6. Config Mode: The station serving as an Enrollee or an external Registrar.
7. Table of Credentials: Displays all credentials obtained by the Registrar. The detailed list includes information about the
SSID, MAC Address, Authentication and Encryption Type. If STA is the Enrollee, the credentials are created immediately
with each WPS success. If STA is the Registrar, RaUI creates a new credential with WPA2-PSK/AES/64Hex-Key and
doesn't change this until switching to STA Registrar.
8. Control items for credentials.
a. Detail: Command to obtain Information about Security and the Key in the credential.
b. Connect: Command to connect to the selected network inside credentials. The active selected credential is as like as the
active selected Profile.
c. Rotate: Command to rotate to connect to the next network inside credentials.
d. Disconnect: Stops the WPS action and disconnects the active link. It then selects the most recent profile on the Profile
Page of RaUI. If there are no profiles, the driver will select any non-security AP.
e. Export Profile: Exports all credentials to a Profile.
f. Delete: Deletes an existing credential. And then selects the next credential. If there is not another credential, the driver
will select any non-security AP.
9. PIN: Start to add to Registrar using PIN configuration method. If STA Registrar, remember that enter PIN Code read
from your Enrollee before starting PIN.
10. PBC: Start to add to AP using PBC configuration method.
After the user clicks PIN or PBC, please do not rescan within two-minutes of the connection. If you
want to abort this setup within the interval, restart PIN/PBC or click "Disconnect" to stop WPS action.
11. WPS associate IE: Sends the association request with WPS IE during the WPS setup. It is optional for STA.
12. WPS probe IE: Sends the probe request with WPS IE during WPS setup. It is optional for STA.
13. Progress Bar: Displays the rate of progress from Start to Connected.
14. Status Bar: Displays the current WPS Status.
15. Automatically select the AP: Starts to add to AP by using to select the AP automatically in PIN method.
**There are examples in section 2-7-3 (PIN Enrollee Setup), section 2-7-4(PBC
Enrollee Setup) and section 2-7-5 (Registrar Configures and AP) **
