5. TECHNICAL INFORMATION

GEARMOTOR WEIGHT
FROG A
11 Kg
FROG AV
11 Kg
* Can be adjusted using CAME control panels
BOLT FOR REMOVAL
& INSERTION OF M6
GREASE NIPPLE
(NOT SUPPLIED)
405mm
WIDTH OF GATE
* AN ELECTRIC LOCK IS SUGGESTED WHEN THE GATE WING IS WIDER
5.1 - Technical Specification
POWER CURRENT
SUPPLY
230V a.c 1,9 A
230V a.c 2,5 A

5.2 - Casing Dimensions

5.3 - Operating Limits

2.00 MTS
2.50 MTS
*3.50 MTS
POWER DUTY MAX.
CICLE TORQUE
200 W 30% * 320 Nm
300 W 30% * 240 Nm
60mm 60mm
160mm
WEIGHT OF GATE
THAN 3.5M
21
REDUCTION TRAVEL
RATIO TIME
1/1152 18 sec.
1/1152 9 sec.
Fig 24
330mm
800 Kg
600 Kg
400 Kg
CAPACITOR
16 uF
20 uF
