
Page 313 When Driving i-ACTIVSENSE Indication on display Distance be- Distance be- tween vehi- tween vehi- Multi-information display cles guide- cles guide- lines lines (During (During Active driving dis- Instrument cluster (Type Instrument cluster (Type travel at travel at play about 40 about 80 km/h (25 km/h (50...
Page 314 When Driving i-ACTIVSENSE Driver Attention Alert (DAA) The DAA is a system which detects driver fatigue and decreased attentiveness, and encourages the driver to take a rest. When the vehicle is driven inside traffic lane lines at about 65 to 140 km/h (41 to 86 mph), the DAA estimates the amount of accumulated fatigue and decreased attentiveness of the driver based on the information from the Forward Sensing Camera (FSC) and other vehicle information, and encourages the driver to take a rest using an indication on the...
Page 315 When Driving i-ACTIVSENSE NOTE The DAA operates when all of the following conditions are met.  The vehicle speed is about 65 to 140 km/h (41 to 86 mph).  The system detects white (yellow) lane lines.  The system has completed learning of the driver’s driving data. ...
Page 316 When Driving i-ACTIVSENSE Rear Cross Traffic Alert (RCTA) The RCTA system is designed to assist the driver in checking the area to the rear of the vehicle on both sides while the vehicle is reversing by alerting the driver to the presence of vehicles approaching the rear of the vehicle.
Page 317  and operation of the system is stopped. If the Blind Spot Monitoring (BSM) OFF Indicator Light remains illuminated, have the vehicle inspected at an Authorised Mazda Dealer as soon as possible. Some problem with the system including the Blind Spot Monitoring (BSM) warning ...
Page 318 When Driving i-ACTIVSENSE The temperature near the radar sensors becomes extremely hot due to driving for long  periods on slopes during the summer. The battery voltage has decreased.  Under the following conditions, the radar sensors (rear) cannot detect target objects or it ...
Page 319 When Driving i-ACTIVSENSE Turn off the RCTA system while pulling a trailer or while an accessory such as a bicycle  carrier is installed to the rear of the vehicle. Otherwise, the radio waves emitted by the radar will be blocked causing the system to not operate normally. 4-161...
Page 320 When Driving i-ACTIVSENSE Mazda Radar Cruise Control (MRCC) (Manual Transaxle) The MRCC system is designed to maintain headway control with a vehicle ahead according to your vehicle's speed using a radar sensor (front) to detect the distance to the vehicle ahead and a preset vehicle speed without you having to use the accelerator or brake pedals.
Page 321 When Driving i-ACTIVSENSE Long, descending slopes (to maintain distance between vehicles, the system automatically and continuously applies the brakes which could result in the loss of brake power.) Slopes with a steep gradient (The vehicle ahead may not be detected correctly, your vehicle may slide while stopped by the stop hold control, and it may accelerate suddenly after it starts moving.) For safety purposes, switch the MRCC system off when it is not being used.
Page 322 If there is a problem with the MRCC system, a message is displayed on the multi-information display. Check the centre display to verify the problem and then have your vehicle inspected by an expert repairer, we recommend an Authorised Mazda Repairer. Refer to Message Indicated on Display on page 7-61.
Page 323 When Driving i-ACTIVSENSE ▼ Close Proximity Warning If your vehicle rapidly closes in on the vehicle ahead because the vehicle ahead applies the brakes suddenly while you are travelling in headway control, the warning sound activates and the brake warning is indicated in the display. Always verify the safety of the surrounding area and depress the brake pedal while keeping a safer distance from the vehicle ahead.
Page 324 When Driving i-ACTIVSENSE Turning on the system switch SET+ switch RES switch switch SET- switch MODE switch CANCEL switch OFF switch When the MODE switch is pressed once, the MRCC system turns on, and the MRCC main indication (white) turns on and the vehicle speed and the distance between the vehicles while in headway control can be set.
Page 325 When Driving i-ACTIVSENSE The set speed and the inter-vehicle distance display filled with white lines is displayed. The MRCC main indication (white) switches to the MRCC set indication (green) at the same time. Indication on multi-information display Indication on active driving Travel status display Type A...
Page 326 When Driving i-ACTIVSENSE How to set the distance-between-vehicles during headway control The distance-between-vehicles is set to a shorter distance by pressing the switch. The distance-between-vehicles is set to a longer distance by pressing the switch. The distance-between-vehicles can be set to 4 levels; Long, medium, short, and extremely short distance.
Page 327 When Driving i-ACTIVSENSE When the ignition is switched to ACC or OFF and then the engine is started again, the  system automatically sets the distance-between-vehicles to the previous setting. How to change the set vehicle speed NOTE When accelerating using the SET To accelerate/decelerate using the SET ...
Page 328 When Driving i-ACTIVSENSE The shift lever is in the reverse (R) Turning off the system  position. Press the OFF/CANCEL switch two times while the MRCC system is operating to Under the following conditions, the switch off the system. MRCC cancel indication is displayed in the multi-information display and a single beep sound is heard.
Page 329 When Driving i-ACTIVSENSE ▼ Shift-up/Shift-down Request Display The shift-up or shift-down request display in the active driving display or multi-information display may be indicated while the MRCC is operating. When this occurs, shift gears because the gear position is not appropriate. Indication on display Request Multi-information display...
Page 330 When Driving i-ACTIVSENSE When the SET or SET switch is Always drive carefully: pressed, the cruise set indication (green) is The warnings and brake control will not turned on and headway control begins. operate after the headway control function is cancelled and the system is switched to NOTE only the cruise control function.
Page 331 When Driving i-ACTIVSENSE The set speed can be adjusted When the vehicle speed is less than 21  incrementally (1 km/h (1 mph) km/h (13 mph), the cruise control increments) by pressing the switch and function is cancelled. In this case, the releasing it immediately.
Page 332: Mazda Radar Cruise Control With Stop & Go Function (Mrcc With Stop & Go Function)
When Driving i-ACTIVSENSE Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) (Automatic Transaxle) The MRCC with Stop & Go function system is designed to maintain headway control with a vehicle ahead according to your vehicle's speed using a radar sensor (front) to detect the distance to the vehicle ahead and a preset vehicle speed without you having to use the accelerator or brake pedals.
Page 333 When Driving i-ACTIVSENSE Roads where frequent and repetitive acceleration and deceleration occur (Driving under these conditions using the MRCC with Stop & Go function system is not possible). When entering and exiting interchanges, service areas, and parking areas of highways (If you exit a highway while headway control is in use, the vehicle ahead will no longer be tracked and your vehicle may accelerate to the set speed).
Page 334 When Driving i-ACTIVSENSE During headway control travel, the system accelerates and decelerates your vehicle in  conjunction with the speed of the vehicle ahead. However, if it is necessary to accelerate for a lane change or if the vehicle ahead brakes suddenly causing you to close in on the vehicle rapidly, accelerate using the accelerator pedal or decelerate using the brake pedal depending on the conditions.
Page 335 When Driving i-ACTIVSENSE ▼ Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) Display Indication The MRCC with Stop & Go function setting status and operation conditions are indicated on the multi-information display and the active driving display.
Page 336 In the following cases, the MRCC with Stop & Go function system is cancelled when the  vehicle is travelling at 30 km/h (20 mph) or less and “Mazda Radar Cruise Control disabled under 30 km/h (20 mph)” is displayed in the multi-information display.
Page 337 When Driving i-ACTIVSENSE There is a problem with the stop hold control function.  There is a problem with the Electric Parking Brake (EPB).  It may not be possible to set the MRCC with Stop & Go function system directly after ...
Page 338 When Driving i-ACTIVSENSE How to set the speed 1. Adjust the vehicle speed to the desired setting using the accelerator pedal. 2. Headway control begins when the SET or SET switch is pressed. The set speed and the inter-vehicle distance display filled with white lines is displayed. The MRCC with Stop &...
Page 339 When Driving i-ACTIVSENSE Headway control is not possible if the vehicle ahead is driving faster than your vehicle's  set speed. Adjust the system to the desired vehicle speed using the accelerator pedal. How to set the distance-between-vehicles during headway control The distance-between-vehicles is set to a shorter distance by pressing the switch.
Page 340 When Driving i-ACTIVSENSE When the ignition is switched to ACC or OFF and then the engine is started again, the  system automatically sets the distance-between-vehicles to the previous setting. How to change the set vehicle speed NOTE The setting speed can be changed by To accelerate/decelerate using the SET ...
Page 341 When Driving i-ACTIVSENSE The selector lever is in the P (Park), N NOTE  If the set speed is not indicated in the (Neutral), or R (Reverse) position. display, the control does not resume even if the RES switch is pressed. Under the following conditions, the MRCC with Stop &...
Page 342 When Driving i-ACTIVSENSE ▼ Stop Hold Control While in headway control using the MRCC with Stop & Go function system, your vehicle will stop when a vehicle ahead stops. When the vehicle is stopped and the stop hold control operates, the MRCC with Stop & Go function indicator light turns on. NOTE If the MRCC with Stop &...
Page 343 When Driving i-ACTIVSENSE If the vehicle ahead starts moving within 3 seconds after your vehicle is stopped by the  stop hold control, headway control will resume even if you do not resume driving your vehicle, such as by depressing the accelerator pedal. Resume driving information If you do not resume driving within a few seconds after the vehicle ahead starts moving, the multi-information display vehicle-ahead indication flashes to urge the driver to resume...
Page 344 When Driving i-ACTIVSENSE To increase speed using accelerator WARNING pedal Depress the accelerator pedal and press the Always turn off the cruise control function SET or SET switch at the desired when it is not in use: speed. Leaving the cruise control function turned If the switch is not operated, the system on when it is not in use is dangerous as it returns to the set speed after you release...
Page 345 When Driving i-ACTIVSENSE NOTE If the vehicle speed decreases by about  15 km/h (9.4 mph) or more than the set speed, the cruise control function may be cancelled. When the vehicle speed is less than 21  km/h (13 mph), the cruise control function is cancelled.
Page 346 When Driving i-ACTIVSENSE Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) The LAS & LDWS alerts the driver that the vehicle may be deviating from its lane and it provides steering assistance to help the driver stay within the vehicle lanes. The Forward Sensing Camera (FSC) detects the white lines (yellow lines) of the vehicle lane in which the vehicle is travelling and if the system determines that the vehicle may deviate from its lane, it operates the electric power steering to assist the driver's steering...
Page 347 Do not modify the suspensions. Always use wheels of the specified type and size for the front and rear wheels. Consult an expert repairer, we recommend an Authorised Mazda Repairer for tyre replacement. NOTE When the direction indicator lever is operated for a lane change, the LAS & LDWS is ...
Page 348 When Driving i-ACTIVSENSE If the steering wheel, accelerator pedal, or brake pedal is operated abruptly and the  vehicle moves close to a white (yellow) line, the system determines that the driver is making a lane change and the LAS & LDWS operation is temporarily cancelled. The LAS &...
Page 349 When Driving i-ACTIVSENSE There are various road markings or lane markings of various shapes near an  intersection. ▼ System Operation standby. When all of the following conditions are met, the LAS & LDWS Make sure that the LAS & LDWS OFF indication (white) is displayed in the indicator light in the instrument cluster is multi-information display, and the system...
Page 350 When Driving i-ACTIVSENSE NOTE When the system detects a white  The LAS & LDWS indication is grey when (yellow) lane line on one side only, the the system detects only a white (yellow) system will not operate the steering line on either the left or right, and the wheel operation assist and the indication changes to white when the...
Page 351 When Driving i-ACTIVSENSE If the driver takes his or her hands off Steering operation assist operational/   the steering wheel (not holding the non-operational steering wheel), the warning sound is Cancel sensitivity (likelihood of  activated and an alert is indicated in the steering assist) multi-information display or the active Vehicle lane line display...
Page 352 When Driving i-ACTIVSENSE Auto cancel The driver takes his/her hands off the  steering wheel. In the following cases, the LAS & LDWS (The LAS & LDWS is designed to is automatically cancelled, the LAS & assist the driver's steering operation LDWS warning indication (amber) turns and it will resume operation on, and an alert is displayed.
Page 353 When Driving i-ACTIVSENSE The system becomes operational when all Vehicle lane line display of the following conditions are met. When the LAS & LDWS becomes operational while on standby, the vehicle The system detects white (yellow) lane  lane lines are displayed in the lines on both the right and left sides or multi-information display.
Page 354 Have your cancelled automatically. The LAS & vehicle inspected at an expert repairer, LDWS resumes automatically after the we recommend an Authorised Mazda operation. Repairer. The steering wheel is operated abruptly. ...
Page 355 When Driving i-ACTIVSENSE ▼ Lane Departure Warning If the system determines that the vehicle may deviate from its lane, the lane departure warning (beep sound, rumble sound , or steering wheel vibration) is activated and the direction in which the system determines that the vehicle may deviate is indicated in the multi-information display or the active driving display.
Page 356 When Driving i-ACTIVSENSE The rumble sound is a reproduction of the sound which occurs when a vehicle passes over a rumble strip. Rumble Groove 4-198...
Page 357: Adjustable Speed Limiter (Asl)
When Driving i-ACTIVSENSE Adjustable Speed Limiter (ASL) The ASL is a function to prevent the vehicle from being driven at a vehicle speed faster than a set speed. The vehicle speed is controlled to kept it below the set speed even if the accelerator pedal is depressed.
Page 358 Instrument Cluster Type B Instrument Cluster Type C *1: Needle indicates set speed. Cruise control system Mazda Radar Cruise Control (MRCC) or Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) MODE switch SET+ switch RES/+ switch...
Page 359 When Driving i-ACTIVSENSE ▼ Adjustable Speed Limiter (ASL) Main Indication (White)/Adjustable Speed Limiter (ASL) Set Indication (Green) The indication has 2 colours. ASL main indication (white) The indication is display in white when the MODE switch is pressed and the ASL is activated.
Page 360 When Driving i-ACTIVSENSE With Mazda Radar Cruise Control (MRCC) or Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) Displays when the SET or SET switch is operated and the speed is set. Active Driving Display...
Page 361 When Driving i-ACTIVSENSE Accelerator pedal is strongly depressed  Active Driving Display Instrument Cluster Instrument Cluster Instrument Cluster Type A Type B Type C ▼ Speed Limiter Warning Beep Indicated in instrument cluster If the vehicle speed exceeds the set speed by about 5 km/h (3 mph) or more, a warning sound operates continuously and the ASL display flashes at the same time.
Page 362 5 km/h (3 mph). Be careful not to drive over the set speed. (With Mazda Radar Cruise Control (MRCC) or Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function))
Page 363 When the MODE switch is pressed while the ASL is operating, the system switches NOTE to the cruise control, Mazda Radar Cruise When the ignition is switched off, the Control (MRCC), or Mazda Radar Cruise system status before it was turned off is Control with Stop &...
Page 364 (With cruise control) times.  When the vehicle set speed is displayed (With Mazda Radar Cruise Control in the instrument cluster, press the RES/ (MRCC) or Mazda Radar Cruise switch to set the displayed vehicle Control with Stop & Go function speed.
Page 365 Press the RES/ switch to resume the operation at the previous set speed. The ASL display remains displayed. With Mazda Radar Cruise Control (MRCC) or Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) Press the RES switch to resume the operation at the previous set speed.
Page 366 When Driving i-ACTIVSENSE Advanced Smart City Brake Support (Advanced SCBS) The Advanced SCBS alerts the driver of a possible collision using the display and a warning sound when the Forward Sensing Camera (FSC) detects a vehicle ahead or pedestrian and determines that a collision with the object is unavoidable while the vehicle is driven at a vehicle speed of about 4 to 80 km/h (2 to 50 mph) if the object is a vehicle ahead and about 10 to 80 km/h (6.2 to 50 mph) if the object is a pedestrian.
Page 367 When Driving i-ACTIVSENSE The vehicle is being towed or when towing another vehicle. The vehicle is on a chassis roller. When driving on rough roads such as in areas of dense grass or off-road. Refer to Stopping the Advanced Smart City Brake Support (Advanced SCBS) System Operation on page 4-210 on how to turn off the Advanced SCBS system.
Page 368 When Driving i-ACTIVSENSE ▼ Smart City Brake Support (SCBS) If the vehicle is stopped by the Advanced  SCBS operation and the brake pedal is Indicator Light (Red) not depressed, the warning beep sounds If the Advanced SCBS is operating, the 1 time after about 2 seconds and the indicator light (red) flashes.
Page 369 When Driving i-ACTIVSENSE (SCBS) OFF indicator light in the instrument cluster will illuminate. Press the switch again to turn the system back on. The Smart City Brake Support (SCBS) OFF indicator light will turn off. 4-211...
Page 370: Smart City Brake Support [Forward] (Scbs F)
When Driving i-ACTIVSENSE Smart City Brake Support [Forward] (SCBS F) The SCBS F system alerts the driver of a possible collision using an indication in the display and a warning sound when the Forward Sensing Camera (FSC) detects a vehicle ahead and determines that a collision with a vehicle ahead is unavoidable while the vehicle is being driven at a vehicle speed of about 4 to 80 km/h (2 to 50 mph).
Page 371 When Driving i-ACTIVSENSE CAUTION In the following cases, turn the system off to prevent a mis-operation: The vehicle is being towed or when towing another vehicle. The vehicle is on a chassis roller. When driving on rough roads such as in areas of dense grass or off-road. Refer to Stopping the Smart City Brake Support [Forward] (SCBS F) system Operation on page 4-214 on how to turn off the SCBS F system.
Page 372 When Driving i-ACTIVSENSE If you suddenly come close to a vehicle ahead.  2-wheeled vehicles, pedestrians, animals or standing trees.  Vehicle is driven with some of the tyres having significant wear.  (Manual transaxle)  If the vehicle is stopped by the Smart City Brake Support (SCBS) operation and the clutch pedal is not depressed, the engine stops.
Page 373 When Driving i-ACTIVSENSE When the SCBS F system is turned off, the Smart City Brake Support (SCBS) OFF indicator light turns on. When the engine is restarted, the system becomes operational. Without SCBS OFF switch Refer to Personalisation Features on page 9-13.
Page 374: Smart City Brake Support [Reverse] (Scbs R)
(rear), stop using the SCBS R system immediately and have your vehicle inspected by an expert repairer, we recommend an Authorised Mazda Repairer. If the vehicle continues to be driven with cracks or scratch marks left around an ultrasonic sensor, the system may operate unnecessarily and cause an unexpected accident.
Page 375 When Driving i-ACTIVSENSE Do not apply a strong force to an ultrasonic sensor (rear): When washing the vehicle, do not spray highly pressurised water against an ultrasonic sensor (rear), or rub it strongly. In addition, do not hit the rear bumper forcefully when loading and unloading cargo Otherwise, the sensors may not detect obstructions correctly which could cause the SCBS R system to not operate normally, or it could operate unnecessarily.
Page 376 When Driving i-ACTIVSENSE The height of the obstruction is high such as trucks with high loading platforms.  The obstruction is small.  The obstruction is thin such as a signpost.  The obstruction is positioned away from the centre of the vehicle. ...
Page 377 When Driving i-ACTIVSENSE The Smart City Brake Support (SCBS) warning indication (amber) turns on when the  system has a malfunction. Refer to Taking Action on page 7-54. ▼ Automatic Brake Operation Display When the SCBS R system is turned off, the Smart City Brake Support (SCBS) “SCBS Automatic Brake”...
Page 378: Smart Brake Support (Sbs)
When Driving i-ACTIVSENSE Smart Brake Support CAUTION (SBS) In the following cases, turn the system off to prevent a mis-operation: The SBS system alerts the driver of a possible collision using a display and The vehicle is being towed or when warning sound if the radar sensor (front) towing another vehicle.
Page 379 When Driving i-ACTIVSENSE When warnings and messages, such ▼ Collision Warning  as a dirty windscreen, related to the If there is the possibility of a collision with Forward Sensing Camera (FSC) are a vehicle ahead, the beep sounds being displayed in the continuously and a warning is indicated in multi-information display.
Page 380 When Driving i-ACTIVSENSE 360° View Monitor The 360° View Monitor consists of the following functions which assist the driver in checking the area surrounding the vehicle using various indications in the centre display and a warning sound while the vehicle is being driven at low speeds or while parking. Top view ...
Page 381 When Driving i-ACTIVSENSE 360°View Monitor Range : Cameras : Ultrasonic sensors : Radar sensors (rear) WARNING Always confirm the safety of the area around the vehicle with the mirrors and directly with your eyes when driving. The 360°View Monitor is an auxiliary device which assists the driver in checking the safety of the area around the vehicle.
Page 382 Do not rub the camera lens forcefully, or clean it with an abrasive or hard brush. Otherwise, it could scratch the camera lens and negatively affect the images. Consult an Authorised Mazda Repairer for repair, painting, or replacement of the front/rear camera, front bumper and door mirrors.
Page 383 When Driving i-ACTIVSENSE The 360°View Monitor has limitations. Objects under the bumper or near both ends of the  bumper cannot be displayed. Obstructions above the upper image range of the camera are not displayed.  Under the following conditions, the screen might be difficult to view, however this does ...
Page 384 When Driving i-ACTIVSENSE ▼ Types of Images Displayed on the Screen Top view/Front view Displays the image of the area around the vehicle and the vehicle front. Top view screen Front view screen Front wide view Displays the image of the front of the vehicle (wide-area). Side view Displays the image of the left and right sides of the vehicle.
Page 385 When Driving i-ACTIVSENSE Top view/Rear view Displays the image of the area around the vehicle and the rear of the vehicle. Top view screen Rear view screen Rear wide view Displays the image of the rear of the vehicle (wide-area). 4-227...
Page 386 When Driving i-ACTIVSENSE ▼ How to Use the System Top view/Front view, Front wide view, Side view Indication Images are displayed on the screen when the 360°View Monitor switch is pressed with all of the following conditions met. The ignition is switched ON. ...
Page 387 When Driving i-ACTIVSENSE Display switching You can change the displayed screen by pressing the commander knob or by touching the switch camera icon on the screen while the top view/front view, front wide view, or the side view is displayed. Switch camera icon Top view/Front view Front wide view...
Page 388 When Driving i-ACTIVSENSE When a switch around the commander knob is pressed.  (Manual transaxle)  The parking brake is applied. (Automatic transaxle)  The selector lever is shifted to P position (displayed when the selector lever is in a position other than P).
Page 389 When Driving i-ACTIVSENSE Display switching The displayed screen can be switched by pressing the commander knob or by touching the switch camera icon on the screen while the top view/rear view, rear wide view is displayed. Switch camera icon Top view/Rear view Rear wide view NOTE The top view/rear view and rear wide view automatically display whether or not the 360°...
Page 390 When Driving i-ACTIVSENSE Screen operation/icon WARNING Always stop the vehicle when adjusting the 360°View Monitor image quality. Do not adjust the 360°View Monitor image quality while driving. If you adjust the 360° View Monitor image quality (such as brightness, contrast, tone, and colour density) while driving, it could lead to an unexpected accident.
Page 391 When Driving i-ACTIVSENSE Display range (Screen display) (Actual condition) Target object NOTE In the top view screen, the areas in black at the front and rear of the vehicle image and the  seams where each of the camera images merge are blind spots. Because images displayed in the top view screen are processed from each camera, the top ...
Page 392 When Driving i-ACTIVSENSE Viewing the screen (When the projected vehicle (When the projected vehicle path line display is on) path line display is off) Display/Icon Content Parking sensor view Displays the parking sensor detection condition when the parking sensor is activated. For details, refer to the parking sensor obstruction detection indication and warning sound.
Page 393 When Driving i-ACTIVSENSE CAUTION The parking sensor detection range has limitations. For example, obstructions closing in from the side and objects short in height may not be detected. Always confirm the safety around the vehicle visually when driving. For details, refer to the parking sensor obstruction detection indication and warning sound. Refer to Parking Sensor System on page 4-287.
Page 394 When Driving i-ACTIVSENSE Display range (Screen display) (Actual condition) Target object Viewing the screen Display/Icon Content Extended vehicle width lines and dis- Indicates the approximate width of the vehicle and the distance tance guide lines (red/blue) (from front end of bumper) in front of the vehicle. The red lines indicate the points up to about 0.5 m (20 in) ...
Page 395 When Driving i-ACTIVSENSE NOTE The parking sensor obstruction detection indication does not display. Switch the screen  display to the top view/front view or side view display if the parking sensor warning sound is activated. The front wide view screen displays the image in front of the vehicle at a wide angle and ...
Page 396 When Driving i-ACTIVSENSE Display/Icon Content Projected vehicle path lines (amber) Indicates the approximate projected path of the vehicle. Moves in conjunction with the steering wheel operation. The projected vehicle path lines (amber) indicate the path the inner side of the vehicle is expected to travel. Vehicle parallel guide lines (blue) Indicates the approximate vehicle width including the door mirrors.
Page 397 When Driving i-ACTIVSENSE Do not turn the steering wheel any more until the vehicle has passed the obstruction, even if the obstruction is not visible on the side view image. If the steering wheel is turned even more, the vehicle may contact the obstruction if it is turned sharply. NOTE Because there might be a difference between the image displayed on the screen and the ...
Page 398 When Driving i-ACTIVSENSE If an image containing an object with a conspicuous colour is picked up by any of the  cameras, the whole screen may be affected and it may display in that colour. Obstructions displayed in the rear view may not display on the top view screen. ...
Page 399 When Driving i-ACTIVSENSE Display/Icon Content Projected vehicle path distance guide These guide lines indicate the approximate distance to a point lines (red/amber) measured from the rear of the vehicle (from the end of the bumper). The red line indicates the point about 0.5 m (20 in) from the ...
Page 400 When Driving i-ACTIVSENSE 1. Back the vehicle into the parking space by turning the steering wheel so that the vehicle enters the centre of the parking space. (Screen display) (Actual condition) 2. After the vehicle starts entering the parking space, stop and adjust the steering wheel so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal, and then continue backing up slowly.
Page 401 When Driving i-ACTIVSENSE Range of displayed screen image (Screen display) (Actual condition) Target object Viewing the screen Display/Icon Content Extended vehicle width lines and dis- These guide lines indicate the approximate width of the vehi- tance guide lines (red/blue) cle and distance to a point measured from the rear of the vehi- cle (from the end of the bumper).
Page 402 When Driving i-ACTIVSENSE Display/Icon Content Blind Spot Monitoring (BSM) warning Indicates when the Rear Cross Traffic Alert (RCTA) has oper- lights ated. For details, refer to Rear Cross Traffic Alert (RCTA). Refer to Rear Cross Traffic Alert (RCTA) on page 4-158. NOTE The parking sensor obstruction detection indication does not display.
Page 403 When Driving i-ACTIVSENSE Side camera Obstruction Margin of error Rear camera Margin of error Obstruction There is a steep up or down grade in the road at the front or rear of the vehicle If there is a steep up or down grade in the road at the front or rear of the vehicle, obstructions picked up by the camera can appear farther or closer than the actual distance from the vehicle.
Page 404 When Driving i-ACTIVSENSE Front camera Appears further than Appears closer than actual distance actual distance Actual obstruction Obstruction appearing Obstruction appearing on screen on screen Actual obstruction A: Distance of obstruction being viewed on screen B: Actual distance of obstruction from vehicle Side camera Appears further than Appears closer than...
Page 405 Centre display indication Cause Action to be taken “No image signal reception” is dis- Have your vehicle inspected The control unit might be damaged. played by an Authorised Mazda Re- pairer. Screen is pitch-black and blank The camera might be damaged. 4-247...
Page 406: Forward Sensing Camera (Fsc)
Advanced Smart City Brake Support (Advanced SCBS)  Smart City Brake Support [Forward] (SCBS F)  Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)  Smart Brake Support (SBS)  Forward Sensing Camera (FSC) The Forward Sensing Camera (FSC) determines the conditions ahead of the vehicle while travelling at night and detects traffic lanes.
Page 407 Always keep the windscreen glass around the camera clean by removing dirt or fogging. Use the windscreen defroster to remove fogging on the windscreen. Consult an expert repairer, we recommend an Authorised Mazda Repairer regarding cleaning the interior side of the windscreen around the Forward Sensing Camera (FSC).
Page 408 Advanced Smart City Brake Support (Advanced SCBS) Smart City Brake Support [Forward] (SCBS F) Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) Smart Brake Support (SBS) The direction in which the Forward Sensing Camera (FSC) is pointed has been finely adjusted.
Page 409 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) warning  indication Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go  function) warning indication Smart Brake Support/Smart City Brake Support (SBS/SCBS) warning indication/ ...
Page 410 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) warning  indication Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go  function) warning indication Smart Brake Support/Smart City Brake Support (SBS/SCBS) warning indication/ ...
Page 411 When Driving i-ACTIVSENSE A pedestrian is in a dark location such as during the night, or blends into the  background by wearing clothes matching the background colour. 4-253...
Page 412 Your vehicle is equipped with a radar sensor (front). The following systems also use the radar sensor (front). Mazda Radar Cruise Control (MRCC)  Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)  Distance Recognition Support System (DRSS) ...
Page 413 Do not remove, disassemble, or modify the radar sensor (front). For repairs, replacement or paint work around the radar sensor (front), consult an Authorised Mazda Repairer. Do not modify the suspension. If the suspension are modified, the vehicle's posture could change and the radar sensor (front) may not be able to correctly detect a vehicle ahead or an obstruction.
Page 414 When Driving i-ACTIVSENSE When driving on roads with little traffic  and few vehicles ahead or obstructions for the radar sensor (front) to detect, “Front radar blocked” may be temporarily displayed, however, this does not indicate a problem. The radar sensors are regulated by the ...
Page 415 If the rear bumper receives a severe impact, the system may no longer operate normally. Stop the system immediately and have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. NOTE The detection ability of the radar sensors (rear) has limitations. In the following cases, ...
Page 416 For repairs or replacement of the radar sensors (rear), or bumper repairs, paintwork, and  replacement near the radar sensors, consult an expert repairer, we recommend an Authorised Mazda Repairer. Turn off the system while pulling a trailer or while an accessory such as a bicycle carrier ...
Page 417 When Driving i-ACTIVSENSE Ultrasonic Sensor (Rear) The ultrasonic sensors (rear) function by emitting ultrasonic waves which are reflected off obstructions at the rear and the returning ultrasonic waves are picked up by the ultrasonic sensors (rear). Ultrasonic sensor (rear) The ultrasonic sensors (rear) are mounted in the rear bumper. 4-259 *Some models.
Page 418 When Driving i-ACTIVSENSE Front Camera/Side Cameras/Rear Camera Your vehicle is equipped with a front camera, side cameras, and a rear camera. The 360° View Monitor uses each camera. The front camera, side cameras, and rear camera shoot images of the area surrounding the vehicle.
Page 419 NOTE If your Mazda has the following steering switch, your Mazda is equipped the Mazda Radar Cruise Control (MRCC) system or the Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) system.
Page 420 When Driving Cruise Control Refer to Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) on page 4-174. switch SET+ switch RES switch switch SET- switch MODE switch CANCEL switch OFF switch ▼ Cruise Main Indication (White)/...
Page 421 When Driving Cruise Control NOTE (Vehicles with Adjustable Speed  When the ignition is switched OFF, the Limiter (ASL)) system status before it was turned off is The MODE switch for the Adjustable maintained. For example, if the ignition is Speed Limiter (ASL) is pressed.
Page 422 When Driving Cruise Control The vehicle speed preset using the cruise Increasing speed with a single RES/ control is displayed in the instrument switch operation cluster. Instrument cluster display for vehicle Instrument Cluster speed indicated in km/h: 1 km/h (0.6 mph) Type A Type B Instrument cluster display for vehicle...
Page 423 When Driving Cruise Control ▼ To Resume Cruising Speed at More When the cruise control system is  Than 25 km/h (16 mph) temporarily cancelled by even one of the applicable cancel conditions, the speed If the cruise control system temporarily cannot be re-set.
Page 424 If tyre pressure is too low in one or more tyres, the system will inform the driver via the warning light in the instrument cluster and by the warning beep sound. Refer to Contact Authorised Mazda Repairer and Have Vehicle Inspected on page 7-45. Refer to Taking Action on page 7-54.
Page 425 When the warning light flashes, there may interference with the receiver unit. be a system malfunction. Consult an A digital device such as a personal Authorised Mazda Dealer.  computer. A system error activation may occur in the A current converter device such as a following cases: ...
Page 426 Authorised Mazda Dealer change your wheels or both, have the work done by tyre and complete ID signal code an Authorised Mazda Dealer, or the tyre registration. pressure sensors may be damaged. The wheels equipped on your Mazda are...
Page 427 For purchase of a tyre pressure sensor and registration of the tyre pressure sensor ID signal code, consult an Authorised Mazda Dealer. When reinstalling a previously removed  tyre pressure sensor to a wheel, replace the grommet (seal between valve body/ sensor and wheel) for the tyre pressure sensor.
Page 428 PM may not be removed and the an expert repairer, we recommend an diesel particulate filter indicator light may Authorised Mazda Repairer. If the vehicle is illuminate under the following conditions: not inspected and continues to be driven, If the vehicle is driven at 15 km/h (9 ...
Page 429 If the diesel particulate filter indicator light starts flashing, have the vehicle inspected immediately at an expert repairer, we recommend an Authorised Mazda Repairer. If the vehicle is not inspected and continues to be driven, the engine may malfunction.
Page 430 SCR warning light turns on/flashes. Refer to Selective Catalytic Reduction (SCR) System Indications on page 4-272. ® In this case, consult an Authorised Mazda Dealer. If AdBlue needs to be replenished, add ® AdBlue following the specified procedure.
Page 431 . If there is a problem with the SCR system/AdBlue , consult an Authorised Mazda Repairer. The vehicle speed may be restricted for a while even if the warning light turned off after having the vehicle repaired. To cancel the vehicle speed restriction immediately, switch the ignition OFF after the warning light turns off, and then switch the ignition ON again.
Page 432 When Driving Selective Catalytic Reduction (SCR) System Multi-information display indi- Driving restric- Status Warning sound warning cation tion light Vehicle continues to be driven with Sound is activated when ® AdBlue in diluted remaining-dis- Engine restarting Flashes form tance-to-empty indication not possible (Maximum driving is 0 km (0 miles)
Page 433 When Driving Rear View Monitor Rear View Monitor The rear view monitor provides visual images of the rear of the vehicle when reversing. WARNING Always drive carefully confirming the safety of the rear and the surrounding conditions by looking directly with your eyes: Reversing the vehicle by only looking at the screen is dangerous as it may cause an accident or a collision with an object.
Page 434 When Driving Rear View Monitor When replacing the tyres, consult an expert repairer, we recommend an Authorised Mazda  Repairer. Replacing the tyres could result in deviation of the guide lines which appear on the display. If the vehicle's front, side, or rear has been involved in a collision, the alignment of the ...
Page 435 When Driving Rear View Monitor ▼ Displayable Range on the Screen The images on the screen may be different from the actual conditions. (Screen display) Garnish Obstruction detection indication in parking sensor system Bumper (Actual view) Object NOTE The displayable range varies depending on the vehicle and road conditions. ...
Page 436 When Driving Rear View Monitor ▼ Viewing the Display Predicted vehicle path assist lines display type The projected path guidance mode displays the predicted path of the vehicle after you turn the steering wheel. Use this mode for parking your vehicle in a parking space or garage. a) Projected vehicle path (yellow) These lines are displayed as a reference for the projected path of the vehicle.
Page 437 When Driving Rear View Monitor Always check the area to the vehicle's rear and the surrounding area directly with your eyes while backing up. Fixed assist lines display type Guide lines which indicate the width of the vehicle (yellow) are displayed on the screen as a reference to the approximate width of the vehicle in comparison to the width of the parking space you are about to back into.
Page 438 When Driving Rear View Monitor Predicted vehicle path assist lines display type NOTE The following shows an example of vehicle parking in which the steering wheel is turned to the right when backing up the vehicle. The operation is reversed when backing up the vehicle from the opposite direction.
Page 439 When Driving Rear View Monitor 3. After your vehicle begins entering the parking space, continue backing up slowly so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal. (Display condition) (Vehicle condition) 4.
Page 440 When Driving Rear View Monitor NOTE Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes. In the image of the parking space (or garage) displayed on the screen, the back end and ...
Page 441 When Driving Rear View Monitor 2. Confirming the surrounding conditions, reverse the vehicle. (Display condition) (Vehicle condition) 3. After your vehicle begins entering the parking space, continue backing up slowly so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal.
Page 442 When Driving Rear View Monitor NOTE Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes. In the image of the parking space (or garage) displayed on the screen, the back end and ...
Page 443 When Driving Rear View Monitor When there is a steep grade behind the vehicle When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the screen appears farther (downgrade: closer) than the actual distance. Appears Appears farther than closer than actual...
Page 444 When Driving Rear View Monitor When reversing near a three-dimensional object When reversing near an overhanging object, the vehicle may hit the object even if the anticipated course line does not contact the object on the screen. The position of the object displayed on the screen is different from the actual position because the anticipated course lines on the screen are displayed based on a horizontal road surface.
Page 445 When Driving Parking Sensor System Parking Sensor System The parking sensors use ultrasonic sensors which detect obstructions around the vehicle when the vehicle is driven at low speeds, such as during garage or parallel parking, and a buzzer sound and detection indicator notify the driver of the approximate distance from the vehicle to the surrounding obstruction.
Page 446 Always have the system inspected at an expert repairer, we recommend an Authorised  Mazda Repairer if any shock is applied to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect obstructions. (With front sensor and front corner sensor) ...
Page 447 When Driving Parking Sensor System ▼ Sensor Detection Range The sensors detect obstructions within the following range. A: About 55 cm (About 21.7 in) B: About 55 cm (About 21.7 in) Rear corner sensor detection range C: About 100 cm (About 39.3 in) Front sensor detection range D: About 150 cm (About 59.1 in) Rear sensor detection range...
Page 448 When Driving Parking Sensor System Display Distance between vehicle and obstruction Without 360° view monitor With 360° view Front Sensor /Front Rear Sensor/Rear Without front sen- With front sensor monitor Corner Sensor Corner Sensor sor and front cor- and front corner ner sensor sensor Yellow...
Page 449 When Driving Parking Sensor System ▼ Park Assist Sensor System Operation Vehicles without front sensor/front corner sensor The parking sensors can be used when the shift lever/selector lever is shifted to the R position with the ignition switched ON. Vehicles with front sensor/front corner sensor When the parking sensor switch is pressed with the ignition switched ON, the buzzer sounds and the indicator light turns on.
Page 450 When Driving Parking Sensor System As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the vehicle illuminates. Without 360° view monitor With 360° view monitor Front sensor Front sensor Left front Right front Left front Right front corner sensor corner sensor...
Page 451 If the system does soiling not recover, have the vehi- cle inspected at an expert repairer, we recommend an Authorised Mazda Re- pairer. ▼ Parking Sensor Warning Beep The beeper sounds as follows while the system is operating. Front Sensor...
Page 452 When Driving Parking Sensor System Distance between vehicle and obstruction Distance Detec- Beeper sound tion area Rear Sensor Front Sensor Approx. 60―45 cm (23.6―17.7 Approx. 60―45 cm (23.6―17.7 Medium intermit- Far distance tent sound Approx. 45―35 cm (17.7―13.7 Approx. 45―35 cm (17.7―13.7 Fast intermittent Middle distance sound...
Page 453 The system may have a malfunction. Have the vehicle inspected at an expert pressed at a vehicle speed of 10 repairer, we recommend an Authorised Mazda Repairer as soon as possible. km/h (6 mph) or less. The system may have a malfunction. Have the vehicle inspected at an expert The beep sound is not heard.
Page 454 MEMO 4-296...
Page 455 Interior Features Use of various features for ride comfort, including air-conditioning and audio system. Air-Conditioning System....5-4 Audio Set [Type B Operating Tips......5-4 (touchscreen)]........5-66 Vent Operation......5-5 Basic Operation Method.....5-66 Manual Type......... 5-7 Home screen....... 5-70 Fully Automatic Type....5-11 Volume/Display/Sound Controls........
Page 456 Interior Equipment....... 5-145 Sunvisors........5-145 Interior Lights......5-145 Accessory Sockets....5-149 USB Power Outlet ....5-151 Cup Holder....... 5-152 Bottle Holder......5-153 Storage Compartments..... 5-153 Removable Ashtray ....5-157 *Some models.
Page 457 MEMO...
Page 458: Interior Features
For details, consult an expert repairer, with the ignition switched ON when the we recommend an Authorised Mazda engine is not running. Repairer. (With i-stop) ...
Page 459: Vent Operation
Interior Features Air-Conditioning System Centre Vents Vent Operation Knob Open ▼ Adjusting the Vents Directing airflow To adjust the direction of airflow, move Close the adjustment knob. Dial * Some models NOTE Rear Vents When using the air conditioner under ...
Page 460 Interior Features Air-Conditioning System ▼ Selecting the Airflow Mode Instrument panel Vents Defroster and Floor Vents Defroster Vents Instrument panel and Floor Vents Floor Vents * With rear vents NOTE The location airflow exits the air vents and the airflow amount may change depending on the open or close status of the air vents.
Page 461: Manual Type
Interior Features Air-Conditioning System Manual Type Temperature control dial Fan control dial Mode selector dial A/C switch Air intake selector switch Rear window defogger switch ▼ Control Switches A/C switch Press the A/C switch to turn the air Temperature control dial conditioner on.
Page 462 Interior Features Air-Conditioning System Recirculated air position (indicator light NOTE illuminated) If the windscreen fogs up easily, set the  mode selector dial to the position. Outside air is shut off. Use this position If cooler air is desired at face level, set when going through tunnels, driving in ...
Page 463 Interior Features Air-Conditioning System NOTE WARNING When maximum cooling is desired, set  the temperature control dial to the Do not defog the windscreen using the extreme cold position and set the air position with the temperature control set intake selector to the recirculated air to the cold position: position, then turn the fan control dial Using the...
Page 464 Interior Features Air-Conditioning System NOTE One of the functions of the air conditioner is dehumidifying the air and, to use this function, the temperature does not have to be set to cold. Therefore, set the temperature control dial to the desired position (hot or cold) and turn on the air conditioner when you want to dehumidify the cabin air.
Page 465: Fully Automatic Type
Interior Features Air-Conditioning System Fully Automatic Type Air-conditioning system information is displayed on the display. Airflow display Air intake selector Windscreen defroster switch (recirculated air position) Rear window defogger switch Air intake selector (outside air position) SYNC (synchronized Power switch AUTO switch temperature) switch Driver temperature...
Page 466 Interior Features Air-Conditioning System Temperature control dial Fan control switch This dial controls temperature. Turn it The fan has 7 speeds. The selected speed clockwise for hot and anticlockwise for will be displayed. cold. Mode selector switch When the SYNC switch is on: ...
Page 467 Interior Features Air-Conditioning System The A/C ECO function is designed to Interconnection mode (indicator light  economize use of the air-conditioning turns on) system. “A/C ECO” is displayed to The set temperature for the driver and indicate that the air-conditioning system front passenger is controlled is operating at optimum control.
Page 468 Interior Features Air-Conditioning System To turn off the system, press the power NOTE Use the temperature control dial to switch. increase the air flow temperature and NOTE defog the windscreen more quickly. Turn the temperature control dial to  ▼ Sunlight/Interior temperature adjust the temperature between 15 °C sensor (60 °F) and 29 °C (84 °F).
Page 469: Before Using The Audio System
Interior Features Before Using the Audio System Audio Control Switch ▼ Mute Switch Press the mute switch ( ) once to mute ® Without Bluetooth Hands-Free audio, press it again to resume audio output. NOTE If the ignition is switched off with the audio muted, the mute will be cancelled.
Page 470 Interior Features Before Using the Audio System Radio stations which have been previously DVD (Type B) stored in the auto memory tuning (Type Press the seek switch ( ) to skip forward A)/favourite radio (Type B) can be called to the beginning of the next chapter. up by pressing the seek switch ( , Press the seek switch ( ) to return to the while any radio station stored in the auto...
Page 471: Aux/Usb Mode
A)........... page 5-30 system. For vehicles with the navigation ④ How to use AUX mode (Type system, the SD card (Mazda genuine) with B)........... page 5-85 stored map data is inserted into the SD ⑤ How to use USB mode (Type card slot and used.
Page 472 Interior Features Before Using the Audio System ▼ How to connect USB port/Auxiliary CAUTION jack Depending on the portable audio device, Type A noise may occur when the device is connected to the vehicle accessory socket. USB port Auxiliary jack (If noise occurs, do not use the accessory socket.) NOTE...
Page 473: Aerial
Interior Features Before Using the Audio System 2. If there is a cover on the auxiliary jack Aerial or USB port, remove the cover. (Type ▼ Type A 3. Connect the device plug/connector The aerial is embedded into the rear lead to the auxiliary jack/USB port.
Page 474: Audio Set [Type A (Non-Touchscreen)]
Interior Features Audio Set [Type A (non-touchscreen)] Power/Volume/Sound Controls Audio display Menu button Power/Volume/Audio control dial ▼ Power ON/OFF Setting value Indication Turn Anti- Turn Switch the ignition to ACC or ON. Press clockwise Clockwise the power/volume dial to turn the audio system on.
Page 475 Interior Features Audio Set [Type A (non-touchscreen)] *2 Depending on the model, this function BT SETUP mode may not be available. Music and other audio such as voice data NOTE recorded on portable audio devices and If not operated for several seconds, the mobile phones available on the market display returns to the previous display.
Page 476: Clock
Interior Features Audio Set [Type A (non-touchscreen)] Clock :00 button Audio control dial Audio display Clock button Menu button Hour/Minute set switch 3. When the button is pressed, the time ▼ Setting the time will be reset as follows: The clock can be set at any time when the (Example) ignition is switched to ACC or ON.
Page 477: Operating The Radio
Interior Features Audio Set [Type A (non-touchscreen)] Operating the Radio Without Radio Data System (RDS) Audio display Channel preset buttons Scan button Tuning button Auto memory button Band selector button With Radio Data System (RDS) Audio display Channel preset buttons Programme-type information button Tuning button Scan button...
Page 478 Interior Features Audio Set [Type A (non-touchscreen)] Seek tuning 3. Repeat this operation for the other stations and bands you want to store. Automatic search for radio stations starts To tune one in the memory, select AM when the tuning button ( , ) is pressed (Without Radio Data System (RDS)), until a beep sound is heard.
Page 479 Interior Features Audio Set [Type A (non-touchscreen)] Alternative frequency (AF) Press the programme-type information button ( , ) while in FM mode. The AF functions on FM stations. Press the programme-type code and “PTY” will be menu button ( ) and select the AF displayed during reception.
Page 480: How To Use Aux Mode
Interior Features Audio Set [Type A (non-touchscreen)] Emergency broadcast How to use AUX mode If an emergency broadcast is received, the 1. Switch the ignition to ACC or ON. emergency broadcast intercedes even 2. Press the power/volume dial to turn the while using other functions (FM, USB audio system on.
Page 481: How To Use Usb Mode
Interior Features Audio Set [Type A (non-touchscreen)] How to use USB mode Random button Audio display Repeat button Text button Play/Pause button Folder up button Track down/Reverse button Media/Scan button Track up/Fast-forward button Folder down button Playback of the USB device is in the Type Playable data ...
Page 482 Interior Features Audio Set [Type A (non-touchscreen)] Track search Folder repeat Press the track up button ( ) once to skip 1. Press the repeat button (1) during forward to the beginning of the next track. playback, and then press the button Press the track down button ( ) within a again within 3 seconds to play the few seconds after playback begins to track...
Page 483 Interior Features Audio Set [Type A (non-touchscreen)] ▼ Switching the display The information displayed on the audio display changes as follows each time the text button (3) is pressed during playback. Information displayed Button on audio display File number/Elapsed time Folder number/File num- File name Folder name...
Page 484: How To Use Ipod Mode
Interior Features Audio Set [Type A (non-touchscreen)] How to use iPod mode Audio display Text button Play/Pause button Random button Category down button Repeat button Category up button Track down/Reverse button List up button Track up/Fast-forward button Media/Scan button List down button An iPod may not be compatible depending Do not remove the iPod while in the ...
Page 485 Interior Features Audio Set [Type A (non-touchscreen)] Press the track down button ( ) after a Repeat playback few seconds (depends on iPod software 1. Press the repeat button (1) during version) have elapsed to start playback playback to play the current track from the beginning of the current track.
Page 486: Error Indications
If you cannot clear the error indication, take the vehicle Information displayed Button to an expert repairer, we recommend an on audio display Authorised Mazda Repairer. File number/Elapsed time CHECK USB File number When the message “CHECK USB” is...
Page 487: Bluetooth
 connected. CAUTION ® Some Bluetooth mobile devices are not compatible with the vehicle. Consult an Authorised Mazda Repairer, Mazda's call centre or Web support centre for information regarding ® Bluetooth mobile device compatibility: Phone: (Germany) 0800 4263 738 (8:00―18:00 Central European Time) (Except Germany) 00800 4263 7383 (8:00―18:00 Central European Time)
Page 488 Interior Features Audio Set [Type A (non-touchscreen)] Web: http://www.mazdahandsfree.com ® Applicable Bluetooth specification (Recommended) Ver. 2.0 ▼ Component Parts Audio unit Talk button, Pick-up button and Hang-up button Talk button Pick-up button Hang-up button Microphone Microphone Microphone (hands-free) The microphone is used for speaking voice commands or when making a Hands-free call. Talk button Activates the voice recognition.
Page 489 Interior Features Audio Set [Type A (non-touchscreen)] Volume adjustment The power/volume dial of the audio unit is used to adjust the volume. Turn the dial to the right to increase volume, to the left to decrease it. The volume can also be adjusted using the volume button on the steering wheel. NOTE If the volume is lower compared to other audio modes, increase the volume from the device side.
Page 490: Bluetooth ® Preparation
Interior Features Audio Set [Type A (non-touchscreen)] 16. If “Yes”, the system switches to the ® Bluetooth Preparation device registration mode. If “No”, the system returns to standby status. ▼ Bluetooth ® Hands-Free Preparation ▼ Device pairing (Bluetooth ® Pairing code setting Hands-Free) The 4-digit pairing code setting for ®...
Page 491 Device registration can also be done by  to its instruction manual. operating the audio unit. 10. Select “Mazda” from the device list Depending on the device, the  searched by the device. registration status may be lost after a 11.
Page 492 Interior Features Audio Set [Type A (non-touchscreen)] 1. Press the pick-up button or talk button 10. Prompt: “Returning to main menu.” with a short press. ▼ Device selection (Bluetooth ® 2. Say: [Beep] “Setup” Hands-Free) 3. Prompt: “Select one of the following: Pairing options, confirmation prompts, If several devices have been paired, the language, password, select phone or...
Page 493 Interior Features Audio Set [Type A (non-touchscreen)] 3. Prompt: “Select one of the following: 1. Press the pick-up button or talk button Pairing options, confirmation prompts, with a short press. language, password, select phone or 2. Say: [Beep] “Setup” select music player.” 3.
Page 494 Interior Features Audio Set [Type A (non-touchscreen)] 4. Say: [Beep] “Pairing options” ® ▼ Bluetooth Audio Preparation 5. Prompt: “Select one of the following: ® Bluetooth audio device set-up Pair, edit, delete, list, or set pin code.” 6. Say: [Beep] “Edit” ®...
Page 495 Interior Features Audio Set [Type A (non-touchscreen)] With Radio Data System (RDS) Display Mode Function Deleting link to Blue- PAIR DE- Pairing dele- ® LETE tion mode tooth audio device Displaying vehicle's Device infor- DEVICE ® mation dis- Bluetooth unit infor- INFO play mode mation...
Page 496 Interior Features Audio Set [Type A (non-touchscreen)] ® ® Pairing a Bluetooth audio device 5. Operate the Bluetooth audio device which has a four-digit PIN code and set it to the pairing mode while “PAIRING” is flashing. 1. Using the audio control dial, select the 6.
Page 497 Interior Features Audio Set [Type A (non-touchscreen)] 3. Press the audio control dial while “PIN ® ▼ Device selection (Bluetooth Audio) 0000” is displayed. If several devices have been paired, the “PAIRING” flashes on the audio ® Bluetooth unit links the device last display.
Page 498 Interior Features Audio Set [Type A (non-touchscreen)] 4. Turn the audio control dial to select the If a hands-free type mobile phone  name of the device you would like to has been the most recently paired link. ® device, the Bluetooth unit links this device.
Page 499 Interior Features Audio Set [Type A (non-touchscreen)] 4. Rotate the audio control dial and select 7. Press the audio control dial to delete the name of the paired device you the selected device. would like to delete. NOTE Select “GO BACK” and press the Device name 1 audio control dial to return to the “PAIR DELETE”...
Page 500: Available Language
Interior Features Audio Set [Type A (non-touchscreen)] NOTE Available Language When “GO BACK” is selected and the audio control dial is pressed, the The available languages are English, display returns to “DEVICE INFO”. French, Spanish, Italian, German, Dutch, and Portuguese. If the language setting is changed, all of the voice guidance and voice input commands are done in the selected language.
Page 501: Security Setting
Interior Features Audio Set [Type A (non-touchscreen)] NOTE Security Setting Other language settings can also be made while in the current setting by If a password is set, the system cannot be saying the name of the language in the activated unless the password is input.
Page 502 Interior Features Audio Set [Type A (non-touchscreen)] 4. If the correct password is input, voice (Ex. “Calling John's device. Is this guidance “XXXXXX... (Ex. “Mary's correct?”) device”) (Device tag) is connected” is When the confirmation prompt function is announced. turned off: If the password is incorrect, voice (Ex.
Page 503: Bluetooth ® Audio
Interior Features Audio Set [Type A (non-touchscreen)] If a general mobile phone device is USB ® Bluetooth Audio  connected during music playback over ® the Bluetooth connection, the ® Applicable Bluetooth specification ® Bluetooth connection is disconnected. (Recommended) For this reason, you cannot have music Ver.
Page 504 Interior Features Audio Set [Type A (non-touchscreen)] If the current device version is lower Reverse than AVRCP Ver. 1.3: “BT Audio” is Press and hold the reverse down button displayed. If the current device is AVRCP Ver. 1.3: The playback time is displayed. ▼...
Page 505: Bluetooth ® Hands-Free
Interior Features Audio Set [Type A (non-touchscreen)] ® ▼ Bluetooth audio device information ® Bluetooth Hands-Free display ▼ Making a Call ® If a Bluetooth audio device is connected, the following information is displayed in Phonebook Usage the audio display. Telephone calls can be made by saying the name of a person (voice tag) whose phone AVRCP Ver.
Page 506 Interior Features Audio Set [Type A (non-touchscreen)] 2. Say: [Beep] “Phonebook” have been removed.”. Then go back to 3. Prompt: “Select one of the following: Step 13. New entry, edit, list names, delete, 17. Prompt: “Number saved. Would you erase all or import contact.” like to add another number for this 4.
Page 507 Interior Features Audio Set [Type A (non-touchscreen)] 8. Prompt: “Adding XXXXX... (Ex. 9. Prompt: “XXXXX... (Ex. “Mary's “Mary's phone”) (Voice tag). Is this phone”) (Registered voice tag) XXXX correct?” (Ex. “Home”) (Registered location). Is 9. Say: [Beep] “Yes” this correct?” 10.
Page 508 Interior Features Audio Set [Type A (non-touchscreen)] Phonebook data deletion NOTE Do this function only when parked. It is (Erasing individual phonebook data) too distracting to attempt while driving Individual data registered to the and you may make too many errors to be ®...
Page 509 Interior Features Audio Set [Type A (non-touchscreen)] 5. Prompt: “XXXXX..., XXXXX..., Telephone Number Input XXXXX... (Ex. “John's phone”, NOTE Mary's phone, Bill's phone)” (Voice Practice this while parked until you are guidance reads out the voice tags confident you can do it while driving in a registered to the phonebook.) non-taxing road situation.
Page 510 Interior Features Audio Set [Type A (non-touchscreen)] Emergency calls cancelled, and the line can be switched to a standard call using a device (Mobile A call can be made to the emergency phone). phone number (112) using the voice input 1.
Page 511 Interior Features Audio Set [Type A (non-touchscreen)] Method 1 Making calls using the phonebook 1. Press the pick-up button. 1. Press the talk button with a short press. 2. Prompt: “Swapping calls.” 2. Say: [Beep] “Call” 3. Prompt: “Name please.” Method 2 4.
Page 512: Voice Recognition
Interior Features Audio Set [Type A (non-touchscreen)] Commands useable anytime during Voice Recognition voice recognition In this section, the basic operation of the “Help” or “Go Back” are commands voice recognition is explained. which can be used at anytime during voice recognition.
Page 513: Voice Recognition Learning Function (Speaker Enrolment)
Interior Features Audio Set [Type A (non-touchscreen)] Speak clearly, without pausing between Voice Recognition  words or numbers. Learning Function Close the windows to reduce loud noises  from outside the vehicle, or turn down (Speaker Enrolment) the airflow of the air-conditioning ®...
Page 514 Interior Features Audio Set [Type A (non-touchscreen)] 5. The voice guidance reads out the voice 8. Say: [Beep] “0123456789” (Say the input command number (refer to the voice input command for voice voice input command list for voice recognition learning (1 to 8) according recognition learning).
Page 515 Interior Features Audio Set [Type A (non-touchscreen)] NOTE The applicable phrase appears in the  audio display. After user voice registration is  completed, voice guidance “Speaker enrolment is complete” is announced. Voice recognition learning on/off 1. Press the pick-up button or talk button with a short press.
Page 516: Troubleshooting
Perform pairing using the following procedure. The pairing information paired to Pairing cannot be performed again ® the Bluetooth unit or device is not Clear “Mazda” stored in the de-  recognised correctly. vice. Perform pairing again.  Unable to perform pairing ®...
Page 517 If you pair your phone which has already been paired to your vehicle more than once in  the past, you need to delete “Mazda” on your mobile device. Then, execute the ® Bluetooth search on your mobile device once again, and pair to a newly detected “Mazda”.
Page 518 Interior Features Audio Set [Type A (non-touchscreen)] Symptom Cause Solution method A poor connection or malfunction with the microphone may have oc- There is a malfunction in the micro- Poor voice recognition curred. Consult an expert repairer, phone. we recommend an Authorised Maz- da Repairer.
Page 519 Interior Features Audio Set [Type A (non-touchscreen)] Symptom Cause Solution method If the number has been registered When a call is made from the vehi- into the phonebook, the incoming/ cle, the telephone number is updated The number has not been registered outgoing call record is updated by in the incoming/outgoing call record into the phonebook.
Page 520: Audio Set [Type B (Touchscreen)]
Additionally, depending on future software updates, the content may successively change without notice. For additional information regarding Mazda Connect, please refer to the following  Website. http://infotainment.mazdahandsfree.com/ Audio Set (Type B) has 3 different human interfaces.
Page 521 Interior Features Audio Set [Type B (touchscreen)] Switches around commander knob The following operations can be done by pressing the switches around the commander knob. : Displays the home screen. : Displays the Entertainment screen. : Displays the Navigation screen (Only navigation-equipped vehicles). For operation of the Navigation screen, refer to the navigation system manual.
Page 522 Interior Features Audio Set [Type B (touchscreen)] ▼ Touch panel operation CAUTION Do not press the screen strongly or press it with a sharp-pointed object. Otherwise, the screen could be damaged. NOTE For safety reasons, operation of the centre display is disabled while the vehicle is being driven.
Page 523 Interior Features Audio Set [Type B (touchscreen)] 2. Touch the slider with your finger and move to the desired level. Swipe 1. Touch the screen with your finger and move up or down. 2. Items which were not displayed can be displayed. Return to previous screen 1.
Page 524: Home Screen
Interior Features Audio Set [Type B (touchscreen)] Home screen Icon Function Applications Information such as average fuel economy, maintenance, and warnings can be verified. Depending on the grade and specification, the screen display may differ. Entertainment Operates audio such as the radio and CDs. The audio source most recently used is dis- played.
Page 525: Volume/Display/Sound Controls
Interior Features Audio Set [Type B (touchscreen)] Volume/Display/Sound Controls Audio control switch Commander switch Volume dial Volume ▼ Volume adjustment Daytime/nighttime (Mode) screen setting Turn the commander switch volume dial. The daytime or nighttime screen can be The volume switch on the steering switch selected.
Page 526 Interior Features Audio Set [Type B (touchscreen)] Contrast adjustment Indication Setting value ® Bose AudioPilot Adjust the centre display contrast using On/Off (Automatic volume ad- the slider. justment) Display setting reset Beep On/Off (Audio operation sound) All of the screen setting values can be Standard audio reset to their initial settings.
Page 527 Interior Features Audio Set [Type B (touchscreen)] It reacts only to sustained noise sources and not intermittent ones, such as speed bumps. An enhanced DSP algorithm allows faster and more effective compensation for unusual situations, such as driving on a very rough road or at high speeds.
Page 528: Operating The Radio
Interior Features Audio Set [Type B (touchscreen)] Operating the Radio ▼ Radio ON Select the icon on the home screen to display the Entertainment screen. When selecting the desired radio, the following icons are indicated in the lower part of the centre display. AM/FM Radio Icon Function...
Page 529 Interior Features Audio Set [Type B (touchscreen)] NOTE 5. Select (With Radio Data System (RDS)) Changing Favourites list order When the icon is selected while FM is selected, each programme is 1. Select the icon to display the selected. Favourites list. 2.
Page 530 Interior Features Audio Set [Type B (touchscreen)] If a TA broadcast is received while in the NOTE Only one Genre can be selected. TA mode, the TA broadcast intercedes even while using other functions (FM, CD, USB device, AUX, BT audio, Aha™ radio, or Stitcher™...
Page 531: Operating The Digital Audio Broadcasting (Dab) Radio
Interior Features Audio Set [Type B (touchscreen)] Operating the Digital Audio Broadcasting (DAB) Radio ▼ What is DAB radio? DAB radio is a digital broadcasting system for radio. DAB radio provides a high-quality radio sound source using an auto frequency switching function in boundary areas.
Page 532 Interior Features Audio Set [Type B (touchscreen)] Icon Function Displays sound settings to adjust audio quality level. Refer to Volume/Display/Sound Controls on page 5-71. Example of use (Update station list and Item Setting Function listen to DAB radio) On: If the reception con- dition is bad, a DAB sta- 1.
Page 533: Operating The Compact Disc (Cd) Player
Interior Features Audio Set [Type B (touchscreen)] Operating the Compact Disc (CD) Player CD slot CD eject button Ejecting the CD Type Playable data Music/MP3/WMA/AA Music data (CD-DA)  Press the CD eject button ( ) to eject the C CD player MP3/WMA/AAC file ...
Page 534 Interior Features Audio Set [Type B (touchscreen)] ▼ Playback Select the icon on the home screen with a CD inserted and display the Entertainment screen. When is selected, the following icons are indicated in the lower part of the centre display.
Page 535 Interior Features Audio Set [Type B (touchscreen)] Icon Function If selected within a few seconds of a song which has started to play, the previous song is selected. If more than a few seconds have elapsed after a song has begun to play, the song currently being played is replayed from the beginning.
Page 536: Operating The Digital Versatile Disc (Dvd) Player
Interior Features Audio Set [Type B (touchscreen)] Operating the Digital Versatile Disc (DVD) Player DVD slot DVD eject button Type Playable data DVD VIDEO/ DVD VIDEO/DVD-VR DVD-VR player file Inserting the DVD Insert the DVD into the slot, label-side up. The DVD is inserted automatically and the top menu screen of the DVD disc and controller are displayed.
Page 537 Interior Features Audio Set [Type B (touchscreen)] ▼ Playback Select the icon on the home screen with a DVD inserted and display the Entertainment screen. When is selected, the DVD top menu screen and the controller are displayed. When starting the playback by operating the controller, the following icons are displayed at the bottom of the screen.
Page 538 Interior Features Audio Set [Type B (touchscreen)] NOTE Function Screen colour can be adjust- For safety reasons, images are not  ed using the slider. displayed while the vehicle is being Screen settings can be reset driven. to initial values. Slide the of the controller to move ...
Page 539: How To Use Aux Mode
Interior Features Audio Set [Type B (touchscreen)] How to use AUX mode ▼ Playback 1. Select the icon on the home screen to display the Entertainment screen. 2. Select to switch to the AUX mode. The following icons are displayed in the lower part of the centre display.
Page 540: How To Use Usb Mode
Interior Features Audio Set [Type B (touchscreen)] How to use USB mode Type Playable data USB mode MP3/WMA/AAC/OGG file This unit does not support a USB 3.0 device. In addition, other devices may not be supported depending on the model or OS version. The recommended capacity of the USB memory is 16 GB or less.
Page 541 Interior Features Audio Set [Type B (touchscreen)] Icon Function Displays sound settings to adjust audio quality level. Refer to Volume/Display/Sound Controls on page 5-71. NOTE If a file name in the USB memory is too long, it could cause operation problems such as ...
Page 542 Interior Features Audio Set [Type B (touchscreen)] Example of use (to play all tracks in USB device) (Method 1) 1. Select to display the category list. 2. Select All the tracks in the USB device are displayed. 3. Select a desired track. The selected track is played.
Page 543 ® For information related to the most recent Gracenote database which can be used and how to install it, go to the Mazda Hands Free Website: http://www.mazdahandsfree.com Introduction Gracenote, the Gracenote logo and logotype are either a registered trademark or a trademark of Gracenote, Inc.
Page 544 4. Select . The list of the update package stored in the USB device and the version are displayed. 5. Select the package to use the update. 6. Select NOTE ® Gracenote can be downloaded from the Mazda Hands-free Website. 5-90...
Page 545: How To Use Apple Carplay
GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/OR APPLICATIONS OBSOLETE AND/OR UNUSABLE. TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL MAZDA OR ITS AFFILIATES BE LIABLE FOR PERSONAL INJURY, OR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, WITHOUT LIMITATION, DAMAGES...
Page 546 Interior Features Audio Set [Type B (touchscreen)] When using Apple CarPlay, please avoid distraction and use Apple CarPlay responsibly. Stay fully aware of driving conditions and always obey applicable laws. NOTE Apple CarPlay is provided by Apple and its use is subject to your agreement to the Apple ...
Page 547 To return to Mazda Connect screen Press and hold on the commander switch. 1 The voice recognition function of Mazda Connect cannot be used while Apple CarPlay is connected. To End Apple CarPlay To end Apple CarPlay, disconnect the Apple-genuine connector cord from the USB terminal and disconnect the iPhone from the connector cord.
Page 548: How To Use Android Auto™ Mode
GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/OR APPLICATIONS OBSOLETE AND/OR UNUSABLE. TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL MAZDA OR ITS AFFILIATES BE LIABLE FOR PERSONAL INJURY, OR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, WITHOUT LIMITATION, DAMAGES...
Page 549 Interior Features Audio Set [Type B (touchscreen)] When using Android Auto™, please avoid distraction and use Android Auto™ responsibly. Stay fully aware of driving conditions and always obey applicable laws. NOTE Android Auto™ is provided by Google and its use is subject to your agreement to the ...
Page 550 To return to the Mazda Connect screen Press and hold on the commander switch. 1 The voice recognition function of Mazda Connect cannot be used while Android Auto™ is connected. To end Android Auto™ To end the Android Auto™ mode, disconnect the Android™-genuine connector cord from the USB terminal or disconnect the Android™...
Page 551 Interior Features Audio Set [Type B (touchscreen)] If Android Auto™ cannot be connected When the message, “Mobile Device Error”, is displayed and Android Auto™ cannot be connected. Make sure that the Android™ Smartphone in question is compatible with Android Auto™. Before trying to reconnect your Android™...
Page 552: Bluetooth
CAUTION ® Some Bluetooth mobile devices are not compatible with the vehicle. Consult an Authorised Mazda Repairer, Mazda's call centre or Web support centre for information regarding ® Bluetooth mobile device compatibility: Phone: (Germany) 0800 4263 738 (8:00―18:00 Central European Time)
Page 553 Interior Features Audio Set [Type B (touchscreen)] (Except Germany) 00800 4263 7383 (8:00―18:00 Central European Time) (Worldwide) 49 (0) 6838 907 287 (8:00―18:00 Central European Time) Web: http://www.mazdahandsfree.com ® Applicable Bluetooth specification (Recommended) Ver. 1.1/1.2/2.0 EDR/2.1 EDR/3.0 (conformity) ▼ Component Parts Audio unit Talk button, Pick-up button and Hang-up button Talk button...
Page 554 Interior Features Audio Set [Type B (touchscreen)] Hang-up button Ends the call or refuses an incoming call. In addition, it ends the voice recognition operation. Commander switch The commander switch is used for volume adjustment and display operation. Tilt or turn the commander knob to move the cursor.
Page 555: Bluetooth ® Preparation
(Peripheral ® the device equipped with Bluetooth device). to be paired to the unit using the following 7. Select “Mazda” from the device list procedure. A maximum of 7 devices searched by the device. ® including Bluetooth audio devices and ®...
Page 556 If pairing is redone on the same the Hands-free or audio.  mobile phone device, first clear Hands-free: Phone calls and  ® “Mazda” displayed on the Bluetooth E-mail/SMS setting screen of the mobile device. ® Audio: Bluetooth audio, Aha™, ...
Page 557: Available Language
Interior Features Audio Set [Type B (touchscreen)] Deleting all devices Available Language 1. Select the icon on the home screen The language can be changed. to display the Settings screen. Refer to Settings on page 5-124. 2. Select the tab. NOTE 3.
Page 558: Bluetooth ® Audio
Interior Features Audio Set [Type B (touchscreen)] ® Bluetooth Audio AVRCP Function A2DP Ver. Ver. Ver. ® Applicable Bluetooth specification (Recommended) pends pends Ver. 1.1/1.2/2.0 EDR/2.1 EDR/3.0 Shuffle — — on de- on de- (conformity) vice vice Response profile pends pends A2DP (Advanced Audio Distribution ...
Page 559 Interior Features Audio Set [Type B (touchscreen)] ® ▼ Switching to Bluetooth audio mode ® To listen to music or voice audio recorded to a Bluetooth audio device, switch to the ® Bluetooth audio mode to operate the audio device using the audio system control panel. ®...
Page 560 Interior Features Audio Set [Type B (touchscreen)] Icon Function (AVRCP Ver. 1.3 or higher) Plays songs in the folder in random order. When selected again, the songs on the device are played in random order. Select it again to cancel. Icons change during folder shuffle or device shuffle.
Page 561: How To Use Aha
Interior Features Audio Set [Type B (touchscreen)] How to Use Aha™ ▼ What is Aha™? Aha™ is an application which can be used to enjoy various Internet content such as Internet radio and podcasts. Stay connected to your friends activities by getting updates from Facebook and Twitter. Using the location-based service, nearby services and destinations can be searched or real-time local information can be obtained.
Page 562 Interior Features Audio Set [Type B (touchscreen)] Icon Function Dislike Evaluates the current content as “Dislike”. Reverses for 15 seconds. Map (vehicles with navigation system) Displays the destination searched by the location based services on the navigation system. Call A call can be made to the telephone number of a shop searched using the Location Based Services.
Page 563 Interior Features Audio Set [Type B (touchscreen)] Function Select the desired station. Guidance is provided to the searched destination near the vehicle's posi- Nearby tion. You can designate desired categories previously set using the filter setting on your device. NOTE The available Location Based Services may differ because the services depend on the content provided by Aha™.
Page 564: How To Use Stitcher™ Radio
Interior Features Audio Set [Type B (touchscreen)] How to Use Stitcher™ Radio ▼ What is Stitcher™ Radio? Stitcher™ radio is an application which can be used to listen to Internet radio or stream podcasts. Recommended content is automatically selected by registering content which you put into your favourites, or by pressing the Like or Dislike button.
Page 565 Interior Features Audio Set [Type B (touchscreen)] Icon Function Plays the station. Select it again to pause playback. Goes to the next station. Displays sound settings to adjust audio quality level. Refer to Volume/Display/Sound Controls on page 5-71. Station list 1.
Page 566: Bluetooth ® Hands-Free
Audio Set [Type B (touchscreen)] 2. The programme is automatically ® Bluetooth Hands-Free deleted from the favourites station. ▼ Making a Call For Mazda Connect, making calls is possible using any of the following 6 methods: Phonebook downloaded from  ® Bluetooth...
Page 567 Interior Features Audio Set [Type B (touchscreen)] Screen operation 6. Download will be started from the mobile phone. 1. Select the icon on the home screen NOTE to display the Communication screen. 2. Select to display the contact If “Import All Contacts” is performed ...
Page 568 Interior Features Audio Set [Type B (touchscreen)] Calling a favourite 6. Slide the contact or move it using the commander switch, then select 1. Select the icon on the home screen Changing contact name of your to display the Communication screen. favourites 2.
Page 569 Interior Features Audio Set [Type B (touchscreen)] Numeral or symbol entry Use the dial pad. Long-press the to input +. Select to delete the currently input value. Long-press to delete all input values. Redial Function Makes a call to the last person called (latest person on outgoing call record) from the mobile phone/vehicle.
Page 570 Interior Features Audio Set [Type B (touchscreen)] ▼ Receiving an Incoming Call When an incoming call is received, the incoming call notification screen is displayed. The “Incoming Call Notifications” setting must be on. Refer to Communication Settings on page 5-120. To accept the call, press the pick-up button on the audio control switch or select the screen.
Page 571 Interior Features Audio Set [Type B (touchscreen)] NOTE can be downloaded, displayed, and played (read by the system). If the ignition is switched off during a  Additionally, replies can also be made to hands-free call, the line is transferred to calls and messages in the received the device (Mobile phone) messages.
Page 572 Interior Features Audio Set [Type B (touchscreen)] A message list is created for each The “Email Notifications” (E-mail) or  device. “SMS Notifications” (SMS) setting must If the connected device does not be on.  correspond to MAP 1.0, the AT Refer to Communication Settings on page command is used to download.
Page 573 Interior Features Audio Set [Type B (touchscreen)] Icon Function Only replies to the sender of the currently displayed message. Select the sentence on the displayed reply screen and select the sentence for sending from the preset message. Select (Only E-mail) Replies to all members including CC.
Page 574 Interior Features Audio Set [Type B (touchscreen)] Select the icon to return to the  previous screen without storing the edit. ▼ Communication Settings Select the icon on the home screen to display the Communication screen. Select to change the setting. Item Setting Function...
Page 575: Voice Recognition
Interior Features Audio Set [Type B (touchscreen)] To prevent a deterioration in the voice Voice Recognition recognition rate and voice quality, the following points should be observed: ▼ Basic Operation Method The voice recognition cannot be  Activating Voice Recognition performed while voice guidance or the beep sound is operating.
Page 576 Interior Features Audio Set [Type B (touchscreen)] NOTE If the voice recognition performance is not satisfactory. Refer to Troubleshooting on page 5-127. 5-122...
Page 577 Interior Features Audio Set [Type B (touchscreen)] ▼ Voice Command List Voice command When the talk button is pressed and the following command is spoken, the audio or navigation can be operated. The commands in the () can be omitted. The specified name and number are put into the {}.
Page 578: Settings
Interior Features Audio Set [Type B (touchscreen)] Settings NOTE Depending on the grade and specification, the screen display may differ. Select the icon on the home screen and display the Settings screen. Switch the tab and select the setting item you want to change. You can customize settings in the setup display as follows: Item Function...
Page 579 Interior Features Audio Set [Type B (touchscreen)] Item Function ® Refer to Bluetooth Preparation on page Bluetooth 5-101. An Android Auto™ mode connection can be set on or off when connecting an Android™ Smartphone. Android Auto The setting takes effect directly after switching on/off.
Page 580: Applications
Interior Features Audio Set [Type B (touchscreen)] Applications NOTE Depending on the grade and specification, the screen display may differ. Select the icon on the home screen to display the Applications screen. The following information can be verified. Top screen Item Function Fuel Consumption Display...
Page 581: Troubleshooting
Interior Features Audio Set [Type B (touchscreen)] Troubleshooting Apple CarPlay use-related issues Symptom Cause Solution method Apple CarPlay cannot launch even though an Apple-genuine connector Use the USB port displaying the You used the wrong USB port. cord is inserted into the USB port mark to start Apple CarPlay.
Page 582 Bluetooth audio and Android Auto™. ® ces connected via Bluetooth be adjusted. ® Mazda Bluetooth Hands-Free Customer Service ® If you have any problems with Bluetooth , contact our toll-free customer service centre. Phone: (Germany) 0800 4263 738 (8:00―18:00 Central European Time) (Except Germany) 00800 4263 7383 (8:00―18:00 Central European Time)
Page 583 Service. Perform pairing using the following procedure: 1. Delete the applicable Blue- ® tooth device on the Mazda Connect. 2. Delete “Mazda” from the Blue- ® tooth search screen of the ® Bluetooth device. The pairing information paired to 3. Perform pairing again.
Page 584 If you pair your phone which has already been paired to your vehicle more than once in  the past, you need to delete “Mazda” on your mobile device. Then, execute the ® Bluetooth search on your mobile device once again, and pair to a newly detected “Mazda”.
Page 585 Interior Features Audio Set [Type B (touchscreen)] Hands-Free operates slowly.  Voice recognition related problems Symptom Cause Solution method Poor voice recognition Excessive, slow speech.  Excessive, forceful speech  (shouting). Regarding the causes indicated on Speaking before the beep sound ...
Page 586 Interior Features Audio Set [Type B (touchscreen)] Regarding problems with calls Symptom Cause Solution method For about 3 seconds after starting a When starting a call, vehicle noise ® This does not indicate a problem call, the Bluetooth unit's Noise from the other party can be heard with the device.
Page 587: Appendix
Interior Features Appendix Do not spill any liquid on the audio Things You Need to Know system. WARNING Always adjust the audio while the vehicle is stopped: Do not adjust the audio control switches Do not insert any objects, other than CDs, while driving the vehicle.
Page 588 Interior Features Appendix FM characteristics also be encountered when in close proximity to the transmitter. An FM broadcast range is usually about 40―50 km (25―30 miles) from the source. Because of extra coding needed to break the sound into 2 channels, stereo FM Reflected wave Direct has even less range than monaural...
Page 589 Interior Features Appendix Strong signal noise an hour. Wait for normal operation to return before attempting to use the unit. This occurs very close to a transmitter tower. The broadcast signals are extremely Handling the CD player strong, so the result is noise and sound The following precautions should be breakup at the radio receiver.
Page 590 Interior Features Appendix A new CD may have rough edges on its Be sure never to touch the signal surface   inner and outer perimeters. If a disc with when handling the CDs. Pick up a CD rough edges is used, proper setting will by grasping the outer edge or the edge not be possible and the CD player will of the hole and the outer edge.
Page 591 Interior Features Appendix Storing CDs in the vehicle exposed to CAUTION  direct sunlight or high temperature may damage the CD-R/CD-RWs, and make Do not use an audio file extension on files them unplayable. other than audio files. In addition, do not CD-R/CD-RW exceeding 700 MB ...
Page 592 Interior Features Appendix AAC files written under specifications 1 Windows Media and Microsoft are  other than the indicated specification registered trademarks of Microsoft may not play normally or files or folder Corporation U.S. in the United States names may not display correctly. and other countries.
Page 593 Interior Features Appendix ▼ Operating Tips for DVD Player A new DVD may have rough edges on  its inner and outer perimeters. If a disc Condensation phenomenon with rough edges is used, proper setting will not be possible and the DVD player Immediately after turning on the heater will not play the DVD.
Page 594 Interior Features Appendix Be sure never to touch the signal surface scratches, smudges, dirt, etc., or due to  when handling the DVDs. Pick up a dust or condensation on the lens inside DVD by grasping the outer edge or the the unit.
Page 595 Interior Features Appendix NOTE Mark Meaning Indicates the region code Video data (DVD-Video/DVD-VR files)  for which a disc can be written to DVD/DVD-R/DVD R/ played. DVD-RW/DVD RW can be played. ALL indicates global ap- This unit is compatible for playback of plicability, and a number ...
Page 596 Interior Features Appendix Multi-language NOTE Playback may not be possible depending As a function of the DVD player, audio or  on the type and condition of the USB subtitles for the same video images can be flash memory even if the audio file stored in multiple languages and the complies with the standard.
Page 597 If data in the iPod is lost while it is operate your iPhone while driving. Disconnect the iPhone when it is not in connected to the unit, Mazda cannot use. If the device is left in the cabin, it guarantee recovery of any lost data.
Page 598 Interior Features Appendix NOTE To prevent loss or damage of stored data, we recommend that you always back up your data. ▼ Operating Tips for Android™ Requires the Android Auto app on Google Play and an Android compatible smartphone running Android™ 5.0 Lollipop or higher.
Page 599: Interior Equipment
Interior Features Interior Equipment Sunvisors Interior Lights When you need a sunvisor, lower it for use NOTE in front or swing it to the side. Do not leave the lights on for long periods Sunvisor while the engine is turned off. Otherwise the battery power could be depleted.
Page 600 Interior Features Interior Equipment Type B illuminate the front map lights, and then press the lens again to turn them off. Switch Overhead Lights The DOOR OFF switch can be switched between the DOOR posi- tion and DOOR OFF position. DOOR position The lights turn on when any of the ...
Page 601 Interior Features Interior Equipment The overhead lights turn on in NOTE  conjunction with a door opening/ Once the rear map lights have been  closing. turned off, they will turn on and off in The illuminated entry system is on. ...
Page 602 Interior Features Interior Equipment Ambient Light An ambient light continuously turn on when the ignition is switched ON. An ambient light dim when the position lights or headlights are turned on. Ambient light NOTE An ambient light turn on or off in conjunction with the illuminated entry system when the ...
Page 603: Accessory Sockets
(Type B) Accessory Sockets The illumination entry system does not operate in conjunction with the Only use genuine Mazda accessories or overhead lights when the overhead the equivalent requiring no greater than lights are turned on using the overhead 120 W (DC 12 V, 10 A).
Page 604 Do not use accessories that require more than 120 W (DC 12 V, 10 A). Do not use accessories that are not genuine Mazda accessories or the equivalent. Close the cover when the accessory socket is not in use to prevent foreign objects and liquids from getting into the accessory socket.
Page 605: Audio System
Interior Features Interior Equipment How to connect USB Power Outlet The groove in the armrest box can be used The USB power outlets can be used to pass the cord of the device into the box regardless of whether the ignition is to connect it to the USB power outlets.
Page 606: Cup Holder
Interior Features Interior Equipment Cup Holder ▼ Rear The rear cup holder is on the rear centre armrest. WARNING Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot liquids while the vehicle is moving is dangerous.
Page 607: Bottle Holder
Interior Features Interior Equipment Bottle Holder Storage Compartments Bottle holders are on the inside of the WARNING doors. Front Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving.
Page 608 Interior Features Interior Equipment ▼ Overhead Console ▼ Centre Console This console box is designed to store To open, pull the release latch. eyeglasses or other accessories. Push and release to open. Type A Storage tray The storage tray can be removed. Type B Storage tray ▼...
Page 609 Interior Features Interior Equipment ▼ Luggage Compartment Cargo Securing Loops WARNING Make sure luggage and cargo is secured before driving: Not securing cargo while driving is dangerous as it could move or be crushed during sudden braking or a collision and cause injury. Use the loops in the luggage compartment to secure cargo with a rope or net.
Page 610 Interior Features Interior Equipment Side cargo sub-compartment Open the cover to put small items in the cargo sub-compartment. NOTE Loading golf bags (Some golf bags may not fit using the following methods depending on their sizes.) Up to four golf bags can be carried in the luggage compartment. (With luggage compartment cover) When loading four golf bags, remove the luggage compartment cover and store it in the cargo sub-compartment.
Page 611: Removable Ashtray
Interior Features Interior Equipment ▼ Rear Coat Hooks Removable Ashtray The removable ashtray can be fixed and WARNING used in either of the front cup holders. WARNING Never hang heavy or sharp objects on the assist grips and coat hooks: Hanging heavy or sharp-ended objects Only use the removable ashtray in its fixed such as a coat hanger from the assist grips...
Page 612 MEMO 5-158...
Page 613 Maintenance and Care How to keep your Mazda in top condition. Essential Information......6-2 Appearance Care......6-65 Introduction........6-2 Exterior Care......6-65 Interior Care........6-70 Scheduled Maintenance....6-3 Scheduled Maintenance....6-3 Maintenance Monitor....6-15 Owner Maintenance......6-18 Owner Maintenance Precautions......... 6-18 Bonnet.........6-20 Engine Compartment Overview........6-22 Engine Oil........6-24...
Page 614: Maintenance And Care
If you are unsure about any procedure this manual describes, we strongly urge you to have a reliable and qualified technician perform the work, we recommend an Authorised Mazda Repairer. Authorised Mazda technicians and genuine Mazda parts are dedicated to your vehicle.
Page 615 Authorised Mazda Repairer. ▼ Europe My Mazda Service My Mazda Service is the maintenance monitoring feature that alerts you of mainte- nance needs by turning on the wrench indicator light and/or displaying a specific mes- sage in the instrument panel.
Page 616 Maintenance and Care Scheduled Maintenance Maintenance 2nd 3rd 4th 9th 10th 11th 12th SKYACTIV-G 2.0, SKYACTIV-G 2.5, AND SKYACTIV-D 2.2 Drive belts Cooling system Replace at first 200,000 km (125,000 miles) or 10 years; after that, every Engine coolant 100,000 km (62,500 miles) or 5 years. Battery Brake lines, hoses and connections Brake fluid...
Page 617 Maintenance and Care Scheduled Maintenance Flexible setting is factory preset for some countries in Europe. Consult an Authorised Mazda Repairer for details. Flexible setting can be set if the vehicle is operated mainly where none of the following conditions apply.
Page 618 Maintenance and Care Scheduled Maintenance ▼ Except Europe Israel Number of months or kilometres, whichever comes first Maintenance Interval Months 96 108 120 132 144 ×1000 km 90 105 120 135 150 165 180 Spark plugs Replace every 120,000 km or 6 years. Fuel filter Replace every 135,000 km.
Page 619 Maintenance and Care Scheduled Maintenance L: Lubricate C: Clean T: Tighten D: Drain Remarks: Also inspect the air conditioner drive belts, if installed. If the vehicle is operated primarily under any of the following conditions, inspect the drive belts at every 10,000 km or shorter.
Page 620 Maintenance and Care Scheduled Maintenance Number of months or kilometres, whichever comes first. Maintenance Interval Months 96 108 120 132 144 ×1000 km 90 105 120 135 150 165 180 Replace when indicator is ON. (Max interval:12months or Flexible 15,000 km) Other than Engine oil filter flexible...
Page 621 Maintenance and Care Scheduled Maintenance Number of months or kilometres, whichever comes first. Maintenance Interval Months 96 108 120 132 144 ×1000 km 90 105 120 135 150 165 180 Cabin air filter (if installed) Tyres (including spare tyre) (with inflation pres- sure adjustment) Inspect annually.
Page 622 Maintenance and Care Scheduled Maintenance f) Driving in mountainous conditions continually Flexible setting can be set if the vehicle is operated mainly where none of the following conditions apply. a) Purpose of vehicle use is police car, taxi or driving school car. b) Driving in dusty conditions c) Extended periods of idling or low speed operation The vehicle calculates the remaining oil life based on engine operating conditions and lets you know when an...
Page 623 Tanzania Replace every 3,000 km (1,875 miles) or 3 months. Fuel filter Replace every 60,000 km (37,500 miles). Affected Clean the fuel system by Mazda genuine deposit cleaner at every 10,000 *4*5 Fuel system km (6,250 miles). countries Evaporative system (if installed) SKYACTIV-D 2.2...
Page 624 Maintenance and Care Scheduled Maintenance Number of months or kilometres (miles), whichever comes first. Months 12 18 24 30 36 42 48 54 60 66 72 78 84 90 96 Maintenance Inter- ×1000 km 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 ×1000 miles 6.25 12.5 18.75 25 31.25 37.5 43.75 50 56.25 62.5 68.75 75 81.25 87.5 93.75 100 Except be- low coun-...
Page 625 Extended periods of idling or low speed operation c) Driving in extremely hot conditions Use Mazda genuine deposit cleaner. Using non-genuine deposit cleaner would cause internal failure of the fuel system. Refer to 3-29, 9-7 for the details. Brunei, Cambodia, Indonesia, Laos, Malaysia, Myanmar, Philippines, Thailand, Vietnam...
Page 626 Maintenance and Care Scheduled Maintenance Also inspect the air conditioner drive belts, if installed. If the vehicle is operated primarily under any of the following conditions, inspect the drive belts more often than the recommended intervals. a) Driving in dusty conditions b) Extended periods of idling or low speed operation c) Driving for long period in cold temperatures or driving regularly at short distance only d) Driving in extremely hot conditions...
Page 627 Maintenance Monitor ▼ Maintenance Monitor (Type A audio) “Oil Change” with flexible setting is available. Consult an Authorised Mazda Repairer for details . When the engine oil flexible maintenance setting is selected, the wrench indicator light in the instrument cluster will be illuminated when remaining oil life becomes less than 1,000 km (600 mile), or remaining days are less than 15 (Whichever comes first).
Page 628 Whenever the engine oil is replaced, the vehicle engine control unit reset is necessary for SKYACTIV-G 2.5T and SKYACTIV-D 2.2. Your Authorised Mazda Repairer will be able to reset the engine control unit or refer to the vehicle engine control unit reset procedure on page 6-27.
Page 629 Maintenance and Care Scheduled Maintenance Item Explanation Displays the engine oil life until the oil replacement is due. The wrench indication/indicator light in the instrument cluster Oil life (%) will be illuminated when remaining oil life distance is less than 1,000 km (600 mile), or remaining days are less than 15 Oil Change (whichever comes first).
Page 630: Owner Maintenance
Improper do-it yourself maintenance during the warranty period may affect warranty coverage. For details, read the separate Mazda Warranty statement provided with the vehicle. If you are unsure about any servicing or maintenance procedure, have it done by an expert repairer, we recommend an Authorised Mazda Repairer.
Page 631 Maintenance and Care Owner Maintenance If you must run the engine while working under the bonnet, make certain that you remove all jewellery (especially rings, bracelets, watches, and necklaces) and all neckties, scarves, and similar loose clothing before getting near the engine or cooling fan which may turn on unexpectedly: Working under the bonnet with the engine running is dangerous.
Page 632: Bonnet
Maintenance and Care Owner Maintenance 2. Insert your hand into the bonnet Bonnet opening, slide the latch lever to the right, and lift up the bonnet. WARNING Lever Always check that the bonnet is closed and securely locked: A bonnet that is not closed and securely locked is dangerous as it could fly open while the vehicle is moving and block the driver's vision which could result in a...
Page 633 Maintenance and Care Owner Maintenance 2. Lift the bonnet, grasp the padded area on the support rod, and secure the support rod in the clip. Verify that the support rod is secured in the clip before closing the bonnet. Clip Clip Clip 3.
Page 634: Engine Compartment Overview
Maintenance and Care Owner Maintenance Engine Compartment Overview SKYACTIV-G 2.0 and SKYACTIV-G 2.5 Brake/Clutch fluid reservoir Windscreen washer fluid reservoir Engine oil-dipstick Battery Fuse block Cooling system cap Engine coolant reservoir Engine oil-filler cap SKYACTIV-G 2.5T Windscreen washer fluid reservoir Brake fluid reservoir Engine oil-filler cap Battery...
Page 635 Maintenance and Care Owner Maintenance SKYACTIV-D 2.2 Brake/Clutch fluid reservoir Windscreen washer fluid reservoir Engine oil-filler cap Battery Fuse block Cooling system cap Engine coolant reservoir Engine oil dipstick 6-23...
Page 636: Engine Oil
Temperature Range SAE Viscosity Numbers –40 –30 –20 –10 Grade –40 –20 Recommended oils Mazda Original Oil Supra 0W-20 Mazda Original Oil Ultra 5W-30 Alternative Oil Quality 0W-20 API SN or ACEA A5/B5 5W-30 *1 Use API SM/SN in Kazakhstan.
Page 637 Temperature Range SAE Viscosity Numbers –40 –30 –20 –10 Grade –40 –20 Recommended oils Mazda Original Oil Supra DPF 0W-30 Mazda Original Oil Ultra DPF 5W-30 Alternative Oil Quality 0W-30 ACEA C3 5W-30 (Except Europe and Taiwan) Temperature Range SAE Viscosity Numbers –30 –20 –10...
Page 638 “X” mark on the dipstick, replace the engine oil. This should be done by an expert repairer, we recommend an Authorised Mazda Repairer. When replacing the engine oil, inspect the oil level using the oil dipstick and refill so that the engine oil level is within the range between MIN and MAX as shown in the figure.
Page 639 SKYACTIV-G 2.0 and SKYACTIV-G 2.5 vehicles with the engine oil flexible maintenance setting selected. After replacing the engine oil, have a repair shop such as an Authorised Mazda Repairer perform the initialization (engine oil data resetting) of the recorded value. If the value recorded by the computer is not initialized, the wrench indicator light may not turn off or it may turn on earlier than normal.
Page 640 Maintenance and Care Owner Maintenance 4. Pull out the dipstick, wipe it clean, and If it is near or below MIN, add enough reinsert it fully. oil to bring the level to MAX. SKYACTIV-G 2.0, SKYACTIV-G CAUTION 2.5, and SKYACTIV-G 2.5T Do not overfill the engine oil.
Page 641: Engine Coolant
Engine Coolant Changing the coolant should be done by an expert repairer, we recommend an ▼ Inspecting Coolant Level Authorised Mazda Repairer. WARNING Inspect the antifreeze protection and coolant level in the coolant reservoir at least once a year―at the beginning of the Do not use a match or live flame in the winter season―and before travelling...
Page 642 If the coolant reservoir is empty or new coolant is required frequently, consult an expert repairer, we recommend an Authorised Mazda Repairer. If it is at or near L, add enough coolant to the coolant reservoir to provide freezing and corrosion protection and to bring the level to F.
Page 643: Brake/Clutch Fluid
The level normally drops with accumulated distance, a condition associated with wear of brake and clutch linings. If it is excessively low, have the brake/clutch system inspected by an expert repairer, we recommend an Authorised Mazda Repairer. Left-hand drive model 6-31...
Page 644: Window And Headlight Washer
Maintenance and Care Owner Maintenance Window and Headlight AdBlue® (With Selective Washer Fluid Catalytic Reduction (SCR) System) ▼ Inspecting Washer Fluid Level ® AdBlue Handling WARNING CAUTION Use only windscreen washer fluid or plain If AdBlue ® water in the reservoir: gets in your mouth, wash your Using radiator antifreeze as washer fluid is mouth with a large amount of water...
Page 645 CAUTION the fluid freezes in the urea tank, you may not be able to tell if the correct Use a Mazda genuine product or a amount of fluid was added. product conforming to ISO22241-1 for AdBlue®. If incompatible AdBlue® is used, the Selective Catalytic Reduction (SCR) system may not operate normally.
Page 646 Owner Maintenance Replenishment of AdBlue® by an Percentage (%) indica-  Reference replenish- tion for remaining Authorised Mazda Dealer is ment amount amount recommended. If you want to replenish About 9.0 L (2.4 US gal, the AdBlue® yourself, follow the 25 —...
Page 647 Contact an expert repairer, we sounds. recommend an Authorised Mazda 10. Switch the ignition ON once. Repairer if a warning is displayed. If the 11. Check the following while the vehicle warning remains displayed, the urea is stopped.
Page 648: Body Lubrication
If the AdBlue® level (%) shows no increase or the speed restriction does not cancel even while driving the vehicle, consult an expert repairer, we recommend an Authorised Mazda Repairer. 6-36...
Page 649: Wiper Blades
Maintenance and Care Owner Maintenance ▼ Replacing Windscreen Wiper Blades Wiper Blades When the wipers no longer clean well, the blades are probably worn or cracked. CAUTION Replace them. Hot waxes applied by automatic car CAUTION washers have been known to affect the wiper's ability to clean windows.
Page 650 Maintenance and Care Owner Maintenance 2. Slide the blade component in the 4. Pull the end of the blade rubber from direction of the arrow while pressing the blade holder groove in the direction the wiper arm tab to remove the blade of the arrow and remove the blade component from the wiper arm.
Page 651 Maintenance and Care Owner Maintenance 5. Insert the end of the new blade rubber 6. After pulling the blade rubber in the into the groove of the blade holder direction of the arrow and sliding the until it contacts the end of the blade blade rubber to a position to check the holder.
Page 652 Maintenance and Care Owner Maintenance 9. Align the blade component projection 1. Raise the wiper arm and rotate the with the wiper arm notch. wiper blade to the right until it unlocks, then remove the blade. Notch Projection 10. Slide the blade component and install it to the wiper arm.
Page 653 Maintenance and Care Owner Maintenance 3. Remove the metal stiffeners from the blade rubber and install them in the new blade. CAUTION Do not bend or discard the stiffeners. You need to use them again. 4. Carefully insert the new blade rubber. Then install the blade assembly in the reverse order of removal.
Page 654: Battery
Maintenance and Care Owner Maintenance Battery WARNING Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery: Working without eye protection is dangerous. Battery fluid contains SULPHURIC ACID which could cause blindness if splashed into your eyes.
Page 655 Maintenance and Care Owner Maintenance Keep all flames and sparks away from open battery cells because hydrogen gas is produced from open battery cells while charging the battery or adding battery fluid: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode.
Page 656 ▼ Battery Replacement Upper level Contact an Authorised Mazda Repairer for a battery replacement purchase. Lower level Inspect the electrolyte level at least once a week. If it is low, remove the caps and add...
Page 657: Key Battery Replacement
Replacing the battery at an Authorised CAUTION Mazda Repairer is recommended to prevent damage to the key. If replacing the Make sure the battery is installed battery by yourself, follow the instruction. correctly. Battery leakage could occur if it is not installed correctly.
Page 658 Maintenance and Care Owner Maintenance 3. Insert the tape-wrapped flathead CAUTION screwdriver into the gap and slide it in the direction of the arrow. Be careful not to allow the rubber Cover ring shown in the figure to be scratched or damaged. If the rubber ring detaches, reattach it before inserting a new battery.
Page 659: Tyres
Maintenance and Care Owner Maintenance Tyres Use only a Mazda-genuine tyre valve cap: Use of a non-genuine part is dangerous as For reasons of proper performance, safety, the correct tyre air pressure cannot be and better fuel economy, always maintain...
Page 660 Replacing just one tyre is dangerous. It could cause poor handling and poor braking resulting in loss of vehicle control. Mazda strongly recommends that you replace all four tyres at the same time. Forward If a tyre wears evenly, a wear indicator...
Page 661 Maintenance and Care Owner Maintenance Replace the tyre when this happens. The temporary spare tyre has a tread life of less than 5,000 km (3,000 miles). The Tread wear tread life may be shorter depending on indicator driving conditions. The temporary spare tyre is for limited use, however, if the tread wear solid-band indicator appears, replace the tyre with the same type of temporary...
Page 662 Maintenance and Care Owner Maintenance For details, contact an expert repairer,  we recommend an Authorised Mazda Repairer. Proper tyre balancing provides the best riding comfort and helps reduce tread wear. Out-of-balance tyres can cause vibration and uneven wear, such as cupping and flat spots.
Page 663: Light Bulbs
Maintenance and Care Owner Maintenance Light Bulbs Type A Type B Headlights (High/Low beam) Running lights/Position lights Headlights (Wide-range low beam) Running lights Front fog lights Front direction indicator lights Position lights Side direction indicator lights Brake lights 6-51 *Some models.
Page 664  caused by the flying glass. repairer, we recommend an Authorised If the glass portion is touched with bare Mazda Repairer. hands, body oil could cause the bulb to If the halogen bulb is accidentally  overheat and explode when lit.
Page 665  The LED bulb cannot be replaced as a single unit because it is an integrated unit. The LED bulb has to be replaced with the unit. We recommend an Authorised Mazda Repairer when the replacement is necessary. Bulb type 5.
Page 666 Maintenance and Care Owner Maintenance 3. Pull the centre of each plastic retainer 6. Disconnect the bulb from the socket. using a flathead screwdriver and remove the retainers, and then partially peel back the over fender. Removal Installation 7. Install the new bulb in the reverse order of the removal procedure.
Page 667 Maintenance and Care Owner Maintenance 3. Turn the screws anticlockwise and Brake lights/Tail lights remove them. 7. Install the new bulb in the reverse 4. Pull the unit rearward to remove it. order of the removal procedure. Rear fog light 1.
Page 668  The LED bulb cannot be replaced as a single unit because it is an integrated unit. The LED bulb has to be replaced with the unit. We recommend an Authorised Mazda Repairer when the replacement is necessary. Bulb type...
Page 669 Maintenance and Care Owner Maintenance Rear map lights Luggage compartment light 1. Wrap a small flathead screwdriver with a soft cloth to prevent damage to the lens and remove the lens unit by carefully prying on the edge of the lens unit with the flathead screwdriver.
Page 670: Fuses
If the same fuse blows again, avoid using that system and consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. 4. Disconnect the bulb by pulling it out. ▼ Fuse Replacement...
Page 671 Always replace a fuse with a genuine Mazda fuse or equivalent of the same rating. Otherwise you may damage the electric system. 6. Reinstall the cover and make sure that it is securely installed.
Page 672 Blown Normal WARNING Do not replace the main fuse by yourself. Have an Authorised Mazda Repairer perform the replacement: Replacing the fuse by yourself is dangerous because the MAIN fuse is a high current fuse. Incorrect replacement could cause an electrical shock or a short circuit resulting in a fire.
Page 673 Maintenance and Care Owner Maintenance ▼ Fuse Panel Description Fuse block (Engine compartment) FUSE DESCRIPTION PROTECTED COMPONENT RATING CABIN.+B 50 A For protection of various circuits 30 A For protection of various circuits INJECTOR 30 A Engine control system ENG.SUB SCR1 20 A Engine control system...
Page 674 Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING AUDIO 30 A Audio system , For protection of various circuit DCDC REG FAN GE 30 A Cooling fan ENG.MAIN 40 A Engine control system ABS/DSC M 50 A ABS, Dynamic stability control system FAN DE 40 A Cooling fan...
Page 675 Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING FUEL WARM 25 A Fuel warmer TAIL 15 A Tail lights, Number plate lights SCR2 25 A Engine control system FUEL PUMP2 HAZARD 25 A Hazard warning flashers, Direction indicator lights, Tail lights H/L LOW R 15 A Headlight low beam (RH)
Page 676 Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING D.LOCK 25 A Power door locks SEAT WARM 20 A Seat warmer SUNROOF 10 A Sunroof F.OUTLET 15 A Accessory sockets MIRROR 7.5 A Power control mirror R.OUTLET1 15 A Accessory sockets SCR3 15 A...
Page 677 These acids can settle on a vehicle's finish. As the water evaporates, Prevention the acid becomes concentrated and can It is necessary to have your Mazda washed damage the finish. and waxed to preserve its finish according And the longer the acid remains on the to the instructions in this section.
Page 678 Maintenance and Care Appearance Care Water Marks Chipped paint can lead to rust forming  on your Mazda. Before this happens, Occurrence repair the damage by using Mazda Rain, fog, dew, and even tap water can touch-up paint according to the contain harmful minerals such as salt and instructions in this section.
Page 679 When prompt washing with NOTE plain water is ineffective, use a mild soap Mazda is not responsible for scratches  made for use on vehicles. caused by automatic car washes or improper washing.
Page 680 Repair damage to the finish caused by wash stone chipping, damage during parking High water temperature and high water etc., by using Mazda touch-up paint before pressure car washers are available rust begins to form. First, remove the dirt depending on the type of car wash and grease with a clean soft cloth.
Page 681 Should repairs be necessary, consult an expert repairer, we recommend an ▼ Bright-Metal Maintenance Authorised Mazda Repairer. They are well informed on how repairs should be made. Use tar remover to remove road tar and  insects. Never do this with a knife or ▼...
Page 682 Maintenance and Care Appearance Care ▼ Plastic Part Maintenance Interior Care When cleaning the plastic lenses of the  lights, do not use petrol, paraffin, WARNING rectified spirit, paint, thinner, highly acidic detergents, or strongly alkaline Do not spray water into the vehicle cabin: detergents.
Page 683 ▼ Leather Upholstery Maintenance Authorised Mazda Repairer: If a seat belts is used under such a 1. Remove dust and sand using a vacuum condition, it cannot function at its full cleaner.
Page 684 Maintenance and Care Appearance Care Alcohol, such as in cosmetic or hair ▼ Active Driving Display  dressing items Maintenance If the leather upholstery gets wet,  Windscreen type promptly remove moisture with a dry cloth. Remaining moisture on the The dust-proof sheet has a coating.
Page 685 Maintenance and Care Appearance Care NOTE Be particularly careful when cleaning shiny surface panels and metallic parts such as plating as they can be scratched easily. ▼ Cleaning the Window Interiors If the windows become covered with an oily, greasy, or waxy film, clean them with glass cleaner.
Page 686 MEMO 6-74...
Page 687: If Trouble Arises
If Trouble Arises Helpful information on what to do if a problem arises with the vehicle. Mazda ERA-GLONASS....7-2 Overheating........7-36 Overheating........ 7-36 Mazda ERA-GLONASS .....7-2 Emergency Towing......7-38 Parking in an Emergency....7-13 Towing Description....7-38 Parking in an Emergency....7-13 Towing Hooks......
Page 688 The system operates automatically when the vehicle receives an impact of a certain level or more in a collision, or it can be operated manually using the Mazda ERA-GLONASS switch if an emergency situation arises such as sudden illness.
Page 689: Mazda Era-Glonass
Speaker, Aerial WARNING When using the Mazda ERA-GLONASS, keep medical devices such as an implanted heart pacemaker or defibrillator about 22 cm (8.7 in) or more away from the vehicle's aerial: Otherwise, the operation of the medical device may be affected by radio waves.
Page 690: Mazda Era-Glonass
If Trouble Arises Mazda ERA-GLONASS ▼ Flow of Mazda ERA-GLONASS Call centre/ Mazda ERA-GLONASS Police/ User status Emergency Automatic call Manual call services Mazda ERA-GLONASS switch Automatic call made Emergency situation arises due to vehicle such as collision or sudden...
Page 691 Do not disassemble the Mazda ERA-GLONASS. Otherwise, it could become damaged and may not function in an emergency. The Mazda ERA-GLONASS has a special built-in battery so that it can operate even if the power supply from the vehicle is cut such as in an accident.
Page 692 If a call is disconnected or a call cannot be made to the call centre correctly, an automatic  call is made again to the call centre. Redialing cannot be cancelled. 1. If the vehicle receives an impact of a certain level or more in a collision, the Mazda ERA-GLONASS begins operating automatically.
Page 693 If Trouble Arises Mazda ERA-GLONASS 2. The indicator light (green) on the Mazda ERA-GLONASS switch flashes slowly (0.5 second intervals) and the call is made to the call centre. Green 3. When the connection is established with the call centre, the indicator light (green) flashes somewhat quickly (0.3 second intervals) and the beep sounds simultaneously,...
Page 694 To cancel the redialing, refer to Manual emergency call cancellation. 1. Make sure that the ignition is switched ON. 2. Long-press the Mazda ERA-GLONASS switch on the overhead console and then release your finger from the switch. Mazda ERA-GLONASS switch 3.
Page 695 NOTE If a call to the call centre does not connect even though the indicator light shows a call is possible, make a call to the police or other authority by means other than the Mazda ERA-GLONASS. Manual emergency call cancellation...
Page 696 ▼ Test Mode The test mode function makes sure that the Mazda ERA-GLONASS can operate normally. Have your vehicle tested at an Authorised Mazda Repairer when performing the test mode. Method to start test mode Switch the ignition ON while the parking brake is applied, and wait 2 minutes with the vehicle stopped.
Page 697 Return the signal lever to off Turn off the hazard warning lights. Within 5 seconds Move the signal lever up to right turn Both red and green Mazda ERA-GLONASS switch indicator lights turn on. Within 1 second Move the signal lever down to left turn...
Page 698 If Trouble Arises Mazda ERA-GLONASS After the procedure is completed, the test mode is performed in the following order automatically. Procedure is completed Switch to test mode Call is placed to call centre Vehicle information is sent Start of voice call...
Page 699: Parking In An Emergency
If Trouble Arises Parking in an Emergency Parking in an Emergency Roadside Emergency Triangle Retaining Strap The hazard warning lights should always be used when you stop on or near a Keep the roadside emergency triangle in roadway in an emergency. the left side trim and secure it with the strap.
Page 700: Flat Tyre
NOTE Your vehicle may or may not be equipped with a spare tyre, jack, wheel brace, and tool bag. For details, consult an Authorised Mazda Repairer. Spare tyre and tools are stored in the locations illustrated in the diagram. With spare tyre...
Page 701 If Trouble Arises Flat Tyre Without spare tyre Emergency flat tyre Type A Towing eyelet repair kit Jack lever Jack Wheel brace Type B Emergency flat tyre Towing eyelet repair kit Jack Jack lever Wheel brace Some models. 7-15...
Page 702 Make sure the screw thread is  adequately lubricated. ▼ Spare Tyre Your Mazda has a temporary spare tyre. The temporary spare tyre is lighter and smaller than a conventional tyre, and is designed only for emergency use and should be used only for VERY short periods.
Page 703 Do not use your temporary spare tyre Connector on any other vehicle, it has been NOTE designed only for your Mazda. Extra strength may be required to Use only one temporary spare tyre on uncouple the connector. Be sure to your vehicle at the same time.
Page 704: Emergency Flat Tyre Repair Kit
The emergency flat tyre repair kit included Spare tyre hold-down bolt with your Mazda is for a temporary repair of a slightly damaged flat tyre resulting from running over nails or similar sharp objects on the road surface.
Page 705 The emergency flat tyre repair kit cannot  be used in the following cases. Consult an expert repairer, we recommend an Authorised Mazda Repairer. Tyre sealant Injection hose The period of effective use for the tyre ...
Page 706 If Trouble Arises Flat Tyre 4. Unload passengers and luggage, and CAUTION remove the emergency flat tyre repair kit. If the bottle is shaken after the injection Type A hose is screwed on, tyre sealant could spray out from the injection hose. Tyre sealant contacting clothing or other objects may be impossible to remove.
Page 707 NOTE The tyre sealant cannot be reused. Purchase a new tyre sealant kit at an Authorised Mazda Repairer. 11. Pull out the injection hose from the valve. Reinsert the valve core into the valve and turn it clockwise to install it.
Page 708 Do not throw away the empty tyre valve. sealant bottle after use. Return the empty tyre sealant bottle to an Authorised Mazda Repairer when replacing the tyre. The empty tyre sealant bottle will need to be used to Valve Compressor hose extract and dispose of the used sealant from the tyre.
Page 709 Operating the compressor above 300 we recommend an Authorised kPa (3.1 kgf/cm , 3 bar, 43.5 psi) is Mazda Repairer and keep the vehicle dangerous. When the inflation pressure speed below 80 km/h (50 mph). rises above 300 kPa (3.1 kgf/cm , 3 bar, If the vehicle is driven 80 km/h (50...
Page 710 Repairer promptly and have the tyre use it if it has expired. Have the tyre replaced. Mazda recommends that the sealant replaced at an Authorised Mazda tyre be replaced with a new one. If the Repairer before the period of effective use tyre is to be repaired and reused, has expired.
Page 711: Changing A Flat Tyre (With Spare Tyre)
If Trouble Arises Flat Tyre 1. Park on a hard, level surface off the Changing a Flat Tyre right-of-way and firmly set the parking (With Spare Tyre) brake. 2. Put a vehicle with an automatic NOTE transaxle in Park (P), a manual If the following occurs while driving, it transaxle in Reverse (R) or 1, and turn could indicate a flat tyre.
Page 712 If Trouble Arises Flat Tyre ▼ Removing a Flat Tyre 2. Loosen the wheel nuts by turning them anticlockwise one turn each, but do not remove any wheel nuts until the tyre WARNING has been raised off the ground. When jacking-up a vehicle, always shift the shift lever to 1st or R (manual transaxle vehicle) or shift the selector lever to P (automatic transaxle vehicle), apply the...
Page 713 Mazda: your hand until the jack head is Using a jack that is not designed for inserted into the jack-up position. your Mazda is dangerous. The vehicle could slip off the jack and seriously injure someone. Tyre blocks Never place objects under the jack: Jacking the vehicle with an object under the jack is dangerous.
Page 714 ▼ Mounting the Spare Tyre your Mazda is firmly in position and that it cannot slip or move. 1. Remove dirt and grime from the mounting surfaces of the wheel and hub, including the hub bolts, with a cloth.
Page 715 Because the wheel studs and wheel the tyre to come off, resulting in an nuts on your Mazda have metric accident. In addition, wheel nuts and threads, using a non-metric nut is bolts could be damaged if tightened dangerous.
Page 716 If Trouble Arises Flat Tyre WARNING Do not drive with any tyres that have incorrect air pressure: Driving on tyres with incorrect air pressure is dangerous. Tyres with incorrect pressure could affect handling and result in an accident. When you check the regular tyres' air pressure, check the spare tyre, too.
Page 717: Battery Runs Out
If Trouble Arises Battery Runs Out Jump-Starting Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. WARNING Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 718 If Trouble Arises Battery Runs Out Route the jumper leads away from parts that will be moving: Connecting a jumper lead near or to moving parts (cooling fans, belts) is dangerous. The lead could get caught when the engine starts and cause serious injury. CAUTION Use only a 12 V booster system.
Page 719 Do not disconnect the jumper leads while the message is displayed. 8. Disconnect the jumper leads in the reverse order of their connection. 9. Install the battery cover. 10. Have your vehicle inspected by an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. 7-33...
Page 720: Emergency Starting
If Trouble Arises Emergency Starting Starting a Flooded Engine Push-Starting (SKYACTIV-G 2.0, Do not push-start your Mazda. SKYACTIV-G 2.5, and WARNING SKYACTIV-G 2.5T) Never tow a vehicle to start it: If the engine fails to start, it may be Towing a vehicle to start it is dangerous.
Page 721: Running Out Of Fuel (Skyactiv-D 2.2)
If the engine does not start the first time, try starting it several more times. If it still does not start, contact an expert repairer, we recommend an Authorised Mazda Repairer. 7-35...
Page 722: Overheating
Authorised Mazda Open the bonnet ONLY after steam is no Repairer. 6. Make sure the cooling fan is operating,...
Page 723 Coolant reservoir If you find a leak or other damage, or if coolant is still leaking: Stop the engine and call an expert repairer, we recommend an Authorised Mazda Repairer. SKYACTIV-G 2.0 and SKYACTIV-G Cooling fan Cooling system cap If you find no problems, the engine is...
Page 724: Emergency Towing
Always tow a 4WD vehicle with all four by an expert repairer, we recommend an wheels off the ground: Authorised Mazda Repairer or a Towing a 4WD vehicle with either the front commercial tow-truck service. or rear wheels on the ground is dangerous...
Page 725 If Trouble Arises Emergency Towing Do not tow with sling-type equipment. CAUTION This could damage your vehicle. Use wheel-lift or flatbed equipment. Follow these instructions when towing the vehicle with all wheels on the ground. 1. Shift to neutral (Manual transaxle), or the N position (Automatic transaxle).
Page 726: Towing Hooks
3. Securely install the towing eyelet using tool with a soft cloth to prevent the wheel brace or equivalent. damage to a painted bumper, and open Consult an Authorised Mazda the cap located on the front or rear Repairer. bumper.
Page 727 If Trouble Arises Emergency Towing Rear Towing eyelet Wheel brace 4. Hook the towing rope to the towing eyelet. CAUTION If the towing eyelet is not securely tightened, it may loosen or disengage from the bumper when towing the vehicle. Make sure that the towing eyelet is securely tightened to the bumper.
Page 728: Warning/Indicator Lights And Warning Sounds
WARNING Do not drive with the brake system warning light illuminated. Contact an expert repair‐ er, we recommend an Authorised Mazda Repairer to have the brakes inspected as soon as possible: Brake System Warning Driving with the brake system warning light illuminated is dangerous. It indicates that Light your brakes may not work at all or that they could completely fail at any time.
Page 729 Do not drive with both the ABS warning light and brake warning light illuminated. Warning Have the vehicle towed to an expert repairer, we recommend an Authorised Mazda Re‐ pairer to have the brakes inspected as soon as possible: Driving when the brake system warning light and ABS warning light are illuminated simultaneously is dangerous.
Page 730 If the message is displayed, stop the vehicle in a safe place and do not operate the steering wheel. There is no problem if the message in the display turns off after a while. Contact an expert repairer, we recommend an Authorised Mazda Repairer if the message is displayed continuously.
Page 731 If the ABS warning light stays on while you're driving, the ABS control unit has detected a system malfunction. If this occurs, your brakes will function normally as if the vehicle had no ABS. Should this happen, consult an expert repairer, we recommend an Authorised Mazda Re- pairer as soon as possible. NOTE...
Page 732 This indicates a malfunction with the vehicle system. Check the message indicated in the Master Warning In- display and consult an expert repairer, we recommend an Authorised Mazda Repairer. dication/Warning For details, refer to the explanations for the warning/indicator lights, in the warning/indi- Light cator lights section, which match the symbol in the upper part of the display.
Page 733 The light flashes if the Electric Parking Brake (EPB) has a malfunction. If the light re- mains flashing even if the Electric Parking Brake (EPB) switch is operated, consult an ex- pert repairer, we recommend an Authorised Mazda Repairer as soon as possible. 7-47...
Page 734 The fuel tank level being very low or approaching empty. If the check engine light remains on, or it flashes continuously , do not drive at high Check Engine Light speeds and consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. WARNING If the check engine light turns on, do not disconnect the battery leads.
Page 735 If the automatic transaxle warning indication/light illuminates, the transaxle has an electri‐ cation/Warning cal problem. Continuing to drive your Mazda in this condition could cause damage to your Light transaxle. Consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible.
Page 736 When the light is turned on The light turns on under the following conditions. The system may have a malfunction. Have the vehicle checked at an expert repairer, we recommend an Authorised Mazda Re- pairer. When there is a malfunction in the 4WD system.
Page 737 Authorised Mazda Repairer or a tyre repair station. Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Page 738 Light pert repairer, we recommend an Authorised Mazda Repairer as soon as possible. Refer to Emergency Operation for Starting the Engine on page 4-10. If the engine does not start with the correct key, and the security indicator light remains illuminated or flashing, try the following: Make sure the key is within the operational range for signal transmission.
Page 739 Signal Warning A problem in the system may be indicated under the following conditions. Have your vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. The light does not turn on when the ignition is switched ON.
Page 740 Warning/Indicator Lights and Warning Sounds Signal Warning This light illuminates if there is a malfunction in the LED headlight. Have your vehicle inspected by an expert repairer, we recommend an Authorised Mazda Repairer. LED Headlight Warning Light ▼ Taking Action Take the appropriate action and verify that the warning light turns off.
Page 741 If Trouble Arises Warning/Indicator Lights and Warning Sounds Signal Warning Action to be taken The seat belt warning light turns on if the driver or front passenger's seat is occupied and the seat belt is not fastened with the ig- nition switched ON.
Page 742 Authorised Mazda Repairer or a tyre repair station.
Page 743 Leaks need to be addressed by more than simply refilling the trouble tyre as leaks are dangerous ― take it to an expert repairer, we recommend an Authorised Mazda Repairer which has all the equipment to fix tyres, TPMS systems and order the best replacement tyre for your vehicle.
Page 744 If Trouble Arises Warning/Indicator Lights and Warning Sounds Signal Cause Action to be taken Take the key from another manufacturer A key from another manufacturer similar to similar to the key out of the operation the key is in the operation range. range.
Page 745 Cancel the AUTOHOLD function or the cle is being held in a stop position by the Mazda Radar Cruise Control with Stop AUTOHOLD function or during the & Go function (MRCC with Stop & Go...
Page 746 If Trouble Arises Warning/Indicator Lights and Warning Sounds Display Content Action to be taken Indicates the possibility of the vehicle not being held in the stopped position by Depress and hold your foot on the brake the AUTOHOLD function, such as on pedal.
Page 747: Message Indicated On Display
▼ Stop Vehicle in Safe Place Immediately If the following messages are displayed in the centre display (Type B audio), a vehicle system may be malfunctioning. Stop the vehicle in a safe place and contact an Authorised Mazda Repairer. Display Indicated Condition Displays if the engine coolant temperature has increased excessively.
Page 748 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Verify Display Content Displays in the following cases: Display Indicated Condition/Action to be taken The following message is displayed when the temperature around the centre display is high. Lowering the temperature in the cabin or the temperature around the centre display by avoiding direct sunlight is recommended.
Page 749: Warning Sound Is Activated
If lights are on and the ignition is switched expert repairer, we recommend an to ACC or off, a continuous beep sound Authorised Mazda Repairer to have the will be heard when the driver's door is vehicle inspected as soon as possible.
Page 750 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Ignition Not Switched Off (STOP) NOTE Because the key utilizes low-intensity Warning Beep radio waves, the Key Removed From European models Vehicle Warning may activate if the key is carried together with a metal object or it If the driver's door is opened with the is placed in a poor signal reception area.
Page 751 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Key Left-in-vehicle Warning Beep ▼ Outside Temperature Warning (With the advanced keyless Beep function) Warns the driver of the possibility of icy If all the doors and luggage compartment roads when the outside temperature is low. are locked using another key while the key If the outside temperature is lower than is left in the cabin, the beep which sounds...
Page 752 You can change the vehicle speed setting simultaneously, have your vehicle at which the warning is triggered. inspected at an expert repairer, we recommend an Authorised Mazda ▼ 120 km/h Warning Beep Repairer. If the vehicle speed exceeds 120 km/h, a ▼...
Page 753 ▼ Mazda Radar Cruise Control we recommend an Authorised Mazda (MRCC) System Warnings Repairer. The Mazda Radar Cruise Control (MRCC) system warnings notify the driver of (When the SCR warning light turns on/ system malfunctions and cautions on use flashes) when required.
Page 754 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Mazda Radar Cruise Control with ▼ Lane Departure Warning Sound Stop & Go function (MRCC with While the system is operating, if the Stop & Go function) System system determines that the vehicle may...
Page 755 5 km/h (3 mph). Be careful not to drive over the set speed. (With Mazda Radar Cruise Control (MRCC) or Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)) If the set speed is set lower than the current...
Page 756: When Liftgate Cannot Be Opened
Lever Cover After performing this emergency measure, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. 7-70...
Page 757: Active Driving Display Does Not Operate
If the active driving display does not operate, switch the ignition off and then restart the engine. If the active driving display does not operate even with the engine restarted, have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. 7-71...
Page 758 MEMO 7-72...
Page 759: Important Consumer Information Including Warranties And Add-On Equipment
Customer Information Important consumer information including warranties and add-on equipment. Warranty..........8-2 Declaration of Conformity....8-10 Registering Your Vehicle in A Declaration of Conformity..8-10 Foreign Country......8-2 Add-On Non-Genuine Parts and Electromagnetic Compatibility..8-47 Accessories........8-3 Electromagnetic Compatibility......8-47 Cell Phones.........8-4 Cell Phones Warning....8-4 Collection/Disposal of Old Equipment/ Used Battery........8-49 Collection and Processing of Data in...
Page 760: Customer Information
Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorised Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 761: Add-On Non-Genuine Parts And Accessories
Other parts and accessories than those mentioned above have not been examined and approved by Mazda unless explicitly stated by Mazda. We cannot certify the suitability of such products. Mazda is not liable for any damage caused by the use of such products. WARNING...
Page 762: Cell Phones
Customer Information Cell Phones Cell Phones Warning WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your country: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver's hands.
Page 763: Collection And Processing Of Data In The Vehicle
Customer Information Collection and Processing of Data in the Vehicle Collection and Processing of Data in the Vehicle In-vehicle data processing Electronic control units are installed in your vehicle. These control units process data they, for example, receive from vehicle sensors, generate themselves or exchange with each other. Some control units are required for the safe operation of your vehicle, others provide you with support while driving (driver assistance systems) or enable comfort or infotainment functions.
Page 764 Customer Information Collection and Processing of Data in the Vehicle For more information on your legal rights relating to Mazda (for example, your right to the deletion and correction of data), please refer to the applicable Data Protection Policy on the country-specific Mazda website, where contact details are also provided.
Page 765: The Vehicle
The data from the vehicle may be read out by employees of the Mazda Network (e.g. authorised workshops, manufacturer) or by third parties (e.g., breakdown services, independent repair shops). The same applies in the case of warranty cases and quality assurance measures.
Page 766 Customer Information Collection and Processing of Data in the Vehicle address book data for use in conjunction with an integrated hands-free system or  integrated navigation system, navigation destinations entered,  data relating to the use of internet services.  This data for comfort and infotainment functions may be stored locally on the vehicle or it may be located on a device that you have connected to your vehicle (e.g., smartphone, USB stick or MP3 player).
Page 767 Collection and Processing of Data in the Vehicle Services provided by the manufacturer For our online services, the respective functions are described by Mazda in an appropriate place (e.g., in the operating instructions and/or on the country-specific Mazda website) and provided together with the associated data protection information.
Page 768: Declaration Of Conformity
Customer Information Declaration of Conformity Declaration of Conformity ▼ Keyless Entry System/Immobilizer System 8-10...
Page 769 Customer Information Declaration of Conformity 8-11...
Page 770 Customer Information Declaration of Conformity ▼ Blind Spot Monitoring (BSM) System Hereby, FURUKAWA AUTOMOTIVE SYSTEMS INC., declares that the radio equipment type 24GMMR1A is in compliance with Directive 2014/53/EU. 8-12...
Page 771 Customer Information Declaration of Conformity The full text of the EU declaration of conformity is available at the following internet address: http://www.furukawaas.co.jp/english/approval/ 8-13...
Page 772 Customer Information Declaration of Conformity 8-14...
Page 773 Customer Information Declaration of Conformity 8-15...
Page 774 Customer Information Declaration of Conformity 8-16...
Page 775 Customer Information Declaration of Conformity 8-17...
Page 776 Customer Information Declaration of Conformity 8-18...
Page 777 Customer Information Declaration of Conformity 8-19...
Page 778 Customer Information Declaration of Conformity 8-20...
Page 779 Customer Information Declaration of Conformity ▼ Tyre Pressure Monitoring System 8-21...
Page 780 Customer Information Declaration of Conformity 8-22...
Page 781 Customer Information Declaration of Conformity 8-23...
Page 782 Customer Information Declaration of Conformity 8-24...
Page 783 Customer Information Declaration of Conformity 8-25...
Page 784 Customer Information Declaration of Conformity 8-26...
Page 785 Customer Information Declaration of Conformity 8-27...
Page 786 Customer Information Declaration of Conformity ▼ Radio System Type A 8-28...
Page 787 Customer Information Declaration of Conformity 8-29...
Page 788 Customer Information Declaration of Conformity 8-30...
Page 789 Customer Information Declaration of Conformity Type B 8-31...
Page 790 Customer Information Declaration of Conformity 8-32...
Page 791 Customer Information Declaration of Conformity 8-33...
Page 792 Customer Information Declaration of Conformity ▼ Audio System Type A(non-touchscreen) 8-34...
Page 793 Customer Information Declaration of Conformity 8-35...
Page 794 Customer Information Declaration of Conformity 8-36...
Page 795 Customer Information Declaration of Conformity Type B(touchscreen) 8-37...
Page 796 Customer Information Declaration of Conformity 8-38...
Page 797 Customer Information Declaration of Conformity 8-39...
Page 798 Customer Information Declaration of Conformity 8-40...
Page 799 Customer Information Declaration of Conformity 8-41...
Page 800 Customer Information Declaration of Conformity ▼ Distance Recognition Support System (DRSS)/Mazda Radar Cruise Control (MRCC)/Smart Brake Support (SBS) 8-42...
Page 801 Customer Information Declaration of Conformity 8-43...
Page 802 Customer Information Declaration of Conformity 8-44...
Page 803 Customer Information Declaration of Conformity For Vehicles sold in Moldova MODEL: DNMWR006 8-45...
Page 804 Customer Information Declaration of Conformity ▼ Mazda ERA-GLONASS 8-46...
Page 805: Electromagnetic Compatibility
10 regulation as related to electromagnetic compatibility. Radio Frequency (RF) transmitter equipment (e.g. cellular telephones, amateur radio transmitters, etc.) may only be fitted to your Mazda if they comply with the parameters shown in the table below. 1 UN-R stands for United Nations Regulation.
Page 806 Customer Information Electromagnetic Compatibility Frequency Band (MHz) Maximum output power (Wattage) Aerial Positions 1710 ― 1885 1885 ― 2025 2400 ― 2500 0.01 In a cabin ® Only for Bluetooth NOTE After the installation of RF transmitters, check for disturbances from and to all electrical equipment in the vehicle, both in the standby and transmit modes.
Page 807: Collection/Disposal Of Old Equipment/Used Battery
Customer Information Collection/Disposal of Old Equipment/Used Battery Information for Users on Collection and Disposal of Old Equipment and Used Batteries When disposing your old battery, please refer to the information as follows. ▼ Information on Disposal in the European Union These crossed-out wheeled bin symbols on the products, packaging, and/or accompanying documents mean that used electronic products and batteries should not be mixed with general household waste.
Page 808 Customer Information Collection/Disposal of Old Equipment/Used Battery ▼ Information on Disposal in Other Countries Outside the European Union The above symbols are only valid in the European Union. If you wish to discard old products and used batteries, please contact your local authorities, your waste disposal service or the point of sales where you purchased the items, and ask for the correct method of disposal.
Page 809 Specifications Technical information about your Mazda. Identification Numbers..... 9-2 Personalisation Features....9-13 Vehicle Information Labels..9-2 Personalisation Features..... 9-13 Specifications........9-5 Specifications....... 9-5...
Page 810: Specifications
Specifications Identification Numbers ▼ Chassis Number/Vehicle Vehicle Information Identification Number (Ireland, UK, Labels Swaziland, Namibia, Botswana, Lesotho, vehicles assembled in ▼ Vehicle Identification Number Russian Federation) (South Africa, Arab Gulf Chassis Number Cooperation Council, Iraq) Open the cover shown in the figure to The vehicle identification number legally check the chassis number.
Page 811 Specifications Identification Numbers Vehicles assembled in Russian ▼ Engine Number Federation SKYACTIV-G 2.0, SKYACTIV-G 2.5, and SKYACTIV-G 2.5T Forward ▼ Tyre Pressure Label SKYACTIV-D 2.2 Left-hand drive model Forward Right-hand drive model...
Page 812 Specifications Identification Numbers ▼ Conformity Plate (Arab Gulf Cooperation Council, Iraq) Production year and month are shown on this plate.
Page 813 Specifications Specifications Specifications ▼ Engine Petrol engine Specification Item SKYACTIV-G 2.0 SKYACTIV-G 2.5 SKYACTIV-G 2.5T Type DOHC-16V in-line, 4-cylinder 83.5 × 91.2 mm (3.29 × 3.59 Bore × Stroke 89.0 × 100 mm (3.50 × 3.94 in) Displacement 1,998 ml (1,998 cc) 2,488 ml (2,488 cc) Compression ra- 13.0...
Page 814 ACEA C3 Alternative Oil Quality 0W-30/5W-30 0W-30 ACEA C3 5W-30 Refer to Recommended Oil on page 6-24. Mazda Original Oils are specially designed/tested for the respective engine. For optimum performance we recommend to use Mazda Original Oils at all times.
Page 815 Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3 or DOT-4 Mazda Long Life Gear Oil G7 is superior oil for low fuel cost and optimum shift-feel. Using Mazda Long Life Gear Oil G7 is recommended. If Mazda Long Life Gear Oil G7 cannot be obtained, use standard oil (API Service GL-4 (SAE 75W-80)).
Page 816 Specifications Specifications Item Capacity Left-hand drive model 7.1 L (7.5 US qt, 6.2 Imp qt) Manual transaxle Right-hand drive model 7.0 L (7.4 US qt, 6.2 Imp qt) SKYAC- Israel 7.4 L (7.8 US qt, 6.5 Imp qt) Automat- TIV-G 2.0 ic trans- Left-hand drive model 7.4 L (7.8 US qt, 6.5 Imp qt)
Page 817 Specifications Specifications Item Vehicle specification 17 inch styled steel wheel 1,585 mm (62.4 in) vehicle 17 inch aluminium wheel Front tread 1,595 mm (62.8 in) vehicle 19 inch aluminium wheel 1,595 mm (62.8 in) vehicle 17 inch styled steel wheel 1,585 mm (62.4 in) vehicle 17 inch aluminium wheel...
Page 818 Specifications Specifications Interior light Category Light bulb Wattage UN-R LED type ― Luggage compartment light Bulb type ― LED type ― Overhead light (Front)/Map lights Bulb type ― LED type ― Rear map lights Bulb type ― LED type ― Vanity mirror lights Bulb type ―...
Page 819 The tyres have been optimally matched with the chassis of your vehicle. When replacing tyres, Mazda recommends that you replace tyres of the same type originally fitted to your vehicle. For details, contact an expert repairer, we recommend an Authorised Mazda Repairer.
Page 820 Refer to Fuses on page 6-58. ▼ Brakes If you require information regarding the wear limit specification for the brake disc plates and the measurement method, please contact an expert repairer, we recommend an Authorised Mazda Repairer. The information is made freely available. 9-12...
Page 821 Personalisation Features The following personalisation features can be set or changed by the customer or an Author- ised Mazda Repairer. Consult an Authorised Mazda Repairer for details. Additionally, some of the personalisation features can be changed by the customer depend- ing on the feature.
Page 822 Specifications Personalisation Features Settings Change Factory Set- Available Set- Item Feature Method ting tings The timing at which the steering wheel op- eration assist of the Lane-keep Assist Sys- Late Early/Late A ― tem (LAS) & Lane Departure Warning System (LDWS) oper- ates can be changed.
Page 823 Specifications Personalisation Features Settings Change Factory Set- Available Set- Item Feature Method ting tings The system can be changed so that Blind Spot On/Off A ― Monitoring (BSM) does not operate. Blind Spot Mon- itoring (BSM) High/ (page 4-141) High Low/ A ―...
Page 824 Specifications Personalisation Features Settings Change Factory Set- Available Set- Item Feature Method ting tings Vehicle Lock: Out of Park Unlock: In Park/ Lock: Shifting Out of Park/ Lock: When Lock: When Door locks Operation condition of auto lock/unlock func- Driving Un- Driving Unlock: In Park/ (page 3-13)
Page 825 Specifications Personalisation Features Settings Change Factory Set- Available Set- Item Feature Method ting tings High/ Med. High/ Auto-light con- Timing by which lights turn on Medium Medium/ A ― trol (page 4-87) Med. Low/ Adaptive Front Lighting System On/Off A ― Operational/non-operational (AFS) (page 4-135)
Page 826 C ― ance Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda recommends that these systems remain On. Only the volume of the warning beep during Blind Spot Monitoring (BSM) operation can be changed. The volume of the warning beep during Rear Cross Traffic Alert (RCTA) operation cannot be changed.
Page 827 Specifications Personalisation Features This system functions only when the navigation system is functioning. When the ultrasonic sensors detect an obstruction, the contents indicated on the centre display switches to the 360°View Monitor. (Vehicles with 360°View Monitor) If the auto-wiper control is set to Off, the wiper lever position is set to intermittent operation.
Page 828 MEMO 9-20...
Page 829: Index
Index 10-1...
Page 830 Index Manual Type........5-7 Operating Tips....... 5-4 Accessory Socket......5-149 Vent Operation.......5-5 Active Driving Display..... 4-73 Antilock Brake System (ABS)..4-115 Adaptive Front Lighting System Armrest Box........5-154 (AFS)..........4-135 Ashtray..........5-157 Adaptive LED Headlights (ALH)... 4-138 Audio Control Switch AdBlue® (With Selective Catalytic Adjusting the Volume....5-15 Reduction (SCR) System)....6-32 Mute Switch........
Page 831 Index Aerial........... 5-19 Bluetooth® [Type B (touchscreen)] Appendix........5-133 Bluetooth® Audio..... 5-104 Audio Control Switch....5-15 Bluetooth® Hands-Free.....5-112 Audio Set [Type A (non- Bluetooth® Preparation.....5-101 touchscreen)]....... 5-20 Body Lubrication......6-36 Audio Set [Type B Bonnet Release........6-20 (touchscreen)]......5-66 Bottle Holder........5-153 AUX/USB mode......5-17 Brakes Before Using the Audio...
Page 832 Index Emergency Starting Push-starting........ 7-34 Defogger..........4-100 Running out of fuel (SKYACTIV-D Mirror.........4-100 2.2)..........7-35 Rear window......4-100 Starting a flooded engine Deposit Cleaner.........3-29 (SKYACTIV-G 2.0, SKYACTIV-G Diesel Particulate Filter (SKYACTIV-D 2.5, and SKYACTIV-G 2.5T)..7-34 2.2)...........4-270 Emergency Stop Signal System..4-113 Dimensions..........9-8 Emergency Towing Direction Indicators......4-94 Towing description......
Page 833 Index Flat Tyre..........7-14 Coming home light......4-90 Mounting the spare tyre....7-28 Control......... 4-87 Removing a flat tyre....7-26 Flashing........4-90 Floor Mat.......... 3-54 Headlight flashing....... 4-90 Fluid High-low beam......4-90 Brake/Clutch........6-31 Leaving home light..... 4-91 Washer......... 6-32 Levelling........4-91 Fluids Running lights......
Page 834 Lane Departure Warning System (LDWS) Display......4-30 (LDWS) Display......4-48 Maintenance Monitor....4-29 Maintenance Monitor....4-47 Mazda Radar Cruise Control with Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function (MRCC with Stop & Go function) Display..4-31 Stop &...
Page 835 Lane-keep Assist System (LAS) & Vehicle Speed Alarm....4-66 Lane Departure Warning System Warning Indication/Warning (LDWS)........4-188 Lights........... 4-67 Mazda Radar Cruise Control with Interior Care........6-70 Stop & Go function (MRCC with Active driving display Stop & Go function)....4-174 maintenance......... 6-72 Mazda Radar Cruise Control Cleaning the window interiors..6-73...
Page 836 Maintenance Monitor......6-15 Keys.............3-2 Map Lights........5-145 Key suspend function....3-7 Mazda ERA-GLONASS..... 7-2 Transmitter........3-4 Mazda Radar Cruise Control with Stop & Key Left-in-luggage Compartment Go function (MRCC with Stop & Go Warning beep (With the advanced function).......... 4-174 keyless function)....... 7-64 Close proximity warning...
Page 837 Index Meters..........4-20 Mirrors Radar Sensors (Rear)...... 4-257 Outside mirrors......3-36 Radar Sensor (Front).......4-254 Rearview mirror......3-38 Rearview Mirror........3-38 Mirror Defogger......4-100 Rear Coat Hooks......5-157 Multi-information Display (Type Rear Cross Traffic Alert (RCTA)..4-158 A)............4-22 Rear Door Child Safety Locks..3-17 Multi-information Display (Type Rear Fog Light........
Page 838 Index Roadside Emergency Triangle Retaining Stopping the Smart City Brake Strap..........7-13 Support [Forward] (SCBS F) system Rocking the Vehicle......3-55 operation........4-214 Running-In........3-52 Smart City Brake Support [Reverse] (SCBS R)........4-216 Stopping the Smart City Brake Support [Reverse] (SCBS R) system Saving Fuel and Protection of the operation........
Page 839 Tyre chains........3-56 Lane Departure Warning sound... 7-68 Tyre inflation pressure....6-47 Lights-on reminder...... 7-63 Tyre rotation........ 6-48 Mazda Radar Cruise Control with Tyre Inflation Pressure Warning Stop & Go function (MRCC with Beep...........7-66 Stop & Go function) system Tyre Pressure Monitoring System... 4-266 warnings........7-68...
Page 840 Index Outside temperature warning Winter Driving........3-55 beep..........7-65 Wiper Power Liftgate Warning Beep..7-65 Replacing Rear Window Wiper Power steering warning buzzer..7-66 Blade..........6-40 Request switch inoperable warning Replacing windscreen wiper beep (With the advanced keyless blades........... 6-37 function)........7-64 Seat belt warning beep....7-63 Selective Catalytic Reduction (SCR) 120 km/h warning beep....

Mazda CX-5 Manual

Index 10

2 Essential Safety Equipment

Seats

Seat Warmer/Seat Ventilation/Heated Steering Wheel

Seat Belt Systems

Child Restraint

SRS Air Bags

3 Before Driving

Keys

Advanced Keyless Entry

System

Doors and Locks

Fuel and Emission

Mirrors

Windows

Security System

Driving Tips

Towing

4 When Driving

Start/Stop Engine

Manual Transaxle Operation

Automatic Transaxle

Switches and Controls

Brake

Abs/Tcs/Dsc

I-ELOOP

Forward Driving

5 Interior Features

Air-Conditioning System

Before Using the Audio System

Audio Set [Type a (Non-Touchscreen)]

Audio Set [Type B (Touchscreen)]

Appendix

Interior Equipment

6 Maintenance and Care

7 If Trouble Arises

Mazda ERA-GLONASS

Parking in an Emergency

Flat Tyre

Battery Runs out

Emergency Starting

Overheating

Emergency Towing

Warning/Indicator Lights and Warning Sounds

When Liftgate Cannot be Opened

Active Driving Display Does Not Operate

Quick Links

Chapters

Troubleshooting

Related Manuals for Mazda CX-5

Summary of Contents for Mazda CX-5
