General data
Table 4 - RTWD High Seasonal Effi ciency - R134a (Continued)
Indicative performances
Cooling Capacity (1)
Total Power input in cooling (1)
Heating Capacity (2)
Total Power input in heating (2)
Compressor
Compressor Number per Circuit
Type
Model
Evaporator
Quantity
Type
Evaporator model
Evaporator Water Content volume
Two pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s)
Evap. Water Flow rate - Maximum
(3)
Nominal water connection size
(Grooved coupling)
Three pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s)
Evap. Water Flow rate - Maximum
(3)
Nominal water connection size
(Grooved coupling)
Condenser
Quantity
Type
Condenser model
Condenser Water Content volume
Two pass condenser
Cond. Water Flow rate - Minimum
Cond. Water Flow rate - Maximum
Nominal water connection size
(Grooved coupling)
Dimensions (4)
Unit Length
Unit Width
Unit Height
Weights (5)
Shipping Weight
Operating Weight
System data (6)
Nb of refrigerant circuit
Minimum cooling load %
Standard unit
R134a refrigerant charge Circuit1 /
Circuit 2 (6)
Oil charge Circuit1 / Circuit 2
POE Oil type
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C - for detailed performances consult
order write up.
(2) Indicative performance at Evaporator water temperature: 10°C / 7°C - Condenser water temperature 40°C/45°C - for detailed performances consult
order write up.
(3) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(4) These dimensions are the maximum for a specifi c size, they may vary from one confi guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(5) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(6) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
14
RTWD RTWD
140 160
(kW) 531.1 597.7
(kW) 108.8 115.4
(kW) 562.2 629.2
(kW) 132.1 141.3
# 1/1 1/1
M1/M2 M2/M2
# 1 1
E3AM2 E3AM1
(l) 77.0 72.6
9.5 11.7
(l/s) 43.0
(in) -
DN125-5' DN150-6'
(mm) (139.7 mm) (168.3 mm) (168.3 mm)
6.4 7.8
(l/s) 23.3 28.6
(in) -
DN100-4' DN100-4'
(mm) (114.3 mm) (114.3 mm) (114.3 mm)
# 1 1
C3AM2 C3AM1
(l) 86.8 93.0
(l/s) 10.9 5.4
(l/s) 39.9 19.9
(in) -
DN150-6' DN150-6'
(mm) (168.3 mm) (168.3 mm) (168.3 mm)
(mm) 3400 3830
(mm) 1300 1300
(mm) 1950 2010
(kg) 3832 4168
(kg) 3996 4386
# 2 2
% 30 30
(kg) 45/45 45/45
(l) 6.8/6.8 6.8/6.8
RTWD RTWD RTWD
180 200 220
658.5 708.6 765.4
128.9 140.3 159.5
691.1 744.0 812.9
155.4 167.5 187.1
1/1 1/1 1/1
Screw
M2/N1 N1/N1 N1/N2
1 1 1
Flooded shell and tube heat exchanger
E3AMJ E5AM2 E5AM1
77.0 84.5 113.3
12.7 15.1 14.1
46.6 55.3
DN150-6' DN150-6' DN150-6'
(168.3 mm) (168.3 mm)
8.5 10.1 9.3
31 36.9 34.3
DN100-4' DN100-4' DN100-4'
(114.3 mm) (114.3 mm)
1 1 1
Shell and Tube Heat Exchanger
C3AMJ C5AM2 C5AM2
99.0 118 117.8
5.4 6.6 15.4
19.9 24.4 56.4
DN150-6' DN150-6' DN150-6'
(168.3 mm) (168.3 mm)
3830 3490 3490
1330 1340 1340
2010 2010 2010
4389 4571 4487
4622 4839 4718
2 2 2
30 30 30
45/44 55/55 55/56
6.8/6.8 6.8/6.8 6.8/9.9
OIL048E or OIL023E
RTWD RTWD RTWD
250 260 270
836.4 900.6 979.5
172.5 202.8 218.1
888.4 959.0 1032.9
202.5 230.0 248.8
1/1 1/1 1/1
N2/N2 N1/N2 N2:N2
1 1 1
E5AMJ E5AMJ E5AMJ
120.3 113.3 120.3
15.1 14.1 15.1
DN150-6' DN150-6' DN150-6'
(168.3 mm) (168.3 mm) (168.3 mm)
10.1 9.3 10.1
36.9 34.3 36.9
DN100-4' DN100-4' DN100-4'
(114.3 mm) (114.3 mm) (114.3 mm)
1 1 1
C5AM1 C5AM1 C5AM1
133.3 117.8 133.3
18.0 15.4 18.0
65.9 56.4 65.9
DN150-6' DN150-6' DN150-6'
(168.3 mm) (168.3 mm) (168.3 mm)
3490 3490 3490
1340 1340 1340
2010 2010 2010
4540 4487 4540
4793 4718 4793
2 2 2
30 30 30
55/55 54/54 61/61
9.9/9.9 9.9/9.9 9.9/9.9
