Hardware Installation Manual
AudioCodes Mediant™ Family of Session Border Controllers (SBC)
Mediant 9000 SBC Series
Mediant 9000 Rev. B
Mediant 9030
Mediant 9080
Version 7.2

Advertisement

Table of Contents
loading

Related Manuals for AudioCodes Mediant 9000 SBC Series

Summary of Contents for AudioCodes Mediant 9000 SBC Series

  • Page 1 Hardware Installation Manual AudioCodes Mediant™ Family of Session Border Controllers (SBC) Mediant 9000 SBC Series Mediant 9000 Rev. B Mediant 9030 Mediant 9080 Version 7.2...

  • Page 3: Table Of Contents

    Hardware Installation Manual Contents Table of Contents Introduction ....................... 11 Specifications ....................13 Physical Description ..................15 Physical Dimensions ....................15 Front Panel ......................15 3.2.1 Front Panel LEDs ....................16 Rear Panel ......................17 3.3.1 Rear Panel LEDs ....................19 Deploying the Device ..................
  • Page 4 Mediant 9000 Series SBC List of Figures Figure 3-1: Front Panel .......................... 15 Figure 3-2: Front Panel LEDs ........................ 16 Figure 3-3: Rear Panel - – Mediant 9080 / Mediant 9000 Rev. B ............17 Figure 3-4: Rear Panel – Mediant 9030 ....................17 Figure 3-5: Rear Panel LEDs –...
  • Page 5 Hardware Installation Manual Contents List of Tables Table 2-1: Specifications ........................13 Table 3-1: Physical Dimensions ......................15 Table 3-2: Front Panel ........................... 15 Table 3-3: Front-Panel LEDs ......................... 16 Table 3-4: Rear Panel ..........................17 Table 3-5: Rear Panel LEDs ........................19 Table 5-1: Supported Configurations with SFP Network Cards ............

  • Page 6: Document #: Ltrt

    Mediant 9000 Series SBC This page is intentionally left blank. Hardware Installation Manual Document #: LTRT-41667...
  • Page 7 Please contact your local recycling authority for disposal of this product. Customer Support Customer technical support and services are provided by AudioCodes or by an authorized AudioCodes Service Partner. For more information on how to buy technical support for AudioCodes products and for contact information, please visit our website at https://www.audiocodes.com/services-support/maintenance-and-support.
  • Page 8 Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g., use of power strips.) Warning: For all service and maintenance issues, contact AudioCodes technical support (see “Customer Support” above). Hardware Installation Manual...
  • Page 9 41667 Mediant 9030 (and Mediant 9080) added Documentation Feedback AudioCodes continually strives to produce high quality documentation. If you have any comments (suggestions or errors) regarding this document, please fill out the Documentation Feedback form on our website at https://online.audiocodes.com/documentation-feedback.
  • Page 10 Mediant 9000 Series SBC This page is intentionally left blank. Hardware Installation Manual Document #: LTRT-41667...

  • Page 11: Introduction

    Hardware Installation Manual 1. Introduction Introduction This document describes the hardware of AudioCodes' carrier-grade Mediant 9000 SBC Series and its basic deployment. Note: This document describes the Mediant 9000 series that is based on HPE ProLiant DL360 Gen10. To identify the type of Mediant 9000 product, run the show system hardware command, as shown in the examples below.
  • Page 12 Mediant 9000 Series SBC This page is intentionally left blank. Hardware Installation Manual Document #: LTRT-41667...

  • Page 13: Specifications

    Hardware Installation Manual 2. Specifications Specifications The table below lists the device's specifications. Table 2-1: Specifications Resource Mediant 9080 / Mediant 9000 Rev. B Mediant 9030 Chassis Type 1RU System 2 x 12 Cores, 2.6 GHz, 19.25MB Cache 2 x 8 Cores, 2.1 GHz, 11MB Cache Memory 96 GB, DDR4-2666/PC4-21300 32 GB, DDR4-2666/PC4-21300...
  • Page 14 Mediant 9000 Series SBC This page is intentionally left blank. Hardware Installation Manual Document #: LTRT-41667...

  • Page 15: Physical Description

    Hardware Installation Manual 3. Physical Description Physical Description This section provides a physical description of the device. Physical Dimensions The device's physical dimensions are listed in the table below. Table 3-1: Physical Dimensions Item Description Physical Dimensions 4.29 x 43.46 x 70.7 cm (1.69 x 17.11 x 27.83 in) Weight (approximate) Between 13.04 (28.74 lb) kg and 16.27 kg (35.86 lb) Environmental...

  • Page 16: Front Panel Leds

    Mediant 9000 Series SBC 3.2.1 Front Panel LEDs The front panel LEDs are shown in the figure below and described in the subsequent table. Figure 3-2: Front Panel LEDs Table 3-3: Front-Panel LEDs Item # Description Status Solid blue = activated. UID LED/button* •...

  • Page 17: Rear Panel

    Hardware Installation Manual 3. Physical Description Rear Panel The rear panel is displayed in the figure below and described in the subsequent table. Figure 3-3: Rear Panel - – Mediant 9080 / Mediant 9000 Rev. B Figure 3-4: Rear Panel – Mediant 9030 Table 3-4: Rear Panel Description Item #...
  • Page 18 Mediant 9000 Series SBC Description Item # Mediant 9080 / Mediant 9000 Rev. B Mediant 9030 Unsupported NIC ports (dust Quad 1-GbE copper ports covered) Note: These ports can be used only for signaling (SIP), OAMP, and HA Maintenance. iLO Management Port Serial port USB 3.0 ports Quad 1-GbE copper ports...

  • Page 19: Rear Panel Leds

    Hardware Installation Manual 3. Physical Description 3.3.1 Rear Panel LEDs The rear panel LEDs are shown in the figure below and described in the subsequent table. Figure 3-5: Rear Panel LEDs – Mediant 9080 / Mediant 9000 Rev. B Figure 3-6: Rear Panel LEDs – Mediant 9030 Table 3-5: Rear Panel LEDs Item # Description...
  • Page 20 Mediant 9000 Series SBC Item # Description Status (Right LED) NIC activity status: Quad 1-GbE  copper ports Solid green = Activity exists.  Flashing green = Activity exists.  Off = No activity exists  (Left LED) NIC link status: ...

  • Page 21: Deploying The Device

    Hardware Installation Manual 4. Deploying the Device Deploying the Device This chapter describes how to deploy the device. The following sections are described: Deploying the Rail Kit  Connecting to Power and Replacing Power Supply  Connecting Display and Keyboard ...

  • Page 22: Connecting To Power And Replacing Power Supply

    Mediant 9000 Series SBC Connecting to Power and Replacing Power Supply This section lists the various warnings, cautions and notes regarding connecting to the power supply and replacing power supply units. Warning: To reduce the risk of electric shock or energy hazards: •...
  • Page 23 Hardware Installation Manual 4. Deploying the Device Warning: To reduce the risk of personal injury from hot surfaces, allow the power supply or power supply blank to cool before touching it. Caution: For DC power supply, use only the ring terminals provided with the power supply for customer-built power connections.

  • Page 24: Connecting Display And Keyboard

    Mediant 9000 Series SBC Connecting Display and Keyboard To perform initial configuration, display and keyboard are required. Connect the display to the 15-pin HD D-Sub (HD-15) VGA port.  Connect the keyboard to the USB port.  Connecting Device to IP Network for 1-GbE Copper This section shows how to connect the device to the IP network using the copper 1-GbE ports.

  • Page 25: Figure 4-3: Connecting The Device To The Ip Network - Mediant 9080 / Mediant 9000 Rev. B

    Hardware Installation Manual 4. Deploying the Device Note: Mediant 9080 / Mediant 9000 Rev. B: The figure represents a configuration with • 12x1GbE ports. If the device is configured with 10GbE ports (GE_9 until GE_12), then the correct port order is as follows: GE_12 | GE_11 | GE_10 | GE_9. Mediant 9030: GE_1, GE_2, GE_3, and GE_4 ports can be used only for signaling •...

  • Page 26: Connecting Device To Ip Network With Sfp

    Mediant 9000 Series SBC Connecting Device to IP Network with SFP The following procedure describes how to cable the device to the network, using the 1.25 Gbps optical Small Form-Factor Pluggable (SFP) transceiver modules. Caution Laser This device contains a Class 1 LED/Laser emitting device, as defined by 21CFR 1040 and IEC825.

  • Page 27: Viewing Network Port Status

    Hardware Installation Manual 4. Deploying the Device Viewing Network Port Status Use the show network physical-port CLI command to view network port status (up/down) and MAC address: Figure 4-6: Viewing Network Port Status # show network physical-port Port Num Port Name MAC Address Speed Duplexity Link Status...
  • Page 28 Mediant 9000 Series SBC This page is intentionally left blank. Hardware Installation Manual Document #: LTRT-41667...

  • Page 29: Fiber Network Card Support

    Note: The Network cards “Quad SFP+ 10G with LX transceivers” and “Quad SFP+ 10G with SX transceivers” must be ordered from AudioCodes. Replacing Copper NIC with Fiber Network Card If you want to replace the copper NIC with the Fiber Network Card, follow the below procedure.
  • Page 30 Mediant 9000 Series SBC This page is intentionally left blank. Hardware Installation Manual Document #: LTRT-41667...

  • Page 31: Initial Configuration

    Hardware Installation Manual 6. Initial Configuration Initial Configuration This chapter describes the procedures for the initial configuration of the device. Reconfiguring Default IP Address to Match Customer Network Settings The device is supplied with software preinstalled. By default, the device is assigned with a default IP address that will most likely be inaccessible from the customer's network.
  • Page 32 Mediant 9000 Series SBC If the device is connected to the IP network that uses VLAN ID (for example, VLAN ID 10), type the following commands to configure it in the Ethernet Device table (otherwise skip to step 10): (config-network)# interface network-dev 0 (network-dev-0)# vlan-id 10 (network-dev-0)# tagging tagged (network-dev-0)# exit...

  • Page 33: Licensing The Device

    Hardware Installation Manual 6. Initial Configuration Licensing the Device The device is supplied with a pre-installed software and License Key. Use the pre-installed License Key to enable the call capacity and features that you ordered. To upgrade your License Key, refer to the device's User's Manual. Version 7.2 Mediant 9000 Series SBC...
  • Page 34 Mediant 9000 Series SBC This page is intentionally left blank. Hardware Installation Manual Document #: LTRT-41667...

  • Page 35: A Installation And Upgrade Issues

    Reinstalling Software SBC from ISO Image The device is pre-installed on the device’s server. In case a clean installation of the device’s software is required, you should download the latest installation image from the AudioCodes Website and install the software from the ILO virtual drive.

  • Page 36: Figure A-1: Mounting Iso Image From Remote Console

    Mediant 9000 Series SBC Figure A-1: Mounting ISO Image from Remote Console Reset the server from the Remote Console by using (for example) the 'Power Switch' button. The server boots from the Remote Console (see Figure A-2) and the Mediant SE SBC Installation Menu is displayed (see Figure A-3).

  • Page 37: Figure A-3: Installation Start Prompt

    Hardware Installation Manual A. Installation and Upgrade Issues Figure A-3: Installation Start Prompt Press the ENTER key; installation commences from the ILO virtual drive; a bar shows installation progress. Figure A-4: Installation in Progress Wait for the 'Complete' prompt, notifying you when installation is complete, to be displayed.
  • Page 38 Mediant 9000 Series SBC This page is intentionally left blank. Hardware Installation Manual Document #: LTRT-41667...

  • Page 39: B Rescue Options

    Hardware Installation Manual B. Rescue Options Rescue Options The device features a System Snapshots mechanism that provides the capability of returning the system to a previous state. The mechanism may be used as a rescue option if a system malfunction occurs. For more information, refer to the device's User's Manual. Version 7.2 Mediant 9000 Series SBC...
  • Page 40 Website: https://www.audiocodes.com/ ©2018 AudioCodes Ltd. All rights reserved. AudioCodes, AC, HD VoIP, HD VoIP Sounds Better, IPmedia, Mediant, MediaPack, What’s Inside Matters, OSN, SmartTAP, User Management Pack, VMAS, VoIPerfect, VoIPerfectHD, Your Gateway To VoIP, 3GX, VocaNom, AudioCodes One Voice and CloudBond are trademarks or registered trademarks of AudioCodes Limited.
