Specifications - Pioneer VSX-916-K Operating Instructions Manual

Additional information

Specifications

Amplifier section
• Continuous power output (stereo)
Front . . . . . . . .100 W (DIN 1kHz, THD 1.0 %, 8
• Power output (surround)
Front
. . . . . 100 W per channel (1 kHz, THD 1.0 %, 8
Center . . . . . . . . . . 100 W (1 kHz, THD 1.0 %, 8
Surround . . . . . . . . . . . . . . . . .100 W per channel
Surround Back. . . . . . . . . . . . .100 W per channel
Audio section
• Input (Sensitivity/Impedance)
CD, DVR/VCR, CD-R/TAPE/MD,
DVD/LD, TV/SAT. . . . . . . . . . . . . . . .200 mV/47 k
• Frequency response
CD, DVR/VCR, CD-R/TAPE/MD, DVD/LD,
TV/SAT . . . . . . . . . . . . . . 5 Hz to 100 000 Hz
• Output (Level/Impedance)
DVR/VCR REC, CD-R/TAPE/
MD REC . . . . . . . . . . . . . . . . . . . . . 200 mV/2.2 k
• Tone control
Bass . . . . . . . . . . . . . . . . . . . . . . . ± 6 dB (100 Hz)
Treble . . . . . . . . . . . . . . . . . . . . . . ± 6 dB (10 kHz)
Loudness . . . . . . +10 dB/+5 dB (100 Hz/10 kHz)
• Signal-to-Noise Ratio DIN (Continuous
rated power output / 50mW)
CD, DVR/VCR, CD-R/TAPE/MD,
DVD/LD, TV/SAT. . . . . . . . . . . . . . . . . 88 dB/64 dB
Video Section
• Input (Sensitivity/Impedance)
DVR/VCR, DVD/LD, TV/SAT . . . . . . . .1 Vp-p/75
• Output (Level/Impedance)
DVR/VCR, MONITOR OUT . . . . . . . . .1 Vp-p/75
Ω
Ω
Ω
Ω
(1 kHz, THD 1.0 %, 8
(1 kHz, THD 1.0 %, 8 Ω
Ω
dB
Ω
(at volume level –50 dB)
Ω
Ω
• Frequency response
DVR/VCR, DVD/LD,
TV/SAT MONITOR . . . . . . 5 Hz to 7 MHz
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . 55 dB
Crosstalk . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 dB
Component video section
)
• Input (Sensitivity)
DVD/LD, TV/SAT, DVR/VCR . . . . . . . . 1 Vp-p/75
)
• Output (Level/Impedance)
)
MONITOR OUT . . . . . . . . . . . . . . . . . . 1 Vp-p/75
• Frequency response
)
DVD/LD, TV/SAT,
)
DVR/VCR MONITOR . . . 5 Hz to 40 MHz
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . 60 dB
FM Tuner Section
Frequency Range . . . . . . . . 87.5 MHz to 108 MHz
Usable Sensitivity . . . . . . . . . . Mono:13.2 dBf, IHF
50 dB Quieting Sensitivity . . . . . . . Mono: 20.2 dB
Signal-to-Noise Ratio . . . Mono: 73 dB (at 85 dBf)
Distortion. . . . . . . . . . . . . . . .Stereo: 0.5 % (1 kHz)
Alternate Channel Selectivity . . . . . . . . . . . 60 dB
Stereo Separation. . . . . . . . . . . . . . . 40 dB (1 kHz)
Frequency Response . . . . . . . . . . 30 Hz to 15 kHz
Antenna Input (DIN). . . . . . . . . .75 Ω unbalanced
AM Tuner Section
Frequency Range . . . . . . . . .531 kHz to 1 602 kHz
Sensitivity (IHF, Loop antenna) . . . . . . . 350 µV/m
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . 50 dB
Antenna . . . . . . . . . . . . . . . . . . . . . . Loop antenna
Miscellaneous
Power requirements
. . . . . . . . . . . . . . . AC 220 V to 230 V, 50 Hz/60 Hz
Power consumption . . . . . . . . . . . . . . . . . . . 360 W
In standby . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 W
Dimensions
. . . . . 420 (W) mm x 158 (H) mm x 352.5 (D) mm
Weight (without package) . . . . . . . . . . . . . . 9.0 kg
dB
Ω
Ω
dB
(1.3 µV/ 75 Ω)
Stereo: 38.6 dBf
Stereo: 70 dB (at 85 dBf)
(400 kHz)
(±1 dB)
14
69
En
