13. Specifications
13.1 Specifications of the Prometheus I
Overview
Digital MicroMirror Device™
Native resolution
Housing
Lamp
Light output
Screen size
Brightness uniformity
Color uniformity
Native contrast ratio
Color gamut
Digital Video Inputs
Control I/O
Projector diagnostics
Prime lenses
Power requirements
Dimensions
Weight
Ambient temperature
Exhaust airflow
Options
166
3 x 1.38" DC4K dark metal devices
4,096 x 2,160 pixels
Hermetically sealed DMD and optical assembly
2kW included (Xenon)
Up to 4kW possible
Compatible with models from all major brands
7,950 lumens
Up to 6.5 m (21.3 ft) wide
80% at sides, 75% at corners
Meets the DCI/SMPTE 431-1 specs
Target: 1,840:1
Min: 1,680:1
native red: x = 0.7; y = 0.3
native green: x = 0.2; y = 0.76
native blue: x = 0.145; y = 0.04
4 x 3Gb/s HD-SDI inputs (max. two single-link HD-SDI, one dual-link HD-SDI or one
quad link 4K)
2 x DVI input
Ethernet
8x GPIO
Serial RS232
Via Communicator postproduction software (included)
Via PC touch panel (optional)
Via SNMP agent
1.13 - 1.31
1.31 - 1.86
1.45 - 2.13
1.63 - 2.53
1.95 - 3.26
(equivalent throw ratios for 4K 1.38" DMD)
200-240 V
30 A
50-60 Hz
604(H) x 754(W) x 1129(D) mm
23.78(H) x 29.69(W) x 44.45(D) inch
NB: min. 5 cm of air inlet spacing required at the bottom of projector
134 kg (295 lbs)
35°C / 95°F
350 CFM
ACS-2048
3D add-ons
Touch panel
Pedestal
R5905963 PROMETHEUS SERIES 09/03/2015
