Controls

1
Platform Control Panel
1 Horn button
2 Platform level switch
3 Platform rotate switch
4 Jib boom up/down switch
5 Auxiliary power switch
6 Drive speed select switch
7 Glow plug switch (option)
8 Engine start switch
8
2 3
19
9 Engine idle (rpm) control switch
- Rabbit and foot switch symbol:
- Turtle symbol: low idle
- Rabbit symbol: high idle
10 Gasoline/LPG models: Gasoline/LPG
select switch
Deutz Diesel models: Glow plug switch (option)
11 Red Emergency Stop button
Genie Z-60/34
Fourth Edition · First Printing
4
17
18
foot switch activated high idle
5
6
16
Part No. 82315
