3. Physical installation
3.8

Connecting a UPS to the projector electronics

W
ARNING
requirements" for more information about the requirements of the UPS.
How to connect the UPS
1. Install the UPS according to the instructions of the manufacturer and the local regulations.
2. Connect the power output cord from the UPS unit to the UPS inlet socket of the projector (right socket).
Connect directly (A) or drag the cable behind the front cover so that the front cover can be removed without removing the UPS
INLET cable (B).
A
2
Image 3-17
UPS connection
3. Secure the UPS inlet socket with a fixation spring. Handle as follow:
- Squeeze the fixation spring together.
- Slide the fixation spring on the fixation pins while squeezing together and push it against the power plug.
- Release the fixation spring.
4. Install on the power outlet the second fixation spring to prevent losing it (2).
C
AUTION
AC power supply cord (minimum 0,75 mm² or 18 AWG and minimum 300V)
C
AUTION
36
:
Only use UPS units which are suitable for the Prometheus. See chapter "General", "Installation
1
:
The electrical connection with the UPS INLET socket of the projector must be done with a certified
:
Do not use the power OUTLET socket of the projector to provide power to other equipment!
B
