12. Convergence

12.1 Open the sealed compartment

This procedure assumes that the side cover of the projector is already removed.
C
AUTION
Necessary tools
3 mm Allen wrench
How to open the sealed compartment
1. Remove both hexagon head cap screws (1).
Image 12-1
Sealed cover fixation
2. Lift up the cover plate slightly using both lower lips (2) and then remove the cover by taking it away from the projector.
158
:
This procedure may only be done by a qualified and trained service technician.
1
R5905963 PROMETHEUS SERIES 09/03/2015
