Setting The Default Route Metric - 3Com SuperStack II 3300 User Manual

Modifying a Range
Removing a Range
Setting the Default
Route Metric
To modify information associated with a previously defined range:
1 Enter the following at the top-level menu:
ip ospf areas modifyRange
The following prompt is displayed:
Select area {1-2}:
2 Enter the index number of the area that contains the range to modify.
Enter IP address of range to modify:
3 Enter the IP address of the range to modify.
Enter IP address:
4 Enter the new IP address if you want to change it. Press Enter if you do
not want to change it.
Enter subnet mask [255.255.0.0]:
5 Enter the subnet mask. Press Enter if you do not want to change it.
Advertise this area range (yes,no) [yes]:
6 Specify whether to advertise the range on the network. The default is yes.
To remove a previously defined range:
1 Enter the following at the top-level menu:
ip ospf areas removeRange
The following prompt is displayed:
Select area {1-2}:
2 Enter the index number of the area containing the range you want to
remove.
Enter IP address of range to delete:
3 Enter the IP address of the range you want to delete.
The default route metric value indicates the cost for a default route. If the
cost is greater than 0, the router advertises itself as the default router to
the area.
The default metric value is 0, which indicates no advertisement.

Setting the Default Route Metric

87
