Page 1 PROline Prosonic Flow 93 BA 079D/06/en/05.02 Nr. 50101739 FOUNDATION Fieldbus valid from software version: V 1.01.XX (amplifier) V 1.01.XX (communication) Ultrasonic Flow Measuring System Description of Device Functions Fieldbus Foundation 0000 0000 0001 0001 0002 0002 0003 0003 0004 0004...
Page 2 PROline Prosonic Flow 93 FOUNDATION Fieldbus Endress+Hauser...
Page 3 PROline Prosonic Flow 93 FOUNDATION Fieldbus Operation PROline Prosonic Flow 93 FOUNDATION Fieldbus - with local operation: see Page 5 - with FOUNDATION Fieldbus: see Page 85 Endress+Hauser...
Page 4 PROline Prosonic Flow 93 FOUNDATION Fieldbus Registered trademarks FOUNDATION Fieldbus™ Registered trademark of Fieldbus FOUNDATION, Austin, USA S-DAT™, T-DAT™, F-CHIP™, FieldTool™, FieldCheck™, Applicator™ Registered trademarks of Endress+Hauser Flowtec AG, Reinach, Switzerland Endress+Hauser...
Page 5: Table Of Contents
PROline Prosonic Flow 93 FOUNDATION Fieldbus Contents (local operation) Contents (local operation) Notes on using this manual ..........
Page 6 Contents (local operation) PROline Prosonic Flow 93 FOUNDATION Fieldbus Block BASIC FUNCTION ..........
Page 7: Notes On Using This Manual
PROline Prosonic Flow 93 FOUNDATION Fieldbus 1 Notes on using this manual Notes on using this manual There are various ways of locating the description of a function of your choice in the manual: Using the table of contents to locate a function description The designations of all the cells in the function matrix are listed in the table of contents.
Page 8: Function Matrix
2 Function matrix PROline Prosonic Flow 93 FOUNDATION Fieldbus Function matrix General layout of the function matrix The function matrix consists of four levels: Blocks → Groups → Function groups → Functions 0000 0001 0002 0003 0009 … 0400 0401...
Page 9: Codes Identifying Cells
PROline Prosonic Flow 93 FOUNDATION Fieldbus 2 Function matrix 2.1.5 Codes identifying cells Each cell (block, group, function group and function) in the function matrix has an individual, unique code. Blocks: The code is a letter (A, B, C, etc.) Groups: The code consists of three letters (AAA, ABA, BAA, etc.).
Page 10: Function Matrix Prosonic Flow 93 Foundation Fieldbus
2 Function matrix PROline Prosonic Flow 93 FOUNDATION Fieldbus 2.2 Function matrix Prosonic Flow 93 FOUNDATION Fieldbus BLOCKS GROUPS FUNCTION GROUPS → → MEASURED VARIABLES A MEASURED VALUES see Page 12 → (see Page 11) SYSTEM UNITS see Page 15 ↓...
Page 11: Block Measured Variables
Function Block Groups Functions groups MEASURED MEASURED MAIN VALUES VOLUME FLOW SOUND VELOC. FLOW SIG.STRENGTH Þ Þ Þ Þ VARIABLES VALUES VELOCITY CH1 (AAA) P. 12 (000) P. 12 (0001) P. 12 (0002) P. 12 (0003) P. 12 (0007) P. 12 ß...
Page 12: Group Measured Values
3 Block MEASURED VARIABLES PROline Prosonic Flow 93 FOUNDATION Fieldbus Group MEASURED VALUES 3.1.1 Function group: MAIN VALUES CH1 MEASURED Þ Þ MEASURED VALUES MAIN VALUES CH1 VARIABLES Function description → → MEASURED VARIABLES MEASURED VALUES MAIN VALUES CH1 Use this function group to display the channel 1 measured values currently measured.
Page 13: Function Group: Main Values Ch2
PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Block MEASURED VARIABLES 3.1.2 Function group: MAIN VALUES CH2 MEASURED Þ Þ MEASURED VALUES MAIN VALUES CH1 VARIABLES ß MAIN VALUES CH2 Function description → → MEASURED VARIABLES MEASURED VALUES MAIN VALUES CH2 Use this function group to display the channel 2 measured values currently measured.
Page 14: Function Group: Calculated Main Values
3 Block MEASURED VARIABLES PROline Prosonic Flow 93 FOUNDATION Fieldbus 3.1.3 Function group: CALCULATED MAIN VALUES MEASURED Þ Þ MEASURED VALUES MAIN VALUES CH1 VARIABLES ß MAIN VALUES CH2 ß CALC. MAIN VALUES Function description → → MEASURED VARIABLES MEASURED VALUES CALCULATED MAIN VALUES Displays the calculated measured values.
Page 15: Group System Units
PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Block MEASURED VARIABLES Group SYSTEM UNITS 3.2.1 Function group: CONFIGURATION MEASURED Þ MEASURED VALUES VARIABLES ß Þ SYSTEM UNITS CONFIGURATION Function description → → MEASURED VARIABLES SYSTEM UNITS CONFIGURATION Use this function group to select the units for the measured variables.
Page 16: Function Description
3 Block MEASURED VARIABLES PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → MEASURED VARIABLES SYSTEM UNITS CONFIGURATION UNIT VOLUME Use this function to select the unit for displaying the volume. (0403) Options: Metric: → Cubic centimetre cm³ →...
Page 17: Funktion Group: Additional Configuration
PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Block MEASURED VARIABLES 3.2.2 Funktion group: ADDITIONAL CONFIGURATION MEASURED Þ MEASURED VALUES VARIABLES ß Þ SYSTEM UNITS CONFIGURATION ß ADDIT. CONFIG. Function description → → MEASURED VARIABLES SYSTEM UNITS ADDITIONAL CONFIGURATION Note! The units selected here have no effect on the FOUNDATION Fieldbus. They are only used for the local display and for assigned instrument functions.
Page 18: Function Description
3 Block MEASURED VARIABLES PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → MEASURED VARIABLES SYSTEM UNITS ADDITIONAL CONFIGURATION UNIT VELOCITY Use this function to select the unit for the velocity. The unit selected is valid for (0425) the sound and flow velocity.
Page 19: Block Quick Setup
PROline Prosonic Flow 93 FOUNDATION Fieldbus 4 Block QUICK SETUP Block QUICK SETUP Function Block Group Functions groups SETUP QUICK SETUP T-DAT SAVE/ QUICK SETUP Þ Þ Þ SENSOR COMMISSION. LOAD (1001) P. 19 (1002) P. 19 (1009) P. 19...
Page 20: Sensor Quick Setup
4 Block QUICK SETUP PROline Prosonic Flow 93 FOUNDATION Fieldbus 4.0.1 Sensor Quick Setup ENDRESS+HAUSER 1001 Setup Quick Setup Sensor 2000 HOME-POSITION HOME-POSITION Language ➀ Sensor Units Channel ➁ Selection Channel 2 Channel 1 Channels 6880 Measurement ➂ Selection Sound Velocity...
Page 21: Display
PROline Prosonic Flow 93 FOUNDATION Fieldbus 4 Block QUICK SETUP Note! • The display returns to the SETUP SENSOR (1001) cell if you press the ESC key combination during parameter interrogation. • See numbers in the illustration of the Quick Setup sensor menu: ➀...
Page 22: Commissioning Quick Setup
4 Block QUICK SETUP PROline Prosonic Flow 93 FOUNDATION Fieldbus 4.0.2 Commissioning Quick Setup ENDRESS+HAUSER 1002 Quick Setup Commission 2000 Language HOME-POSITION Presetting System Units ➀ Selection Viscosity Volume flow Temperature Length Velocity Quit System units 0402 0422 0423 0424...
Page 23: Block User Interface
Function Block Groups Functions groups USER CONTROL BASIC CONFIG. LANGUAGE DISPLAY CONTRAST X-LINE CALC. Þ Þ Þ Þ INTERFACE DAMPING MAIN VAL. (CAA) P. 24 (200) P. 24 (2000) P. 24 (2002) P. 24 (2003) P. 24 (2003) P. 24 ß...
Page 24: Group Control
5 Block USER INTERFACE PROline Prosonic Flow 93 FOUNDATION Fieldbus Group CONTROL 5.1.1 Function group: BASIC CONFIGURATION Þ Þ USER INTERFACE CONTROL BASIC CONFIGURATION 200 Function description → → USER INTERFACE CONTROL BASIC CONFIGURATION LANGUAGE Use this function to select the language for all texts, parameters and (2000) messages shown on the local display.
Page 25: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE Function description → → USER INTERFACE CONTROL BASIC CONFIGURATION X-LINE CALCULATED Use this function to indicate which “calculated main value” from the measured MAIN VALUES values of both channels is displayed.
Page 26: Function Group: Unlocking/Locking
• You can also disable programming in this function by entering any number (other than the defined private code). • The Endress+Hauser service organisation can be of assistance if you mislay your personal code. • Access to programming is only valid for local operation in this function. If functions or parameters are to be changed via the FOUNDATION Fieldbus, programming must be enabled separately in the “Un/Locking - Access...
Page 27: Function Group: Operation
PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE 5.1.3 Function group: OPERATION Þ Þ USER INTERFACE CONTROL BASIC CONFIGURATION 200 ß UNLOCKING/LOCKING 202 ß OPERATION Function description → → USER INTERFACE CONTROL OPERATION TEST DISPLAY Use this function to test the operability of the local display and its pixels.
Page 28: Group Main Line
5 Block USER INTERFACE PROline Prosonic Flow 93 FOUNDATION Fieldbus Group MAIN LINE 5.2.1 Function group: CONFIGURATION Þ USER INTERFACE CONTROL ß Þ MAIN LINE CONFIGURATION Function description → → USER INTERFACE MAIN LINE CONFIGURATION ENDRESS+HAUSER A = main line, B = additional line, C = information line...
Page 29: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE Function description → → USER INTERFACE MAIN LINE CONFIGURATION 100% VALUE Note! (2201) This function is not available unless one of the following options was selected in the ASSIGN (2200) function: •...
Page 30: Function Group: Multiplex
5 Block USER INTERFACE PROline Prosonic Flow 93 FOUNDATION Fieldbus 5.2.2 Function group: MULTIPLEX Þ USER INTERFACE CONTROL ß Þ MAIN LINE CONFIGURATION ß MULTIPLEX Function description → → USER INTERFACE MAIN LINE MULTIPLEX ASSIGN Use this function to define the second reading to be displayed in the main line...
Page 31: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE Function description → → USER INTERFACE MAIN LINE MULTIPLEX 100% VALUE Note! (2221) This function is not available unless one of the following options was selected in the ASSIGN (2220) function: •...
Page 32: Group Additional Line
5 Block USER INTERFACE PROline Prosonic Flow 93 FOUNDATION Fieldbus Group ADDITIONAL LINE 5.3.1 Function group: CONFIGURATION Þ USER INTERFACE CONTROL ß MAIN LINE ß Þ ADDITIONAL LINE CONFIGURATION Function description → → USER INTERFACE ADDITIONAL LINE CONFIGURATION ENDRESS+HAUSER A = main line, B = additional line, C = information line...
Page 33: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE Function description → → USER INTERFACE ADDITIONAL LINE CONFIGURATION Contd: Options (contd.): ASSIGN PID - IN VALUE (controlled variable) (2400) PID - CAS IN VALUE (remote setpoint value) PID - OUT VALUE (manipulated variable)
Page 34: Function Description
5 Block USER INTERFACE PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → USER INTERFACE ADDITIONAL LINE CONFIGURATION DISPLAY MODE Note! (2403) This function is not available unless one of the following options was selected in the ASSIGN (2400) function: •...
Page 35: Function Group: Multiplex
PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE 5.3.2 Function group: MULTIPLEX Þ USER INTERFACE CONTROL ß MAIN LINE ß Þ ADDITIONAL LINE CONFIGURATION ß MULTIPLEX Function description → → USER INTERFACE ADDITIONAL LINE MULTIPLEX ASSIGN Use this function to define the second reading to be displayed in the additional...
Page 36: Function Description
5 Block USER INTERFACE PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → USER INTERFACE ADDITIONAL LINE MULTIPLEX Contd: Note! ASSIGN Multiplex mode is suspended as soon as a fault/notice message is generated. (2420) The appropriate error message appears on the display: •...
Page 37: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE Function description → → USER INTERFACE ADDITIONAL LINE MULTIPLEX DISPLAY MODE Note! (2423) This function is not available unless one of the following options was selected in the ASSIGN (2420) function: •...
Page 38: Group Information Line
5 Block USER INTERFACE PROline Prosonic Flow 93 FOUNDATION Fieldbus Group INFORMATION LINE 5.4.1 Function group: CONFIGURATION Þ USER INTERFACE CONTROL ß MAIN LINE ß ADDITIONAL LINE ß Þ INFORMATION LINE CONFIGURATION Function description → → USER INTERFACE INFORMATION LINE...
Page 39: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE Function description → → USER INTERFACE INFORMATION LINE CONFIGURATION ASSIGN Options (contd.): (2600) AI 1 - OUT VALUE (contd.) AI 2 - OUT VALUE AI 3 - OUT VALUE AI 4 - OUT VALUE...
Page 40: Function Description
5 Block USER INTERFACE PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → USER INTERFACE INFORMATION LINE CONFIGURATION DISPLAY MODE Note! (2603) This function is not available unless one of the following options was selected in the ASSIGN (2600) function: •...
Page 41: Function Group: Multiplex
PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE 5.4.2 Function group: MULTIPLEX Þ USER INTERFACE CONTROL ß MAIN LINE ß ADDITIONAL LINE ß Þ INFORMATION LINE CONFIGURATION ß MULTIPLEX Function description → → USER INTERFACE INFORMATION LINE MULTIPLEX...
Page 42: Function Description
5 Block USER INTERFACE PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → USER INTERFACE INFORMATION LINE MULTIPLEX Contd: Note! ASSIGN Multiplex mode is suspended as soon as a fault/notice message is generated. (2620) The appropriate error message appears on the display: •...
Page 43: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE Function description → → USER INTERFACE INFORMATION LINE MULTIPLEX DISPLAY MODE Note! (2623) This function is not available unless one of the following options was selected in the ASSIGN (2620) function: •...
Page 44: Block Totalizers
Function Block Groups Functions groups TOTALIZERS TOTALIZER 1 CONFIGURA- ASSIGN UNIT TOTALIZER RESET Þ Þ Þ Þ TION TOTALIZER MODE TOTALIZER (DAA) P. 45 (300) P. 45 (3000) P. 45 (3001) P. 46 (3002) P. 46 (3003) P. 46 ß Ý ß...
Page 45: Group Totalizer (1
PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 Block TOTALIZERS Group TOTALIZER (1...3) 6.1.1 Function group: CONFIGURATION Þ Þ TOTALIZERS TOTALIZER 1 CONFIGURATION ß Þ TOTALIZER 2 CONFIGURATION ß Þ TOTALIZER 3 CONFIGURATION Function description → → TOTALIZERS TOTALIZER (1...3) CONFIGURATION The function descriptions below apply to totalizers 1...3;...
Page 46: Function Description
6 Block TOTALIZERS PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → TOTALIZERS TOTALIZER (1...3) CONFIGURATION UNIT TOTALIZER Use this function to define the unit for the totalizer's measured variable, as (3001) selected beforehand. Options: Metric: → Cubic centimetre cm³...
Page 47: Function Group: Operation
PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 Block TOTALIZERS 6.1.2 Function group: OPERATION Þ Þ TOTALIZERS TOTALIZER 1 CONFIGURATION ß ß OPERATION Þ TOTALIZER 2 CONFIGURATION ß ß OPERATION Þ TOTALIZER 3 CONFIGURATION ß OPERATION Function description → → TOTALIZERS TOTALIZER (1...3)
Page 48: Group Handling Totalizers
6 Block TOTALIZERS PROline Prosonic Flow 93 FOUNDATION Fieldbus Group HANDLING TOTALIZERS Þ TOTALIZERS TOTALIZER 1 ß TOTALIZER 2 ß TOTALIZER 3 ß Þ HANDLING TOTALIZERS DJA Handling totalizer functions Function description → → TOTALIZERS HANDLING TOTALIZERS Handling totalizer functions...
Page 49: Block Basic Function
Function Block Groups Functions groups BASIC FOUNDATION CONFIGURATI WRITE SIMULATION DEVICE Þ Þ Þ Þ FUNCTION FIELDBUS PROTECT PD-TAG (GGA) P. 50 (620) P. 50 (6200) P. 50 (6201) P. 50 (6203) P. 50 ß Ý ß Ý FUNCTION BLOCK OUT VALUE PID_IN VALUE CASCADE IN...
Page 50: Group Foundation Fieldbus
7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus Group FOUNDATION FIELDBUS 7.1.1 Function group: CONFIGURATION Þ Þ BASIC FUNCTION FOUNDATION FIELDBUS GGA CONFIGURATION Function description → → BASIC FUNCTION FOUNDATION FIELDBUS CONFIGURATION WRITE PROTECT Use this function to check whether the device parameters can be accessed (6200) via the FOUNDATION Fieldbus.
Page 51: Function Group: Function Blocks
PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Block BASIC FUNCTION 7.1.2 Function group: FUNCTION BLOCKS Þ Þ BASIC FUNCTION FOUNDATION FIELDBUS GGA CONFIGURATION ß FUNCTION BLOCKS Function description → → BASIC FUNCTION FOUNDATION FIELDBUS FUNCTION BLOCKS BLOCK SELECTION Use this function to select a function block whose value and status is shown in the subsequent functions.
Page 52: Function Group: Information
7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus 7.1.3 Function group: INFORMATION Þ Þ BASIC FUNCTION FOUNDATION FIELDBUS GGA CONFIGURATION ß FUNCTION BLOCKS ß INFORMATION Function description → → BASIC FUNCTION FOUNDATION FIELDBUS OPERATION MANUFACTURER ID Displays the manufacturer ID.
Page 53: Group Process Parameter (Ch1
PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Block BASIC FUNCTION Group PROCESS PARAMETER (CH1...CH2) 7.2.1 Function group: CONFIGURATION Þ BASIC FUNCTION FOUNDATION FIELDBUS GGA ß Þ PROCESS PARAM. CH1 GIA CONFIGURATION ß Þ PROCESS PARAM. CH2 GIB CONFIGURATION Function description →...
Page 54: Function Description
7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → BASIC FUNCTION PROCESS PARAMETER (CH1...CH2) CONFIGURATION PRESSURE SHOCK The closure of a valve can cause brief but severe movements of the liquid in SUPPRESSION the piping system, movements which the measuring system registers. The...
Page 55: Function Group: Adjustment
PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Block BASIC FUNCTION 7.2.2 Function group: ADJUSTMENT Þ BASIC FUNCTION FOUNDATION FIELDBUS GGA ß Þ PROCESS PARAM. CH1 GIA CONFIGURATION ß ADJUSTMENT ß Þ PROCESS PARAM. CH2 GIB CONFIGURATION ß ADJUSTMENT Function description →...
Page 56: Function Group: Pipe Data
7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus 7.2.3 Function group: PIPE DATA Þ BASIC FUNCTION FOUNDATION FIELDBUS GGA ß Þ PROCESS PARAM. CH1 GIA CONFIGURATION ß ADJUSTMENT ß PIPE DATA ß Þ PROCESS PARAM. CH2 GIB CONFIGURATION ß...
Page 57: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Block BASIC FUNCTION Function description → → BASIC FUNCTION PROCESS PARAMETER (CH1...CH2) PIPE DATA NOMINAL DIAMETER Use this function to select the nominal diameter of the pipe. (6521) Options: OTHERS DN 25/1" DN 40/1½"...
Page 58: Function Description
7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → BASIC FUNCTION PROCESS PARAMETER (CH1...CH2) PIPE DATA REFERENCE VALUE Note! (6523) This function does not appear unless “SOUND VELOCITY PIPE” was selected in the MEASUREMENT function (6880, Page 63).
Page 59: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Block BASIC FUNCTION Function description → → BASIC FUNCTION PROCESS PARAMETER (CH1...CH2) PIPE DATA WALL THICKNESS Use this function to enter the thickness of the pipe walls. (6527) Measuring the wall thickness If the wall thickness is not known, it can be measured.
Page 60: Function Group: Liquid Data
7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus 7.2.4 Function group: LIQUID DATA Þ BASIC FUNCTION FOUNDATION FIELDBUS GGA ß Þ PROCESS PARAM. CH1 GIA CONFIGURATION ß ADJUSTMENT ß PIPE DATA ß LIQUID DATA ß Þ PROCESS PARAM. CH2 GIB CONFIGURATION ß...
Page 61: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Block BASIC FUNCTION Function description → → BASIC FUNCTION PROCESS PARAMETER (CH1...CH2) LIQUID DATA SOUND VELOCITY Use this function to enter the sound velocity of the liquid. LIQUID (6542) Measuring the sound velocity of the liquid If the sound velocity of the liquid is not known, it can be measured.
Page 62: Group System Parameter (Ch1
7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus Group SYSTEM PARAMETER (CH1...CH2) 7.3.1 Function group: CONFIGURATION Þ BASIC FUNCTION FOUNDATION FIELDBUS GGA ß PROCESS PARAM. CH1 GIA ß PROCESS PARAM. CH2 GIB ß Þ SYSTEM PARAM. CH1 CONFIGURATION ß...
Page 63: Group Sensor Data (Ch1
PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Block BASIC FUNCTION Group SENSOR DATA (CH1...CH2) 7.4.1 Function group: SENSOR PARAMETER Þ BASIC FUNCTION FOUNDATION FIELDBUS GGA ß PROCESS PARAM. CH1 GIA ß PROCESS PARAM. CH2 GIB ß SYSTEM PARAM. CH1 ß...
Page 64: Function Description
7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → BASIC FUNCTION SENSOR DATA (CH1...CH2) SENSOR PARAMETER SENSOR TYPE Note! (6881) This function is only available if “OFF” was not selected in the MEASUREMENT function (6880, see Page 63).
Page 65: Function Description
PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Block BASIC FUNCTION Function description → → BASIC FUNCTION SENSOR DATA (CH1...CH2) SENSOR PARAMETER SENSOR Note! CONFIGURATION This function is not available unless one of the following options was selected (6882) in the MEASUREMENT function (6880): •...
Page 66: Function Description
7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → BASIC FUNCTION SENSOR DATA (CH1...CH2) SENSOR PARAMETER WIRE LENGTH Note! (6885) This function is not available unless “CLAMP ON” is set in the MEASUREMENT function (6880, see Page 63), and the number of traverses selected in the SENSOR CONFIGURATION function (6882, see Page 65) is 1 or 3.
Page 67: Function Group: Calibration Data
PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Block BASIC FUNCTION 7.4.2 Function group: CALIBRATION DATA Þ BASIC FUNCTION FOUNDATION FIELDBUS GGA ß PROCESS PARAM. CH1 GIA ß PROCESS PARAM. CH2 GIB ß SYSTEM PARAM. CH1 ß SYSTEM PARAM. CH2 ß...
Page 68: Function Description
7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → BASIC FUNCTION SENSOR DATA (CH1...CH2) CALIBRATION DATA DEVIATION ARC Note! LENGTH This function is not available unless “INSERTION” is set in the MEASUREMENT (6895) function (6880, see Page 63) and “DUAL PATH” was selected in the SENSOR CONFIGURATION function (6882, see Page 65).
Page 69: Display
Function Block Groups Functions groups SUPERVISION SYSTEM CONFIGURA- ALARM DELAY Þ Þ Þ TION (JAA) P. 70 (800) P. 70 (8005) P. 70 ß Ý ß Ý OPERATION ACT. SYS. PREV. SYS. SIM. SIM. VALUE SIM. SYSTEM RESET TROUBLE- Þ Þ...
Page 70: Block Supervision
8 Block SUPERVISION PROline Prosonic Flow 93 FOUNDATION Fieldbus Group SYSTEM 8.1.1 Function group: CONFIGURATION Þ Þ SUPERVISION SYSTEM CONFIGURATION Function description → → SUPERVISION SYSTEM CONFIGURATION ALARM DELAY Use this function to specify a time period for suppressing the appearance of (8005) fault or notice messages.
Page 71: Function Group: Operation
CONDITION (8040) Note! All error messages are described in detail in the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA 078D/06/en. Display: “SYSTEM OK” or the fault/notice message with the highest priority. PREVIOUS SYSTEM Use this function to view the fifteen most recent fault and notice messages CONDITIONS since measuring last started.
Page 72: Function Description
8 Block SUPERVISION PROline Prosonic Flow 93 FOUNDATION Fieldbus Function description → → SUPERVISION SYSTEM OPERATION VALUE SIMULATION Note! MEASURAND This function is not displayed unless the SIMULATION (8044) MEASURAND (8043) function is active. Use this function to specify a selectable value, (e.g. 12 m³/s). This is used to test the associated functions in the flowmeter itself and downstream FOUNDATION Fieldbus function blocks.
Page 73: Group System Ch2
PROline Prosonic Flow 93 FOUNDATION Fieldbus 8 Block SUPERVISION Group SYSTEM CH2 8.2.1 Function group: OPERATION Þ SUPERVISION SYSTEM ß Þ SYSTEM CH2 OPERATION Function description → → SUPERVISION SYSTEM CH2 OPERATION SIMULATION Use this function to activate the simulation of a measured variable.
Page 74: Group Version-Info
8 Block SUPERVISION PROline Prosonic Flow 93 FOUNDATION Fieldbus Group VERSION-INFO 8.3.1 Function group: SENSOR Þ SUPERVISION SYSTEM ß SYSTEM CH2 ß Þ VERSION-INFO SENSOR Function description → → SUPERVISION VERSION-INFO SENSOR SERIAL NUMBER Displays the serial number of the sensor.
Page 75: Function Group: F-Chip
PROline Prosonic Flow 93 FOUNDATION Fieldbus 8 Block SUPERVISION 8.3.3 Function group: F-CHIP Þ SUPERVISION SYSTEM ß SYSTEM CH2 ß Þ VERSION-INFO SENSOR ß AMPLIFIER ß F-CHIP Function description → → SUPERVISION VERSION-INFO F-CHIP STATUS F-CHIP Use this function to check whether an F-CHIP is installed and which software (8240) options are available.
Page 76: Factory Settings
9 Factory settings PROline Prosonic Flow 93 FOUNDATION Fieldbus Factory settings SI units (not for USA and Canada) 9.1.1 Low flow cut off, totalizer Nominal diameter Low flow cut off / flow unit Totalizer unit [mm] [inch] (approx. v = 0.04 m/s)
Page 77: Us Units (Only For Usa And Canada)
PROline Prosonic Flow 93 FOUNDATION Fieldbus 9 Factory settings 9.2 US units (only for USA and Canada) 9.2.1 Low flow cut off, totalizer Nominal diameter Low flow cut off / flow unit Totalizer unit [inch] [mm] (approx. v = 0.04 m/s)
Page 78: Display
9 Factory settings PROline Prosonic Flow 93 FOUNDATION Fieldbus Endress+Hauser...
Page 79: Index (Function Matrix)
PROline Prosonic Flow 93 FOUNDATION Fieldbus 10 Index (function matrix) 10 Index (function matrix) Blöcke .....11 ......70...
Page 80 10 Index (function matrix) PROline Prosonic Flow 93 FOUNDATION Fieldbus 2... (continued) ......36 .
Page 81: Index (Local Operation)
PROline Prosonic Flow 93 FOUNDATION Fieldbus 11 Index (local operation) 11 Index (local operation) Actual system conditions ......71 Sensor distance .
Page 82 11 Index (local operation) PROline Prosonic Flow 93 FOUNDATION Fieldbus (continued "Function group") ......71 Operation (system) .
Page 83 PROline Prosonic Flow 93 FOUNDATION Fieldbus 11 Index (local operation) Unit Sensor Length ........17 Configuration.
Page 84 11 Index (local operation) PROline Prosonic Flow 93 FOUNDATION Fieldbus Endress+Hauser...
Page 85 PROline Prosonic Flow 93 FOUNDATION Fieldbus Contents (FOUNDATION Fieldbus) Contents (FOUNDATION Fieldbus) Operation via FOUNDATION Fieldbus ........
Page 86 Contents (FOUNDATION Fieldbus) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) ........
Page 87: Operation Via Foundation Fieldbus
– One Discrete Output, see Page 184. – One PID function block (PID controller), see Page 197. Analog Input Transducer Function Block Block FOUNDATION Fieldbus Discrete Output Block Resource Block Block Fig. 1: PROline Prosonic Flow 93 FOUNDATION Fieldbus block model Endress+Hauser...
Page 88 By means of the Discrete Output function block (DO), various actions and functions in PROline Prosonic Flow 93 FOUNDATION Fieldbus can be initiated or controlled via the FOUNDATION Fieldbus, such as resetting the totalizers, for example.
Page 89: Resource Block
PROline Prosonic Flow 93 FOUNDATION Fieldbus 2 Resource Block Resource Block A Resource Block contains all the data which uniquely identify and characterise the field device. It is an electronic version of a nameplate on the field device. Parameters of the Resource Block include device type, device name, manufacturer ID, serial number, etc.
Page 90: Write Protection And Simulation
2 Resource Block PROline Prosonic Flow 93 FOUNDATION Fieldbus Write protection and simulation Write protection of the device parameters and simulation in the Analog Input and Discrete Output function block can be enabled or disabled via jumpers on the FOUNDATION Fieldbus I/O board, (see Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en, Section 5.4).
Page 91: Resource Block Parameters
PROline Prosonic Flow 93 FOUNDATION Fieldbus 2 Resource Block Resource Block parameters The following table lists both the FOUNDATION Fieldbus parameters and the Endress+Hauser-specific parameters, (from Page 99), of the Resource Block: Resource Block / base index 258 Parameter Write access with...
Page 92 Simulation possible in the Analog Input function block via the SIMULATE parameter and in the Discrete Output function block via the SIMULATE_D parameter, (see also settings for simulation mode in the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en, Section 5.4). OUT OF SERVICE The block has the status "Out of Service".
Page 93 PROline Prosonic Flow 93 FOUNDATION Fieldbus 2 Resource Block Resource Block / base index 258 Parameter Write access with Description operating mode (MODE_BLK) DD_REV read only Displays the revision number of the device description. Note! This display can be used to check whether the correct system files (DD = Device Description) are being used for linking into the host system.
Page 94 Displays the free system time (in percent) available for execution of further function blocks. Note! Since the function blocks of PROline Prosonic Flow 93 FF are permanently configured, this parameter always displays the value FREE_SPACE read only Displays the free system memory (in percent) available for execution of further function blocks.
Page 95 The time interval displayed relates to storage of the following dynamic device parameters: • OUT • PV • FIELD_VAL Note! Since PROline Prosonic Flow 93 FF does not store the dynamic device parameter in the non-volatile memory, this parameter always displays the value 0 Endress+Hauser...
Page 96 2 Resource Block PROline Prosonic Flow 93 FOUNDATION Fieldbus Resource Block / base index 258 Parameter Write access with Description operating mode (MODE_BLK) RESTART AUTO - OOS This parameter is used to reset the field device in various ways. Options: UNINITIALIZED Normal operating status.
Page 97 PROline Prosonic Flow 93 FOUNDATION Fieldbus 2 Resource Block Resource Block / base index 258 Parameter Write access with Description operating mode (MODE_BLK) SHED_ROUT AUTO - OOS Specifies the monitoring time for checking the connection between the fieldbus host system and the PID function block in the ROUT operating mode.
Page 98 NOT LOCKED Device data can be modified via the FOUNDATION Fieldbus. Note! For information on hardware write protection configuration, see the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en, Section 5.4. WRITE_PRI AUTO - OOS Specifies the action taken in the event of a write protection alarm, (WRITE_ALM parameter, see Page 97).
Page 99 PROline Prosonic Flow 93 FOUNDATION Fieldbus 2 Resource Block Resource Block / base index 258 Parameter Write access with Description operating mode (MODE_BLK) Endress+Hauser parameters (manufacturer-specific) Sensor - read only Displays the sensor serial number. Serial Number Amplifier - read only Displays the hardware revision number of the amplifier.
Page 100: Transducer Blocks (Transmission Blocks)
PROline Prosonic Flow 93 FOUNDATION Fieldbus Transducer Blocks (transmission blocks) Overview PROline Prosonic Flow 93 FOUNDATION Fieldbus's Transducer Blocks contain all the measuring and device-specific parameters of the flowmeter. The settings directly connected with flow measurement or the application are made here. They form the interface between sensor-specific measured value preprocessing and the Analog Input function blocks required for automation.
Page 101 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) Transducer Block “TRANSDUCER_CH1”, Flow Channel 1 (Basic index 1200) Simulation - Value Measurand Signals CH1 Volume Simulation - System Param. - CH 2 Flow CH1 Measurand Positive Zero Return...
Page 102: Signal Processing
3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus Signal processing The Transducer Blocks TRANSDUCER_CH1 (flow channel 1, base index 1200) and TRANSDUCER_CH2 (flow channel 2, base index 1300) receive several signal variables as input values from the sensor, (sound velocity, flow velocity). Other process variables are derived from these signal variables, (see Section 3.3 Block output values).
Page 103: Block Output Values
PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) Block output values The Transducer Blocks make the following output values (process variables) available to the downstream Analog Input function blocks: • Transducer Block TRANSDUCER_CH1 (flow channel 1, base index 1200): –...
Page 104: Selecting The Operating Mode
Analog Input function block. • Please refer to the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en, if problems arise when configuring the function blocks. Alarm detection and processing The Transducer Blocks do not generate any process alarms.
Page 105: Diagnosis
Transducer Block TRANSDUCER_DIAG (base index 1600) in the “Diagnosis - Actual System Condition” parameter, (see Page 156). More information on eliminating errors can be found in the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA 078D/06/en. Access to manufacturer-specific parameters...
Page 106: Foundation Fieldbus Parameters Of The Transducer Blocks
3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus FOUNDATION Fieldbus parameters of the Transducer Blocks The following table provides you with a description of all the specified FOUNDATION Fieldbus parameters of the Transducer Blocks. The E+H-specific parameters are explained from Page 109 onwards.
Page 107 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) FOUNDATION Fieldbus parameters (Transducer Blocks, transmission blocks) Parameter Write access Description with operating mode (MODE_BLK) MODE_BLK AUTO - OOS Displays the current (Actual) and desired (Target) operating mode of the relevant Transducer Block, the permitted modes (Permitted) supported by the Transducer Block in question and the normal operating mode (Normal).
Page 108 • In addition, the active block alarm can be acknowledged in this parameter group. • PROline Prosonic Flow 93 FF does not use this parameter to display a process alarm since these are generated in the BLOCK_ALM parameter of the Analog Input function block, (see Page 169).
Page 109: Overview Of Transducer Blocks With E+H Parameters
(More detailed information on write protection is provided in the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en, Section 5.4). • You can disable programming again by entering any number (other than the access code) in this parameter.
Page 110 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) System Value - read only Displays the current volume flow. The volume flow is made...
Page 111 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) System Value - read only Displays the current sound velocity. The sound velocity is made...
Page 112 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) System Unit - AUTO - OOS For selecting the unit for the viscosity of the fluid.
Page 113 (see Page 126). Options: CANCEL START Factory setting: CANCEL Caution! Before carrying this out, please refer to the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, (BA078D/ 06/en), for a detailed description of the procedure for zero point adjustment. Endress+Hauser...
Page 114 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Low Flow Cut Off AUTO - OOS Use this function to assign the switch point for the low flow cut off.
Page 115 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Pressure Shock AUTO - OOS The closure of a valve can cause brief but severe movements of...
Page 116 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Pipe Data - AUTO - OOS For selecting the standard pipe.
Page 117 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Pipe Data - AUTO - OOS For selecting the pipe material.
Page 118 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Pipe Data - AUTO - OOS Entry of the sound velocity in the pipe.
Page 119 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Pipe Data - read only Displays the unit for the pipe circumference.
Page 120 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Pipe Data - read only Displays the unit for the sound velocity of the liner.
Page 121 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Liquid Data - AUTO - OOS Entry of the liquid temperature.
Page 122 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Liquid Data - read only Displays the unit for the minimum liquid sound velocity selected in Unit Min.
Page 123 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Sensor Param. - AUTO - OOS Note! Sensor Type This parameter is only active if "OFF" was not selected in the “Sensor Param.
Page 124 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Sensor Param. - AUTO - OOS Note! Sensor This parameter is not active unless one of the following options Configuration was selected in the “Sensor Param.
Page 125 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Sensor Param. - read only Note! Wire Length This parameter is not active unless "CLAMP ON" was selected in the “Sensor Param.
Page 126 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Sensor Param. - read only Displays the unit used for the display in the “Sensor Param. - ARC Unit ARC Length Length”...
Page 127 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_CH1” and “TRANSDUCER_CH2” (E+H parameters) / Base index 1200 and 1300 Parameter Write access Description with operating mode (MODE_BLK) Calibration Data - read only Displays the unit used for the entry in the “Calibration Data - Unit Deviation Deviation Sensor Distance”...
Page 128 • The simulation functions independently of the position of the relevant jumpers on the I/O board, (see Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en, Section 5.4). • The setting is not saved if the power supply fails.
Page 129: E+H Parameters: Transducer Block "Transducer_Disp" (Display)
(More detailed information on write protection is provided in the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en, Section 5.4). • You can disable programming again by entering any number (other than the access code) in this parameter.
Page 130 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Configuration - AUTO - OOS Use this parameter to select the language for all texts, parameters Language and messages shown on the local display.
Page 131 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Configuration - AUTO - OOS Use this parameter to indicate which “calculated main value” from Xline the measured values of both channels is displayed.
Page 132 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) A = Main line, B = Additional ENDRESS+HAUSER line, C = Information line Main Line -...
Page 133 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Main Line - AUTO - OOS Note! 100%-Value The input is not active unless one of the following was selected in the "Main Line - Assign"...
Page 134 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Main Line AUTO - OOS Use this parameter to define the second reading to be displayed in...
Page 135 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Main Line AUTO - OOS Use this parameter to define the maximum number of places after Multiplex - the decimal point for the second value displayed in the main line.
Page 136 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) A = Main line, B = Additional ENDRESS+HAUSER line, C = Information line Add. Line -...
Page 137 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Add. Line - AUTO - OOS Note! 100%-Value The input is not active unless one of the following was selected in the "Add.
Page 138 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Add. Line - AUTO - OOS Note! Display Mode Selection is not active unless one of the following was selected in the "Add.
Page 139 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Add. Line AUTO - OOS Use this parameter to define the second reading to be displayed in...
Page 140 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Add. Line AUTO - OOS Note! Multiplex - The input is not active unless one of the following was selected in the 100%-Value "Add.
Page 141 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Add. Line AUTO - OOS Note! Multiplex - Selection is not active unless one of the following was selected in the Display Mode "Add.
Page 142 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) A = Main line, B = Additional ENDRESS+HAUSER line, C = Information line Info Line -...
Page 143 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Info Line - AUTO - OOS Note! 100%-Value The input is not active unless one of the following was selected in the "Info Line - Assign"...
Page 144 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Info Line - AUTO - OOS Note! Display Mode Selection is not active unless one of the following was selected in the "Info Line - Assign"...
Page 145 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Info Line AUTO - OOS Use this parameter to define the second reading to be displayed in...
Page 146 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Info Line AUTO - OOS Note! Multiplex - The input is not active unless one of the following was selected in the 100%-Value "Info Line - Multiplex Assign"...
Page 147 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_DISP” (E+H parameters) / base index 1500 Parameter Write access Description with operating mode (MODE_BLK) Info Line AUTO - OOS Note! Multiplex - Selection is not active unless one of the following was selected in the Display Mode "Info Line - Multiplex Assign"...
Page 148: E+H Parameters: Transducer Block "Transducer_Tot" (Totalizer)
(More detailed information on write protection is provided in the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en, Section 5.4). • You can disable programming again by entering any number (other than the access code) in this parameter.
Page 149 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_TOT” (E+H parameters) / base index 1550 Parameter Write access Description with operating mode (MODE_BLK) Totalizer 1 - AUTO - OOS Use this parameter to view the total for the totalizer's measured System Value variable aggregated since measuring commenced.
Page 150 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_TOT” (E+H parameters) / base index 1550 Parameter Write access Description with operating mode (MODE_BLK) Totalizer 1 - AUTO - OOS For assigning a measured variable to the totalizer.
Page 151 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_TOT” (E+H parameters) / base index 1550 Parameter Write access Description with operating mode (MODE_BLK) Totalizer 2 - AUTO - OOS Use this parameter to view the total for the totalizer's measured System Value variable aggregated since measuring commenced.
Page 152 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_TOT” (E+H parameters) / base index 1550 Parameter Write access Description with operating mode (MODE_BLK) Totalizer 2 - AUTO - OOS For assigning a measured variable to the totalizer.
Page 153 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_TOT” (E+H parameters) / base index 1550 Parameter Write access Description with operating mode (MODE_BLK) Totalizer 3 - AUTO - OOS Use this parameter to view the total for the totalizer's measured System Value variable aggregated since measuring commenced.
Page 154 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_TOT” (E+H parameters) / base index 1550 Parameter Write access Description with operating mode (MODE_BLK) Totalizer 3 - AUTO - OOS For assigning a measured variable to the totalizer.
Page 155 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_TOT” (E+H parameters) / base index 1550 Parameter Write access Description with operating mode (MODE_BLK) Totalizer AUTO - OOS Resets totalizers 1–3 (“Totalizer x - System Value” parameter) to Handling - zero simultaneously.
Page 156: E+H Parameters: Transducer Block "Transducer_Diag" (Diagnosis)
(More detailed information on write protection is provided in the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en, Section 5.4). • You can disable programming again by entering any number (other than the access code) in this parameter.
Page 157 PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) “TRANSDUCER_DIAG” (E+H parameters) / base index 1600 Parameter Write access Description with operating mode (MODE_BLK) System - AUTO - OOS Use this parameter to define a time span for which the criteria for...
Page 158 3 Transducer Blocks (transmission blocks) PROline Prosonic Flow 93 FOUNDATION Fieldbus “TRANSDUCER_DIAG” (E+H parameters) / base index 1600 Parameter Write access Description with operating mode (MODE_BLK) System - AUTO - OOS Use this parameter to rectify errors in the EEPROM. The EEPROM Trouble- is divided into a number of blocks.
Page 159: E+H Parameters: Transducer Block "Transducer_Serv" (Service)
PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks) 3.14 E+H parameters Transducer Block “TRANSDUCER_SERV” (service) The Transducer Block “TRANSDUCER_ SERV” (base index 1650, service) contains all the parameters required for servicing. As these parameters affect the accuracy and functionality of the device, changes may only be made by E+H service technicians.
Page 160: Analog Input Function Block
4 Analog Input function block PROline Prosonic Flow 93 FOUNDATION Fieldbus Analog Input function block In the Analog Input function block (AI function block), the process variables from the Transducer Blocks “TRANSDUCER_CH1” (flow channel 1, base index 1200), “TRANSDUCER_ CH2” (flow channel 2, base index 1300) and “TRANSDUCER_ TOT”...
Page 161 The simulation mode is enabled by means of jumpers on the I/O board, (see Operating Instructions for PROline Prosonic Flow 93 FF, BA078D/06/en, Section 5.4). The L_TYPE parameter is used to select the linearisation type of the input or simulation value, (see Page 174): •...
Page 162: Selecting The Operating Mode
4 Analog Input function block PROline Prosonic Flow 93 FOUNDATION Fieldbus The MODE_BLK parameter group, (see Page 177), is used to select the operating mode of the Analog Input function block. If the MAN (manual) operating mode is selected then the output value OUT, (see Page 177), can be specified directly.
Page 163: Linearisation Types
PROline Prosonic Flow 93 FOUNDATION Fieldbus 4 Analog Input function block Linearisation types In the Analog Input function block, the input value from the Transducer Block can be linearised via the L_TYPE parameter, (see Page 174). The following types of linearisation are available: •...
Page 164: Status Of The Output Value Out
Transducer Block TRANSDUCER_DIAG (diagnosis, base index 1600) via the “Diagnosis - Actual System Condition” parameter. A list of all the error messages (including troubleshooting measures) is provided in the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en. Simulation of input/output...
Page 165: Diagnosis
PROline Prosonic Flow 93 FOUNDATION Fieldbus 4 Analog Input function block Diagnosis Block errors and diagnosis information are displayed in the Analog Input function block via the BLOCK_ERR parameter, (see Page 170). A description of the block errors supported is provided on Page 170.
Page 166 4 Analog Input function block PROline Prosonic Flow 93 FOUNDATION Fieldbus 4.10 Limit values The limit values are based on the output value OUT. If the output value OUT exceeds or undershoots the defined limit values, an alarm is sent to the fieldbus host system via the limit value process alarms.
Page 167 PROline Prosonic Flow 93 FOUNDATION Fieldbus 4 Analog Input function block 4.12 Parameters of the Analog Input function block The following table shows all the parameters available for the Analog Input function block. Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 168 4 Analog Input function block PROline Prosonic Flow 93 FOUNDATION Fieldbus Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 169 PROline Prosonic Flow 93 FOUNDATION Fieldbus 4 Analog Input function block Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 170 “Diagnosis - Actual System Condition” parameter in the Transducer Block “TRANSDUCER_DIAG” (diagnosis, base index 1600). More information on eliminating errors can be found in the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus,BA078D/06/en. Note! The “INPUT FAILURE” block error is relayed to downstream function blocks or higher-level process control systems by means of the status “BAD”...
Page 171 CHANNEL parameter. Releases or restricts the access authorisation of a fieldbus host GRANT_ AUTO - MAN - DENY system to the field device. Note! This parameter is not evaluated by PROline Prosonic Flow 93 FOUNDATION Fieldbus. Endress+Hauser...
Page 172 4 Analog Input function block PROline Prosonic Flow 93 FOUNDATION Fieldbus Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 173 PROline Prosonic Flow 93 FOUNDATION Fieldbus 4 Analog Input function block Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 174 4 Analog Input function block PROline Prosonic Flow 93 FOUNDATION Fieldbus Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 175 PROline Prosonic Flow 93 FOUNDATION Fieldbus 4 Analog Input function block Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 176 4 Analog Input function block PROline Prosonic Flow 93 FOUNDATION Fieldbus Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 177 PROline Prosonic Flow 93 FOUNDATION Fieldbus 4 Analog Input function block Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 178 4 Analog Input function block PROline Prosonic Flow 93 FOUNDATION Fieldbus Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 179 • The BLOCK_ERR parameter of the Analog Input function block indicates whether simulation is active, (see Page 170). • The simulation mode is enabled by means of jumpers on the I/O board, (see Operating Instructions for PROline Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en). ST_REV read only Displays the revision status of the static data.
Page 180 4 Analog Input function block PROline Prosonic Flow 93 FOUNDATION Fieldbus Analog Input function block / Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630...
Page 181 PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Discrete Output function block Discrete Output function block The Discrete Output (DO) function block processes the discrete setpoint value received from an upstream function block or higher-level process control system, with which various instrument functions (e.g. zero point adjustment or totalizer reset) can be initiated in the downstream Transducer Blocks.
Page 182 5 Discrete Output function block PROline Prosonic Flow 93 FOUNDATION Fieldbus Signal processing in the RCAS (remote cascade operation) operating mode is largely identical to the CAS operating mode. However, in this operating mode, control of the SP_D parameter does not take place via an upstream function block but rather via a fieldbus host system.
Page 183 PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Discrete Output function block Input allocation of the CAS_IN_D, RCAS_IN_D, OUT_D, SP_D parameters Status changes Action → Discrete state 0 Discrete state 1 Reserved → Discrete state 0 Discrete state 2 Positive zero return channel 1 “ON”...
Page 184 5 Discrete Output function block PROline Prosonic Flow 93 FOUNDATION Fieldbus Parameters of the Discrete Output function block Discrete Output function block / base index 780 Parameter Write access Description with operating mode (MODE_BLK) ALERT_KEY AUTO - MAN - Entry of the identification number of the plant unit.
Page 185 In the AUTO operating mode, the value of the SP_D parameter is used as a setpoint value. CHANNEL Note! With PROline Prosonic Flow 93 FOUNDATION Fieldbus, this parameter is fixed at 16. Assignment of the logical hardware channels of the Transducer Blocks “TRANSDUCER_CH1” (flow channel 1, base index 1200), “TRANSDUCER_CH 2”...
Page 186 GRANT_ AUTO - MAN - Releases or restricts the access authorisation of a fieldbus host DENY OOS - CAS - system to the field device. RCAS Note! This parameter is not evaluated by PROline Prosonic Flow 93 FOUNDATION Fieldbus. Endress+Hauser...
Page 187 PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Discrete Output function block Discrete Output function block / base index 780 Parameter Write access Description with operating mode (MODE_BLK) IO_OPTS Activates the options for processing the input and output values of the function block (I/O options).
Page 188 OOS - CAS - to a description of the possible states of the PV_D parameter. RCAS Note! This parameter is not evaluated by PROline Prosonic Flow 93 FOUNDATION Fieldbus. RCAS_IN_D AUTO - MAN - In this parameter, the discrete setpoint value (value and status)
Page 189 PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Discrete Output function block Discrete Output function block / base index 780 Parameter Write access Description with operating mode (MODE_BLK) SIMULATE_D AUTO - MAN - Simulation of the value and status of the process variable PV_D.
Page 190 In this parameter, the fieldbus host system can store a reference OOS - CAS - to a description of the possible states of the PV_D parameter. RCAS Note! This parameter is not evaluated by PROline Prosonic Flow 93 FOUNDATION Fieldbus. Endress+Hauser...
Page 191 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) PID function block (PID controller) A PID function block contains the input channel processing, the proportional integral- differential control (PID) and the analog output channel processing. The configuration of the PID function block depends on the automation task.
Page 192 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block equation The PID function block (PID controller) can be used for various automation strategies. The function block has a flexible control algorithm that can be configured differently depending on the application.
Page 193 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) Selecting the operating mode The operating mode is set by means of the MODE_BLK parameter group, (see Page 210). The PID function block supports the following operating modes: •...
Page 194 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus Limit values The limit values are based on the value of the process variable PV, (see Page 212). If the process variable PV exceeds or undershoots the defined limit values, an alarm is sent to the fieldbus host system via the limit value process alarms.
Page 195 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) Example: Basic PID control The continual flow into a container is to be controlled. The volume flow of the fluid is captured via a flow transmitter (FT) and made available to the PID function block via an Analog Input function block.
Page 196 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus Example of configuration The measuring range of the flowmeter (controlled variable) is 0...30 m The desired flow value (setpoint value) is specified manually by means of the SP parameter and should be 15 m /h.
Page 197 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) 6.10 Parameters of the PID function block The following table shows all the parameters available for the PID function block: PID function block (PID controller) / base index 810...
Page 198 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) ALARM_HYS ROUT - RCAS - Entry of the hysteresis value for the upper and lower warning or CAS - AUTO - alarm limit values.
Page 199 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) ALARM_SUM ROUT - RCAS - Displays the current status of the process alarms.
Page 200 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) BKCAL_HYS ROUT - RCAS - Entry of the hysteresis value for the upper and lower manipulated CAS - AUTO - variable range limit value OUT_HI_LIM and OUT_LO_LIM.
Page 201 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) BKCAL_IN ROUT - RCAS - Displays the analog input value and status copied in the case of...
Page 202 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) CAS_IN ROUT - RCAS - Displays the analog setpoint value and status copied from an CAS - AUTO - external function block in the CAS operating mode.
Page 203 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) DV_HI_LIM ROUT - RCAS - Entry of the limit value for the upper control deviation. If the...
Page 204 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) DV_LO_LIM ROUT - RCAS - Entry of the limit value for the lower control deviation. If the...
Page 205 DENY CAS - AUTO - MAN - OOS Note! This parameter is not evaluated by PROline Prosonic Flow 93 FF. HI_ALM ROUT - RCAS - Alarm status display for the upper warning limit value, (HI_LIM), CAS - AUTO -...
Page 206 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) HI_HI_PRI ROUT - RCAS - Specifies the action taken when the upper alarm limit value CAS - AUTO - (HI_HI_LIM) is exceeded.
Page 207 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) HI_PRI ROUT - RCAS - Specifies the action taken when the upper warning limit value CAS - AUTO - (HI_LIM) is exceeded.
Page 208 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) LO_LO_ALM ROUT - RCAS - Alarm status display for the lower alarm limit value, (LO_LO_LIM),...
Page 209 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) LO_PRI ROUT - RCAS - Specifies the action taken when the lower warning limit value CAS - AUTO - (LO_LIM) is undershot.
Page 210 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) MODE_BLK ROUT - RCAS - Displays the current (Actual) and desired (Target) operating...
Page 211 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) MAN - OOS Displays the output value (manipulated variable) of the PID function block.
Page 212 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) OUT_SCALE Definition of the measuring range (lower and upper limit), the physical unit and the number of decimal places for the manipulated variable (OUT).
Page 213 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) PV_SCALE Definition of the measuring range (lower and upper limit), the physical unit and the number of decimal places for the process variable (PV).
Page 214 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) ROUT_IN ROUT - RCAS - In this parameter, the manipulated variable (value and status) CAS - AUTO - provided by the fieldbus host system is read in and displayed.
Page 215 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) SP_HI_LIM ROUT - RCAS - Entry of the upper limit of the setpoint value (reference value).
Page 216 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) STATUS_ Selects the available status options for specifying the status OPTS processing and processing of the output value OUT.
Page 217 PROline Prosonic Flow 93 FOUNDATION Fieldbus 6 PID function block (PID controller) PID function block (PID controller) / base index 810 Parameter Write access Description with operating mode (MODE_BLK) TRK_VAL ROUT - RCAS - Displays the analog input value and input status read in from...
Page 218 6 PID function block (PID controller) PROline Prosonic Flow 93 FOUNDATION Fieldbus Endress+Hauser...
Page 219 PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Index Index (FOUNDATION Fieldbus) ACK_OPTION SW-Revision No....... 99 AI function block .
Page 220 7 Index PROline Prosonic Flow 93 FOUNDATION Fieldbus (continued) BLOCK_ALM Deviation AI function block......169 Arc length .
Page 221 PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Index SW-Revision number......99 Type ........99 HARD_TYPES .
Page 222 7 Index PROline Prosonic Flow 93 FOUNDATION Fieldbus Main line E+H parameters, Assign........132 Transducer Block diagnosis "TRANSDUCER_DIAG"...
Page 223 PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Index Pressure Shock Suppression ..... . 115 Wire Length ....... . . 125 Sensor serial number .
Page 224 7 Index PROline Prosonic Flow 93 FOUNDATION Fieldbus (continued) Transducer System Param. Blocks ........100 Adjust zero point.
Page 225 PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Index Un-/locking - access code TRANSDUCER_DISP ......129 Un-/Locking - Access Status TRANSDUCER_CH1/_CH2 .
Page 226 ❑ Belorgsintez Canada Philippines Poland Minsk ❑ Endress+Hauser Ltd. ❑ Endress+Hauser Philippines Inc. ❑ Endress+Hauser Polska Sp. z o.o. Tel. (0172) 508473, Fax (0172) 508583 Burlington, Ontario Metro Manila Warszawy Belgium / Luxembourg Tel. (905) 6819292, Fax (905) 6819444 Tel. (2) 3723601-05, Fax (2) 4121944 Tel.

Endress+Hauser PROline Prosonic Flow 93 Function Manual

Contents (Local Operation)

1 Notes on Using this Manual

2 Function Matrix

3 Block MEASURED VARIABLES

4 Block QUICK SETUP

5 Block USER INTERFACE

6 Block TOTALIZERS

7 Block BASIC FUNCTION

8 Block SUPERVISION

9 Factory Settings

10 Index (Function Matrix)

11 Index (Local Operation)

Contents (Foundation Fieldbus)

1 Operation Via FOUNDATION Fieldbus

2 Resource Block

3 Transducer Blocks (Transmission Blocks)

4 Analog Input Function Block

Quick Links

Chapters

Related Manuals for Endress+Hauser PROline Prosonic Flow 93

Summary of Contents for Endress+Hauser PROline Prosonic Flow 93

Table of Contents
