Trane RTWD Installation Operation & Maintenance page 19

Table 7 - RTWD High Effi ciency - R1234ze
Indicative performances
Cooling Capacity (1)
Total Power input in cooling (1)
Heating Capacity (2)
Total Power input in heating (2)
Compressor
Compressor Number per Circuit
Type
Model
Evaporator
Quantity
Type
Evaporator model
Evaporator Water Content volume
Two pass evaporator
Evap. Water Flow rate - Minimum (3)
Evap. Water Flow rate - Maximum (3)
Nominal water connection size
(Grooved coupling)
Three pass evaporator
Evap. Water Flow rate - Minimum (3)
Evap. Water Flow rate - Maximum (3)
Nominal water connection size
(Grooved coupling)
Condenser
Quantity
Type
Condenser model
Condenser Water Content volume
Two pass condenser
Cond. Water Flow rate - Minimum
Cond. Water Flow rate - Maximum
Nominal water connection size
(Grooved coupling)
Dimensions (4)
Unit Length
Unit Width
Unit Height
Weights (5)
Shipping Weight
Operating Weight
System data (6)
Nb of refrigerant circuit
Minimum cooling load %
Standard unit
R1234ze refrigerant charge Circuit1 /
Circuit 2 (6)
Oil charge Circuit1 / Circuit 2
POE Oil type
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C - for detailed performances consult
order write up.
(2) Indicative performance at Evaporator water temperature: 10°C / 7°C - Condenser water temperature 40°C/45°C - for detailed performances consult
order write up.
(3) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(4) These dimensions are the maximum for a specifi c size, they may vary from one confi guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(5) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(6) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
RLC-SVX14H-GB
RTWD RTWD
100 110
HE HE
(kW) 359 394
(kW) 70 77
(kW) 386 425
(kW) 80 88
# 1/1 1/1
M1/M1 M1/M2
# 1 1
Flooded shell and tube heat exchanger
E3AM E3AM
(l) 91 91
(l/s) 11.8 11.8
(l/s) 43.1 43.1
(in) -
5" (139.7) 5" (139.7)
(mm)
(l/s) 7.8 7.8
(l/s) 28.7 28.7
(in) -
4" 4"
(mm) (114.3 mm) (114.3 mm)
# 1 1
C3AM C3AM
(l) 99 99
(l/s) 13 13
(l/s) 48 48
(in) -
6" 6"
(mm) (168.3 mm) (168.3 mm)
(mm) 3395 3395
(mm) 1148 1148
(mm) 1943 1943
(kg) TBD TBD
(kg) TBD TBD
# 2 2
% 0.30 0.30
(kg) TBD TBD
(l) TBD TBD
General data
RTWD RTWD RTWD
120 130 140
HE HE HE
434 476 534
84 93 98
467 513 576
96 106 111
1/1 1/1 1/1
Screw
M2/M2 M2/N5 N5/N5
1 1 1
E3AM E3AM E4AM
91 91 118
11.8 11.8 12.7
43.1 43.1 46.6
6"
5" (139.7) 5" (139.7)
(168.3 mm)
7.8 7.8 8.5
28.7 28.7 31.1
4" 4" 4"
(114.3 mm) (114.3 mm) (114.3 mm)
1 1 1
Shell and tube heat exchanger
C3AM C3AM C4AM
99 99 131
13 13 15
48 48 57
6" 6" 6"
(168.3 mm) (168.3 mm) (168.3 mm)
3395 3395 3811
1148 1148 1155
1943 1943 1998
TBD TBD TBD
TBD TBD TBD
2 2 2
0.30 0.30 0.30
TBD TBD TBD
TBD TBD TBD
OIL0066E or OIL0067E
RTWD RTWD
160 170
HE HE
584 636
107 117
630 684
122 133
1/1 1/1
N5/N6 N6/N6
1 1
E4AM E4AM
118 118
12.7 12.7
46.6 46.6
6" 6"
(168.3 mm) (168.3 mm)
8.5 8.5
31.1 31.1
4" 4"
(114.3 mm) (114.3 mm)
1 1
C4AM C4AM
131 131
15 15
57 57
6" 6"
(168.3 mm) (168.3 mm)
3811 3811
1155 1155
1998 1998
TBD TBD
TBD TBD
2 2
0.30 0.30
TBD TBD
TBD TBD
19
