Trane RTWD Installation Operation & Maintenance page 45

Table 15 - RTWD Extra High Effi ciency R134a
Unit size
Unit Type
Unit Application
Evap Application
Comp Starter
Compressor
Circuit 1
Circuit 2
Unit @ Max
Disconnect Switch Digit 26=C
Circuit Breaker + Bus bar
Digit 26=D
RLC-SVX14H-GB
Digit 12
Digit 15
Digit 21
digit 24
C1
C2
Motor RLA (A)
Motor LRA (A)
Max Amps (A)
Max Power input (kW)
Motor RLA (A)
Motor LRA (A)
Max Amps (A)
Max Power input (kW)
Starting Amps (A)
Amps ctl + auxiliaires
Max. Amps (A)
displacement power factor (DPF)
short circuit withstand rating
(kA)
Fuse size (A) C1 160 aM-T1 200 gG-T1 200 aM-T1 200 gG-T1 200 gG-T1 200 aM-T1 160 aM-T1 200 gG-T1
Fuse size (A) C2 160 aM-T1 200 gG-T1 200 aM-T1 200 gG-T1 200 gG-T1 200 aM-T1 200 aM-T1 200 gG-T1
Disconect Switch Size
Max connecting Wire (mm²)
Bus bar width (mm)
circuit breaker size (A) C1 NSX 160A
circuit breaker size (A) C2 NSX 160A
Bus bar connection Copper bar
Max connecting Wire (mm²)
160 160 160
3 3 3
A A A
1 1 2;3
Y B Y
M2 LoVi M2 LoVi M2 HiVi
M2 LoVi M2 LoVi M2 HiVi
98.0 98.0 98.0
259.0 0.0 259.0
114.0 102.9 114.0
66.3 67.7 66.3
98.0 98.0 98.0
259.0 0.0 259.0
114.0 102.9 114.0
66.3 67.7 66.3
375.0 207.7 375.0
2.0 2.0 2.0
230.0 207.7 230.0
0.84 0.95 0.84
35 35 35
6X250A 6X250A 6X250A
- T1 - T1 - T1
2 x 185 2 x 185 2 x 185
32 32 32
NSX 160A NSX 160A
NSX 160A NSX 160A
Copper bar Copper bar
50x8 50x8 50x8
2 x 240 2 x 240 2 x 240
160 160 160
3 3 3
A B;C B;C
2;3 * *
B B Y
M2 HiVi M2 HiVi M2 HiVi
M2 HiVi M2 HiVi M2 HiVi
98.0 132.8 132.8
0.0 0.0 259.0
102.9 153.3 166.0
67.7 100.9 98.9
98.0 132.8 132.8
0.0 0.0 259.0
102.9 153.3 166.0
67.7 100.9 98.9
207.7 308.7 427.0
2.0 2.0 2.0
207.7 308.7 334.0
0.95 0.95 0.86
35 35 35
6X250A 6X250A 6X250A
- T1 - T1 - T1
2 x 185 2 x 185 2 x 185
32 32 32
NSX 160A NSX 250A NSX 250A
NSX 160A NSX 250A NSX 250A
Copper bar Copper bar Copper bar
50x8 50x8 50x8
2 x 240 2 x 240 2 x 240
180 180
3 3
A A
1 1
Y B
M2 LoVi M2 LoVi
N1 LoVi N1 LoVi
98.0 98.0
259.0 0.0
114.0 102.9
66.3 67.7
116.8 116.8
291.0 0.0
141.0 128.8
83.1 84.8
407.0 233.7
2.0 2.0
257.0 233.7
0.85 0.95
35 35
6X250A 6X250A
- T1 - T1
2 x 185 2 x 185
32 32
NSX 160A NSX 160A
NSX 160A NSX 160A
Copper bar Copper bar
50x8 50x8
2 x 240 2 x 240
45
