Wiring In The Safety Photocells; Inserting The Radio Frequency Card - CAME FROG series Installation Instructions Manual

2.3 - Wiring in the Safety Photocells

SAFETY BEAMS SHOULD BE FITTED APPROXIMATELY
IF FITTING A SECOND ARC LINE OF SAFETY BEAMS THEN C & NC MUST BE WIRED IN "SERIES"

2.4 - Inserting the Radio Frequency Card

ZA4
15 INCHES FROM GROUND LEVEL
CONTROL PANEL
10 11
TX
10
11
SAFETY
BEAM
TRANSMITTER
Fig 9
2 C1
RX
SAFETY
BEAM
RECEIVER
INSERT THE RADIO FREQUENCY
CARD INTO THE SMALL SOCKET
ON THE CONTROL PANEL
(ENSURE THAT THE POWER IS
TURNED OFF TO THE CONTROL
PANEL BEFORE INSERTING THE
FREQUENCY CARD)
ANTENNA
WIRING
POINT
10
Fig 8
NC
C
C
NC
10
11
