Daikin FTE09MV2S Service Manual page 22

Removal of Drain Pan Unit / Swing Motor
Step
Remove the drain pan
4
unit from the indoor
unit.
2. Remove the swing motor.
Remove the screw of
1
the swing motor.
2 Pull out the swing
motor.
20
Procedure
Hook
(R4378)
When reassembling, make
sure that the hook at the left
side is fitted in the groove.
(R4379)
Swing motor
(R4380)
(R4381)
Si041138
Points
Removal Procedure
