DPxK-19B/23B/P
Installation manual
For DP2K-19B, DP2K-23B, DP2K-P, DP4K-19B, DP4K-23B and
DP4K-P
R5905067/07
17/09/2012

Advertisement

Table of Contents
loading

Related Manuals for Barco DP2K-19B

Summary of Contents for Barco DP2K-19B

  • Page 1 DPxK-19B/23B/P Installation manual For DP2K-19B, DP2K-23B, DP2K-P, DP4K-19B, DP4K-23B and DP4K-P R5905067/07 17/09/2012...
  • Page 2 Barco Inc. Media and Entertainment Division 11101 Trade Center Drive, Rancho Cordova, California 95670, USA Phone: +1 916 859-2500 Fax: +1 916 859-2515 Support: www.Barco.com/esupport Visit us at the web: www.barco.com Barco nv Entertainment Division Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.36.883.86...
  • Page 3 Changes Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war- ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.
  • Page 4 GNU-GPL code If you would like a copy of the GPL source code contained in this product shipped to you on CD, please contact Barco. The cost of preparing and mailing a CD will be charged. Guarantee and Compensation Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. On receipt, the purchaser must immediately inspect all delivered goods for damage incurred during transport, as well as for material and manufacturing faults Barco must be informed immediately in writing of any complaints.
  • Page 5 Projector Part name Toxic or hazardous substances and elements Cr6+ PBDE Connectors and cables Fans Heat radiation module (metal parts) Card reader Speaker (exclude PCB) Remote control (exclude PCB) O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit requirement in SJ/T11363-2006.

  • Page 7: Table Of Contents

    Table of contents TABLE OF CONTENTS 1. Safety ....................... .. 3 General considerations.
  • Page 8 Specifications of the DP2K-19B........

  • Page 9: Safety

    • Before operating this equipment please read this manual thoroughly and retain it for future reference. • Installation and preliminary adjustments should be performed by qualified Barco personnel or by authorized Barco service deal- ers. • All warnings on the projector and in the documentation manuals should be adhered to.

  • Page 10: Important Safety Instructions

    1. Safety Important safety instructions To prevent the risk of electrical shock • This projector should be operated from an AC power source. Ensure that the mains voltage and capacity matches the projector electrical ratings. If you are unable to install the AC requirements, contact your electrician. Do not defeat the purpose of the grounding.
  • Page 11 fire extinguishers. Never use water on an electrical fire. Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector.
  • Page 12 If the product exhibits a distinct change in performance, indicating a need for service. • Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitu- tions may result in degraded performance and reliability, fire, electric shock or other hazards.
  • Page 13 1. Safety AUTION Xenon compact arc lamps are highly pressurized. When ignited, the normal operating temperature of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accordance to the manufacturer’s instructions. The bulb is stable at room temperature, but may still explode if dropped or otherwise mishandled.
  • Page 14 1. Safety R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 15: General

    • DP4K-23B Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guar- antee. Observing the specification mentioned in this chapter is critical for projector performance. Neglecting this can result in loss of warranty.
  • Page 16 five (5) times the complete load of the system. Barco offers a pedestal for the B-series projector. This universal pedestal allows a solid and easy setup of the projector.

  • Page 17: Unpacking The Projector

    2. General Unpacking the projector What has to be done ? Upon delivery, the projector is packed in a carton box upon a wooden pallet and secured with banding and fastening clips. Fur- thermore, to provide protection during transportation, the projector is surrounded with foam. Once the projector has arrived at the installation site, it needs to be removed from the carton box and wooden pallet in a safe manner without damaging the projector.
  • Page 18 2. General Image 2-2 Remove outer carton 3. Remove the inner carton box. Image 2-3 Remove inner carton 4. Loosen the banding by pulling the free end of the banding loop in the clip. Take off the upper carton plate (1) Remove from the wooden pallet (2) R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 19: Initial Inspection

    Save all packing material until the inspection is completed. If damage is found, file claim with carrier immediately. The Barco Sales and Service office should be notified as soon as possible.

  • Page 20: Installation Process Overview

    This check should confirm that there are no broken knobs or connectors, that the cabinet and panel surfaces are free of dents and scratches, and that the operating panel is not scratched or cracked. The Barco Sales and Service office should be notified as soon as possible if this is not the case.
  • Page 21 2. General 12.Registration of the projector. The B-series projector is DCI compliant and should be registered by Barco. Therefore, the digital certificate inside the projector will be used to secure encryption key communication between the projector and the rest of the theatre system (server and theatre management system).
  • Page 22 2. General R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 23: Physical Installation

    Positioning at port window Barco offers a pedestal for the B-series projector. This universal pedestal allows a solid and easy setup of the projector. The universal pedestal has a separate compartment to install the UPS unit (if available) for the B-series projector.
  • Page 24 3. Physical installation 2. If a film projector is already present (projector will be off-center), try to optimize aim (see ref B image 3-2). Note: Unlike film projectors, it is best to keep the projector lens surface as parallel to the screen as possible, even if it is significantly above the screen center.

  • Page 25: Installation Of The Exhaust System

    90° Inclined screen Image 3-4 Projector tilting Barco offers a pedestal for the B-series projector. This universal pedestal allows you to easily tilt the projector forward up to 6°. Installation of the exhaust system ARNING THE USE OF AN EXHAUST SYSTEM IS MANDATORY ! ARNING Never look into the exhaust output.
  • Page 26 3. Physical installation Image 3-5 Exhaust system Ensure good condition of the lamp house blower. Keep the blower inlet clean for unrestricted air flow. To ensure maximum lamp life, operate the lamp house blower and the exhaust system for at least ten minutes after extinguishing the lamp.

  • Page 27: Access To The Power Connection

    3. Physical installation Image 3-6 Fan power connection Access to the power connection Necessary tools Flat screw driver 6 mm How to access 1. Remove the back cover. 2. Loosen both captive screws (1). Image 3-7 Power connection cover, captive screws Image 3-8 Power connection cover, captive screws 3.

  • Page 28: Connecting The Dpxk-19B/23B/P With The Power Net

    3. Physical installation Image 3-9 Terminal strip accessible The terminal strip and connection plate is accessible. Connecting the DPxK-19B/23B/P with the power net ARNING The total electrical installation should be protected by an appropriate rated and readily accessi- ble disconnect switch, circuit breakers and ground fault current interrupters. The installation shall be done according to the local electrical installation codes.

  • Page 29: Power Loop Through To The Projector Electronics

    Short power link cable with plug type C13/C14 How to loop through the power 1. Plug in the short power cable (1) which was delivered with the projector. Warning: Always use the Barco short power cable which is delivered with the projector. R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 30: Connecting A Ups To The Projector Electronics

    3. Physical installation Image 3-11 Power loop through connection 2. Secure both plugs of the short cable with a fixation spring (2). Handle as follow: Squeeze the fixation spring together. Slide the fixation spring on the fixation pins (3) while squeezing together and push it against the power plug. Release the fixation spring.
  • Page 31 3. Physical installation Image 3-12 UPS connection 3. Secure the UPS inlet socket with a fixation spring. Handle as follow: Squeeze the fixation spring together. Slide the fixation spring on the fixation pins while squeezing together and push it against the power plug. Release the fixation spring.
  • Page 32 3. Physical installation R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 33: Lamp & Lamp House

    4. Lamp & Lamp House 4. LAMP & LAMP HOUSE ARNING DO NOT PERMIT UNAUTHORIZED PERSONNEL TO PERFORM OR ATTEMPT ANY PHASE OF XENON LAMP HANDLING OR SERVICE. ONLY TRAINED AND QUALIFIED TECHNICAL SERVICE PERSONNEL ARE ALLOWED TO HANDLE THE XENON LAMP. AUTION Xenon compact arc lamps are highly pressurized.
  • Page 34 4. Lamp & Lamp House AUTION Xenon compact arc lamps are highly pressurized. When ignited, the normal operating temperature of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accordance to the manufacturer’s instructions.

  • Page 35: Supported Xenon Lamps For The S/M Lamp House

    Prior to install the lamp it’s important to check with the Communicator software if the lamp is listed in the list of supported lamps for this projector. Supported lamp types and their respective anode/cathode adapters for the S/M Lamp House: Lamp type Cathode adapter S/M Lamp House Barco Order No. Supplier 4kW DHP OSRAM XBO R865555K R9855937...

  • Page 36: Removal Of The Xenon Lamp From Manual S/M Lamp House

    4. Lamp & Lamp House AUTION Due to its high internal pressure, the lamp may explode in either hot or cold states if improperly handled. Necessary tools 10mm nut driver or flat screw driver. How to remove the Lamp House from the projector? 1.
  • Page 37 4. Lamp & Lamp House AUTION Xenon compact arc lamps are highly pressurized. When ignited, the normal operating temperature of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accordance to the manufacturer’s instructions.
  • Page 38 4. Lamp & Lamp House Image 4-7 3. Release the four quarter turn screws (reference 5 image 4-8) of the UV blocker assembly as illustrated. Make sure that the anode support remains in its position while releasing the screws. Image 4-8 4.
  • Page 39 4. Lamp & Lamp House 6. Gently remove the xenon lamp together with the anode socket out of the Lamp House. Do not use excessive force upon the xenon lamp. Normally the xenon lamp will easily slide out the cathode socket of the Lamp House. Warning: Supporting the xenon lamp with one hand while pulling it out with other hand prevents it from bumping against the chassis of the Lamp House.

  • Page 40: Installation Of The Xenon Lamp In Manual S/M Lamp House

    4. Lamp & Lamp House 9. Remove the cathode adapter from the xenon lamp by releasing the hexagon socket head cap screw (reference 9 image 4-14) of the adapter as illustrated. Use a 5mm Allen wrench. Note: Some xenon lamps have a cathode pin with screw threat (reference 10 image 4-14). Image 4-14 Reinstall the UV blocker assembly and the side cover in case you do not intend to install another xenon lamp immediately in the Lamp House.
  • Page 41 4. Lamp & Lamp House ARNING Always wear protective clothing (welder’s jacket) when handling xenon lamps. ARNING Always wear clean leather gloves with wrist protectors when handling xenon lamps. This procedure assumes that the anode support assembly and the side cover are already removed from the Lamp House due to the removal of the xenon lamp.
  • Page 42 4. Lamp & Lamp House Image 4-16 Tip: Write down the serial number of the xenon lamp. You will need this while updating the lamp parameters after installation of the xenon lamp. The serial number of the xenon lamp is engraved in the neck of the xenon lamp. 3.
  • Page 43 4. Lamp & Lamp House Image 4-18 5. Slide the anode connector in its position on the Lamp House as illustrated. Caution: Avoid any tension on the anode wire, so there is no mechanical stress on the lamp. Image 4-19 6.
  • Page 44 4. Lamp & Lamp House Image 4-21 8. Install the side cover of the Lamp House and fasten the three quarter turn screws (reference 4 image 4-22) of the cover. Note: Please ensure that the quarter turn screws turning wires are flush with the cover or interference will occur while inserting the Lamp House into the projector.

  • Page 45: Installation Of The Lamp House

    4. Lamp & Lamp House A realignment of the xenon lamp in its reflector is required after the installation of the xenon lamp in the Lamp House. Installation of the Lamp House ARNING This procedure may only be performed by qualified technical service personnel. AUTION Due to its high internal pressure, the lamp may explode in either hot or cold states if improperly handled.

  • Page 46: Resetting The Lamp Parameters

    4. Lamp & Lamp House Image 4-25 Resetting the lamp parameters AUTION The “LAMP INFO” parameters MUST be updated after each installation of an xenon lamp inside the Lamp House. Neglecting this update will result in poor performance and short life time of the xenon lamp. For a new lamp, how to reset the values 1.
  • Page 47 4. Lamp & Lamp House Image 4-26 Reset lamp info, new lamp A Reset lamp parameters selection window opens (2). 2. To get new lamps, click on From new list (3). The lamp article and serial number opens (4). 3. Fill out the article number of the new lamp (5a) click on Select (5b) to display a list of possible article numbers (6).
  • Page 48 4. Lamp & Lamp House Image 4-27 Reset lamp info, used lamp A Reset lamp parameters window opens (2). 2. To get history of the used lamps, click from history (3). The Reset lamp history selection window opens (4). 3. Click on Select (5) to display a list of possible lamps (6). 4.

  • Page 49: Realignment Of The Lamp In Its Reflector (Manual Lamp House)

    4. Lamp & Lamp House 5. The lamp parameters can be edited by the user under personnel maintenance and responsibility. If you want to change these parameters, check the check box in front of Edit lamp parameters (11). The current parameter fields become active (12). 6.
  • Page 50 4. Lamp & Lamp House Image 4-29 Realignment points 6. Switch of the projector. 7. Reinstall the lamp cover. R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 51: Lenses & Lens Holder

    • Scheimpflug adjustment Available lenses Which lenses are available for my projector? The table below is subject to changes and was last updated on 01/06/2012. Consult my.barco.com for the most recent information about available lenses. Product Number 2K zoom range...
  • Page 52 5. Lenses & lens holder Image 5-1 Image 5-2 Image 5-3 R9855958 R9855942 R9855943 Image 5-4 Image 5-5 Image 5-6 R9855963 R9855945 R9855964 Image 5-7 Image 5-8 Image 5-9 R9855946 R9855947 R9856294 Image 5-10 Image 5-11 R9856297 R9856300 R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 53: Lens Selection

    2. Login on my.barco.com. If you are not yet registered click on Sign up for my.barco.com and follow the instructions. With the created login and password, it is possible to enter the my.barco.com. When your login is correct, the my.barco.com start page is displayed.
  • Page 54 5. Lenses & lens holder 3. Place the lens holder in the “unlocked” position by moving the lens lock handle (1) towards the lens power supply socket (2). Image 5-13 Unlock lens holder 4. Ensure that the lens holder stands in the On-Axis position (horizontal and vertical mid position). Note: The lens holder is placed default in the On-Axis position at factory.

  • Page 55: Lens Removal

    5. Lenses & lens holder Image 5-15 Fix lens AUTION Never transport the projector with a Lens mounted in the Lens Holder. Always remove the Lens before transporting the projector. Neglecting this can damage the Lens Holder and Prism. Lens removal How to remove a lens? 1.

  • Page 56: Lens Shift, Zoom & Focus

    5. Lenses & lens holder Image 5-17 Remove lens It’s recommended to place the Lens caps of the original Lens packaging, back on both sides of the removed Lens to protect the optics of the Lens. It’s recommended to place the foam rubber of the original projector packaging, back in the Lens opening to prevent intrusion of dust.

  • Page 57: Scheimpflug Adjustment

    5. Lenses & lens holder Image 5-19 If no, use the zoom barrel on the lens to zoom in or out. How to focus? 1. Use the “+” and “-” focus keys on the local keypad to focus the image on the screen. Image 5-20 Scheimpflug adjustment What has to be done ?
  • Page 58 5. Lenses & lens holder Scheimpflug adjustment points Image 5-22 Scheimpflug adjustments Indication on drawing Function Locking nut 1, 2 and 3 Scheimpflug adjustment nuts A, B, C and D Set screws a, b, c and d lock nuts 1, 2 and 3 are adjustment points. 4 is a locking point and NOT used during Scheimpflug adjustment.
  • Page 59 5. Lenses & lens holder Image 5-24 Center focusing 6. Sharpen bottom left corner of the screen by adjusting nut 1. Image 5-25 Left bottom focusing 7. Sharpen bottom right corner of the screen by adjusting nut 2. R5905067 DPXK-19B/23B/P 17/09/2012...
  • Page 60 5. Lenses & lens holder Image 5-26 Right bottom focusing 8. Sharpen top right corner of the screen by adjusting nut 3 Image 5-27 Corner focusing 9. Repeat from step 6 until the projected focus pattern is as sharp as possible in the center, left, right, top and bottom of the screen. How to fix the Scheimpflug Start the fixation as follows (steps must be followed strictly) : 1.
  • Page 61 5. Lenses & lens holder 1/3 to 1/2 Image 5-28 4. Fasten lock nut d. 5. Tighten nut 4 until the offset of the image movement created in step 3 is canceled. Tip: The amount of image movement in step 3 will determine how tight the nut in step 5 will need to be turned to return the image to its original position R5905067 DPXK-19B/23B/P 17/09/2012...
  • Page 62 5. Lenses & lens holder R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 63: Input & Communication

    6. Input & communication 6. INPUT & COMMUNICATION Overview • Introduction • Local keypad of the DPxK B-series projector • Communication ports of the DPxK B-series projector • Source input ports of the DPxK B-series projector • Optional Quad 3G-SDI input board •...

  • Page 64: Local Keypad Of The Dpxk B-Series Projector

    6. Input & communication Local keypad of the DPxK B-series projector Identification of the keys Image 6-2 Local keypad Marker area for macro name Numeric keyboard Standby key Dowser open/close switch Test pattern toggle switch Lens shift up/down, left/right Lens focus Lens zoom Numeric keys All the numeric keys (2) of the local keypad have a blue backlight during normal operation.

  • Page 65: Communication Ports Of The Dpxk B-Series Projector

    6. Input & communication Communication ports of the DPxK B-series projector Location of the communication ports STAT STAT STAT STAT CINEMA CONT POWER SMPTE 292/424 IN SYNC OK SYNC OK RS232 IN 3D INTERFACE PERIPHERAL PORT 10 / 100 / 1000 BASE-T DVI INPUT GENERAL PURPOSE IN/OUT DVI A...

  • Page 66: Source Input Ports Of The Dpxk B-Series Projector

    6. Input & communication Can be used to connect external 3D devices to the projector. All signals necessary for 3D projection can be provided via this con- nector. PERIPHERAL PORT For future use. Source input ports of the DPxK B-series projector Location of the source input ports STAT STAT...

  • Page 67: Optional Quad 3G-Sdi Input Board

    6. Input & communication Input Source Vertical rate Scan type Color space Sampling Color depth standard Single DVI VESA (640x480) 72 Progressive 4:4:4 8 bit Single DVI VESA (800x600) 60 Progressive 4:4:4 8 bit Single DVI VESA (800x600) 72 Progressive 4:4:4 8 bit Progressive...
  • Page 68 6. Input & communication Image 6-7 Quadrant connection To configure the input, consult the Communicator manual Source formats Advanced settings General settings Source Port Port type Mode Scan type Color Pixel mapping Calibration space A or B HD-SDI Single 4:2:2 10 Progressive YCbCr HD-SDI-Single link...
  • Page 69 6. Input & communication General settings Advanced settings Source Port Port type Mode Scan type Color Pixel mapping Calibration space Progressive - field bit inverted Progressive SF- 2nd field dominant Progressive SF- 1st field dominant HD-SDI Single 4:2:2 10 Progressive YCbCr HD-SDI-Single link Single...
  • Page 70 6. Input & communication General settings Advanced settings Source Port Port type Mode Scan type Color Pixel mapping Calibration space 2K-3D A or B 3G-SDI link - 3D 4:2:2 10 Progressive YCbCr 3G - Level B - Dual Single bits/color stream Dual (separate left / right eye)
  • Page 71 6. Input & communication General settings Advanced settings Source Port Port type Mode Scan type Color Pixel mapping Calibration space 4:4:4 10 Progressive 3G - Level A - Single bits/color Interleaved 3G - Level B - Interleaved 4:4:4 12 Progressive XYZ/RGB 3G - Level A - Single...

  • Page 72: Led Indications On The Integrated Cinema Processor Module

    6. Input & communication General settings Advanced settings Source Port Port type Mode Scan type Color Pixel mapping Calibration space 3G - Level B - Quad Link Progressive SF - 2nd XYZ/RGB 3G - Level A - Quad Single field dominant Link 3G - Level B - Quad Link...

  • Page 73: Communicator Touch Panel

    7. Communicator Touch Panel 7. COMMUNICATOR TOUCH PANEL Overview • Introduction • Installation of the touch panel interface Introduction Communicator Touch Panel for digital cinema projectors The Communicator Touch Panel is designed for multi-user command and control, the Communicator enables users to learn quickly and operate efficiently - using an elegant and flexible touch panel interface.

  • Page 74: Installation Of The Touch Panel Interface

    7. Communicator Touch Panel Touch screen Communication panel Knob to operate central swivel clamp Base of swivel arm Power input 12 VDC, 1.5A RS232 port (sub-D) Ethernet port (RJ45) AUTION For more information about the use of the Communicator Touch Panel, consult its user guide. Installation of the touch panel interface Necessary tools •...
  • Page 75 7. Communicator Touch Panel Image 7-5 Touch panel mounted Image 7-4 Mount touch panel 3. Place the touch panel interface on the mounting plate of the swivel arm and fasten the two wing nuts (W) as illustrated. Image 7-6 Mount touch panel 4.
  • Page 76 7. Communicator Touch Panel Image 7-8 Connections R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 77: Starting Up

    8. Starting up 8. STARTING UP About this chapter This chapter contains the switch ON and switch OFF procedures of the B-series projector. These procedures enumerate all the important points which have to be checked prior to switching ON the projector. This is to ensure a safe start up of the projector. Overview •...
  • Page 78 8. Starting up R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 79: Projector Registration

    Overview The current projector is DCI compliant and should be registered by Barco. Therefore, the digital certificate inside the projector will be used to secure encryption key communication between the projector and the rest of the theatre system (server and theatre man- agement system).

  • Page 80: Registration Of New Projector

    The procedure below gives an overview of all possible steps which can be displayed. How to register 1. Go to Barco’s Partnerzone on https://my.barco.com. 2. Login into the partnerzone. If you are not yet registered, click on Sign in here and follow the instructions. With the created login and password, it is possible to enter the partnerzone where you can upload the certificate.
  • Page 81 9. Projector registration Image 9-3 Lenses: click on the drop down box and select the lens of the projector when a M25 lens or select Other lens when no M25 lens is used. When other lens is selected, an extra input field appears to fill out the lens type. Anamorphic lens: check when an anamorphic lens is available.
  • Page 82 9. Projector registration If the location is not in the list, click Add new and continue to next step. 7. Fill out all fields with an asterisk for Location, Contact person and Support contact. Click Next >>. Image 9-5 Add new location The new location is added to the list of locations and is selected.
  • Page 83 9. Projector registration Image 9-7 Add new installer The new installer is added to the list of installers and is selected. Click Next >> to continue to next step. The owner input form appears. 10.If the owner is in the list, select the owner and click Next >> to finalize the registration. If the owner is not in the list, click Add new and continue with next step.
  • Page 84 9. Projector registration Image 9-9 Add new owner The new owner is added to the list of owners and is selected. Click Next >> to finalize the registration. The registration is completed. An E-mail will be sent to the person who is logged in. R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 85: Update Registration Of An Existing Projector

    How to update 1. First get a new certificate file. See "Download the certificate file", page 73. 2. Go to Barco’s Partnerzone on https://secure.barco.com/digitalcinema/. 3. Login into the partnerzone. Click Register DC projector and select Update DC projector.
  • Page 86 9. Projector registration The update page is displayed with your registered projectors. Image 9-11 Select projector to update 4. Select the projector for which the registration must be updated. The installation address is displayed in Selection Click >> Next to continue. 5.

  • Page 87: Removal And Installation Of The Projector Covers

    10. Removal and installation of the projector covers 10. REMOVAL AND INSTALLATION OF THE PROJECTOR COVERS ARNING All procedures in this chapter may only be performed by “qualified service technicians” . ARNING Disconnect the power to the circuit mains terminals and unplug the power cord at UPS INLET, unless otherwise specified in the procedure.

  • Page 88: Removal Of The Lamp Cover

    10. Removal and installation of the projector covers 10.1 Removal of the lamp cover Necessary tools Flat screwdriver How to remove 1. Release both captive screws on top of the lamp cover. Image 10-2 Lamp cover, fasting screws 2. Push both lock to each other to release the locks and pull at the same time the bottom side of the cover away form the projector. Image 10-3 Lamp cover, locks 3.

  • Page 89: Removal Of The Rear Cover

    10. Removal and installation of the projector covers Image 10-4 Lamp cover, removal 10.2 Removal of the rear cover Necessary tools Flat screwdriver How to remove 1. Release both captive screws almost at the bottom of the rear cover using a flat screw driver (1). Image 10-5 Rear housing removal R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 90: Removal Of The Input Cover

    10. Removal and installation of the projector covers 2. Remove the rear cover of the projector doing the following: a) gently pull out the top covers of the rear cover (2). b) then move the rear cover away from the projector. 10.3 Removal of the input cover Necessary tools Flat screwdriver...

  • Page 91: Removal Of The

    10. Removal and installation of the projector covers Image 10-7 Input cover removal 10.4 Removal of the front cover Necessary tools Flat screwdriver How to remove 1. Check if the lens is removed. 2. Remove the rubber dust ring from the lens holder. R5905067 DPXK-19B/23B/P 17/09/2012...
  • Page 92 10. Removal and installation of the projector covers Image 10-8 Release cover removal 3. Release the captive screw at the middle bottom of the front cover. 4. Remove the front cover as follow: a) standing in front of the projector, pull the top side of the cover to you until it is unlocked. b) slide the cover away from the projector.

  • Page 93: Removal Of The Side Cover

    10. Removal and installation of the projector covers 10.5 Removal of the side cover Necessary tools Flat screwdriver How to remove 1. Release both captive screws on top of the side cover. Image 10-10 Captive screws 2. Push both lock to each other to release the locks and pull at the same time the bottom side of the cover away form the projector. Image 10-11 Unlock side cover 3.

  • Page 94: Installation Of The

    10. Removal and installation of the projector covers Image 10-12 Side cover 10.6 Installation of the front cover Necessary tools Flat screwdriver How to install 1. Ensure that no lens is mounted. 2. Execute the next steps to install the front cover: a) Hook the bottom side of the cover to the projector.

  • Page 95: Installation Of The Input Cover

    10. Removal and installation of the projector covers Image 10-14 Secure front cover 4. Reinstall the rubber dust ring around the lens holder. 10.7 Installation of the input cover Necessary tools Flat screwdriver How to install 1. Place the top side of the cover on its place. Image 10-15 Mount input cover 2.

  • Page 96: Installation Of The Lamp Cover

    10. Removal and installation of the projector covers Image 10-16 Secure input cover 3. Secure the cover by fastening the captive screw. 10.8 Installation of the lamp cover Necessary tools Flat screwdriver How to install 1. Place the top side of the cover on its place. R5905067 DPXK-19B/23B/P 17/09/2012...
  • Page 97 10. Removal and installation of the projector covers Image 10-17 Mount lamp cover Close the cover as follow: a) Gently move the bottom side of the cover towards the projector b) Push both lock to each other and push at the same time the cover against the projector frame. c) Release both locks so that they lock in their receivers.

  • Page 98: Installation Of The Rear Cover

    10. Removal and installation of the projector covers 10.9 Installation of the rear cover Necessary tools Flat screwdriver How to install 1. Install the rear cover of the projector doing the following: a) Bring the rear cover towards its final position. b) Gently push the locking studs into the receivers (1).
  • Page 99 10. Removal and installation of the projector covers Image 10-20 2. Secure the cover by fasting both captive screws. Image 10-21 Lock side cover R5905067 DPXK-19B/23B/P 17/09/2012...
  • Page 100 10. Removal and installation of the projector covers R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 101: Maintenance

    11. Maintenance 11. MAINTENANCE About this chapter This chapter describes how to remove the dust filters Overview • Remove and clean the front dust filter • Remove and clean both bottom dust filters • Cleaning the lens • Cleaning the exterior of the projector •...
  • Page 102 11. Maintenance Image 11-1 Front dust filter Clean the dust filter 1. Remove most contamination with a vacuum cleaner in an other room or outside. 2. Blow remaining dust away with compressed air in an other room or outside. Mount the dust filter 1.

  • Page 103: Remove And Clean Both Bottom Dust Filters

    11. Maintenance 11.2 Remove and clean both bottom dust filters How to remove 1. Remove the side cover. 2. Slide out the bottom front dust filter. Image 11-3 Bottom front dust filter 3. Slide out the bottom back dust filter. Image 11-4 Bottom back dust filter Clean the dust filter...

  • Page 104: Cleaning The Exterior Of The Projector

    11. Maintenance 2. Wipe lenses in a one single direction. Warning: Do not wipe back and forwards across the lens surface as this tends to grind dirt into the coating. 3. Do not leave the cleaning cloth in either an open room or lab coat pocket, as doing so can contaminate the cloth. 4.

  • Page 105: Cooling Liquid Refill

    11. Maintenance 11.6 Cooling liquid refill ARNING This procedure may only be performed by qualified technical service personnel. Order info cooling liquid B1909086K : bottle of 1 liter cooling liquid. Necessary parts Cooling liquid How to refill 1. Remove the side cover, see "Removal of the side cover", page 87. 2.
  • Page 106 11. Maintenance Image 11-7 Keypad The color of the backlight of the numeric keys 1 to 6 of the local keypad changes from blue to yellow. 4. Enter pin code within 5 seconds. In case no keys are pressed, the color of the backlight of the numeric keys 1 to 6 changes back to blue. In case of an incorrect code entry, the color of the backlight of the numeric keys changes to red for 1 second and then back to blue.

  • Page 107: Convergence

    12. Convergence 12. CONVERGENCE About this chapter This chapter describes how to prepare the projector for convergence adjustment and how to adjust the convergence. Overview • Open the sealed compartment • Close the sealed compartment • Convergence controls • Red on blue convergence •...

  • Page 108: Close The Sealed Compartment

    12. Convergence Image 12-2 Sealed cover, remove A security warning will be displayed on the projector. Execute the procedure “Authorization to clear security warning on the projector”. 12.2 Close the sealed compartment Necessary tools 3 mm Allen wrench How to close the sealed compartment 1.

  • Page 109: Convergence Controls

    12. Convergence Image 12-4 Sealed cover, fixation 12.3 Convergence controls Definitions-Abbreviations • X: Horizontal direction on the screen, with origin in the centre of the screen and + to the right • Y: Vertical direction on the screen, with origin in the centre of the screen and + to the top •...

  • Page 110: Red On Blue Convergence

    12. Convergence Convergence Test pattern For the manual correction of the DMD convergence, a typical convergence test pattern is generated. For a 4K projector, use the 4K test pattern. Image 12-6 Convergence test pattern Work Instructions: • GREEN and RED DMD’s are to be adjusted with reference to the BLUE dmd. •...

  • Page 111: Green On Blue Convergence

    12. Convergence 4. To translate RED horizontally in the X - direction, turn [3] anti-clockwise. 5. For clockwise rotations of RED, turning [1] anti-clockwise would generally suffice. If much rotation is required, [2] may also be turned in the opposite direction. Slight corrections to Y may be required after rotation. 6.
  • Page 112 12. Convergence Green Image 12-8 Green on blue convergence R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 113: Specifications

    • Specifications of the DP4K-P • Dimensions of the B-series projector • Dimensions of the universal pedestal A.1 Specifications of the DP2K-19B Overview Digital MicroMirror Device™ 3 x 1.2" DC2K dark metal devices Native resolution 2,048 x 1,080 pixels Housing...

  • Page 114: Specifications Of The Dp4K-19B

    A. Specifications A.2 Specifications of the DP4K-19B Overview Digital MicroMirror Device™ 3 x 1.38" DC4K dark metal devices Native resolution 4,096 x 2,160 pixels Housing Hermetically sealed DMDs and optical assembly Lamp 1.2kW - 3kW (Xenon lamp) Light Output 19,000 lumens (3 kW lamp) Screen size Up to 19m / 62 ft wide Contrast ratio...

  • Page 115: Specifications Of The Dp2K-23B

    A. Specifications A.3 Specifications of the DP2K-23B Overview Digital MicroMirror Device™ 3 x 1.2” DC2K dark metal devices Native resolution 2048 x 1080 pixels Housing Hermetically sealed DMDs and optical assembly Lamp 1.2kW - 4kW (Xenon lamp) 24,500 lumens Light Output Screen size Up to 23 m / 75ft wide Contrast ratio...

  • Page 116: Specifications Of The Dp2K-P

    A. Specifications Control I/O Ethernet, 8x GPIO, Serial RS232 Prime Lenses 1.13 - 1.31 > 1.27 - 1.86 > 1.45 - 2.13 > 1.63 - 2.53 > 1.95 - 3.26 > 2.53 - 4.98 > equivalent throw ratios for 4K 1.38" DMD Projector Diagnostics via PC touch panel >...

  • Page 117: Specifications Of The Dp4K-P

    A. Specifications Ethernet Control I/O > 8x GPIO > Serial RS232 Prime Lenses 1.25 - 1.45 > 1.4 - 2.05 > 1.6 - 2.35 > 1.8 - 2.8 > 2.15 - 3.6 > 2.8 - 5.5 Color gamut native red: x = 0.7; y = 0.3 >...
  • Page 118 A. Specifications 207.5 37.5 41.5 381.5 min. 31 Image A-1 Dimensions in mm R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 119: Dimensions Of The Universal Pedestal

    A. Specifications A.8 Dimensions of the universal pedestal Dimensions 876,3 Image A-2 Dimensions given in millimeters. R5905067 DPXK-19B/23B/P 17/09/2012...
  • Page 120 A. Specifications R5905067 DPXK-19B/23B/P 17/09/2012...

  • Page 121: Pin Configurations

    B. Pin configurations B. PIN CONFIGURATIONS Overview • About General Purpose Inputs & Outputs (GPIO) • Pin configurations of the communication ports • Pin configurations of the inputs B.1 About General Purpose Inputs & Outputs (GPIO) General Purpose inputs Eight (8) opto-isolated general purpose inputs are available. These inputs are used to trigger the execution of macro files. For more explanation about the association of a macro to a GPI, consult the user guide of the Communicator touch panel.

  • Page 122: Pin Configurations Of The Communication Ports

    B. Pin configurations • Generate Falling Edge – generate a falling edge on the external GPO port if the present state of the output is high. If the present state of the external GPO is low, no edge will be generated. •...

  • Page 123: Pin Configurations Of The Inputs

    B. Pin configurations General Purpose In/Out GPOUT 8 P GPOUT 8 N reserved reserved reserved reserved reserved Ethernet port 10/100 Base-T — RJ45 port 1000 Base-T — RJ45 port Pair Color Description Description white/green TXD+ TX0+ green TXD- TX0- white/orange RXD+ RX0+ —...
  • Page 124 B. Pin configurations R5905067 DPXK-19B/23B/P 17/09/2012...
  • Page 125 Revision Sheet Barco nv Entertainment Division/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11, Fax: +32 56.36.88.24 Support: www.Barco.com/esupport, Web: www.barco.com From: Date: Please correct the following points in this documentation (R5905067/07): page wrong correct R5905067 DP K-19B/23B/P 17/09/2012...

This manual is also suitable for:

Dp2k-23bDp2k-pDp4k-19bDp4k-23bDp4k-p

Table of Contents
