- Page 1 User Manual Wireless PCI Express Adapter 300Mbps & 150Mbps CWP-905E &CWP-906E Model: CNet Technology Corporation. www.CNetusa.com...
-
Page 2: Table Of Contents
5.5.3 Statistics ......................... 29 About ..........................30 5.6.1 About ........................30 WPS ..........................30 5.7.1 WPS ........................30 Security ............................32 Auth.\ Encry. Setting – WEP/TKIP/AES ..............32 802.1x Setting ........................ 33 Trouble Shooting .......................... 36 CNet Technology Corporation. www.CNetusa.com... -
Page 3: Introduction
Open your PC case and locate an available PCI Express Adapter CWP-905E or CWP-906E on the motherboard. Slide PCI express Adapter into the PCI slot. Make sure that all of its pins are touching the slot's contacts. You may have to apply a bit of pressure to slide PCI Adapter all the way in. -
Page 4: Install Driver And Utility
1. Insert Installation CD to your CD-ROM drive. And click Driver Installation. The wizard will run and install all neces- sary files to your computer automatically. 2. Click Next to accept the Agreement. Or click Cancel to cancel the installation 3. Click Next CNet Technology Corporation. www.CNetusa.com... - Page 5 CNet Technology Corporation. www.CNetusa.com...
- Page 6 It’s recommended to select Ralink Configuration Tool, which provides fully access to all function of PCI Adapter. b. If you prefer to use the wireless configuration tool provided by Windows 7, please select Microsoft Zero Configuration Tool 5. Click Finish to complete the software installation. CNet Technology Corporation. www.CNetusa.com...
- Page 7 CNet Technology Corporation. www.CNetusa.com...
-
Page 8: Windows Wireless Utility
Figure 1-3 Ralink Utility The Ralink wireless utility starts in compact mode as shown in Figure 1-3. Clicking the expanding icon at the bottom-right corner can change to the full mode as shown in Figure 1-4. CNet Technology Corporation. www.CNetusa.com... -
Page 9: Windows Autoconfig Service
Figure 1-4 Ralink Utility in full mode 4.1.2 Windows AutoConfig Service The following steps outline the procedure for starting/stopping the Windows AutoConfig service. Select "Control Panel" in the start menu Double-click the "System and Security" icon CNet Technology Corporation. www.CNetusa.com... - Page 10 Double-click the "Administrative Tools" icon Double-click "Services" CNet Technology Corporation. www.CNetusa.com...
- Page 11 Double-click "WLAN AutoConfig" Manage the AutoConfig properties in the dialog box CNet Technology Corporation. www.CNetusa.com...
- Page 12 1. Access via network connection icon Right-click the network connection icon in the taskbar, then select "Open Network and Sharing Cen- ter" from the pop-up menu Select "Manage wireless networks" from the tasks list CNet Technology Corporation. www.CNetusa.com...
- Page 13 Right-click the network to bring up the profile managing menu CNet Technology Corporation. www.CNetusa.com...
- Page 14 2. Access via control panel Select "Control Panel" from the start menu Double-click the "Network and Internet" icon CNet Technology Corporation. www.CNetusa.com...
- Page 15 Double-click the "Network and Sharing Center" icon CNet Technology Corporation. www.CNetusa.com...
- Page 16 Select "Manage wireless networks" from the tasks list Right-click the network to bring up the profile managing menu CNet Technology Corporation. www.CNetusa.com...
-
Page 17: Ralink Wireless Utility (Raui)
There are three sections to the RaUI dialog box. These sections are briefly described as follow. Button Section: Include buttons for selecting the Profile page, Network page, Advanced page, Statis- tics page, WMM page, WPS page, the About button, Radio On/Off button and Help. Figure 2-1-2 Button section CNet Technology Corporation. www.CNetusa.com... - Page 18 Figure 2-1-3 Link Information page Figure 2-1-4 Profile page Figure 2-1-5 Network page CNet Technology Corporation. www.CNetusa.com...
- Page 19 Figure 2-1-15. You can double click it to maximize the dialog box if you selected to close it earlier. You may also use the mouse's right button to close RaUI utility. Figure 2-1-8 Ralink icon in system tray CNet Technology Corporation. www.CNetusa.com...
-
Page 20: Profile
RTS Threshold: Users can adjust the RTS threshold number by sliding the bar or keying in the value directly. Fragment Threshold: The user can adjust the Fragment threshold number by sliding the bar or key in CNet Technology Corporation. www.CNetusa.com... -
Page 21: Add/Edit Profile
You can open it by clicking the "Edit" button on the Profile tab. Figure 2-2-1 Add a new Profile Icons and buttons: : To the next page. : Back to the previous page. : Cancel button. CNet Technology Corporation. www.CNetusa.com... - Page 22 Shared, LEAP, WPA and WPA-PSK, WPA2 and WPA2-PSK, 802.1X, WAPI-PSK, and WAPI-CA. Encryption Type: For open and shared authentication mode, the selection of available encryption type are none and WEP. For WPA, WPA2, WPA-PSK and WPA2-PSK authentication mode, both TKIP and AES encryption is available. CNet Technology Corporation. www.CNetusa.com...
- Page 23 Pre-shared Key: This is the key shared between the AP and STA. For WPA-PSK and WPA2-PSK authentication mode, this field must be filled with a key between 8 and 32 characters in length. Figure 2-2-6 802.1x Configuration CNet Technology Corporation. www.CNetusa.com...
-
Page 24: Network
The Listed information includes the SSID, BSSID, Signal, Channel, Encryption algorithm, Authentication and Network type as shown in Figure 2-3-1-1. Figure 2-3-1-1 Network function Definition of each field: SSID: Name of BSS or IBSS network. CNet Technology Corporation. www.CNetusa.com... - Page 25 802.11n (The 802.11n button only exists for APs supporting N mode.) The introduction is as follows: General information contains the AP's SSID, MAC address, authentication type, encryption type, channel, network type, beacon interval, signal strength and supported rates. It is shown in Figure 2-3-1-2. CNet Technology Corporation. www.CNetusa.com...
-
Page 26: Advanced
Figure 2-3-1-2 General information about the Access Point Advanced 5.4.1 Advanced Figure 2-4 shows the Advance functions of RaUI. Figure 2-4 Advance function Wireless mode: Select wireless mode. 2.4G, 5G and 2.4+5G are supported.(2.4G/5GHz options are depend on different products) CNet Technology Corporation. www.CNetusa.com... -
Page 27: Certificate Management
The Certificate Management configuration page as shown in Figure 2-4-2. Figure 2-4-2 Certificate Management function Link Information 5.5.1 Link Status The link status page displays detailed information about the current connection as shown in Figure 2-5-1. CNet Technology Corporation. www.CNetusa.com... -
Page 28: Throughput
Signal Strength 2: Receive signal strength 2, user can choose to display as percentage or dBm for- mat. Signal Strength 3: Receive signal strength 3, user can choose to display as percentage or dBm for- mat. CNet Technology Corporation. www.CNetusa.com... -
Page 29: Statistics
RTS Frames Successfully Receive CTS: Successfully receive CTS after sending RTS frame. RTS Frames Fail To Receive CTS: Failed to receive CTS after sending RTS. Frames Retransmitted Successfully: Successfully retransmitted frames numbers. Reset counters to zero. Receive Statistics: CNet Technology Corporation. www.CNetusa.com... -
Page 30: About
PIN configuration method or a PBC configuration method through an internal or external Registrar. WPS AP List: Displays the SSID of the surrounding APs with WPS IE from the last scan result. CNet Technology Corporation. www.CNetusa.com... - Page 31 PIN/PBC or click "Disconnect" to stop WPS action. Progress Bar: Displays the rate of progress from Start to Connected. Status Bar: Displays the current WPS Status. CNet Technology Corporation. www.CNetusa.com...
-
Page 32: Security
For WPA, WPA2, WPA-PSK and WPA2-PSK authentication mode, both TKIP and AES encryption is available. For WAPI-PSK and WAPI-CA authentication mode, only SMS4 encryption is available. Figure 3-1-2 Authentication \ Encryption Settings in the Profile Page 8021X: This is introduced in the topic of Section 3-2. CNet Technology Corporation. www.CNetusa.com... -
Page 33: 802.1X Setting
TLS/Smart Card: Transport Layer Security. Provides for certificate-based and mutual authentication of the client and the network. It relies on client-side and server-side certificates to perform authenti- cation and can be used to dynamically generate user-based and session-based WEP keys to secure CNet Technology Corporation. www.CNetusa.com... - Page 34 "EAP-FAST" and "LEAP" authentication can key in domain name. Domain names can be keyed in the blank space. Tunnel ID/Password: Identity and Password for the server.. Client Certification Use Client certificate: Client certificate for server authentication. EAP Fast CNet Technology Corporation. www.CNetusa.com...
- Page 35 Allow intermediate certificates: It must be in the server certificate chain between the server certifi- cate and the server specified in the "certificate issuer must be" field. Server name: Enter an authentication sever root. CNet Technology Corporation. www.CNetusa.com...
-
Page 36: Trouble Shooting
BSSs being established, rather than a single BSS with multiple clients associated to it. Check that the Network Connection for the wireless client is configured properly. If Security is enabled, make sure that the correct encryption keys are entered on both PCI express Adapter and the access point. CNet Technology Corporation. www.CNetusa.com...
