Endress+Hauser micropilot M FMR 230 Technical Information

www.aotewell.com
Technical Information
TI 345F/00/en
AoteWell International.inc
www.fa-market.com
Level-Radar
micropilot M
FMR 230/231/240
Smart Transmitter for continuous and
non-contact level measurement
Cost-effective 4...20 mA 2-wire technology
Suitable for hazardous locations
FMR 231
Features and benefits
•
2-wire technology, low price:
A real alternative to differential
pressure, floats and displacers.
2-wire technology reduces wiring costs
and allows easy implementation into
existing systems.
•
Non-contact measurement:
Measurement is almost independent
from product properties.
•
Easy on-site operation via menu-driven
alphanumeric display.
•
Easy commissioning, documentation
and diagnostics via operating software
(ToF Tool).
•
2 frequency ranges – approx. 6 and
26 GHz:
No compromises, the right frequency
for every application.
•
HART or PROFIBUS-PA respectively
Foundation Fieldbus protocol.
•
High temperatures:
Suitable for process temperatures up to
+200 °C (392 °F), up to 400 °C (752 °F)
with high-temperature antenna.
sales@aotewell.com
info@aotewell.com
FMR 240
FMR 230
•
Rod antenna with inactive length:
Reliable measurement in narrow
nozzles, with condensation and
build-up in the nozzle.
Application
The Micropilot M is used for continuous,
non-contact level measurement of
liquids, pastes, and slurries.
The measurement is not affected by
changing media, temperature changes,
gas blankets or vapours.
•
The FMR 230 is especially suited for
measurement in buffer and process
tanks.
•
The FMR 231 has its strengths
wherever high chemical compatibility is
required.
•
The FMR 240 with the small (1½") horn
antenna is ideally suited for small
vessels. Additionally, it provides an
accuracy of ±3 mm.
