Creating and Building a CCSv4 Project for DSP/BIOS Applications

2.1 Creating and Building a CCSv4 Project for DSP/BIOS Applications

2-2
To create a new CCSv4 project that uses DSP/BIOS, follow these steps. You
can also watch these steps being performed by going to the Code Composer
Studio Mediawiki at http://tiexpressdsp.com/wiki/index.php?title=CCSv4,
following the link in the contents to DSP/BIOS, and then following the link to
the Hello World 5.40 demo.
1) Create a CCS project as follows:
a) Open CCSv4 and choose File > New > CCS Project from the menu
bar.
b) In the New CCS Project dialog, type a Project Name. For example,
to begin creating a project using the "hello world" example code
provided with DSP/BIOS, you can type "hellobios5". The default
project location automatically reflects the project name. Then, click
Next.
c) Select your platform type in the Project Type field. For example, you
might select "C6000". Then, click Next.
d) Click Next in the "Additional Project Settings" page.
e) In the "CCS Project Settings" page, select the Device Variant for
your desired platform. For example, you might select "Generic C64x+
Device". Depending on your device, you might also need to adjust
the Device Endianness and Runtime Support Library settings.
f) In the Target content area, select the Use DSP/BIOS v5.xx option.
The version of DSP/BIOS installed with CCSv4 should already be
selected. Then, click Finish. This adds your project to the C/C++
Projects list in CCS.
2) Create a DSP/BIOS Configuration for your project as follows:
a) Choose File > New > DSP/BIOS v5.xx Configuration.
b) Change the Filename to match your project name (if it doesn't
already match). For example, if your project name is "hellobios5",
change the configuration filename to hellobios5.tcf. Then, click Next.
c) Select a platform for the configuration to use from the list of platforms.
These platforms are provided by XDCtools. Then, click Next.
