Mazda CX-5 2018 Owner's Manual

Table of Contents

Quick Links

Table of Contents

Summary of Contents for Mazda CX-5 2018

Page 4 A CAUTION indicates a situation in which bodily injury or damage to your vehicle, or both, could result if the caution is ignored. NOTE A NOTE provides information and sometimes suggests how to make better use of your vehicle. A WARNING indicates a situation in which serious injury or death could result if the warning is ignored.
Page 8 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲...
Page 9 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱...
Page 10 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰...
Page 11 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲...
Page 12 ① ② ③ ④ ⑤ ⑥...
Page 13 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳...
Page 14 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱...
Page 15 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰...
Page 16 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲...
Page 17 ① ② ③ ④ ⑤ ⑥...
Page 18 ① ② ③ ④ ⑤ ⑥...
Page 19 ① ② ③ ④ ⑤...
Page 22 The front seats contain air bag components essential to the supplementary restraint system. Such modifications could damage the supplementary restraint system and result in serious injury. Consult an Authorised Mazda Repairer if there is any need to remove or reinstall the front seats.
Page 23 Do not drive with either front seats reclined: Sitting in a reclined position while the vehicle is moving is dangerous because you do not get the full protection from seat belts. During sudden braking or a collision, you can slide under the lap belt and suffer serious internal injuries.
Page 24 (Manual Seat) When moving the seats forward and rearward or returning a rear-reclined seatback to its upright position, make sure you hold onto the seatback with your hand while operating. If the seatback is not held, the seat will move suddenly and could cause injury. NOTE When returning a rear seat to its original position, place the seat belt in its normal •...
Page 25 ▼ Power operation...
Page 26 ▼ ▼ Be careful when using the seat warmer: The heat from the seat warmer may be too hot for some people, as indicated as follows, and could cause a low-temperature burn. Infants, small children, elderly people, and physically challenged people People with delicate skin People who are excessively fatigued People who are intoxicated...
Page 27 Do not use the seat warmer even when • taking a short nap in the vehicle: The seat may be heated excessively and cause a low-temperature burn. • Do not place heavy objects with sharp projections on the seat, or insert needles or pins into it: This could cause the seat to become excessively heated and result in injury from...
Page 28 If the vehicle has been serviced and the • battery leads disconnected, the programmed seat positions will have been erased. Re-programme the seat positions. NOTE If the driving position movement is not • changed, only the beep sounds. A seat position can be called up even •...
Page 29 NOTE If there is no driving position movement, • a beep is not heard. ▼ ▼ The driving position adjustment is • cancelled in the following cases: Any of the seat adjustment switches is • operated. The SET button is pressed. •...
Page 30 NOTE Make sure there is nobody in the rear seat When you fold down the left seatback, the area before operating (pulling) the remote centre seatback folds down at the same handle: time. Not checking the rear seat area for persons before folding the seatbacks with the strap/ remote handle is dangerous.
Page 31 (Folding the left seatback) Be careful when operating the remote handle with the centre seatback folded down. If a person sitting in the right rear seat places a hand on the centre seatback, it could be pinched by a seatback or seat component causing injury.
Page 32 Before folding the seatbacks down with the remote handle, make sure there is no cup in a rear cup holder. Folding the seatbacks with the remote handle while Always make sure the seat belts are fully a cup is in the cup holder could soil or pulled out from under the seatbacks: damage the seat bottom and seatback.
Page 33 ▼ ▼ Seat belt guide After adjusting the seatback, make sure that it is firmly locked and the red indication is not visible by attempting to lightly move the seatback forward and back: If the red indication is visible, the seatback is not locked.
Page 34 NOTE ▼ ▼ When you adjust the left seatback, the centre seatback moves at the same time. High Be careful when using the seat warmer: The heat from the seat warmer may be too hot for some people, as indicated as follows, and could cause a low-temperature burn.
Page 35 When the engine is stopped while the Do not use the seat warmer with anything • seat warmers are operating and then the having high moisture-retention ability such ignition is switched ON, the seat as a blanket or cushion on the seat: warmers will not turn back on The seat may be heated excessively and automatically.
Page 36 Always drive with the head restraints installed when seats are being used and make sure they are properly adjusted. In addition, always raise the head restraints on the rear outboard seats when they are being used: Driving with the head restraints adjusted too low or removed is dangerous.
Page 37 Always drive with the head restraints installed when seats are being used and make sure they are properly installed: Driving with the head restraints not installed is dangerous. With no support behind your head, your neck could be seriously injured in a collision. After installing a head restraint, try lifting it to make sure that it does not pull out: Driving with an unsecured head restraint is...
Page 38 A damaged seat belt cannot provide adequate protection in a collision. Have an expert repairer, we recommend an Authorised Mazda Repairer inspect all seat belt systems in use during an accident before they are used again.
Page 39 Positioning the Shoulder Portion of the Seat Belt: Improper positioning of the shoulder portion of the seat belt is dangerous. Always make sure the shoulder portion of the seat belt is positioned across your shoulder and near your neck, but never under your arm, on your neck, or on your upper arm. Positioning the Lap Portion of the Seat Belt: The lap portion of the seat belt worn too high is dangerous.
Page 40 Belt retraction may become difficult if the belts and rings are soiled, so try to keep them clean. For more details about cleaning the seat belts, refer to "Seat Belt Maintenance" (page 6-65). Ring ▼ ▼ ▼ ▼...
Page 41 If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting properly, have it inspected at an expert repairer, we recommend an Take up Authorised Mazda Repairer. Keep low slack on hip bone ▼ ▼...
Page 43 Have your seat belts changed immediately if the pretensioner or load limiter has been expended: Always have an expert repairer, we recommend an Authorised Mazda Repairer immediately inspect the seat belt pretensioners and air bags after any collision. Like the air bags, the seat belt...
Page 44 NOTE The pretensioner system may not • operate depending on the type of the collision. For details, refer to the SRS Air Bag Deployment Criteria (page 2- 54). Some smoke (non-toxic gas) will be • released when the air bags and pretensioners deploy.
Page 46 Use the correct size child-restraint system: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size. If not, the child could be seriously injured or even killed in an accident. Follow the manufacturer's instructions and always keep the child-restraint system buckled down: An unsecured child-restraint system is dangerous.
Page 47 Even in a moderate collision, the child-restraint system can be hit by a deploying air bag and moved violently backward resulting in serious injury or death to the child. (Taiwan, except front passenger seat, if equipped with the following label) NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
Page 48 The front passenger air bag deactivation OFF indicator light does not illuminate when seating a child in the child-restraint system. Luggage or other items are placed on the seat with the child in the child-restraint system. A rear passenger or luggage pushing or pulling down on the front passenger seatback. Luggage or other items are placed on the seatback or hung on the head restraint.
Page 49 To avoid burning yourself or a child, check them before you or your child touches them. NOTE Your Mazda is equipped with ISOFIX anchors for attachment of ISOFIX child-restraint systems on the rear seats. When using these anchors to secure a child-restraint system, refer to “Using ISOFIX Anchor” (page 2-40).
Page 50 ▼ NOTE When purchasing, ask the manufacturer of the child-restraint system which type of child-restraint system is appropriate for your child and vehicle. Due to variations in the design of ▼ • child-restraint systems, vehicle seats and seat belts, all child-restraint systems may not fit all seating positions.
Page 51 ▼ ▼ Always install a baby seat in the correct seat position: Installing a baby seat without first consulting the table “Child-Restraint System Suitability for Various Seat Positions” is dangerous. A baby seat Booster seat installed on the wrong seat position cannot be properly secured.
Page 52 Never use a rear-facing child-restraint system on the front passenger seat protected by an air bag: NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in Always install a rear-facing child seat in the front of it, DEATH or SERIOUS INJURY to the correct seat position: CHILD can occur.
Page 53 ▼ ▼ Never install a front-facing child seat in the wrong seat position: Installing a front-facing child seat without first consulting the table “Child-Restraint System Suitability for Various Seat Positions” is dangerous. A front-facing child seat installed in the wrong seat position cannot be properly secured.
Page 54 Do not install a front-facing child-restraint system on the front passenger seat unless it is unavoidable: In a collision, the force of a deploying air bag could cause serious injury or death to the child. If installing a front-facing child-restraint system on the front passenger seat is unavoidable, move the front passenger seat as far back as possible and adjust the seat bottom (height...
Page 55 • • •...
Page 57 NOTE An i-Size child-restraint system refers to a child-restraint system which has acquired • i-Size category certification for the UNECE 129 regulation. Vehicles with the mark indicated on the front surface of a rear seatback are not i-Size • child-restraint certified.
Page 59 Always remove the head restraint and install child-restraint system: Installing a child-restraint system without removing the head restraint is dangerous. ▼ The child-restraint system cannot be installed correctly which may result in death or injury to the child in a collision. Tether strap Forward Always install the head restraint and adjust...
Page 60 ▼ Make sure there are no seat belts or foreign objects near or around the ISOFIX anchor-secured child-restraint system: Not following the child-restraint system manufacturer's instructions when Follow the manufacturer's instructions for installing the child-restraint system is the use of the child-restraint system: dangerous.
Page 61 Always attach the tether strap to the Type A Type B correct tether anchor position: Attaching the tether strap to the incorrect tether anchor position is dangerous. In a collision, the tether strap could come off and loosen the child-restraint system. If the child-restraint system moves it could result in death or injury to the child.
Page 62 Always install the head restraint and adjust it to the appropriate position after removing the child-restraint system: Driving with the head restraint removed is dangerous as impact to the occupant's head cannot be prevented during emergency braking or in a collision, which could result in a serious accident, injury or death.
Page 63 • • • • • • • • • •...
Page 64 Seat belts must be worn in air bag equipped vehicles: Depending only on the air bags for protection during an accident is dangerous. Alone, air bags may not prevent serious injuries. The appropriate air bags can be expected to inflate only in the first accident, such as frontal, near frontal or side collisions that are at least moderate.
Page 65 Extreme Hazard! Never use a rear-facing child-restraint system on the front passenger seat with an air bag that could deploy: NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur. Even in a moderate collision, the child-restraint system can be hit by a deploying air bag and moved violently backward resulting in serious injury or death to the child.
Page 66 Do not attach objects on or around the area where a side air bag deploys: Attaching objects to the front seat in such a way as to cover the outboard side of the seat in any way is dangerous. In an accident the object could interfere with the side air bag, which inflates from the outboard side of the front seats, impeding the added protection of the side air bag system or redirecting the air bag in a way that is dangerous.
Page 67 It also includes installing extra electrical equipment on or near system components or wiring. An expert repairer, we recommend an Authorised Mazda Repairer can provide the special care needed in the removal and installation of front seats. It is important...
Page 68 Neither is likely to cause injury, however, the texture of the air bags may cause light skin injuries on body parts not covered with clothing through friction. Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and •...
Page 71 ▼ ▼...
Page 72 ▼ ▼ ▼ ▼...
Page 73 ▼ ▼ Only one side curtain air bag will deploy on the side of the vehicle that receives the force of an impact. ▼ ▼...
Page 74 NOTE In a frontal offset collision, the equipped air bags and pretensioners may all deploy depending on the direction, angle, and rate of impact.
Page 75 Impacts involving trees or poles Frontal offset impact to the vehicle Rear-ending or running under a truck's tail gate...
Page 76 Side impacts involving trees or poles Side impacts with two-wheeled vehicles Roll-over...
Page 77 ▼...
Page 78 Do not allow an occupant in the front passenger's seat to sit with a posture which makes it difficult for the front passenger occupant classification sensor to detect the occupant correctly: Sitting in the front passenger's seat with a posture which makes it difficult for the front passenger occupant classification sensor to detect the occupant correctly is dangerous.
Page 79 Under the following conditions, the front passenger occupant classification sensor cannot detect a passenger sitting on the front passenger's seat correctly and the deployment/ non-deployment of the air bags cannot be controlled as indicated in the front passenger air bag deactivation indicator light on/off condition chart. For example: A front passenger is seated as shown in the following figure: A rear passenger pushes up on the front passenger seat with their feet.
Page 80 Then, if the front passenger air bag deactivation OFF indicator light still does not turn on, install the child-restraint system on the rear seat and consult an Authorised Mazda Repairer as soon as possible.
Page 81 OFF indicator light remains turned on, move the passenger to the rear seat. If sitting in the rear seat is not possible, slide the front passenger seat as far back as possible. Consult an Authorised Mazda Repairer as soon as possible.
Page 82 • • • • • • • • • • •...
Page 84 The key is near electronic devices such as personal computers. Transmitter Auxiliary key Non-Mazda genuine electronic equipment is installed in the vehicle. There is equipment which discharges radio waves near the vehicle. The key (transmitter) may consume battery power excessively if it receives high-intensity radio waves.
Page 85 Knob • • •...
Page 86 Additional keys can be obtained at an • Authorised Mazda Repairer. Up to 6 keys can be used with the keyless functions per vehicle. Bring all keys to an Authorised Mazda Repairer when additional keys are required. ▼ Changes or modifications not expressly...
Page 87 The volume of the beep sound can also be changed. Refer to Personalisation Features on page 9-12. Use the following procedure to change the setting. 1. Switch the ignition off and close all of NOTE the doors and the liftgate. (European models) •...
Page 88 Type A Type B NOTE (Auto re-lock function) • After unlocking with the key, all doors and the liftgate will automatically lock if any of the following operations are not performed within about 30 seconds. If your vehicle has a theft-deterrent system, the hazard warning lights will flash for confirmation.
Page 89 The luggage compartment is out of the ▼ ▼ • assured operational range, however, if the key (transmitter) is operable the engine will start. Interior aerial Operational range Interior aerial Operational range NOTE The engine may not start if the key is placed in the following areas: Around the instrument panel •...
Page 90 Radio waves from the key may affect repairer, we recommend an Authorised medical devices such as pacemakers: Mazda Repairer for details. If the Before using the key near people who use advanced keyless entry system has been medical devices, ask the medical device...
Page 91 NOTE The system may not operate if you are • too close to the windows or door handles, or liftgate. If the key is left in the following areas • and you leave the vehicle, the doors may NOTE be locked depending on the radio wave When the battery power is low, or in conditions even if the key is left in the places where there are high-intensity radio...
Page 92 Always confirm the safety around the vehicle before opening a door and the liftgate: Suddenly opening a door and the liftgate is dangerous. A passing vehicle or a pedestrian could be hit and cause an Always take all children and pets with you accident.
Page 93 (European models) ▼ All doors and the liftgate will automatically unlock if they are locked using the power door locks with any door open. If all the doors are closed even though the liftgate is open, all the doors will lock.
Page 94 2. Open the driver's door. 3. Within 30 seconds of opening the driver's door, press and hold the LOCK button on the key for 5 seconds or longer. The beep sound activates at the currently set volume. The setting NOTE changes each time the LOCK button on the key is pressed and the beep Confirm that all doors and the liftgate...
Page 95 (Walk-away auto lock function) ▼ A beep sound is heard when all doors and the liftgate are closed while the advanced key is being carried. All doors and the liftgate are locked automatically after about three seconds when the advanced key is out of the operational range.
Page 96 There are only a total of six auto lock/ ▼ • unlock settings available for automatic transaxle vehicles, and three for manual transaxle vehicles. Be sure to press the unlock side of the door-lock switch the correct number of times according to the Do not pull the inner handle on a front selected function number.
Page 97 Current Function Number Press unlock side of lock switch once Press lock side of Function Number 1 lock switch Press 2 times Function Number 2 Cancel setting Press 3 times Wait for 3 second Function Number 3 Function set (The number of beeps Press 4 times heard is the same as...
Page 98 The procedure can be cancelled by • pressing the lock side of the door-lock switch. Never activate the double locking system ▼ with passengers, especially children, still inside the vehicle: Activating the system with passengers, especially children, still inside the vehicle is dangerous.
Page 99 NOTE ▼ You can also activate the system by • pressing the lock button on the transmitter twice within 3 seconds. (With the advanced keyless • function) You can also activate the system by pressing the request switch twice within 3 seconds. Unlocked: Red indicator Lock NOTE...
Page 100 ▼ ▼ Door-lock knob Unlock Lock NOTE When locking the door this way: Be careful not to leave the key inside the • vehicle. The driver's door lock knob cannot be • used while the driver's door is open.
Page 101 It may affect the side or damper stay. Consult an expert repairer, rear field of view. we recommend an Authorised Mazda Repairer if a liftgate damper stay is deformed or damaged for reasons such as a collision or if there is some other Before opening the liftgate, remove any problem.
Page 102 When the liftgate latch is released by ▼ • pressing the electric liftgate opener, the liftgate raises slightly. If the liftgate is not operated for a certain period of time, the liftgate cannot be raised. To open Press the electric liftgate opener again. To close To close the liftgate from its slightly raised position, open it first by pressing...
Page 103 NOTE Never allow children to operate the power Confirm that the liftgate is securely closed. liftgate system: The liftgate, move it without pressing the Allowing children to operate the power electric liftgate opener to verify that the liftgate switch and the keyless entry system liftgate has not been left ajar.
Page 104 NOTE NOTE Do not apply unnecessary force to the When the ignition is switched ON, the • • power liftgate when it is opening/closing transmitter does not operate. electrically. Unnecessary force on the When opening the liftgate by pressing • liftgate may cause it to reverse direction the power liftgate button on the of movement automatically.
Page 105 (Automatic transaxle) • • If the vehicle moves with the selector lever shifted to a position other than P while the liftgate is opening/closing electrically, the liftgate moves as follows: While opening electrically • The buzzer is activated, and the liftgate moves in the reverse direction automatically and closes.
Page 106 Electric liftgate opener NOTE Set the desired fully-open position of the liftgate at the position where it is open more than halfway. The position where it is less than halfway open cannot be set. Power liftgate close switch NOTE After about 3 seconds have elapsed since the switch was pressed, a beep sound is activated 2 times to indicate that the liftgate fully-open position has changed.
Page 107 NOTE The jam-safe equipment does not activate during easy closure operation when the Always check the area around the power power liftgate is between the near-shut liftgate before opening/closing it: position and fully closed position. Not checking for occupants and objects around the power liftgate before opening/ closing it is dangerous.
Page 108 When opening/closing the liftgate, the ▼ • weight of the liftgate is different depending on whether the luggage compartment cover is used or not, however, this does not indicate a malfunction. Do not place anything on top of the luggage compartment cover: Placing luggage or other cargo on top of the luggage compartment cover is dangerous.
Page 109 Strap Side board Holder Luggage board Strap...
Page 110 ▼...
Page 111 Authorised Mazda Dealer. If a deposit cleaner other than the Mazda genuine product is used, it could result in damage to the fuel system or the engine internally; therefore use only the Mazda genuine product.
Page 112 Never add fuel system additives. Otherwise, the emission control system could be damaged. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details. NOTE When refuelling, always add at least 10 L (2.6 US gal, 2.2 Imp gal) of fuel.
Page 113 Either condition will damage the converter and cause poor performance. USE ONLY UNLEADED FUEL. Do not drive your Mazda with any sign of engine malfunction. Do not coast with the ignition switched off. Do not descend steep grades in gear with the ignition switched off.
Page 114 Either condition will damage the converter and cause poor performance. Do not drive your Mazda with any sign of engine malfunction. Do not coast with the ignition switched off. Do not descend steep grades in gear with the ignition switched off.
Page 115 ® Use a Mazda genuine product or a product conforming to ISO22241-1 for AdBlue . If ® incompatible AdBlue is used, the SCR system may not operate normally. In addition, the use ® ® of incompatible AdBlue may be subject to fines and penalties. For the recommended AdBlue consult the nearest expert repairer, we recommend an Authorised Mazda Repairer.
Page 116 Open the windows or adjust the heating or cooling system to draw fresh air when idling the engine: Exhaust gas is dangerous. When the vehicle is stopped with the windows closed and the engine running for a long time even in an open area, exhaust gas, which contains poisonous carbon monoxide, could enter the cabin.
Page 117 Always use only a designated Mazda fuel-filler cap or an approved equivalent, available at an expert repairer, we When removing the fuel-filler cap, loosen recommend an Authorised Mazda the cap slightly and wait for any hissing to Repairer. The wrong cap can result in a...
Page 118 Fuel-filler flap Fuel-filler cap...
Page 119 ▼ ▼ Heated steering wheel switch Never adjust the steering wheel while the Heating area vehicle is moving: Adjusting the steering wheel while the vehicle is moving is dangerous. Moving it can very easily cause the driver to abruptly turn to the left or right. This can lead to loss of control or an accident.
Page 120 The perceived distance of objects in the • outer and inner regions of the wide angle mirror is different. Objects appearing in the outer region are actually further away than they are in ▼ the inner region. Be sure to look over your shoulder before changing lanes: Changing lanes without taking into account the actual distance of the vehicle...
Page 121 Only operate the power folding outside mirror with the vehicle safely parked: Operating the power folding outside mirror while the vehicle is moving is dangerous. Wind blast on the mirror will cause them to Always return the outside mirrors to the collapse and you will be unable to return it driving position before you start driving: to the on-road position, preventing...
Page 122 ▼ ▼ Fold out Do not stack cargo or objects higher than the seatbacks: Cargo stacked higher than the seatbacks is Fold in dangerous. It can block your view in the rearview mirror, which might cause you to hit another car when changing lanes. NOTE For the manual antidazzle mirror, perform NOTE...
Page 123 Antidazzle lever Night NOTE Do not use glass cleaner or suspend • objects on or around the light sensor. Otherwise, light sensor sensitivity will be affected and may not operate normally. Light sensor The auto-dimming function is cancelled • when the ignition is switched ON and the shift/selector lever is in reverse (R).
Page 124 NOTE When driving with only one of the rear windows open, your ears might experience a resonating sound. However, this does not indicate a problem. The sound can be reduced by slightly opening a front window or by changing the size of the rear window opening.
Page 125 ▼ Master control switches Front passenger's window switch Power window Type A Rear window switches lock switch Unlocked Locked Close position position Driver's Open Close window Left rear Open window Type B Front passenger's Unlocked Locked window position position Right rear window NOTE A power window may no longer open/close if you continue to press the switch after fully...
Page 126 After the system has been re-initialized, ▼ each passenger window can be fully opened or closed automatically using the master control switches. ▼ NOTE The jam-safe function may operate NOTE • under the following conditions: Power window system initialization procedure A strong impact is detected while the •...
Page 127 Do not sit on or put heavy items on the area where the sunroof opens and closes. Otherwise, the sunroof could be damaged. Do not open or close the sunroof forcefully during freezing temperatures Do not let passengers stand up or extend or snowfall.
Page 128 Open Close Tilt up NOTE Close (Tilt down) If the sunroof does not operate normally, do the following procedure: 1. Switch the ignition ON. 2. Press the tilt switch, to partially tilt open the rear of the sunroof. 3. Repeat Step 2. The rear of the sunroof tilts open to the fully open position, then closes a little.
Page 129 ▼ NOTE The jam-safe function may operate • under the following conditions: A strong impact is detected while the • sunroof is closing automatically. The sunroof is closing automatically • during very low temperatures. In the event the jam-safe function •...
Page 130 If the engine does not start with the correct key, and the security indicator light keeps illuminating or flashing, the system may have a malfunction. Consult an Authorised Mazda Repairer. NOTE The keys carry a unique electronic code. • For this reason, and to assure your safety, obtaining a replacement key requires some waiting time.
Page 131 • lost. If a key is lost, consult an Authorised Mazda Repairer as soon as possible. If you lose a key, an Authorised Mazda • Repairer will reset the electronic codes of your remaining keys and immobilizer system. Bring all the remaining keys to an Authorised Mazda Repairer to reset.
Page 132 Do not shock or cause an impact to the intrusion sensor or the intrusion sensor bezel. Do not install seats that are not Mazda genuine products. To prevent obstruction of intrusion sensor, do not place objects or cargo near the intrusion sensor that are higher than the head restraints.
Page 133 Refer to Cancelling the Intrusion Sensor (With Intrusion Sensor) on page 3-52. • NOTE The liftgate does not open while the • theft-deterrent system is operating. For vehicles equipped with the power • liftgate, the liftgate can be opened even while the theft-deterrent system is operating by pressing the power liftgate button on the transmitter or the electric...
Page 134 When the doors are locked by NOTE • If any door or the liftgate remains closed pressing the lock button on the transmitter or using the auxiliary for 30 seconds, all the doors and the liftgate automatically re-lock and the theft key while the theft-deterrent system deterrent system arms even if a window is armed, the hazard warning lights...
Page 135 NOTE When the doors are unlocked by pressing the unlock button on the transmitter while the theft-deterrent system is turned off, the hazard warning lights will flash twice to indicate that the system is turned off. ▼ • • • •...
Page 136 • • • • • • • • • • • • • • • • • • • Never stop the engine when going down a hill: Stopping the engine when going down a hill is dangerous. This causes the loss of power steering and power brake control, and may cause damage to the drivetrain.
Page 137 • • Be extremely careful if it is necessary to • downshift on slippery surfaces: Downshifting into lower gear while driving on slippery surfaces is dangerous. The • sudden change in tyre speed could cause the tyres to skid. This could lead to loss of vehicle control and an accident.
Page 138 Loose floor mat(s) will interfere with the foot pedals and could result in an accident. If using an all-weather mat for winter use always remove the original floor mat. Make sure the floor mats are secured with the grommets or the retainers to prevent them from bunching up under the foot pedals (Driver's side): Using a floor mat that is not secured is...
Page 139 Do not spin the wheels at high speed, and do not allow anyone to stand behind a wheel when pushing the vehicle: When the vehicle is stuck, spinning the wheels at high speed is dangerous. The • spinning tyre could overheat and explode. This could cause serious injuries.
Page 140 Drive slowly. Braking performance can ▼ • be adversely affected if snow or ice adheres to the brake components. If this situation occurs, drive the vehicle slowly, releasing the accelerator pedal and lightly applying the brakes several times until the brake performance Chains may affect handling.
Page 141 NOTE Although Mazda recommends hexagon type steel ring chains, all chains within the installation specifications may be used. Tyre Side view Cross section view...
Page 142 Do not drive the vehicle on flooded roads as it could cause short circuiting of electrical/electronic parts, or engine damage or stalling from water absorption. If the vehicle has been immersed in water, consult an expert repairer, we recommend an Authorised Mazda Repairer.
Page 143 After driving at freeway speeds or up a long hill, idle the engine at least 30 seconds before stopping it. Otherwise, the turbocharger could be damaged. However, when i-stop operates, idling is unnecessary. Racing or over-revving the engine, particularly after it's just been started, can damage the turbocharger.
Page 144 Do not tow a trailer during the first 1,000 km (600 miles) of your new Mazda. If you do, you may damage the engine, transaxle, differential, wheel bearings, and other power train components. Damage caused by towing a trailer/caravan in Turkey is not covered by the vehicle's warranty.
Page 145 Be aware of the towing load weight differences when towing at high altitudes. For altitudes exceeding 1,000 meter (3,280 ft 10 in), always reduce the towing load by 10% for every 1,000 meter (3,280 ft 10 in) increase in altitude from the load indicated under the gross combination weight heading in the maximum trailer towing-load table.
Page 148 Always keep tow loads within specified limits as indicated in the Trailer Towing-Load Table: Attempting to tow loads greater than those specified is dangerous as it may cause serious handling and performance problems that could result in personal injury or vehicle damage, or both.
Page 149 ▼ Trailer hitch installation area Unit:mm (in) A:350—420 (13.8—16.5) B:989.7 (38.96) C:1046.9 (41.217) MAX 84 Kg (185.1 lb) Hitch coupling point...
Page 150 ▼ Never use the temporary spare tyre when towing: Using the temporary spare tyre on your vehicle when towing a trailer is dangerous as it could result in tyre failure, loss of control, and injury to vehicle occupants.
Page 151 ▼ Do not connect a trailer lighting system directly to the lighting system of your Mazda. This may damage your vehicle's electrical system and lighting systems. To connect the lighting system, consult an Authorised Mazda Dealer.
Page 152 ▼ Do not connect a hydraulic trailer-brake system to your vehicle's brake system: Connecting a hydraulic trailer-brake system directly to the vehicle brake system is dangerous and will result in inadequate braking and possible injury. ▼ • • • • •...
Page 153 If the vehicle exceeds 100 km/h (62 mph) with a trailer in tow, the vehicle could be damaged. • •...
Page 158 ▼ Before leaving the driver's seat, always switch the ignition off, set the parking brake, and make sure the selector lever is in P (automatic transaxle) position or in 1st gear or R (manual transaxle): Leaving the driver's seat without switching Indicator light the ignition off, setting the parking brake, and shifting the selector lever to P...
Page 159 This does not indicate an abnormality. the key. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details. If the push button start system functions have been deactivated, you can start the engine by following the procedure indicated when the key battery goes dead.
Page 160 This is for improved exhaust gas purification and does not indicate any parts defect. Indicator light Push button start NOTE NOTE If the push button start indicator • (Manual transaxle) • light (green) flashes, make sure that The starter will not operate if the the key is being carried (for vehicles clutch pedal is not depressed with a type A instrument cluster...
Page 161 (page 4-46), repairer, we recommend an messages are displayed in the Authorised Mazda Repairer as soon instrument cluster). Have your vehicle as possible. If this occurs, the engine inspected at an expert repairer, we can be force-started.
Page 162 (manual If the engine still does not start, transaxle) or the brake pedal have your vehicle inspected by an (automatic transaxle) until the Authorised Mazda Repairer (page glow indicator light in the 7-23). instrument cluster turns off and (SKYACTIV-D 2.2) •...
Page 163 (Manual transaxle vehicle with Spare keys or keys for other vehicles • i-stop function) equipped with an immobilizer system If the engine has stopped due to touch or come near the key. stalling, it can be restarted by depressing the clutch pedal within 3 seconds of the engine stopping.
Page 164 (amber) flashes. In this case, the engine may start, however, have the vehicle checked at an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. If the push button start indicator • light (green) does not illuminate, perform the operation from the beginning again.
Page 165 NOTE (SKYACTIV-G 2.0, SKYACTIV-G 2.5) • The cooling fan in the engine compartment could turn on for a few minutes after the ignition is switched from ON to OFF, whether or not the A/C Do not stop the engine while the vehicle is is on or off, to cool the engine moving: compartment quickly.
Page 166 NOTE The i-stop indicator light (green) turns on under the following conditions: • When engine idling is stopped. • Engine idling stop conditions are met while the vehicle is being driven. • The i-stop indicator light (green) turns off when the engine is restarted. •...
Page 168 • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
Page 169 • • • • • • • • • • • • • NOTE Under the following conditions, a period of time is required to stop engine idling The battery power is depleted for some reasons such as the vehicle has not been driven •...
Page 170 Engine-stop period is short or time until next engine idle stop is long The ambient temperature is high or low. • The battery power is depleted. • Power consumption by the vehicle's electrical parts is high. • Engine restarts automatically while engine idling is stopped Under the following conditions, the engine restarts automatically.
Page 171 Battery terminals are disconnected Engine idling may not stop right after the battery terminals are disconnected. In addition, if the battery is replaced, the i-stop functions must be verified. Consult an expert repairer, we recommend an Authorised Mazda Repairer.
Page 172 ▼ NOTE If the engine is stopped with the i-stop function cancelled, the i-stop function becomes operational when the engine is started the next time.
Page 173 ▼ • • Release foot from brake pedal Vehicle brake force maintained Engine restarted Acceleration Do not rely completely on the vehicle roll prevention function. The vehicle roll prevention function is a supplementary function which operates for a maximum of four seconds after releasing the brake pedal and accelerating the vehicle from an engine idling stop condition.
Page 174 Note that the vehicle may move suddenly after the vehicle roll prevention function is released while the vehicle is under the following conditions: The selector lever is in the N position. If the selector lever is shifted to the N position and the brake pedal is released while the i-stop function is operating, the brake force is gradually released.
Page 175 NOTE A problem in the system may be indicated under the following conditions. Have your vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. The light does not turn on when the ignition is switched ON. •...
Page 176 •...
Page 177 Instrument Cluster Type A (With Multi-information Display) Type B (Without Multi-information Display) Steering Switch Active Driving Display (Windscreen Type) (Auto Flip-up Type) ① ② ③...
Page 178 ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬...
Page 179 ▼ ▼ Selector Odometer Press the selector Trip meter A NOTE (Vehicles with type B audio) • Press the selector If the fuel economy data is reset using the fuel economy monitor, or trip A is Trip meter B reset using the trip meter when the Press the selector function which synchronizes the fuel economy monitor and the trip meter is...
Page 180 Only the trip meters record tenths of ▼ • kilometres (miles). The trip record will be erased when: • The power supply is interrupted • (blown fuse or the battery is disconnected). The vehicle is driven over 9999.9 km Do not run the engine with the tachometer •...
Page 181 ▼ If the engine coolant temperature gauge needle (white) flashes, there is a possibility of overheating. Drive slowly to reduce engine load until you can find a safe place to stop the vehicle and wait for the engine to cool down. Full Refer to Overheating on page 7-25.
Page 182 The direction of the arrow ( ) indicates • that the fuel-filler flap is on the left side of the vehicle. • • ▼ ▼ Bright NOTE (With auto-light control) • When the ignition is switched ON in the early evening or at dusk, the instrument panel illumination is dimmed for several seconds until the light sensor detects the NOTE...
Page 183 When the illumination dimmer is NOTE • When the temperature unit indicated in the cancelled, the instrument cluster cannot be dimmed even if the position lights are outside temperature display is changed, the temperature unit indicated in the turned on. engine coolant gauge display changes in When the illumination dimmer is •...
Page 184 ▼ NOTE Even though the distance-to-empty • display may indicate a sufficient amount of remaining driving distance before refuelling is required, refuel as soon as possible if the fuel level is very low or the low fuel warning light illuminates. ▼...
Page 185 Type A Type B Type A ▼ Type B NOTE The vehicle speed alarm display is activated at the same time the beep sound is heard. The set vehicle speed flashes several times.
Page 186 NOTE Always set the vehicle speed according • to the laws and regulations of the country/city in which the vehicle is driven. In addition, always verify the speed of the vehicle using the speedometer. The vehicle speed alarm function can be •...
Page 187 Multi-information Display INFO switch • • • • • • • • • • • • • • • • • • •...
Page 188 Press the INFO switch Current Fuel Economy, Warning message, Trip Meter A, Average Outside Temperature, Fuel Economy, Outside Odometer, Fuel Gauge Temperature, Odometer, Fuel Gauge Press the INFO switch Press the INFO switch Engine Coolant Current Fuel Economy, Temperature Gauge, Trip Meter B, Average Distance-to-empty, Fuel Economy, Outside...
Page 189 ▼ INFO switch NOTE Only the trip meters record tenths of • kilometres (miles). Odometer, The trip record will be erased when: Trip meter A • The power supply is interrupted • (blown fuse or the battery is disconnected). Press the INFO switch The vehicle is driven over 9999.9 km •...
Page 190 ▼ ▼ Full If the high engine coolant temperature 1/4 Full warning light (red) flashes, there is a possibility of overheating. Drive slowly to reduce engine load until you can find a safe place to stop the vehicle and wait for the engine to cool down.
Page 191 ▼ NOTE If the outside temperature is lower than -20 °C (-4 °F), the beep sound does NOTE not operate. However, the mark Under the following conditions, the • illuminates. outside temperature display may differ from the actual outside temperature depending on the surroundings and vehicle conditions: Significantly cold or hot temperatures.
Page 192 ▼ ▼ NOTE Even though the distance-to-empty • display may indicate a sufficient amount of remaining driving distance before refuelling is required, refuel as soon as possible if the fuel level is very low or the low fuel warning light illuminates. The display will not change unless you •...
Page 193 ▼ • • • NOTE If any of the INFO switch is pressed • while a message is displayed, it will no longer be displayed the next time the ignition is switched ON. After the vehicle is serviced and the •...
Page 194 ▼ ▼ ▼ ▼ ▼ ▼ ▼...
Page 195 ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ ▼ NOTE The vehicle speed alarm display is activated at the same time the beep sound is heard. The set vehicle speed flashes several times.
Page 196 NOTE Always set the vehicle speed according • to the laws and regulations of the country/city in which the vehicle is driven. In addition, always verify the speed of the vehicle using the speedometer. The vehicle speed alarm function can be •...
Page 197 Windscreen Type Dust-proof sheet Display Optical receiver Auto Flip-up Type Mirror Combiner Optical receiver Always adjust the display brightness and position with the vehicle stopped: Adjusting the display brightness and position while driving the vehicle is dangerous as doing so could distract your attention from the road ahead and lead to an accident. (With Auto Flip-up Type) Do not try to adjust the angle or open/close the active driving display manually.
Page 198 Do not place beverages near the active driving display. If water or other liquids are splashed on the active driving display, it could cause damage. Do not place objects above the active driving display or apply stickers to the dust-proof sheet/optical receiver as they will cause interference.
Page 199 • • • • • • • • • • • • NOTE The desired driving position (display position, brightness level, display information) can • be called up after programming the position. Refer to Driving Position Memory on page 2-7.
Page 200 Instrument Cluster Type A (With Multi-information Display) Type B (Without Multi-information Display) Centre of Instrument panel Warning/Indicator lights will appear in any of the highlighted areas ▼ ▼...
Page 203 ▼ ▼...
Page 208 ▼ • • • • ▼ NOTE If the vehicle is left with the ignition switched ON without starting the engine and a long period of time has elapsed since preheating finished, the preheating may be performed again and the glow indicator light may turn on.
Page 209 Do not use sudden engine braking on slippery road surfaces or at high speeds: Shifting down while driving on wet, snowy, or frozen roads, or while driving at high speeds causes sudden engine braking, which is dangerous. The sudden change in Neutral position tyre speed could cause the tyres to skid.
Page 210 NOTE ▼ If shifting to R is difficult, shift back into • neutral, release the clutch pedal, and try again. (With i-stop function) • If the engine has stopped due to stalling, it can be restarted by depressing the clutch pedal within 3 seconds of the engine stopping.
Page 211 NOTE The GSI turns off when the following operations are performed. The vehicle is stopped. • The vehicle is put in neutral. • The vehicle is driven in reverse. • The clutch is not fully engaged when • accelerating from a stop. The clutch pedal remains depressed for •...
Page 212 Lock-release button Various Lockouts: Indicates that you must depress the brake pedal and hold in the lock-release button to shift (The ignition must be switched ON). Indicates the selector lever can be shifted freely into any position. Indicates that you must hold in the lock-release button to shift. NOTE The Sport AT has an option that is not included in the traditional automatic transaxle that gives the driver the option of selecting each gear instead of leaving it to the transaxle to...
Page 213 Lock-release button NOTE When the ignition is switched to ACC or • the ignition is switched off, the selector lever cannot be shifted from P position. Button The ignition cannot be switched to OFF • if the selector lever is not in P position. ▼...
Page 214 NOTE (With parking sensor system) When the selector lever is shifted to the R • position with the ignition switched ON, the parking sensor system is activated and a beep sound is heard. Refer to Parking Sensor System on page •...
Page 215 NOTE ▼ ▼ Apply the parking brake or depress the brake pedal before moving the selector lever from N position to prevent the vehicle from moving unexpectedly. ▼ Shift position indication...
Page 216 Manual shift mode Gear position indication indication NOTE If the gears cannot be shifted down • when driving at higher speeds, the gear NOTE position indication will flash twice to Changing to manual shift mode while signal that the gears cannot be shifted driving will not damage the transaxle.
Page 217 NOTE ▼ The GSI turns off when the following operations are performed. The vehicle is stopped. • Manual shift mode is cancelled. • ▼ ▼ Selected gear position Suitable gear position NOTE When driving slowly, the gears may not • shift up.
Page 218 NOTE ▼ When driving at high speeds, the gear • may not shift down. During deceleration, the gear may • automatically shift down depending on vehicle speed. When depressing the accelerator fully, • the transaxle will shift to a lower gear, depending on vehicle speed.
Page 219 ▼ NOTE The gear also shifts down using kickdown while in the second gear fixed mode. NOTE If the vehicle comes to a stop while in the second gear fixed mode, the gear remains in second.
Page 220 Do not let the vehicle move in a direction opposite to the direction selected by the selector lever: Do not let the vehicle move backward with the selector lever in a forward position, or do not let the vehicle move forward with the selector lever in the reverse position.
Page 221 ▼ NOTE To prevent discharging the battery, do not leave the lights on while the engine is off unless • safety requires them. Headlights do not blind drivers approaching in the opposite direction no matter what side • of the road you must drive your vehicle (left-hand or right-hand traffic). Therefore, it is not necessary to adjust the optical axis of the headlights when switching temporarily to driving on the opposite side of the road (left-hand or right-hand traffic).
Page 223 Do not shade the light sensor by adhering a sticker or a label on the windscreen. Otherwise the light sensor will not operate correctly. The light sensor also works as a rain sensor for the auto-wiper control. Keep hands and scrapers clear of the windscreen when the wiper lever is in the position and the ignition is switched ON as fingers could be pinched or the wipers and wiper blades...
Page 224 ▼ High beam ▼ ▼ Low beam ▼ ▼ NOTE The time until the headlights turn off • after all of the doors are closed can be changed. Headlight Refer to Personalisation Features on flashing page 9-12. If no operations are done for 3 minutes •...
Page 225 ▼ ▼ ▼ ▼ • • Unlock button Lock button NOTE NOTE The running lights can be deactivated. Refer to Personalisation Features on page Operation of the leaving home light can • 9-12. be turned on or off. Refer to Personalisation Features on page 9-12.
Page 226 NOTE (With auto-light control) • If the fog light switch is in the position or the headlight switch is in the position, the fog lights will turn on when the headlights, the exterior lights turn on. When the fog light switch is rotated to •...
Page 227 • • NOTE The front fog lights turns on when the • rear fog light is turned on. If the fog light switch is rotated to the • position (the fog light switch returns to ▼ position automatically), the front fog light indicator light in the instrument cluster will also illuminate.
Page 228 ▼ ▼ Fog light switch • Right turn • Right lane change Left lane change NOTE (With auto-light control) Left turn When the headlight switch is in the position and the headlights, exterior lights and instrument panel illuminated, the rear fog light turns on when the rear fog light switch is turned on.
Page 229 ▼ ▼ Use only windscreen washer fluid or plain water in the reservoir: Using radiator antifreeze as washer fluid is dangerous. If sprayed on the windscreen, it will dirty the windscreen, affect your visibility, and could result in an accident. NOTE The three-flash turn signal function can be Only use windscreen washer fluid mixed...
Page 230 If the wipers do not operate even though the wiper switch is turned to a position other than OFF, consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. ▼ INT ring...
Page 231 When the wiper lever is in the position and the ignition is switched ON, the wipers may move automatically in the following cases: If the windscreen above the rain sensor is touched or wiped with a cloth. If the windscreen is struck with a hand or other object from either outside or inside the vehicle.
Page 232 If dirt or foreign matter (Such as ice or NOTE • If the windscreen washer is turned on matter containing salt water) adheres to the windscreen above the rain sensor or when the windscreen wipers are not operating, the windscreen wipers operate if the windscreen is iced, it could cause a few times.
Page 233 ▼ Washer NOTE When the windscreen washer is • operated for the first time after turning on the headlights, the headlight washers operate automatically. If air enters the headlight washer fluid • pipe under conditions such as when the vehicle is brand-new or after an empty washer tank is replenished with washer fluid, washer fluid will not spray even when the wiper lever is operated.
Page 234 Do not use sharp instruments or window cleaners with abrasives to clean the inside of the rear window surface. They may damage the defogger grid inside the window. NOTE This defogger is not designed for • melting snow. If there is an accumulation of snow on the rear window, remove it before using the defogger.
Page 235 Indicator light Indicator light Indicator light ▼ ▼ Indicator light...
Page 236 NOTE The direction indicators do not work • when the hazard warning lights are on. Check local regulations about the use of • hazard warning lights while the vehicle is being towed to verify that it is not in violation of the law.
Page 237 If the brake pedal is depressed while • driving on slippery roads, the emergency stop signal system could operate causing all the turn and lane change signals to flash. Refer to Emergency Stop Signal System on page 4-93. While the emergency stop signal system •...
Page 238 Dry off brakes that have become wet by driving slowly, releasing the accelerator ▼ pedal and lightly applying the brakes several times until the brake performance returns to normal: Driving with wet brakes is dangerous. Increased stopping distance or the vehicle pulling to one side when braking could result in a serious accident.
Page 239 An operation sound occurs when ▼ • applying or releasing the parking brake, however, this does not indicate a malfunction. If the EPB is not used for long periods, • an automatic inspection of the system is performed while the vehicle is parked. Indicator light An operation sound can be heard, however, this does not indicate a...
Page 240 (Green)
Page 241 ▼ • • • • • • NOTE If something such as the driver's foot contacts the accelerator pedal with the engine running and the parking brake applied, the parking brake may be released automatically. If you do not intend to drive immediately, shift the change lever (manual transaxle) to the neutral position, or shift the selector lever (automatic transaxle) to the P or N...
Page 242 Driving with worn disc pads is dangerous. The brakes could fail and cause a serious accident. As soon as you hear a screeching noise consult an expert repairer, we recommend an Authorised Mazda Repairer. ▼ NOTE When the brake pedal is depressed hard •...
Page 243 Do not rely completely on the AUTOHOLD function: The AUTOHOLD function is only designed to assist the brake operation while the vehicle is stopped. Neglecting to operate the brakes and relying only on the AUTOHOLD system is dangerous and could result in an unexpected accident if the vehicle were to suddenly move. Operate the brakes appropriately in accordance with the road and surrounding conditions.
Page 244 Under the following conditions, a problem with the AUTOHOLD is occurring. Have your • vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible. The brake pedal operation demand warning light (red) in the instrument cluster flashes •...
Page 245 ▼ AUTOHOLD standby indicator light NOTE When all of the following conditions are met, the AUTOHOLD operates and the brakes are held. NOTE The ignition is switched ON (engine is • When all of the following conditions are running or stopped by i-stop). met, the AUTOHOLD standby indicator The vehicle is stopped.
Page 246 When about 10 minutes or longer have • passed since the AUTOHOLD operation started, the parking brake is automatically applied. Because the AUTOHOLD is restored when releasing the parking brake, the hold on the brakes by AUTOHOLD function resumes. (Manual transaxle vehicle) •...
Page 247 (Without multi-information display) • If the AUTOHOLD switch is pressed without depressing the brake pedal while the AUTOHOLD is operating (AUTOHOLD active indicator light is turned on), the brake pedal operation demand indicator light (green) in the instrument cluster turns on to notify the driver that it is necessary to depress the brake pedal.
Page 248 HLA does not operate while the • TCS/DSC indicator light is illuminated. Refer to Contact Authorised Mazda Repairer and Have Vehicle Inspected on page 7-34. HLA does not turn off even if the TCS •...
Page 249 NOTE Braking distances may be longer on • loose surfaces (snow or gravel, for example) which usually have a hard foundation. A vehicle with a normal braking system may require less distance to stop under these conditions because the tyres will build up a wedge of surface layer when the wheels skid.
Page 250 Use snow tyres or tyre chains and drive at reduced speeds when roads are covered with ice and/or snow: Driving without proper traction devices on snow and/or ice-covered roads is dangerous. The Traction Control System (TCS) alone cannot provide adequate traction and you could still have an accident.
Page 251 NOTE ▼ When TCS is on and you attempt to free • the vehicle when it is stuck, or drive it out of freshly fallen snow, the TCS (part of the DSC system) will activate. Depressing the accelerator will not increase engine power and freeing the vehicle may be difficult.
Page 252 Use tyres of the correct size specified for your Mazda on all four wheels. Use tyres of the same manufacturer, brand and tread pattern on all four wheels. Do not mix worn tyres. The DSC may not operate correctly when...
Page 253 High-current electricity flows through the following parts, therefore do not touch them. Variable voltage alternator DC-DC converter Capacitor If the capacitor is to be disposed of, always consult an expert repairer, we recommend an Authorised Mazda Repairer. For details, go to the following URL. http://www.mazda.com/csr/environment/recycling ▼ ▼ ▼...
Page 254 If you turn the steering wheel while the message is displayed, it will feel heavier than normal, but this does not indicate an abnormality. Stop the vehicle in a safe location with the engine running and do not attempt to turn the steering wheel. The steering operation will return to normal after the message is no longer displayed.
Page 255 • • NOTE The fuel economy monitor screen after the ignition is switched from ON to OFF is changed to the original fuel economy monitor screen when the ignition is switched ON the next time.
Page 256 ▼ • • NOTE (With Multi-information Display) • The fuel economy data is synchronized (linked) with the average fuel economy • displayed in the tripmeter (TRIP A). To reset the fuel economy data, press the icon in the menu. (The average fuel •...
Page 257 ▼ • • • •...
Page 260 ▼ ▼ ▼...
Page 261 ▼...
Page 262 Drive mode cannot be switched in the following conditions: • ABS/TCS/DSC is operating • The Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go • function) System/Mazda Radar Cruise Control (MRCC) system/cruise control is operating.
Page 263 NOTE If the drive selection cannot be switched to sport mode, the select mode indication flashes to notify the driver.
Page 264 • • • • NOTE Check the tyre inflation pressure label Never spin a wheel that is off the ground: attached to driver's door frame for the Spinning a wheel that is off the ground as a correct tyre inflation pressure. result of the vehicle being stuck or in a ditch is dangerous.
Page 265 • • Never hold the steering wheel to the extreme left or right for more than 5 seconds with the engine running. This could damage the power steering system.
Page 266 ▼...
Page 267 ▼ ▼ • • • • • • • • •...
Page 268 • • • • • • •...
Page 269 NOTE Headlights do not blind drivers • approaching in the opposite direction no matter what side of the road you must drive your vehicle (left-hand or right-hand traffic). Therefore, it is not necessary to adjust the optical axis of the headlights when switching temporarily to driving on the opposite side of the road (left-hand or right-hand traffic).
Page 270 • • • The recognition distance of the Forward Sensing Camera (FSC) varies according to the surrounding conditions. Forward Sensing Camera (FSC) Do not adjust the vehicle height, modify the headlight units, or remove the camera, otherwise the system will not operate normally. Do not rely excessively on the HBC and drive the vehicle while paying sufficient attention to safety.
Page 271 NOTE The timing in which the system switches the headlights changes under the following conditions. If the system does not switch the headlights appropriately, manually switch between high and low beams according to the visibility as well as road and traffic conditions.
Page 273 NOTE The headlight high-beam indicator light turns on while the high beams are on.
Page 274 Do not modify the suspensions or headlight units, or remove the camera. Otherwise, the ALH may not operate normally. Do not rely excessively on the ALH and drive the vehicle while paying sufficient attention to safety. Switch the headlights between the high beams and low beams manually if necessary.
Page 275 When visibility is reduced under rain, snow and foggy conditions. • When driving on roads with sharp curves or undulations. • When the headlights/rear lamps of vehicles ahead or in the opposite lane are dim or not • illuminated. When there is insufficient darkness such as at dawn or dusk. •...
Page 276 Your vehicle Detection areas Always check the surrounding area visually before making an actual lane change: The system is only designed to assist you in checking for vehicles at your rear when making a lane change. Due to certain limitations with the operation of this system, the BSM warning indicator light, the warning sound and the warning screen indicator display may not activate or they might be delayed even though a vehicle is in an adjacent driving lane.
Page 277 In the following cases, the BSM OFF indicator light turns on and operation of the system • is stopped. If the BSM OFF indicator light remains illuminated, have the vehicle inspected at an Authorised Mazda Repairer as soon as possible. Some problem with the system including the BSM warning indicator lights is detected. •...
Page 278 When there is a difference in the height between your driving lane and the adjacent • lane. Directly after the BSM system becomes operable by changing the setting. • If the road width is extremely narrow, vehicles two lanes over may be detected. The •...
Page 279 ▼...
Page 280 Multi-information Display Active Driving Display Detection and warning indicator Detection and warning indicator NOTE ▼ ▼ When the ignition is switched OFF, the system status before it was turned off is maintained. For example, if the ignition is switched OFF while the BSM and Rear Cross Traffic Alert (RCTA) systems are operational, the BSM and Rear Cross Traffic Alert (RCTA) systems remain...
Page 281 Authorised Mazda Repairer. The TSR operates only if the navigation system SD card (Mazda genuine) is inserted in • the SD card slot. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details.
Page 282 Always check the traffic signs visually while driving. The TSR helps prevent the driver from overlooking traffic signs and provides support for safer driving. Depending on the weather conditions or problems with traffic signs, a traffic sign may not be recognised or a traffic sign different from the actual traffic sign may be displayed. Always make it your responsibility as a driver to check the actual traffic signs.
Page 283 A traffic sign is too big or too small. • There is an object similar to the traffic sign being read (such as another traffic sign or • other signs resembling it). The TSR does not operate if the active driving display is set to non-display. •...
Page 284 NOTE Speed limit signs (including auxiliary signs) When the vehicle speed is about 1 km/h (0.6 mph) or faster, the speed limit sign is • displayed when any one of the following conditions are met. The Forward Sensing Camera (FSC) recognises a speed limit sign as a sign targeted for •...
Page 285 The vehicle speed exceeds the displayed speed limit sign by 30 km/h (19 mph) or more • after a certain period of time has elapsed since the speed limit sign was displayed. (Except when there is information for the speed limit sign in the navigation system) Do not enter signs A do not enter sign is displayed when all of the following conditions are met.
Page 286 ▼ 80 km/h is displayed While 100 km/h is displayed Active driving display indication Active driving display indication • • •...
Page 287 • • • NOTE In the following cases, the excessive speed warning stops operating. • The vehicle speed is less than the speed of the displayed speed limit sign. (If the • activation timing for the excessive speed warning is changed in the personalisation features, the excessive speed warning stops operating when the vehicle speed is less than the changed vehicle speed.
Page 288 Do not rely completely on the DRSS and always drive carefully: The ability to detect a vehicle ahead is limited depending on the type of vehicle ahead, the weather conditions, and the traffic conditions. Therefore, if the accelerator and brake pedals are not operated correctly it could lead to an accident.
Page 289 NOTE When the ignition is switched off, the operation status before the system was turned off is • maintained. For example, if the ignition is switched off with the DRSS operable, the system will be operable when the ignition is switched ON the next time. The DRSS can be turned on/off and the system's sensitivity can be changed.
Page 291 Illuminated in amber...
Page 292 Do not rely completely on DAA and always drive carefully: The DAA detects driver fatigue and decreased attentiveness and encourages the driver to take a rest, however, it is not designed to prevent the vehicle from straying. If you rely too much on the DAA it could lead to an accident.
Page 293 NOTE The DAA operates when all of the following conditions are met. • The vehicle speed is about 65 to 140 km/h (41 to 86 mph). • The system detects white (yellow) lane lines. • The system has completed learning of the driver’s driving data. •...
Page 294 Your vehicle Detection areas...
Page 295 • and operation of the system is stopped. If the Blind Spot Monitoring (BSM) OFF Indicator Light remains illuminated, have the vehicle inspected at an Authorised Mazda Dealer as soon as possible. Some problem with the system including the Blind Spot Monitoring (BSM) warning •...
Page 296 The temperature near the radar sensors becomes extremely hot due to driving for long • periods on slopes during the summer. The battery voltage has decreased. • Under the following conditions, the radar sensors (rear) cannot detect target objects or it •...
Page 297 Turn off the RCTA system while pulling a trailer or while an accessory such as a bicycle • carrier is installed to the rear of the vehicle. Otherwise, the radio waves emitted by the radar will be blocked causing the system to not operate normally.
Page 298 • Do not rely completely on the MRCC: The MRCC system has detection limitations depending on the type of vehicle ahead and its conditions, the weather conditions, and the road conditions. Additionally, the system may be unable to decelerate sufficiently to avoid hitting the vehicle ahead if the vehicle ahead applies the brakes suddenly or another vehicle cuts into the driving lane, which could result in an accident.
Page 299 Long, descending slopes (to maintain distance between vehicles, the system automatically and continuously applies the brakes which could result in the loss of brake power.) Slopes with a steep gradient (The vehicle ahead may not be detected correctly, your vehicle may slide while stopped by the stop hold control, and it may accelerate suddenly after it starts moving.) For safety purposes, switch the MRCC system off when it is not being used.
Page 300 ▼ Active Driving Display (Windscreen Type) Active driving display Vehicle ahead display MRCC Distance between vehicle display MRCC Set vehicle speed Multi-information display Vehicle ahead display MRCC Distance between vehicle display MRCC Set vehicle speed Active Driving Display (Auto Flip-up Type) Active driving display Vehicle ahead display MRCC Distance...
Page 301 ▼ Multi-information Display Active Driving Display NOTE In the following cases, the warnings and brakes may not operate even if your vehicle starts closing in on the vehicle ahead. You are driving your vehicle at the same speed as the vehicle ahead. •...
Page 302 • • switch SET+ switch RES switch switch SET- switch MODE switch OFF/CAN switch NOTE If the ignition is switched off while the MRCC system is operating, the system will be • operable when the ignition is switched ON the next time. (European models) •...
Page 303 NOTE If a vehicle ahead is detected while travelling at a constant speed, the vehicle-ahead • indication is displayed and headway control is performed. Additionally, when a vehicle ahead is no longer detected, the vehicle-ahead indication turns off and the system switches back to travel at constant speed.
Page 304 NOTE The distance-between-vehicles differs depending on the vehicle speed, and the slower the • vehicle speed, the shorter the distance. When the ignition is switched to ACC or OFF and then the engine is started again, the • system automatically sets the distance-between-vehicles to the previous setting.
Page 305 NOTE When accelerating using the SET • switch while in headway control, the set vehicle speed can be adjusted but acceleration is not possible. If there is no longer a vehicle ahead, acceleration continues until reaching the set vehicle speed. For the set vehicle speed, check the set vehicle speed indication in the display.
Page 306 • • NOTE If the set speed is not indicated in the • display, the control does not resume even if the RES switch is pressed. • • • • • • •...
Page 307 ▼ NOTE If the gears are not shifted up/down even though the shift-up/down request indication is displayed, load will be applied to the engine and the MRCC system may be automatically cancelled or engine damage could occur.
Page 308 ▼ • Do not use the cruise control function in • the following locations: Otherwise, it could lead to an accident. Roads with sharp curves and where vehicle traffic is heavy and there is insufficient space between vehicles. Always turn off the cruise control function (Driving under these conditions using the when it is not in use: cruise control function is not possible)
Page 309 NOTE The system may not be able to maintain • the set speed constantly depending on driving conditions such as steep up or down slopes. The speed will continue increasing while • the SET switch is pressed and held. The speed will continue decreasing while the SET switch is pressed and held.
Page 310 NOTE If the vehicle speed decreases by about • 15 km/h (9.4 mph) or more than the set speed, the cruise control function may be cancelled. When the vehicle speed is less than 21 • km/h (13 mph), the cruise control function is cancelled.
Page 311 • • • • Do not rely completely on the MRCC with Stop & Go function: The MRCC with Stop & Go function system has detection limitations depending on the type of vehicle ahead and its conditions, the weather conditions, and the road conditions. Additionally, the system may be unable to decelerate sufficiently to avoid hitting the vehicle ahead if the vehicle ahead applies the brakes suddenly or another vehicle cuts into the driving lane, which could result in an accident.
Page 312 Roads where frequent and repetitive acceleration and deceleration occur (Driving under these conditions using the MRCC with Stop & Go function system is not possible). When entering and exiting interchanges, service areas, and parking areas of highways (If you exit a highway while headway control is in use, the vehicle ahead will no longer be tracked and your vehicle may accelerate to the set speed).
Page 313 During headway control travel, the system accelerates and decelerates your vehicle in • conjunction with the speed of the vehicle ahead. However, if it is necessary to accelerate for a lane change or if the vehicle ahead brakes suddenly causing you to close in on the vehicle rapidly, accelerate using the accelerator pedal or decelerate using the brake pedal depending on the conditions.
Page 314 ▼ Active Driving Display (Windscreen Type) Active driving display Vehicle ahead display MRCC Distance between vehicle display MRCC Set vehicle speed Multi-information display Vehicle ahead display MRCC Distance between vehicle display MRCC Set vehicle speed Active Driving Display (Auto Flip-up Type) Active driving display Vehicle ahead display MRCC Distance...
Page 315 ▼ Multi-information Display Active Driving Display NOTE In the following cases, the warnings and brakes may not operate even if your vehicle starts closing in on the vehicle ahead. You are driving your vehicle at the same speed as the vehicle ahead. •...
Page 316 In the following cases, the MRCC with Stop & Go function system is cancelled when the • vehicle is travelling at 30 km/h (19 mph) or less and “Mazda Radar Cruise Control disabled under 30 km/h” is displayed in the multi-information display.
Page 317 NOTE If the ignition is switched off while the MRCC with Stop & Go function system is • operating, the system will be operable when the ignition is switched ON the next time. (European models) • The MRCC with Stop & Go function can switch to the Adjustable Speed Limiter (ASL). Refer to Adjustable Speed Limiter (ASL) on page 4-183.
Page 318 NOTE If a vehicle ahead is detected while travelling at a constant speed, the vehicle-ahead • indication is displayed and headway control is performed. Additionally, when a vehicle ahead is no longer detected, the vehicle-ahead indication turns off and the system switches back to travel at constant speed.
Page 319 NOTE The distance-between-vehicles differs depending on the vehicle speed, and the slower the • vehicle speed, the shorter the distance. When the ignition is switched to ACC or OFF and then the engine is started again, the • system automatically sets the distance-between-vehicles to the previous setting. The warnings and brake control do not NOTE operate while the accelerator pedal is...
Page 320 When accelerating using the SET • switch while in headway control, the set vehicle speed can be adjusted but acceleration is not possible. If there is no longer a vehicle ahead, acceleration continues until reaching the set vehicle • speed. For the set vehicle speed, check •...
Page 322 ▼ NOTE If the MRCC with Stop & Go function system is cancelled during stop hold control, the • vehicle is held in its stopped position. The stop hold control can be cancelled by performing one the following actions. Press the accelerator pedal and resume driving the vehicle. •...
Page 323 If the vehicle ahead starts moving within 3 seconds after your vehicle is stopped by the • stop hold control, headway control will resume even if you do not resume driving your vehicle, such as by depressing the accelerator pedal. ▼...
Page 324 Always turn off the cruise control function when it is not in use: Leaving the cruise control function turned on when it is not in use is dangerous as it could operate unexpectedly, resulting in an accident. NOTE The system may not be able to maintain •...
Page 325 • • • NOTE If the vehicle speed decreases by about • 15 km/h (9.4 mph) or more than the set speed, the cruise control function may be cancelled. When the vehicle speed is less than 21 • km/h (13 mph), the cruise control function is cancelled.
Page 326 "Late" function "Early" function...
Page 327 Do not modify the suspensions. Always use wheels of the specified type and size for the front and rear wheels. Consult an expert repairer, we recommend an Authorised Mazda Repairer for tyre replacement. NOTE When the direction indicator lever is operated for a lane change, the LAS & LDWS is •...
Page 328 If the steering wheel, accelerator pedal, or brake pedal is operated abruptly and the • vehicle moves close to a white (yellow) line, the system determines that the driver is making a lane change and the LAS & LDWS operation is temporarily cancelled. The LAS &...
Page 329 There are various road markings or lane markings of various shapes near an • intersection. ▼ • • • • NOTE The LAS & LDWS indication is white when the system detects only a white (yellow) line on either the left or right, and the indication changes to green when the system detects white (yellow) lines on both the left and right sides.
Page 330 If the driver takes his or her hands off • • the steering wheel (not holding the steering wheel), the warning sound is NOTE activated and an alert is indicated in the multi-information display or the active (When the timing of the steering assist •...
Page 331 Steering operation assist operational/ • non-operational Cancel sensitivity (likelihood of • steering assist) • • • Multi-information Display Active Driving Display • • • Multi-information Display • • Active Driving Display NOTE After the operation, the LAS & LDWS • operation may not operate for a period of 5 seconds at the most until the lane lines are detected.
Page 332 Under the following conditions, the LAS • & LDWS cancels the warning/steering assist automatically. The driver takes his/her hands off the • steering wheel. (The LAS & LDWS is designed to assist the driver's steering operation • and it will resume operation automatically when the driver holds the steering wheel.) •...
Page 333 • • • • • • • •...
Page 334 • is cancelled automatically and the LAS & LDWS OFF indication is displayed in the multi-information display. Have your vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. There is a malfunction in the power • steering.
Page 335 ▼ Multi-information Display Active Driving Display NOTE If you have set the lane departure warning sound to the beep sound/rumble sound • setting, the warning sound may not be heard depending on the surrounding noise conditions. If you have set the lane departure warning system to the steering wheel vibrations setting, •...
Page 336 The rumble sound is a reproduction of the sound which occurs when a vehicle passes over a rumble strip. Rumble Groove...
Page 337 Always turn off the system when changing drivers: If the driver is changed and the new driver is unaware of the ASL function, the vehicle may not accelerate when the driver depresses the accelerator pedal, leading to an accident.
Page 338 (Auto Flip-up Type) Instrument Cluster Type B (Without Multi-information Display) Cruise control system Mazda Radar Cruise Control (MRCC) or Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) MODE switch SET+ switch RES/+ switch...
Page 339 ▼ Active Driving Display With Multi- Without Multi- information Display information Display Active Driving Display With Multi- Without Multi- information Display information Display • • Active Driving Display With Multi- Without Multi- information Display information Display...
Page 340 ▼ ▼ Active Driving Display With Multi- Without Multi- information Display information Display...
Page 341 5 km/h (3 mph). Be careful not to drive over the set speed. (With Mazda Radar Cruise Control (MRCC) or Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function))
Page 342 When the MODE switch is pressed while the ASL is operating, the system switches to the cruise control, Mazda Radar Cruise Control (MRCC), or Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) system.
Page 343 When the vehicle set speed is displayed in the instrument cluster, press the RES/ switch to set the displayed vehicle speed. (With Mazda Radar Cruise Control (MRCC) or Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)) When the vehicle set speed is displayed in the instrument cluster, press the RES switch to set the displayed vehicle speed.
Page 344 Forward Sensing Camera (FSC) Do not rely completely on the Advanced SCBS system: The Advanced SCBS system is only designed to reduce damage in the event of a collision. Over reliance on the system leading to the accelerator pedal or brake pedal being mistakenly operated could result in an accident.
Page 345 In the following cases, turn the system off to prevent a mis-operation: The vehicle is being towed or when towing another vehicle. The vehicle is on a chassis roller. When driving on rough roads such as in areas of dense grass or off-road. Refer to Stopping the Advanced Smart City Brake Support (Advanced SCBS) System Operation on page 4-193 on how to turn off the Advanced SCBS system.
Page 346 (Manual transaxle) • If the vehicle is stopped by the SCBS operation and the clutch pedal is not depressed, the engine stops. ▼ ▼ NOTE The collision warning beep sounds • intermittently while the Advanced SCBS brake or brake assist (Advanced SCBS ▼...
Page 347 ▼ NOTE When the Advanced SCBS system is set to inoperable, the Smart City Brake Support [Reverse] (SCBS R) system and the Smart Brake Support (SBS) are also set to inoperable.
Page 348 Forward Sensing Camera (FSC) Do not rely completely on the SCBS F system: The SCBS F system is only designed to reduce damage in the event of a collision. Over reliance on the system leading to the accelerator pedal or brake pedal being mistakenly operated could result in an accident.
Page 349 In the following cases, turn the system off to prevent a mis-operation: The vehicle is being towed or when towing another vehicle. The vehicle is on a chassis roller. When driving on rough roads such as in areas of dense grass or off-road. Refer to Stopping the Smart City Brake Support [Forward] (SCBS F) system Operation on page 4-196 on how to turn off the SCBS F system.
Page 350 If you suddenly come close to a vehicle ahead. • 2-wheeled vehicles, pedestrians, animals or standing trees. • Vehicle is driven with some of the tyres having significant wear. • (Manual transaxle) • If the vehicle is stopped by the Smart City Brake Support (SCBS) operation and the clutch pedal is not depressed, the engine stops.
Page 351 NOTE When the SCBS F system is set to inoperable, the Smart City Brake Support [Reverse] (SCBS R) system and the Smart Brake Support (SBS) are also set to inoperable.
Page 352 (rear), stop using the SCBS R system immediately and have your vehicle inspected by an expert repairer, we recommend an Authorised Mazda Repairer. If the vehicle continues to be driven with cracks or scratch marks left around an ultrasonic sensor, the system may operate unnecessarily and cause an unexpected accident.
Page 353 Do not apply a strong force to an ultrasonic sensor (rear): When washing the vehicle, do not spray highly pressurised water against an ultrasonic sensor (rear), or rub it strongly. In addition, do not hit the rear bumper forcefully when loading and unloading cargo Otherwise, the sensors may not detect obstructions correctly which could cause the SCBS R system to not operate normally, or it could operate unnecessarily.
Page 354: Manual Transaxle
The height of the obstruction is high such as trucks with high loading platforms. • The obstruction is small. • The obstruction is thin such as a signpost. • The obstruction is positioned away from the centre of the vehicle. •...
Page 355 The Smart City Brake Support (SCBS) warning indication (amber) turns on when the • system has a malfunction. Refer to Warning Indication/Warning Lights on page 4-46. ▼ ▼ ▼ NOTE The collision warning beep sounds • intermittently while the Smart City Brake Support (SCBS) brake is operating.
Page 356 Do not rely completely on the SBS system and always drive carefully: The SBS is designed to reduce damage in the event of a collision, not avoid an accident. The ability to detect an obstruction is limited depending on the obstruction, weather conditions, or traffic conditions.
Page 357 The vehicle is driven at the same speed as the vehicle ahead. • The accelerator pedal is depressed. • The brake pedal is depressed. • The steering wheel is being operated. • The selector lever is being operated. • The direction indicator is being used. •...
Page 358 ▼ NOTE If the SBS system operation is turned off, the Smart City Brake Support (SCBS) system operation is turned off simultaneously.
Page 359 • • • • • •...
Page 360 : Cameras : Ultrasonic sensors : Radar sensors (rear) Always confirm the safety of the area around the vehicle with the mirrors and directly with your eyes when driving. The 360°View Monitor is an auxiliary device which assists the driver in checking the safety of the area around the vehicle.
Page 361 Do not rub the camera lens forcefully, or clean it with an abrasive or hard brush. Otherwise, it could scratch the camera lens and negatively affect the images. Consult an Authorised Mazda Repairer for repair, painting, or replacement of the front/rear camera, front bumper and door mirrors.
Page 362 The 360°View Monitor has limitations. Objects under the bumper or near both ends of the • bumper cannot be displayed. Obstructions above the upper image range of the camera are not displayed. • Under the following conditions, the screen might be difficult to view, however this does •...
Page 363 ▼ Top view screen Front view screen...
Page 364 Top view screen Rear view screen ▼ ▼ •...
Page 365 •...
Page 366 Switch camera icon Top view/Front view Front wide view Side view...
Page 367 NOTE When the shift lever/selector lever is in R position, the displayed screen does not switch to • the top view/front view, front wide view, or the side view. Display of the top view/front view, front wide view, or the side view stops even with the •...
Page 368 • • Switch camera icon Top view/Rear view Rear wide view NOTE The top view/rear view and rear wide view automatically display whether or not the 360° • View Monitor switch is turned on or off when shifting the shift lever/selector lever to R position.
Page 369 Always stop the vehicle when adjusting the 360°View Monitor image quality. Do not adjust the 360°View Monitor image quality while driving. If you adjust the 360° View Monitor image quality (such as brightness, contrast, tone, and colour density) while driving, it could lead to an unexpected accident.
Page 370 ▼ (Screen display) (Actual condition) Target object NOTE In the top view screen, the diagonal lines at the front and rear of the vehicle image and • the seams where each of the camera images merge are blind spots. Because images displayed in the top view screen are processed from each camera, the top •...
Page 371 • • • •...
Page 372 The parking sensor detection range has limitations. For example, obstructions closing in from the side and objects short in height may not be detected. Always confirm the safety around the vehicle visually when driving. For details, refer to the parking sensor obstruction detection indication and warning sound. Refer to Parking Sensor System on page Reference 4-269.
Page 373 (Screen display) (Actual condition) Target object • •...
Page 374 NOTE The parking sensor obstruction detection indication does not display. Switch the screen • display to the top view/front view or side view display if the parking sensor warning sound is activated. The front wide view screen displays the image in front of the vehicle at a wide angle and •...
Page 375 NOTE The setting can be changed so that the projected vehicle path lines are not displayed. Refer to Personalisation Features on page Reference 9-12.
Page 376 (Screen display) (Actual condition) The parking sensor detection range has limitations. For example, obstructions closing in from the side and objects short in height may not be detected. Always confirm the safety around the vehicle visually when driving. For details, refer to the parking sensor obstruction detection indication and warning sound. Refer to Parking Sensor System on page Reference 4-269.
Page 377 ▼ (Screen display) (Actual condition) Target object NOTE In the top view screen, the diagonal lines at the front and rear of the vehicle image and • the seams where each of the camera images merge are blind spots. Because images displayed in the top view screen are processed from each camera, the top •...
Page 378 • • • •...
Page 379 NOTE The setting can be changed so that the projected vehicle path lines are not displayed. Refer to Personalisation Features on page Reference 9-12. The front of the vehicle swings out wide when turning the steering wheel while reversing. Maintain sufficient distance between the vehicle and an obstruction. The parking sensor detection range has limitations.
Page 380 (Screen display) (Actual condition) (Screen display) (Actual condition) ▼ ▼...
Page 381 (Screen display) (Actual condition) Target object • •...
Page 382 NOTE The parking sensor obstruction detection indication does not display. Switch the screen • display to the top view/rear view display if the parking sensor warning sound is activated. The rear wide view screen displays the image at the rear of the vehicle at a wide angle •...
Page 383 Obstruction Margin of error Margin of error Obstruction...
Page 384 Appears further than Appears closer than actual distance actual distance Actual obstruction Obstruction appearing Obstruction appearing on screen on screen Actual obstruction A: Distance of obstruction being viewed on screen B: Actual distance of obstruction from vehicle Appears further than Appears closer than actual distance actual distance...
Page 385 NOTE If the vehicle is on a slope, obstructions taken by the camera can appear farther or closer than the actual distance from the vehicle. (Screen display) (Actual condition) (Screen display) (Actual condition) Sensed distance on screen A > B > C Actual distance B >...
Page 386 • • • • • • • • • Forward Sensing Camera (FSC) Do not modify the suspension: If the vehicle height or inclination is changed, the system will not be able to correctly detect vehicles ahead. This will result in the system not operating normally or mistakenly operating, which could cause a serious accident.
Page 387 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) Traffic Sign Recognition System (TSR) Advanced Smart City Brake Support (Advanced SCBS) Smart City Brake Support [Forward] (SCBS F) Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)
Page 388 Smart Brake Support (SBS) The direction in which the Forward Sensing Camera (FSC) is pointed has been finely adjusted. Do not change the installation position of the Forward Sensing Camera (FSC) or remove it. Otherwise, it could result in damage or malfunction. Always use tyres for all wheels that are of the specified size, and the same manufacturer, brand, and tread pattern.
Page 389 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) warning • indication Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go • function) warning indication Smart Brake Support/Smart City Brake Support (SBS/SCBS) warning indication/ •...
Page 390 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) warning • indication Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go • function) warning indication Smart Brake Support/Smart City Brake Support (SBS/SCBS) warning indication/ •...
Page 391 Do not install a grille guard. If the front part of the vehicle has been damaged in a vehicle accident, the position of the radar sensor (front) may have moved. Stop the system immediately and always have the vehicle inspected at an Authorised Mazda Repairer.
Page 392 Do not remove, disassemble, or modify the radar sensor (front). For repairs, replacement or paint work around the radar sensor (front), consult an Authorised Mazda Repairer. Do not modify the suspension. If the suspension are modified, the vehicle's posture could change and the radar sensor (front) may not be able to correctly detect a vehicle ahead or an obstruction.
Page 393 When driving on roads with little traffic • and few vehicles ahead or obstructions for the radar sensor (front) to detect, “Front radar blocked” may be temporarily displayed, however, this does not indicate a problem. The radar sensors are regulated by the •...
Page 394 If the rear bumper receives a severe impact, the system may no longer operate normally. Stop the system immediately and have the vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer. NOTE The detection ability of the radar sensors (rear) has limitations. In the following cases, •...
Page 395 For repairs or replacement of the radar sensors (rear), or bumper repairs, paintwork, and • replacement near the radar sensors, consult an expert repairer, we recommend an Authorised Mazda Repairer. Turn off the system while pulling a trailer or while an accessory such as a bicycle carrier •...
Page 396 Ultrasonic sensor (rear)
Page 397 Side camera Side camera Front camera Rear camera...
Page 398 NOTE If your Mazda has the following steering switch, your Mazda is equipped the Mazda Radar Cruise Control (MRCC) system or the Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) system.
Page 399 Refer to Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) on page 4-157. switch SET+ switch RES switch switch SET- switch MODE switch OFF/CAN switch NOTE ▼ ▼ When the MODE switch is pressed while...
Page 400 NOTE (Vehicles with Adjustable Speed • When the ignition is switched OFF, the Limiter (ASL)) system status before it was turned off is The MODE switch for the Adjustable maintained. For example, if the ignition is Speed Limiter (ASL) is pressed. switched OFF with the cruise control Release the SET/ or RES/ switch at •...
Page 401 Type A Instrument Cluster Multi-information Display NOTE Accelerate if you want to speed up Active Driving Display temporarily when the cruise control is on. Greater speed will not interfere with or change the set speed. Take your foot off Type B Instrument Cluster the accelerator to return to the set speed.
Page 402 When the cruise control system is ▼ • temporarily cancelled by even one of the applicable cancel conditions, the speed cannot be re-set. (Automatic transaxle) • The cruise control cannot be cancelled while driving in manual mode (selector lever shifted from D to M position). Therefore, engine braking will not be applied even if the transaxle is shifted down to a lower gear.
Page 403 Tyre pressure sensors NOTE When the ambient temperature is low due to seasonal changes, tyre temperatures are also lower. When the tyre temperature decreases, the air pressure decreases as well. The TPMS warning light may illuminate more frequently. Visually inspect the tyres daily before driving, and check tyre pressures monthly with a tyre pressure gauge.
Page 404 As an added safety feature, your vehicle has been equipped with a tyre pressure monitoring system (TPMS) that illuminates a low tyre pressure telltale when one or more of your tyres is significantly under-inflated. Accordingly, when the low tyre pressure telltale illuminates, you should stop and check your tyres as soon as possible, and inflate them to the proper pressure.
Page 405 Authorised Mazda Dealer change your wheels or both, have the work done by tyre and complete ID signal code an Authorised Mazda Dealer, or the tyre registration. pressure sensors may be damaged. The wheels equipped on your Mazda are specially designed for installation of the tyre pressure sensors.
Page 406 For purchase of a tyre pressure sensor and registration of the tyre pressure sensor ID signal code, consult an Authorised Mazda Dealer. When reinstalling a previously removed • tyre pressure sensor to a wheel, replace the grommet (seal between valve body/ sensor and wheel) for the tyre pressure sensor.
Page 407: While Driving
• • NOTE • The engine sound and exhaust gas smell may change when PM is being removed while driving.
Page 408 SCR warning light turns on/flashes. Refer to Selective Catalytic Reduction (SCR) System Indications on page 4-254. ® In this case, consult an Authorised Mazda Dealer. If AdBlue needs to be replenished, add ® AdBlue following the specified procedure.
Page 409 • •...
Page 410 • • • •...
Page 411 Always drive carefully confirming the safety of the rear and the surrounding conditions by looking directly with your eyes: Reversing the vehicle by only looking at the screen is dangerous as it may cause an accident or a collision with an object. The rear view monitor is only a visual assist device when reversing the vehicle.
Page 412 When replacing the tyres, consult an expert repairer, we recommend an Authorised Mazda • Repairer. Replacing the tyres could result in deviation of the guide lines which appear on the display. If the vehicle's front, side, or rear has been involved in a collision, the alignment of the •...
Page 413 ▼ (Screen display) Garnish Obstruction detection indication in parking sensor system Bumper (Actual view) Object NOTE The displayable range varies depending on the vehicle and road conditions. • The displayable range is limited. Objects under the bumper or around the bumper ends •...
Page 414 ▼ The indicated position of the guide lines on the display changes depending on the vehicle conditions (such as the number of occupants/cargo load) and the road conditions (such as a steep gradient to the rear of the vehicle).
Page 415 Always check the area to the vehicle's rear and the surrounding area directly with your eyes while backing up. The guide lines on the screen are fixed lines. They are not synced to the driver's turning of the steering wheel. Always be careful and check the area to the vehicle's rear and the surrounding area directly with your eyes while backing up.
Page 416 NOTE The following shows an example of vehicle parking in which the steering wheel is turned to the right when backing up the vehicle. The operation is reversed when backing up the vehicle from the opposite direction. (Display condition) (Vehicle condition) (Display condition) (Vehicle condition)
Page 417 (Display condition) (Vehicle condition) NOTE Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes. In the image of the parking space (or garage) displayed on the screen, the back end and •...
Page 418 When parking in a space with a division line on only one side of the parking space, the • division line and the vehicle width guide line appear aligned in the monitor, but they may not actually be aligned on the ground. NOTE Images displayed on the monitor from the rear view parking camera are reversed images (mirror images).
Page 419 (Display condition) (Vehicle condition) NOTE Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes. In the image of the parking space (or garage) displayed on the screen, the back end and •...
Page 420 When parking in a space with a division line on only one side of the parking space, the • division line and the vehicle width guide line appear aligned in the monitor, but they may not actually be aligned on the ground. ▼...
Page 421 Appears Appears farther than closer than actual actual distance distance Object on screen Object at actual position Object on screen Object at actual A: Distance between the vehicle and object displayed on the screen. position B: Actual distance between the vehicle and object. (Screen display) (Actual condition) (Actual distance) B>C=A...
Page 422 (Screen display) (Actual view) ▼ ▼ Always adjust the picture quality of the rear view monitor while the vehicle is stopped: Do not adjust the picture quality of the rear view monitor while driving the vehicle. Adjusting the picture quality of the rear view monitor such as brightness, contrast, colour, and tint while driving the vehicle is dangerous as it could distract your attention from the vehicle operation which could lead to an accident.
Page 423 Front corner sensor Rear sensor Front sensor Rear corner sensor Do not rely completely on the parking sensor system and be sure to confirm the safety around your vehicle visually when driving: This system can assist the driver in operating the vehicle in the forward and backward directions while parking.
Page 424 Always have the system inspected at an expert repairer, we recommend an Authorised • Mazda Repairer if any shock is applied to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect obstructions. The system may have a malfunction if the beep does not operate or the indicator light •...
Page 425 ▼ A: About 55 cm (About 21.7 in) B: About 55 cm (About 21.7 in) Rear corner sensor detection range C: About 100 cm (About 39.3 in) Front sensor detection range D: About 150 cm (About 59.1 in) Rear sensor detection range Front corner sensor detection range...
Page 427 ▼ Indicator light • •...
Page 428 NOTE (Automatic transaxle vehicle) • The detection indicator and buzzer of the front sensors/front corner sensors do not operate when the selector lever is in the P position. The detection indicator and buzzer sound do not activate when the parking brake is •...
Page 430 ▼...
Page 431 NOTE If an obstruction is detected in a zone for 6 seconds or more, the beep sound is stopped (except for the close-distance zone). If the same obstruction is detected in another zone, the corresponding beep sound is heard.
Page 432 ▼...
Page 436 • • • • • • Label • • • •...
Page 437 Knob ▼ Open Close Dial NOTE * Some models When using the air conditioner under • humid ambient temperature conditions, the system may blow fog from the vents. Knob Dial Open This is not a sign of trouble but a result of humid air being suddenly cooled.
Page 438 ▼ Instrument panel Vents Defroster and Floor Vents Defroster Vents Instrument panel and Floor Vents Floor Vents * With rear vents NOTE The location airflow exits the air vents and the airflow amount may change depending on the open or close status of the air vents.
Page 439 Temperature control dial Fan control dial Mode selector dial A/C switch Air intake selector switch Rear window defogger switch ▼ ▼ NOTE The air conditioner may not function when the outside temperature approaches 0 °C (32 °F). NOTE The mode selector dial can be set at the •...
Page 440 NOTE If the windscreen fogs up easily, set the • mode selector dial to the position. If cooler air is desired at face level, set • the mode selector dial at the position and adjust the temperature control dial to maintain maximum comfort. The air to the floor is warmer than air •...
Page 441 NOTE When maximum cooling is desired, set • the temperature control dial to the Do not defog the windscreen using the extreme cold position and set the air position with the temperature control set intake selector to the recirculated air to the cold position: position, then turn the fan control dial Using the...
Page 442 NOTE One of the functions of the air conditioner is dehumidifying the air and, to use this function, the temperature does not have to be set to cold. Therefore, set the temperature control dial to the desired position (hot or cold) and turn on the air conditioner when you want to dehumidify the cabin air.
Page 443 Temperature setting display (Driver’s side) Windscreen defroster switch Driver temperature control dial Air intake selector Rear window defogger switch (recirculated air position) Air intake selector Passenger temperature A/C mode display (outside air position) control dial A/C switch AUTO switch OFF switch DUAL switch Fan control switch Mode selector...
Page 444 NOTE • With the airflow mode set to the • position and the temperature control dial set at a medium temperature, heated air is directed to the feet and air • at a comparably lower temperature will flow through the central, left and right vents.
Page 445 ▼ Do not use the position in cold or rainy weather: Using the position in cold or rainy weather is dangerous as it will cause the windows to fog up. Your vision will be hampered, which could lead to a serious accident.
Page 446 When selecting heat, the system will ▼ • restrict airflow until it has warmed to prevent cold air from blowing out of the vents. ▼ Sunlight sensor Set the temperature control to the hot or warm position when defogging ( position): Using the position with the temperature...
Page 447 ▼ ▼ NOTE If the ignition is switched off with the audio muted, the mute will be cancelled. Therefore, when the engine is restarted, the audio is not muted. To mute the audio again, press the mute switch ( ). ▼...
Page 448 ▼...
Page 449 ③ The SD card slot is for the navigation system. For vehicles with the navigation ④ system, the SD card (Mazda genuine) with stored map data is inserted into the SD ⑤ card slot and used. Do not adjust the portable audio unit or a...
Page 450 ▼ Depending on the portable audio device, noise may occur when the device is connected to the vehicle accessory socket. USB port Auxiliary jack (If noise occurs, do not use the accessory socket.) NOTE This mode may not be usable depending •...
Page 451 ▼ When washing the inside of the window which has an aerial, use a soft cloth dampened in lukewarm water, gently wiping the aerial lines. Use of glass cleaning products could damage the aerial. Do not allow the connection plug cord to get tangled with the shift lever (manual ▼...
Page 452 Audio display Menu button Power/Volume/Audio control dial ▼ ▼ ▼ ▼...
Page 453 NOTE If not operated for several seconds, the display returns to the previous display. To reset bass, treble, fade, and balance, press the menu button ( ) for 2 seconds. The unit will beep and “CLEAR” will be displayed.
Page 454 :00 button Audio control dial Audio display Clock button Menu button Hour/Minute set switch ▼ ▼ NOTE When the :00 button (1) is pressed, the • seconds will start at “00”. Switching between 12 and 24-hour clock • • time: Press the menu button ( ) several times until 12 and 24-hour clock time...
Page 455 Without Radio Data System (RDS) Audio display Channel preset buttons Scan button Tuning button Auto memory button Band selector button With Radio Data System (RDS) Audio display Channel preset buttons Programme-type information button Tuning button Scan button Band selector button Traffic announcement button NOTE ▼...
Page 456 NOTE If you continue to press and hold the button, the frequency will continue changing without stopping. NOTE If no stations can be tuned after scanning operations, “A” will be displayed.
Page 457 ▼ NOTE The radio data system (RDS) does not function if it is out of the system's service coverage area. • •...
Page 459 Text button Audio display Random button Play/Pause button Repeat button Folder up button Track down/Reverse button Media/Scan button Track up/Fast-forward button Folder down button CD slot CD eject button • • NOTE ▼ ▼ If a disc has both music data (CD-DA) and MP3/WMA/AAC files, playback of the two or three file types differs depending on how the disc was recorded.
Page 460 NOTE If the unit is left in scan, normal playback will resume where scan was selected.
Page 462 ▼ NOTE The number of characters which can be displayed is restricted. NOTE The information viewable in the display • is only CD information (such as artist name, song title) which has been recorded to the CD. This unit cannot display some •...
Page 463 NOTE When the device is not connected to the • auxiliary jack, the mode does not switch to the AUX mode. Adjust the audio volume using the • portable audio device or audio unit. Audio adjustments other than audio • volume can only be done using the portable audio device.
Page 464 Random button Audio display Repeat button Text button Play/Pause button Folder up button Track down/Reverse button Media/Scan button Track up/Fast-forward button Folder down button Playback of the USB device is in the • order of the folder numbers. Folders which have no MP3/WMA/AAC files are skipped.
Page 465 NOTE If the unit is left in scan, normal playback will resume where scan was selected.
Page 466 ▼ NOTE The information (artist name, music • name) is displayed only when the USB device information in the USB device has information which can be displayed on the screen. This unit cannot display some • characters. Characters which cannot be displayed are indicated by an asterisk ( ).
Page 467 Audio display Text button Play/Pause button Random button Category down button Repeat button Category up button Track down/Reverse button List up button Track up/Fast-forward button Media/Scan button List down button Do not remove the iPod while in the • iPod mode. Otherwise, the data could be damaged.
Page 468 NOTE The types of categories include Playlist, Artist, Album, Song, Podcast, Genre, Composer, and Audio book. NOTE When the selected category is Song or Audio book, there is no list. NOTE The track number being played randomly is in the order of the iPod shuffle table. NOTE If the unit is left in scan, normal playback will resume where scan was selected.
Page 469 ▼ NOTE The information (artist name, music • name) is displayed only when the iPod has information which can be displayed. This unit cannot display some • characters. Characters which cannot be displayed are indicated by an asterisk ( ). NOTE The number of characters which can be displayed is restricted.
Page 470 ▼ NOTE For your safety, a device can be paired only when the vehicle is parked. If the vehicle • starts to move, the pairing procedure will end. Park the vehicle in a safe place before pairing. ® The communication range of a Bluetooth equipped device is about 10 meters (32 ft) or •...
Page 471 ® Some Bluetooth mobile devices are not compatible with the vehicle. Consult an Authorised Mazda Repairer, Mazda's call centre or Web support centre for information regarding ® Bluetooth mobile device compatibility: Phone: (Germany) 0800 4263 738 (8:00 18:00 Central European Time)
Page 472 NOTE If the volume is lower compared to other audio modes, increase the volume from the device side.
Page 473 ▼ ▼ NOTE The initial setting value is “0000”. NOTE A device can be paired only when the • vehicle is parked. If the vehicle starts to move, the pairing procedure will end. Pairing is dangerous while driving - pair up your device before you start driving.
Page 474 NOTE If more than two devices are to be For the operation of the device, refer paired, they cannot be paired with the to its instruction manual. same or similar “device tag”. NOTE When the pairing is completed, the • symbol is displayed.
Page 475 ▼ • • • • • •...
Page 476 NOTE A registered device (Mobile phone) can be deleted using the registration list. NOTE When the selected device connection is • completed, the or symbol is displayed. NOTE Say “All” to delete all devices (Mobile ® Some Bluetooth audio devices need a •...
Page 477 ▼...
Page 478 NOTE ® If a Bluetooth device has already been • paired to the vehicle as a hands-free mobile phone, it does not need to be paired again when using the device as a ® Bluetooth audio device. Conversely, it does not need to be paired again as a hands-free mobile phone if it has ®...
Page 479 If the pairing failed, “Err” flashes • for three seconds. Pairing cannot be performed while • the vehicle is moving. If you attempt to perform pairing while the vehicle is moving, “PAIR DISABLE” is displayed. ® If seven Bluetooth audio devices •...
Page 480 ▼ NOTE If pairing cannot be completed, try • “1234” instead. Refer to the owner's manual of your mobile device for the right PIN code. ® Some Bluetooth audio devices need • a certain amount of time before the “ ” symbol is displayed. If the pairing failed, “Err”...
Page 481 Device name 1 NOTE Device name 2 When “GO BACK” is selected and the audio control dial is pressed, the display returns to “LINK CHANGE”. Device name 3 Device name 4 Device name 5 Device name 6 NOTE Device name 7 ®...
Page 482 If an error occurs while trying to ▼ • link a device, “Err” flashes in the display for three seconds, and the display returns to “LINK CHANGE”. If this occurs, check the ® pairing status of the Bluetooth audio device and the location of the device in the vehicle (not in the luggage compartment or a metal-type box), and then try the link...
Page 483 ▼ NOTE The display changes as follows depending on whether the audio control dial is rotated clockwise or anticlockwise. -Clockwise: “SURE ? YES” displayed -Anticlockwise: “SURE ? NO” displayed NOTE Select “GO BACK” and press the audio control dial to return to the Device name “PAIR DELETE”...
Page 484 NOTE Other language settings can also be made while in the current setting by saying the name of the language in the native pronunciation. NOTE If the language setting is changed, • device registration is maintained. Phonebook records are not cleared, but •...
Page 485 NOTE Do this function only when parked. It is too distracting to attempt while driving and you may make too many errors to be effective. NOTE Do this function only when parked. It is too distracting to attempt while driving and you may make too many errors to be effective.
Page 486 NOTE • If the confirmation prompt function is turned off when making an emergency • call, the system reads out and confirms the command before executing it. NOTE ® The battery consumption of Bluetooth • audio devices increases while ® Bluetooth is connected.
Page 487 If a general mobile phone device is USB • connected during music playback over ® the Bluetooth connection, the ® Bluetooth connection is disconnected. For this reason, you cannot have music ® playback over a Bluetooth connection NOTE and music playback using a USB ®...
Page 488 ▼ ▼ ▼ NOTE NOTE If title information is not available, “NO • Some information may not display TITLE” is displayed. depending on the device, and if the This unit cannot display some • information cannot be displayed, “NO characters. Characters which cannot be TITLE”...
Page 489 ▼ NOTE The “Call” command and the voice tag can be combined. Ex. In Step 2, say, “Call John's phone”, then, Steps 3 and 4 can be skipped. NOTE Do this function only when parked. It is too distracting to attempt while driving and you may make too many errors to be effective.
Page 490 NOTE Do this function only when parked. It is too distracting to attempt while driving and you may make too many errors to be effective.
Page 491 NOTE Do this function only when parked. It is too distracting to attempt while driving and you may make too many errors to be effective. NOTE If there was no previous phone number registered to a location (Ex. “Work”), the prompt will only read out “Number, please”...
Page 492 NOTE Do this function only when parked. It is too distracting to attempt while driving and you may make too many errors to be effective. • • • • •...
Page 493 NOTE Practice this while parked until you are confident you can do it while driving in a NOTE non-taxing road situation. If you are not The “Dial” command and a telephone completely comfortable, make all calls number can be combined. from a safe parking position, and only Ex.
Page 494 ▼ ▼ ▼ ▼ ▼ ▼ NOTE To refuse an incoming call, press the • hang-up button.
Page 495 After receiving a new incoming call, the • previous call is placed on hold.
Page 496 ▼ • • NOTE ® The Bluetooth Hands-Free system is • operable several seconds after the ignition is switched to ACC or ON (requires less than 15 seconds). When operating the audio unit or the • ® A/C while using Bluetooth Hands-Free, the beep sounds or voice guidance (audio unit)/cannot be heard.
Page 497 • • • NOTE If the voice recognition performance is not satisfactory. Refer to Voice Recognition Learning Function (Speaker Enrolment) (Type A) on page 5-66. Refer to Troubleshooting on page 5-68. • • • •...
Page 498 NOTE If an error occurred in the voice recognition learning, re-learning can be done by pressing the talk button with a short press. ▼ ▼...
Page 499 NOTE The applicable phrase appears in the • audio display. After user voice registration is • completed, voice guidance “Speaker enrolment is complete” is announced. NOTE If an error occurred in the voice recognition learning, re-learning can be done by pressing the talk button with a short press.
Page 500 • •...
Page 501 If you pair your phone which has already been paired to your vehicle more than once in • the past, you need to delete “Mazda” on your mobile device. Then, execute the ® Bluetooth search on your mobile device once again, and pair to a newly detected “Mazda”.
Page 502 • •...
Page 504 Additionally, depending on future software updates, the content may successively change without notice. For additional information regarding Mazda Connect, please refer to the following • Website. http://infotainment.mazdahandsfree.com/ •...
Page 505 NOTE Long-press operation of the commander knob is also possible for some functions.
Page 506 ▼ Do not press the screen strongly or press it with a sharp-pointed object. Otherwise, the screen could be damaged. NOTE For safety reasons, operation of the centre display is disabled while the vehicle is being driven. However, items not displayed in grey can be operated using the commander switch while the vehicle is being driven.
Page 509 Audio control switch Commander switch Volume dial Volume switch ▼ ▼ NOTE Press the volume dial to switch the audio MUTE on and off. ▼ • •...
Page 510 ▼ ▼...
Page 512 ▼...
Page 513 NOTE (With Radio Data System (RDS)) When the icon is selected while FM is selected, each programme is selected. ▼ ▼ ▼ NOTE If the battery is disconnected, your Favourites list will be not deleted.
Page 514 NOTE Only one Genre can be selected. NOTE It may take longer to display the station list depending on the reception conditions.
Page 515 ▼ NOTE This unit is also compatible with DAB radio. ▼ ▼ NOTE If the station list is not available, it switches to the station list update screen. Perform the station list updating.
Page 516 NOTE The radio text may not be displayed • depending on the radio station. The radio text cannot be displayed in • DAB-FM mode. If there is no DAB radio signal, “Signal • Lost” is displayed on the screen. Change the ensemble or radio station, or perform station list updating.
Page 517 CD slot CD eject button • • NOTE If a disc has both music data (CD-DA) and MP3/WMA/AAC files, playback of the two or three file types differs depending on how the disc was recorded. NOTE There will be a short lapse before play begins while the player reads the digital signals on the CD.
Page 518 ▼...
Page 519 NOTE Select to move to a folder one level • higher. The appearance of the repeat and • shuffle icons changes depending on the type of operation in which the function is used.
Page 520 DVD slot DVD eject button NOTE There will be a short lapse before play begins while the player reads the digital signals on the DVD.
Page 521 ▼...
Page 522 NOTE For safety reasons, images are not • displayed while the vehicle is being driven. Slide the of the controller to move • the controller. If the mode is switched to DVD mode • once the DVD playback has stopped, the playback restarts without displaying the DVD menu screen.
Page 523 ▼ NOTE If a device is not connected to the auxiliary jack, the mode does not switch to the AUX • mode. Adjust the audio volume using the portable audio device, commander switch, or audio • control switch. Audio adjustments can also be made using the portable audio device's volume setting. •...
Page 524 ▼...
Page 525 NOTE If a file name in the USB memory is too long, it could cause operation problems such as • not being able to playback the song. (Recommended: Within 80 characters) The album art may not display depending on the album art size. •...
Page 526 NOTE Only the tracks in the desired category selected in Step 2 are played. NOTE Only the tracks in the desired folder selected in Step 3 are played.
Page 527 ▼ ® For information related to the most recent Gracenote database which can be used and how to install it, go to the Mazda Hands Free Website: http://www.mazdahandsfree.com...
Page 528 NOTE ® Gracenote can be downloaded from the Mazda Hands-free Website.
Page 529 However, items not displayed in grey can be operated using the commander switch while the vehicle is being driven. ® Some Bluetooth mobile devices are not compatible with the vehicle. Consult an Authorised Mazda Repairer, Mazda's call centre or Web support centre for information regarding ® Bluetooth mobile device compatibility: Phone:...
Page 530 (Except Germany) 00800 4263 7383 (8:00 18:00 Central European Time) (Worldwide) 49 (0) 6838 907 287 (8:00 18:00 Central European Time) Web: http://www.mazdahandsfree.com ▼ Audio unit Talk button, Pick-up button and Hang-up button Talk button Pick-up button Hang-up button Microphone Microphone...
Page 531 NOTE Press the volume dial to switch the audio MUTE on and off. • If the volume is lower compared to other audio modes, increase the volume from the • device side.
Page 532 ▼ NOTE ® The Bluetooth system may not operate • for 1 or 2 minutes after the ignition is switched to ACC or ON. However, this does not indicate a problem. If the ® Bluetooth system does not connect automatically after 1 or 2 minutes have ®...
Page 533 NOTE ▼ When Call history and messages are downloaded automatically, each automatic download setting must be on. Refer to Communication Settings on page 5-120. • • • NOTE The following functions can be used for the Hands-free or audio. Hands-free: Phone calls and •...
Page 534 ▼ NOTE Depending on the language, it may only be available for the screen display, but not for the voice recognition. ▼ ▼...
Page 535 • • NOTE ® The battery consumption of Bluetooth • audio devices increases while ® Bluetooth is connected. If a general mobile phone device is USB • connected during music playback over ® the Bluetooth connection, the ® Bluetooth connection is disconnected. For this reason, you cannot have music ®...
Page 536 ▼ NOTE ® If the application screen is not displayed on the device, Bluetooth audio may not play on • the centre display. ® If Bluetooth audio is used after using Aha™ or Stitcher™ radio, the application on the • mobile device has to be closed first.
Page 538 ▼ NOTE Some information may not display depending on the device, and if the information cannot be displayed, “Unknown - - -” is indicated.
Page 539 ▼ NOTE The service content provided by Aha™ varies depending on the country in which the user • resides. In addition, the service is not available in some countries. ® To operate Aha™ from your Bluetooth device, perform the following in advance: •...
Page 541 NOTE The available Location Based Services may differ because the services depend on the content provided by Aha™.
Page 542 ▼ NOTE ® To operate Stitcher™ Radio from your Bluetooth device, perform the following in • advance: Install the Stitcher™ Radio application to your device. • Create a Stitcher™ Radio account for your device. • Log onto Stitcher™ Radio using your device. •...
Page 543 NOTE Multiple favourites stations can be • selected and registered. Favourites stations registered by oneself • as well those set by default are displayed.
Page 544 ▼ • • • • • •...
Page 545 NOTE If “Import All Contacts” is performed • after saving the phonebook to the ® Bluetooth unit, the phonebook will be overwritten. A maximum of 1,000 contacts can be • registered to the phonebook. Phonebook, incoming/outgoing call • record, and favourite memories are exclusive to each mobile phone to protect privacy.
Page 546 NOTE If the contact is long-pressed when the favourites list is displayed, the contact information can be edited (deleted, moved). NOTE Practice this while parked until you are confident you can do it while driving in a non-taxing road situation. If you are not completely comfortable, make all calls from a safe parking position, and only start driving when you can devote your...
Page 548 ▼...
Page 549 NOTE If the ignition is switched off during a • hands-free call, the line is transferred to the device (Mobile phone) automatically. If the DTMF code has two or more • digits or symbols, each one must be transmitted individually. NOTE ▼...
Page 550 If the connected device does not • correspond to MAP 1.0, the AT command is used to download. The downloaded message indicates that it is already read. Downloading using the AT command • may not function depending on the connected device. If an iPhone is connected, the following •...
Page 551 NOTE Up to three preset messages can be selected. NOTE Select the icon to change the • language. Select the icon to switch between • capitalized and lower-case characters. Select the icon to return to the • previous screen without storing the edit.
Page 552 ▼...
Page 553 ▼ • • • • • • • • • • • • NOTE If the voice recognition performance is not satisfactory. Refer to Troubleshooting on page 5-126.
Page 554 ▼ NOTE Some commands cannot be used depending on the grade and specification. • Some commands cannot be used depending on the device connection conditions and the • use conditions. The commands are examples of the available commands. •...
Page 555 NOTE Depending on the grade and specification, the screen display may differ.
Page 557 NOTE Depending on the grade and specification, the screen display may differ.
Page 560 If you pair your phone which has already been paired to your vehicle more than once in • the past, you need to delete “Mazda” on your mobile device. Then, execute the ® Bluetooth search on your mobile device once again, and pair to a newly detected “Mazda”.
Page 561 • •...
Page 563 Always adjust the audio while the vehicle is stopped: Do not adjust the audio control switches while driving the vehicle. Adjusting the audio while driving the vehicle is dangerous as it could distract your attention from the vehicle operation which could lead to a serious accident.
Page 564 FM Station 40—50km (25—30 miles) Reflected wave Direct Ionosphere FM wave AM wave FM wave 100—200 km (60—120 miles)
Page 565 ▼ ▼ • • Station 2 Station 1 88.3 MHz 88.1 MHz...
Page 566 • • Transparent • • • • • •...
Page 567 • • • ▼ • • • • Do not use an audio file extension on files other than audio files. In addition, do not • change the audio file extension. Otherwise, the unit will not recognise the file correctly •...
Page 568 NOTE Supply of this product only conveys a license for private, non-commercial use Do not use an audio file extension on files and does not convey a license nor imply other than audio files. In addition, do not any right to use this product in any change the audio file extension.
Page 569 ▼ Do not use an audio file extension on files other than audio files. In addition, do not change the audio file extension. Otherwise, the unit will not recognise the file correctly resulting in noise or a malfunction. • • Do not use an audio file extension on files other than audio files.
Page 570 • • • • • • Transparent • • • •...
Page 571 • • • • • • NOTE Video data (DVD-Video/DVD-VR files) • • written to DVD/DVD-R/DVD R/ DVD-RW/DVD RW can be played. This unit is compatible for playback of • dual-layer DVD/DVD-R. Regional number for this unit is [2] or •...
Page 572 ▼ ▼...
Page 573 • data, we recommend that you always If data in the iPod is lost while it is back up your data. connected to the unit, Mazda cannot If a device exceeds the maximum guarantee recovery of any lost data. •...
Page 574 When connecting the iPod to a USB port, all commands are made from the audio unit. iPod control is not possible. NOTE The audio unit cannot display images or videos stored in an iPod.
Page 575 NOTE Do not leave the lights on for long periods Sunvisor while the engine is turned off. Otherwise the battery power could be depleted. • ▼ ▼ • NOTE The rear map lights also turn on and off when the overhead light switch is operated.
Page 576 The rear map lights will not turn off • even if the lens is pressed in the following cases: The overhead light switch is ON. • The overhead light switch is in the • door position with the door open. The illuminated entry system is on.
Page 577 ▼ • • NOTE The illumination time differs depending • on the operation. Battery saver • If an interior light is left on with the ignition switched OFF, the light is turned off automatically after about 30 minutes to prevent battery depletion. The operation of the illuminated entry •...
Page 578 Do not use accessories that require Plug more than 120 W (DC 12 V, 10 A). Do not use accessories that are not genuine Mazda accessories or the equivalent. Close the cover when the accessory socket is not in use to prevent foreign objects and liquids from getting into the accessory socket.
Page 579 Connector USB power outlet To prevent USB power outlets damage or electrical failure, pay attention to the following: Do not use USB devices that require more than 10.5 W (DC 5 V, 2.1 A). Close the lid when the USB power outlets are not in use to prevent foreign objects and liquids from getting into the USB power outlets.
Page 580 ▼ ▼ Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot liquids while the vehicle is moving is dangerous. If the contents spill, you could be scalded. Do not put anything other than cups or drink cans in cup holders: Putting objects other than cups or drink cans in a cup holder is dangerous.
Page 581 Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving. Do not put articles in storage spaces with no lid: Putting articles in storage spaces with no Bottle holder...
Page 582 ▼ ▼ ▼ ▼ ▼ Storage tray...
Page 583 ▼ Make sure luggage and cargo is secured before driving: Not securing cargo while driving is dangerous as it could move or be crushed during sudden braking or a collision and cause injury. Luggage board...
Page 584 NOTE Loading golf bags (Some golf bags may not fit using the following methods depending on their sizes.) Up to four golf bags can be carried in the luggage compartment. (With luggage compartment cover) When loading four golf bags, remove the luggage compartment cover and store it in the cargo sub-compartment.
Page 585 ▼ Never hang heavy or sharp objects on the assist grips and coat hooks: Hanging heavy or sharp-ended objects Only use the removable ashtray in its fixed such as a coat hanger from the assist grips position, and make sure it is completely or coat hooks is dangerous as they can fly inserted: off and hit an occupant in the cabin if a...
Page 588 Malfunction diagnosis connector...
Page 589 NOTE After the prescribed period, continue to follow the described maintenance at the recommended intervals. ▼...
Page 592 ▼...
Page 598 ▼ Instrument panel illumination knob...
Page 599 ▼...
Page 601 • • • • • • Do not perform maintenance work if you lack sufficient knowledge and experience or the proper tools and equipment to do the work. Have maintenance work done by a qualified technician: Performing maintenance work on a vehicle is dangerous if not done properly. You can be seriously injured while performing some maintenance procedures.
Page 602 If you must run the engine while working under the bonnet, make certain that you remove all jewellery (especially rings, bracelets, watches, and necklaces) and all neckties, scarves, and similar loose clothing before getting near the engine or cooling fan which may turn on unexpectedly: Working under the bonnet with the engine running is dangerous.
Page 603 Lever Always check that the bonnet is closed and securely locked: A bonnet that is not closed and securely locked is dangerous as it could fly open while the vehicle is moving and block the driver's vision which could result in a serious accident.
Page 604 ▼ Clip Clip Clip When closing the bonnet, do not push it excessively such as by applying your weight. Otherwise, the bonnet could be deformed.
Page 605 SKYACTIV-G 2.0 and SKYACTIV-G 2.5 Brake/Clutch fluid reservoir Windscreen washer fluid reservoir Engine oil dipstick Battery Fuse block Cooling system cap Engine coolant reservoir Engine oil-filler cap SKYACTIV-D 2.2 Brake/Clutch fluid reservoir Windscreen washer fluid reservoir Engine oil-filler cap Battery Fuse block Cooling system cap Engine coolant reservoir...
Page 606 Temperature Range SAE Viscosity Numbers –40 –30 –20 –10 Grade –40 –20 Recommended oils Mazda Original Oil Supra 0W-20 Mazda Original Oil Ultra 5W-30 Alternative Oil Quality 0W-20 API SN or ACEA A5/B5 5W-30 (Except Europe) Temperature Range SAE Viscosity Numbers –30 –20 –10...
Page 607 Temperature Range SAE Viscosity Numbers –40 –30 –20 –10 Grade –20 –40 Recommended oils Mazda Original Oil Supra DPF 0W-30 Mazda Original Oil Ultra DPF 5W-30 Alternative Oil Quality 0W-30 ACEA C3 5W-30 (Except Europe) Temperature Range SAE Viscosity Numbers –40...
Page 608 Otherwise the wrench indicator light or engine oil warning light may turn on. To reset the engine control unit, consult an expert repairer, we recommend an Authorised Mazda Repairer or refer to the vehicle engine control unit reset procedure on page 6-22.
Page 609 NOTE The initialization (engine oil data resetting) of the recorded value can be performed using the instrument panel illumination knob in the instrument cluster as following: 1. Switch the ignition OFF. 2. Switch the ignition ON with the instrument panel illumination knob pressed, and press and hold the instrument panel illumination knob for about 5 seconds until the master warning light flashes.
Page 610 ▼ ▼ X Mark Do not use a match or live flame in the engine compartment. DO NOT ADD COOLANT WHEN THE ENGINE IS HOT: A hot engine is dangerous. If the engine has been running, parts of the engine compartment can become very hot.
Page 611 NOTE Changing the coolant should be done by an expert repairer, we recommend an Authorised Mazda Repairer. Radiator coolant will damage paint. Rinse it off quickly if spilled. If the “FL22” mark is shown on or near the cooling system cap, use of FL-22 is recommended when replacing engine coolant.
Page 612 ▼ If the brake/clutch fluid level is low, have the brakes inspected: A low brake/clutch fluid level is dangerous. A low level could indicate brake lining wear or a brake system leak which could cause the brakes to fail and lead to an accident.
Page 613 ▼ Use only windscreen washer fluid or plain ® water in the reservoir: If AdBlue gets in your mouth, wash your Using radiator antifreeze as washer fluid is mouth with a large amount of water dangerous. If sprayed on the windscreen, it immediately and seek medical attention.
Page 614 In addition, if the fluid freezes in the urea tank, you may not be able to tell if the correct Use a Mazda genuine product or a amount of fluid was added. product conforming to ISO22241-1 for AdBlue®.
Page 615 Replenishment of AdBlue® by an 1 Even if AdBlue® is added at the • Authorised Mazda Dealer is indicated replenishment amount, recommended. If you want to replenish 100 % may not be indicated on the the AdBlue® yourself, follow the display.
Page 616 If too much AdBlue® is added, the SCR system might display a warning. Contact an expert repairer, we recommend an Authorised Mazda • Repairer if a warning is displayed. If the warning remains displayed, the urea tank may have a problem or it may be •...
Page 617 Hot waxes applied by automatic car washers have been known to affect the wiper's ability to clean windows. To prevent damage to the wiper blades, do not use petrol, paraffin, paint thinner, or other solvents on or near them. When the wiper lever is in the AUTO position and the ignition is switched ON, the wipers may move automatically in the following cases:...
Page 618 ▼ To prevent damage to the wiper arms and other components, do not try to sweep the wiper arm by hand. Do not bend the blade rubber unnecessarily when replacing it. Otherwise, the metal stiffener in the blade may deform and the windscreen wiper operation may be adversely affected.
Page 619 Groove Groove...
Page 620 Notch Projection Groove ▼ ▼ Tabs To prevent damage to the wiper arm and Grooves other components, do not move the wiper by hand.
Page 621 Do not bend or discard the stiffeners. You need to use them again. To prevent damage to the rear window, do not let the wiper arm fall on it.
Page 622 Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery: Working without eye protection is dangerous. Battery fluid contains SULPHURIC ACID which could cause blindness if splashed into your eyes. Also, hydrogen gas produced during normal battery operation, could ignite and cause the battery to explode.
Page 623 Keep all flames and sparks away from open battery cells because hydrogen gas is produced from open battery cells while charging the battery or adding battery fluid: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode.
Page 624 ▼ • • ▼ Upper level Lower level ▼ ▼ NOTE Before performing maintenance or • recharging the battery, turn off all accessories and stop the engine. To disconnect the battery, remove the • negative lead first. Install it last when connecting the battery.
Page 625 • • Make sure the battery is installed correctly. Battery leakage could occur if it • is not installed correctly. When replacing the battery, be careful not to touch any of the internal circuitry and electrical terminals, bend the electrical terminals, or get dirt in the transmitter as the transmitter could be damaged.
Page 626 Cover Cover Be careful not to allow the rubber ring shown in the figure to be scratched or damaged. If the rubber ring detaches, reattach it before inserting a new battery. Rubber ring Cover...
Page 627 Using Different Tyre Types: Driving your vehicle with different types of tyres is dangerous. It could cause poor handling and poor braking; leading to loss of control. Except for the limited use of the temporary spare tyre, use only the same type tyres (radial, bias-belted, bias-type) on all four wheels.
Page 628 ▼ Use only a Mazda-genuine tyre valve cap: Use of a non-genuine part is dangerous as the correct tyre air pressure cannot be maintained if the tyre valve becomes damaged. If the vehicle is driven under this Rotate tyres periodically: condition, the tyre air pressure will Irregular tyre wear is dangerous.
Page 629 Replacing just one tyre is dangerous. It could cause poor handling and poor braking resulting in loss of vehicle control. Mazda strongly recommends that you replace all four tyres at the same time. Do not use your temporary spare tyre rim with a snow tyre or a conventional tyre.
Page 630 (inset/outset). use, however, if the tread wear For details, contact an expert repairer, • solid-band indicator appears, replace the we recommend an Authorised Mazda tyre with the same type of temporary Repairer. spare (page 6-43). ▼ Always use wheels of the correct size on your vehicle: Using a wrong-sized wheel is dangerous.
Page 631 Type A Type B...
Page 632 • caused by the flying glass. repairer, we recommend an Authorised If the glass portion is touched with bare Mazda Repairer. hands, body oil could cause the bulb to If the halogen bulb is accidentally • overheat and explode when lit.
Page 633 ▼ Removal Installation...
Page 634 Removal Installation...
Page 635 Removal Installation...
Page 636 ▼ ▼...
Page 637 When replacing the bulb always disconnect the connector first. Otherwise, electric and electronic devices could be shorted.
Page 638 ▼ ▼...
Page 639 Always replace a fuse with a genuine Mazda fuse or equivalent of the same rating. Otherwise you may damage the electric system. Blown Normal...
Page 640 Do not replace the main fuse by yourself. Have an Authorised Mazda Repairer perform the replacement: Replacing the fuse by yourself is dangerous because the MAIN fuse is a high current fuse. Incorrect replacement could cause an electrical shock or a short circuit resulting in a...
Page 646 Chipped paint can lead to rust forming • on your Mazda. Before this happens, repair the damage by using Mazda touch-up paint according to the instructions in this section. Failure to repair the affected area could lead to serious rusting and expensive repairs.
Page 647 • • • • NOTE Mazda is not responsible for scratches • caused by automatic car washes or improper washing. Scratches are more noticeable on • vehicles with darker paint finishes.
Page 648 Dry off brakes that have become wet by driving slowly, releasing the accelerator pedal and lightly applying the brakes several times until the brake performance returns to normal: Driving with wet brakes is dangerous. Increased stopping distance or the vehicle pulling to one side when braking could result in a serious accident.
Page 649 ▼ ▼ ▼ • ▼ • • Do not use any detergent other than mild detergent. Before using any detergent, verify the ingredients. Otherwise, the product could discolour or stain the aluminium wheels. NOTE Do not use steel wool, abrasive cleaners, or Do not use a wire brush or any abrasive strong detergents containing highly •...
Page 650 (19-inch wheel vehicle) • If your aluminium wheels lose lustre, apply wax which contains no polishing powder. ▼ Do not spray water into the vehicle cabin: Spraying water into the vehicle cabin is • dangerous as electrical devices such as the audio and switches could get wet resulting in a malfunction or vehicle fire.
Page 651 If a seat belt appears frayed or has ▼ abrasions, have it replaced by an Authorised Mazda Repairer: If a seat belts is used under such a condition, it cannot function at its full capacity which could result in serious injury or death.
Page 652 If the leather upholstery comes into ▼ • contact with any of the following, clean it immediately. Leaving it uncleaned could cause premature wear, mold, or stains. Sand or dirt • Grease or oil, such as hand cream • Alcohol, such as in cosmetic or hair •...
Page 653 ▼ NOTE Be particularly careful when cleaning shiny surface panels and metallic parts such as plating as they can be scratched easily. ▼ Do not scrape or scratch the inside of the window glass. It could damage the thermal filaments and the aerial lines. When washing the inside of the window glass, use a soft cloth dampened in lukewarm water, gently wiping the...
Page 656 Strap NOTE The direction indicators do not work • when the hazard warning lights are on. Check local regulations about the use of • hazard warning lights while the vehicle is being towed to verify that it is not in violation of the law.
Page 657 NOTE Your vehicle may or may not be equipped with a spare tyre, jack, wheel brace, and tool bag. For details, consult an Authorised Mazda Repairer. With spare tyre Towing eyelet Type A Jack Screwdriver Jack lever Wrench Wheel brace...
Page 658 Without spare tyre Emergency flat tyre Type A Towing eyelet repair kit Jack lever Jack Wheel brace Type B Emergency flat tyre Towing eyelet repair kit Jack Jack lever Wheel brace Some models.
Page 659 ▼ • • • ▼ ▼ Do not install the temporary spare tyre on the front wheels (driving wheels): Type A Driving with the temporary spare tyre on one of the front driving wheels is dangerous. Handling will be affected. You could lose control of the vehicle, especially on ice or snow bound roads, and have an accident.
Page 660 Do not use your temporary spare tyre Connector on any other vehicle, it has been NOTE designed only for your Mazda. Extra strength may be required to Use only one temporary spare tyre on uncouple the connector. Be sure to your vehicle at the same time.
Page 661 If an emergency repair was performed on a flat tyre using the emergency flat tyre repair kit, have an expert repairer, we recommend an Authorised Mazda Repairer, repair or replace the tyre as soon as possible.
Page 662 Authorised Mazda Repairer. The emergency flat tyre repair kit cannot • be used in the following cases. Consult an expert repairer, we recommend an Authorised Mazda Repairer. Tyre sealant Injection hose The period of effective use for the tyre •...
Page 663 If the bottle is shaken after the injection Type A hose is screwed on, tyre sealant could spray out from the injection hose. Tyre sealant contacting clothing or other objects may be impossible to remove. Shake the bottle before screwing on the injection hose.
Page 664 Remove the valve core carefully. Valve Valve Valve core NOTE The tyre sealant cannot be reused. Purchase a new tyre sealant kit at an Authorised Mazda Repairer. NOTE Store the valve core in a place where it will not get dirty.
Page 665 NOTE Do not throw away the empty tyre sealant bottle after use. Return the empty tyre sealant bottle to an Authorised Mazda Repairer when replacing the tyre. The empty tyre sealant bottle will need to be used to Valve Compressor hose extract and dispose of the used sealant from the tyre.
Page 666 Drive carefully to an expert repairer, we recommend an Authorised kPa (3.1 kgf/cm , 3 bar, 43.5 psi) is Mazda Repairer and keep the vehicle dangerous. When the inflation pressure speed below 80 km/h (50 mph). rises above 300 kPa (3.1 kgf/cm...
Page 667 Check the period of effective use indicated on the bottle label and do not use it if it has expired. Have the tyre sealant replaced at an Authorised Mazda Repairer before the period of effective use has expired. For a tyre which has undergone an...
Page 668 NOTE If the following occurs while driving, it could indicate a flat tyre. Steering becomes difficult. • The vehicle begins to vibrate • excessively. The vehicle pulls in one direction. • Be sure to follow the directions for changing a tyre: Changing a tyre is dangerous if not done properly.
Page 669 ▼ When jacking-up a vehicle, always shift the shift lever to 1st or R (manual transaxle vehicle) or shift the selector lever to P (automatic transaxle vehicle), apply the parking brake, and place wheel blocks in the position diagonally opposed to the jack: Changing a flat tyre without using wheel blocks is dangerous because the vehicle...
Page 670 Use only the jack provided with your Mazda: Jacking position Using a jack that is not designed for your Mazda is dangerous. The vehicle could slip off the jack and seriously injure someone. Never place objects under the jack: Jacking the vehicle with an object under the jack is dangerous.
Page 671 Do not start the engine or shake the vehicle while it is jacked up: Starting the engine or shaking the vehicle while it is jacked up is dangerous as it could cause the vehicle to fall off the jack resulting in an accident.
Page 672 ▼ Do not apply oil or grease to wheel nuts and bolts and do not tighten the wheel nuts beyond the recommended tightening torque: Applying oil or grease to wheel nuts Make sure the mounting surfaces of the and bolts is dangerous. The wheel nuts wheel, hub and wheel nuts are clean could loosen while driving and cause before changing or replacing tyres:...
Page 673 Because the wheel studs and wheel nuts on your Mazda have metric threads, using a non-metric nut is dangerous. On a metric stud, it would not secure the wheel and would...
Page 674 Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it. Keep flames and sparks away from open battery cells and do not allow metal tools to contact the positive ( ) or negative ( ) terminal of the battery when working near a battery.
Page 675 Route the jumper leads away from parts that will be moving: Connecting a jumper lead near or to moving parts (cooling fans, belts) is dangerous. The lead could get caught when the engine starts and cause serious injury. Use only a 12 V booster system. You can damage a 12 V starter, ignition system, and other electrical parts beyond repair with a 24 V power supply (two 12 V batteries in series or a 24 V motor generator set).
Page 676 NOTE If the vehicle is driven while the message is displayed, a beep sound is heard. If you turn the steering wheel while the message is displayed, it will feel heavier than normal, but this does not indicate an abnormality. The steering operation will return to normal after the message is no longer displayed.
Page 677 Never tow a vehicle to start it: Towing a vehicle to start it is dangerous. The vehicle being towed could surge forward when its engine starts, causing the two vehicles to collide. The occupants could be injured. Do not push-start a vehicle that has a manual transaxle.
Page 678 Do not try starting the engine for more than 10 seconds at a time. Doing so, could damage the starter. If the engine does not start on the first try wait about 20 seconds before trying again.
Page 679 Stop the engine and call an expert repairer, we under pressure and cause serious injury. recommend an Authorised Mazda Open the bonnet ONLY after steam is no Repairer. longer escaping from the engine: Steam from an overheated engine is dangerous.
Page 680 If the engine continues to overheat or frequently overheats, have the cooling system inspected. The engine could be seriously damaged unless repairs are made. Consult an expert repairer, we recommend an Authorised Mazda Repairer. Cooling system cap Coolant reservoir Cooling fan...
Page 681 Always tow a 4WD vehicle with all four wheels off the ground: Towing a 4WD vehicle with either the front or rear wheels on the ground is dangerous as the drive train could be damaged, or the vehicle could trail away from the tow truck and cause an accident.
Page 682 Do not tow with sling-type equipment. This could damage your vehicle. Use wheel-lift or flatbed equipment. Follow these instructions when towing the vehicle with all wheels on the ground. 1. Shift to neutral (Manual transaxle), or the N position (Automatic transaxle). 2.
Page 683 Jack lever The towing eyelet should be used in an emergency (to get the vehicle out of a ditch or a snow bank, for example). When using the towing eyelets, always pull the lead or chain in a straight direction with respect to the eyelet. Never apply a sideways force.
Page 684 Towing eyelet Wheel brace If the towing eyelet is not securely tightened, it may loosen or disengage from the bumper when towing the vehicle. Make sure that the towing eyelet is securely tightened to the bumper. Be careful not to damage the towing eyelet and towing hook, vehicle body, or transaxle system when towing under the following conditions:...
Page 685 ▼ ▼ Do not drive with the brake system warning light illuminated. Contact an expert repair‐ er, we recommend an Authorised Mazda Repairer to have the brakes inspected as soon as possible: Driving with the brake system warning light illuminated is dangerous. It indicates that your brakes may not work at all or that they could completely fail at any time.
Page 686 Do not drive with both the ABS warning light and brake warning light illuminated. Have the vehicle towed to an expert repairer, we recommend an Authorised Mazda Re‐ pairer to have the brakes inspected as soon as possible: Driving when the brake system warning light and ABS warning light are illuminated simultaneously is dangerous.
Page 687 Do not drive the vehicle with the high engine coolant temperature warning light illumi‐ nated. Otherwise, it could result in damage to the engine. NOTE If the message is displayed, the power steering will not operate normally. In this • case, the steering wheel can still be operated, however, the operation may feel heavy compared to normal, or the steering wheel could vibrate when turning.
Page 688 ▼ NOTE When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS • warning light may illuminate. If this occurs, it is the result of the weak battery and does not indicate an ABS malfunction. Recharge the battery.
Page 689: Warning Light
Master warning indication Master warning light • • • • • •...
Page 690 Immediately depress the brake pedal if the warning light flashes and the beep sound is acti‐ vated while using the AUTOHOLD function: Because the AUTOHOLD function is cancelled forcibly, the vehicle may move unexpectedly and result in an accident.
Page 691 If the automatic transaxle warning indication/light illuminates, the transaxle has an electri‐ cal problem. Continuing to drive your Mazda in this condition could cause damage to your transaxle. Consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible.
Page 692 • Never tamper with the air bag/pretensioner systems and always have an expert repairer, we recommend an Authorised Mazda Repairer perform all servicing and repairs: Self-servicing or tampering with the systems is dangerous. An air bag/pretensioner could accidentally activate or become disabled causing serious injury or death.
Page 693 Authorised Mazda Repairer or a tyre repair station. Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Page 694 If the engine cannot be started, try starting it using the emergency operation for starting the engine, and have the vehicle inspected at an ex‐ pert repairer, we recommend an Authorised Mazda Repairer as soon as possible. •...
Page 695 If the vehicle continues to be driven while the SCR warning light is flashing, the vehicle may stop running. If the SCR warning light flashes, have the vehicle inspected immediately at an expert repairer, we recommend an Authorised Mazda Repairer. NOTE...
Page 696 • • • NOTE If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors can detect, the system may pause (The Blind Spot Monitoring (BSM) OFF indicator light in the instrument cluster illuminates). However, it does not indicate a malfunction. Always use tyres for all wheels that are of the specified size, and the same manufacture, brand, and tread pattern.
Page 697 ▼ NOTE The light illumination timing may vary be- cause fuel inside the fuel tank moves around according to the driving conditions and the vehicle posture.
Page 698 NOTE If the driver or front passenger's seat belt • is unfastened after the warning light turns on, and the vehicle speed exceeds 20 km/h (12 mph), the warning light flashes again. Placing heavy items on the front passeng- • er's seat may cause the front passenger's seat belt warning function to operate de- pending on the weight of the item.
Page 700 When replacing/repairing the tyres or wheels or both, have the work done by an Authorised Mazda Repairer, or the tyre pressure sensors may be damaged.
Page 702 (Display example)
Page 704 (Display example) ▼...
Page 705 ▼...
Page 706 When the ignition is switched to ACC, • expert repairer, we recommend an the “Ignition Not Switched Off (STOP) Authorised Mazda Repairer to have the Warning Beep” (page 7-53) overrides vehicle inspected as soon as possible. the lights-on reminder. ▼...
Page 707 When a small child sits on the front ▼ • passenger seat, it is possible that the warning beep will not operate. ▼ NOTE Because the key utilizes low-intensity radio waves, the Key Removed From Vehicle Warning may activate if the key is carried together with a metal object or it is placed in a poor signal reception area.
Page 708 ▼ ▼ ▼ ▼ ▼...
Page 709 ▼ ▼ • • • • ▼ • • ▼ ▼ ▼...
Page 710 ▼ ▼ ▼ NOTE A personalised function is available to change the Blind Spot Monitoring (BSM) warning beep sound volume. Refer to Personalisation Features on page 9-12. ▼ • •...
Page 711 ▼ ▼ NOTE The volume of the Lane-keep Assist • System (LAS) & Lane Departure Warning System (LDWS) warning sound can be changed. Refer to Personalisation Features on page 9-12. The type of the Lane-keep Assist System • (LAS) & Lane Departure Warning System (LDWS) warning sound can be changed.
Page 712 5 km/h (3 mph). Be careful not to drive over the set speed. (With Mazda Radar Cruise Control (MRCC) or Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)) If the set speed is set lower than the current...
Page 713 Lever Lever Cover...
Page 717 Be very careful in choosing and installing add-on electrical equipment, such as mobile telephones, two-way radios, stereo systems, and car alarm systems: Incorrectly choosing or installing improper add-on equipment or choosing an improper installer is dangerous. Essential systems could be damaged, causing engine stalling, air-bag (SRS) activation, ABS/TCS/DSC inactivation, or a fire in the vehicle.
Page 718 Please comply with the legal regulations concerning the use of communication equipment in vehicles in your country: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver's hands.
Page 719 • • • • •...
Page 720 ▼...
Page 723 ▼...
Page 730 ▼...
Page 734 ▼ Type A...
Page 737 Type B...
Page 740 ▼ Type A...
Page 743 Type B...
Page 747 ▼...
Page 749 For Vehicles sold in Moldova MODEL: DNMWR006...
Page 750 Do not mount any transceiver, microphones, speakers, or any other item in the deployment path of the air bag system. Do not fasten aerial lead to original vehicle wiring, fuel pipes or brake pipes. Avoid running the aerial lead parallel with the wire harness to the best extent possible. Keep the aerial and power leads at least 100 mm (3.9 in) from any electronic modules and the air bags.
Page 751 NOTE After the installation of RF transmitters, check for disturbances from and to all electrical equipment in the vehicle, both in the standby and transmit modes. Check all electrical equipment: with the ignition ON • with the engine running • during a road test at various speeds.
Page 752 ▼ NOTE The bottom two letters might be used in combination with the crossed-out wheeled bin symbol. In this case it complies with the requirement established by the Directive for the chemical involved. “Pb” and “Cd” mean lead and cadmium respectively.
Page 753 ▼...
Page 756 ▼ ▼ ▼ ▼ ▼...
Page 757 ▼ ▼ Forward ▼ Forward ▼...
Page 758 ▼...
Page 759 ▼ When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the iridium alloy and platinum tips could be damaged. ▼...
Page 760 ▼...
Page 761 ▼...
Page 762 ▼ ▼...
Page 763 ▼ Sample tyre mark and its meaning Nominal section width Mud and snow Nominal aspect ratio in % Speed symbol Construction code Load index (not on ZR tyres) Nominal rim diameter in inches...
Page 764 The tyres have been optimally matched with the chassis of your vehicle. When replacing tyres, Mazda recommends that you replace tyres of the same type originally fitted to your vehicle. For details, contact an expert repairer, we recommend an Authorised...
Page 765 ▼ ▼...
Page 787 8GJ1-EE-18B_1...

Mazda CX-5 2018 Owner's Manual

Quick Links

Related Manuals for Mazda CX-5 2018

Summary of Contents for Mazda CX-5 2018

Page 354: Manual Transaxle

Page 407: While Driving

Page 689: Warning Light

Table of Contents
