Removal of Electrical Box
Step
Disconnect the
5
connector for the fan
motor [S7].
Remove the screw and
6
remove the drip proof
plate.
Pull out the indoor heat
7
exchanger thermistor.
Remove the screw and
8
detach the earth wire.
12
Procedure
Indoor heat
exchanger
thermistor
[S7]
(R11470)
Drip proof plate
(R12721)
Be careful not to lose the clip
for the thermistor.
Clip
(R12722)
Earth wire
(R4345)
Si041138
Points
(R11234)
Removal Procedure
