9 Data Services - Classical IP & IP Routing
Assigning CIP PVCs to
CIP members
Result
168 / 362
Proceed as follows:
Step Action and Description
1 Browse to the 'CIP' web page:
The bottom row of the 'CIP Connections' table allows addition of a
new CIP connection.
2
In the 'Dest' column of the bottom row, click
PVC you want to assign.
3
Depending the RFC1577 compliancy of the remote access router,
the following must be filled in, in the 'Remote IP address' column:
Compliancy
YES
NO
3
Click
A CIP PVC is assigned, and added in the 'CIP Connections' table.
Remote IP Address
You don't have to fill in anything; the
InATMARP
assign the PVC to the CIP member.
You must fill in the exact IP address
of the remote access router; the
PVC is explicitly assigned to the
CIP member.
and to finish the procedure.
and select the CIP
reply will implicitly
3EC 17766 AAAA TCZZA Ed. 01
