- Page 1 Hardware Installation Manual AudioCodes Session Border Controller Series Mediant 9000 SBC Mediant 9080 / 9030 / 9000 Rev. B Version 7.2 and later...
- Page 2 Please contact your local recycling authority for disposal of this product. Customer Support Customer technical support and services are provided by AudioCodes or by an authorized AudioCodes Service Partner. For more information on how to buy technical support for AudioCodes products and for contact information, please visit our website at https://www.audiocodes.com/services-support/maintenance-and-support.
- Page 3 Caution Electrical Shock: Do not attempt to open or disassemble this device. The device carries high voltage. Contact with internal components may cause electrical shock and bodily harm. For all service and maintenance issues, contact AudioCodes technical support (see Customer Support above). Reliable Earthing: Reliable earthing of rack- mounted equipment should be maintained.
- Page 4 Notice Mediant 9000 SBC | Hardware Installation Manual Document Name SBC-Gateway Release Notes for Long Term Support (LTS) Versions 7.4 Mediant 9000 Series SBC User's Manual Document Revision Record LTRT Description 41655 Initial document release for Version 7.2. 41557 Management names of Ethernet ports added.
-
Page 5: Table Of Contents
Content Mediant 9000 SBC | Hardware Installation Manual Table of Contents Introduction Product Configurations Specifications Physical Description Physical Dimensions Front Panel Front Panel LEDs Rear Panel Rear Panel LEDs Deploying the Device Deploying the Rail Kit Connecting to Power and Replacing Power Supply... -
Page 6: Introduction
CHAPTER 1 Introduction Mediant 9000 SBC | Hardware Installation Manual Introduction This document describes the hardware of AudioCodes' carrier-grade Mediant 9000 SBC series and basic deployment. This document describes the Mediant 9000 series that is based on HPE ProLiant DL360 Gen10. -
Page 7: Product Configurations
Mediant 9000 SBC | Hardware Installation Manual Product Configurations The following configurations are available for the Mediant 9080 / 9030 Session Border Controller product. Table 2-1: AudioCodes Mediant 9080 / 9030 Session Border Controller Product Configurations Product Configuration Description Mediant 9030... - Page 8 CHAPTER 2 Product Configurations Mediant 9000 SBC | Hardware Installation Manual Product Configuration Description M9K80/AC/R HA-pair of Mediant 9080 Session Border Controllers (SBC) M9K80/DC Mediant 9080 Session Border Controller (SBC), DC power M9K80/DC/R HA-pair of Mediant 9080 Session Border Controllers (SBC), DC...
-
Page 9: Specifications
2.9 GHz 2933/PC4- 600-GB SAS access 23400 22-MB or 1-TB through iLO Cache SATA For installation instructions of the Mediant 9000 (Gen 8) model, refer to LTRT-41674 Mediant 9000 SBC Hardware Installation Manual Ver. 7.2 and later. - 4 -... -
Page 10: Physical Description
CHAPTER 4 Physical Description Mediant 9000 SBC | Hardware Installation Manual Physical Description This section provides a physical description of the device. Physical Dimensions The device's physical dimensions are listed in the following table. Table 4-1: Physical Dimensions Item Description Physical Dimension 4.29 x 43.46 x 70.7 cm (1.69 x 17.11 x 27.83 in) -
Page 11: Front Panel Leds
CHAPTER 4 Physical Description Mediant 9000 SBC | Hardware Installation Manual Item # Description USB 2.0 port USB 3.0 port iLO Service port Front Panel LEDs The front panel LEDs are shown in the following figure and described in the subsequent table. -
Page 12: Rear Panel
CHAPTER 4 Physical Description Mediant 9000 SBC | Hardware Installation Manual Item # Description Status sequence Solid amber = System in standby ■ ■ Off = No power present** Health LED* ■ Solid green = Normal Flashing green = iLO is rebooting ■... -
Page 13: Rear Panel Leds
CHAPTER 4 Physical Description Mediant 9000 SBC | Hardware Installation Manual Figure 4-4: Rear Panel – Mediant 9030 Table 4-4: Rear Panel Description Item # Mediant 9080 / Mediant 9000 Mediant 9030 Rev. B Slot 1: Quad 1-GbE copper Slot 1: Quad 1-GbE copper ports or Quad 10-... - Page 14 CHAPTER 4 Physical Description Mediant 9000 SBC | Hardware Installation Manual Figure 4-5: Rear Panel LEDs Table 4-5: Rear Panel LEDs Item # Description Status UID LED ■ Solid blue = Identification is activated Flashing blue = System is being managed remotely ■...
- Page 15 CHAPTER 4 Physical Description Mediant 9000 SBC | Hardware Installation Manual Item # Description Status Quad 1-GbE ■ (Right LED) NIC activity status: copper ports Solid green = Activity exists. ✔ ✔ Flashing green = Activity exists. Off = No activity exists ✔...
- Page 16 CHAPTER 4 Physical Description Mediant 9000 SBC | Hardware Installation Manual Item # Description Status ■ LED 2 - link: Off = No link (adapter not receiving power or the ✔ cable connection is faulty) or link established at 10 Mb/s ✔...
-
Page 17: Deploying The Device
CHAPTER 5 Deploying the Device Mediant 9000 SBC | Hardware Installation Manual Deploying the Device This chapter describes how to deploy the device. The following sections are described: ■ Deploying the Rail Kit Connecting to Power and Replacing Power Supply ■... - Page 18 CHAPTER 5 Deploying the Device Mediant 9000 SBC | Hardware Installation Manual ● This equipment must be installed by trained service personnel, as defined by the NEC and IEC 60950-1, Second Edition, the standard for Safety of Information Technology Equipment. ●...
-
Page 19: Connecting Display And Keyboard
CHAPTER 5 Deploying the Device Mediant 9000 SBC | Hardware Installation Manual polarity: ● Black Wire (1): negative (-) polarity ● Red Wire (2): positive (+) polarity The device must be connected (by service personnel) to a socket- outlet with a protective earthing connection ●... - Page 20 CHAPTER 5 Deploying the Device Mediant 9000 SBC | Hardware Installation Manual The intra-building ports of the equipment are suitable for connection to intra-building or unexposed wiring or cabling only. The intra-building ports of the equipment must not be metallically connected to interfaces that connect to the Outside Plant (OSP) or its wiring.
-
Page 21: Connecting Device To Ip Network With Sfp
CHAPTER 5 Deploying the Device Mediant 9000 SBC | Hardware Installation Manual Figure 5-3: Connecting the Device to the IP Network - Mediant 9080 / Mediant 9000 Rev. B Figure 5-4: Connecting the Device to the IP Network - Mediant 9030 ●... -
Page 22: Viewing Network Port Status
CHAPTER 5 Deploying the Device Mediant 9000 SBC | Hardware Installation Manual Incoming optic cabling from the network infrastructure can originate from the top of the rack or from another shelf within the rack. Preserve the minimum-bending ratio indicated by the cable manufacturer. - Page 23 CHAPTER 5 Deploying the Device Mediant 9000 SBC | Hardware Installation Manual 11 GE_11 f4:ce:46:a5:a4:42 DOWN 1 igb rx-zc 12 GE_12 f4:ce:46:a5:a4:43 DOWN 1 igb rx-zc ● For 10G ports, the 'Driver Info' column displays "ixgbe" instead of "igb", but the port name remains the same (i.e., "GE_n"). ● Mediant 9030: The driver info for GE_1 to GE_4 displays "tg3" (instead of "igb").
-
Page 24: Fiber Network Card Support
CHAPTER 6 Fiber Network Card Support Mediant 9000 SBC | Hardware Installation Manual Fiber Network Card Support This section describes the device's fiber network card support. Supported Configurations The network cards located in PCIe slots 1 and 2 (as shown in Rear Panel ), can be replaced with... - Page 25 CHAPTER 6 Fiber Network Card Support Mediant 9000 SBC | Hardware Installation Manual Power on the server. When the device finishes loading, the new SFPs are labeled "GE_9" through to "GE_12" if a single card was replaced, or "GE_5" through to "GE_12" if both cards were replaced.
-
Page 26: Initial Configuration
CHAPTER 7 Initial Configuration Mediant 9000 SBC | Hardware Installation Manual Initial Configuration This chapter describes the procedures for the initial configuration of the device. Reconfiguring Default IP Address to Match Customer Network Settings The device is supplied with software preinstalled. By default, the device is assigned with a default IP address that will most likely be inaccessible from the customer's network. - Page 27 CHAPTER 7 Initial Configuration Mediant 9000 SBC | Hardware Installation Manual # configure network (config-network)# interface network-if 0 Use the Tab key to auto-complete partially entered commands. At the prompt, type the following commands to configure the IP address, prefix length and default gateway: (network-if-0)# ip-address 10.4.212.155...
-
Page 28: Licensing The Device
CHAPTER 7 Initial Configuration Mediant 9000 SBC | Hardware Installation Manual Licensing the Device The device is supplied with a pre-installed software and License Key. Use the pre-installed License Key to enable the call capacity and features that you ordered. To upgrade your License Key, refer to the device's User's Manual. -
Page 29: Installation And Upgrade Issues
Reinstalling Software SBC from ISO Image The device is pre-installed on the device’s server. In case a clean installation of the device’s software is required, you should download the latest installation image from the AudioCodes website and install the software from the ILO virtual drive. - Page 30 CHAPTER 8 Installation and Upgrade Issues Mediant 9000 SBC | Hardware Installation Manual Figure 8-1: Mounting ISO Image from Remote Console Reset the server from the Remote Console by using (for example) the 'Power Switch' button. The server boots from the Remote Console (see following figure) and the Mediant SE SBC Installation Menu is displayed (see figure below 'Installation Start Prompt').
- Page 31 CHAPTER 8 Installation and Upgrade Issues Mediant 9000 SBC | Hardware Installation Manual Figure 8-3: Installation Start Prompt Press the ENTER key; installation commences from the ILO virtual drive; a bar shows installation progress. Figure 8-4: Installation in Progress Wait for the 'Complete' prompt, notifying you when installation is complete, to be displayed.
- Page 32 CHAPTER 8 Installation and Upgrade Issues Mediant 9000 SBC | Hardware Installation Manual Figure 8-5: Installation Complete Disable the Virtual Drive that was selected before for ISO installation. Press ENTER to reboot the server; after rebooting, the server boots from the local disk to the newly installed device software.
-
Page 33: Rescue Options
CHAPTER 9 Rescue Options Mediant 9000 SBC | Hardware Installation Manual Rescue Options The device features a System Snapshots mechanism that provides the capability of returning the system to a previous state. The mechanism may be used as a rescue option if a system malfunction occurs. - Page 34 CHAPTER 9 Rescue Options Mediant 9000 SBC | Hardware Installation Manual This page is intentionally left blank. - 29 -...
