CLI – This example shows the switch configured with primary VLAN 5 and
secondary VLAN 6. Port 3 has been configured as a promiscuous port and mapped
to VLAN 5, while ports 4 and 5 have been configured as a host ports and are
associated with VLAN 6. This means that traffic for port 4 and 5 can only pass
through port 3.
Console#show vlan private-vlan
Primary Secondary
-------- -----------
5
5 6
Console#

Configuring Private VLANs

The Private VLAN Configuration page is used to create/remove primary or
community VLANs.
Command Attributes
• VLAN ID – ID of configured VLAN (1-4094, no leading zeroes).
• Type – There are three types of VLANs within a private VLAN:
- Primary VLANs – Conveys traffic between promiscuous ports, and to
community ports within secondary VLANs.
- Community VLANs - Conveys traffic between community ports, and to their
associated promiscuous ports.
- Isolated VLANs – Conveys traffic only between the VLAN's isolated ports and
promiscuous ports. Traffic between isolated ports within the VLAN is blocked.
• Current – Displays a list of the currently configured VLANs.
Type Interfaces
---------- --------------------------------------
primary Eth1/ 3
community Eth1/ 4 Eth1/ 5
VLAN Configuration
4-153
3-115
3
