5.5 - ZA5 Control Panel Description

Description of Control Panel:
The ZA5 control board is suitable for controlling one automation of ATI, FERNI
and FROG series 230V swing gates with up to 600W power and 50-60Hz
frequency. Wholly designed and built by CAME S.p.A. it meets UNI8612
regulations in force. The board is inserted and fixed to the ABS case (S4339 or
S4340), which has an IP54 protection level, with air recycling inlet and
transformer. the board requires 230V AC at terminal blocks L1-L2 and the inlet is
proetcted with two 5A fuses. A 3.15A fuse proetcts the low voltage command
devices. The accessories' total wattage (24V) must not exceed 20W.
Safety:
PHOTOCELLS CAN BE CONNECTED TO OBTAIN:
Re-Opening : Re-opening during closure (2-C1), if the photocells identify an
obstacle while the gate is closing, they will reverse the direction of movement
until the gate is completely open;
Total stop (1-2), shutdown of gate movement without automatic closing; a
pushbutton or radio remote control must be actuated to resume movement.
Accessories whichcan be Connected to this Unit:
Flashing signal light when gate is in motion 25W max. (E1-W)
Electric lock (11-ES)
Radiofrequency "AF" board
Other functions available
Automatic closing The automatic closing timer is automatically activated at the
end of the opening cycle. The preset, adjustable automatic closing time is
automatically interrupted by the activation of any safety system, and is
deactivated after a STOP command of in case of power failure.
"Operator present" function Gate operators only when the pushbutton is held
down (the radio remote control system is deacticvated);
Adjustments
Trimmer TL Adjustment of operating time;
Trimmer TCA Adjustment of automatic closing
Caution! Disconnect the unit from the main power lines before carrying out any
operation inside the unit.
